Avante ERGOADJUST DELUX User manual

ERGOADJUST DELUX
ADJUSTABLE BED MANUAL

TABLE OF CONTENTS
Safety ………...……………………………….….….… 1
Introduction ………………...………………..………. 3
Care ……………………………………………...... 4
Features ...…………..………………..………..…….....5
Unpacking Your Base ………………….…..…........... 6
Attaching Castors ...……………………...……...…… 7
Attaching Mattress Bars ……………………………… 8
Hand Control Overview…………………..….…........ 9
Troubleshooting ..………………………..…………..12
Product Guarantee ………..………………….....……14
Notes …………………………………………………..16

SAFETY
ATTENTION: Important Safety Disclaimers
Read all instructions before using
your adjustable base. Save these instructions.
WARNING
Always unplug the base from electrical outlet before servicing any part of
the base. Unplug the base before cleaning. To safely disconnect, ensure
base is in a flat position with all motors off.
TO REDUCE THE RISK OF SHOCK, FIRE OR INJURY: For optimal safety and
operation, plug the bed base into a surge protector (not included). Ensure to always
unplug the base from the electrical outlet before servicing or cleaning any part of the
base. Keep the power cord away from heated surfaces. Discontinue use of the bed base
and contact a qualified service centre if it has a damaged cord or plug, if it is not
working properly, or it has been dropped into water. Only use this bed base for its
intended use as described in this manual. Do not use accessories/attachments that are
not recommended by the manufacturer. Improper connection of the equipment can
result in the risk of electrical shock, electrical fire or fault if the plug does not fit your
outlet. Contact a qualified electrician to install a suitable outlet.
PETS AND CHILDREN: Dispose of all packing materials immediately after opening
as it may pose a risk to small children and pets. To avoid injury, it is not advised to
allow children and small pets to play under the bed. Children should not operate the bed
base without adult supervision.
Page 1

SAFETY
• To reduce the risk of falls on height adjustable bases, the base should
always be in its lowest position for sleeping and resting. The highest
position should only be used for carer’s access to the user, ease of
entry and exit of bed for the user and ease of making the bed.
• A minimum of 2 able and fit adults should be present when lifting or
moving the bed. It is recommended to use trolleys or other lifting/
moving devices where possible.
• Careless use of naked flames, cigarettes or other heat sources could set
fire to this product.
• Do not operate whilst any person is under the base whilst raising/
lowering or adjusting the bed.
• Care should be taken that no body parts are in or near the adjustable
frame while operating.
• Ensure the cabling of the bed is free from the mechanism.
• Don’t run over electrical cables when moving the bed.
• Do not manipulate or conduct electrical maintenance on the motors or
any of the beds electrical components or cables. Any electrical work
must be facilitated by a qualified tradesperson.
WARNING
• Stay clear of moving parts while in motion.
• Before adjusting, make sure children and pets are clear of moving
parts and are not under bed base.
• Do not allow children to operate bed base without adult supervision.
Page 2

INTRODUCTION
Congratulations on the purchase of your new
AVANTE ERGOADJUST DELUX BED
Key Features:
• Hi-Lo Lift Function
• Vibration Massage
• Head Tilt Function
• Under-Bed Lighting
• USB Charging Ports
• Wireless Hand Control
• Customisable Pre-set Positions
• 200kg weight rated
Page 3
The ErgoAdjust Delux is Avante’s new advanced adjustable bed
that embodies function and comfort. The bed is equipped with a
full package of functionalities for mobility including Hi-Lo lift
and pre-set customised positions. The ErgoAdjust Delux is also
designed to maximise user experience, featuring vibration
massage, head tilt, USB charging ports, under-bed lighting all
controlled effortlessly with a wireless handset. The ErgoAdjust
Delux is the optimal choice for anyone seeking independent
mobility and a better sleeping experience.

CARE
GENERAL CARE INSTRUCTIONS
• Legs and castors should be checked for tightness regularly.
• When transporting - do not over tighten when restraining.
• Do not exceed the maximum weight limit for this bed
(200kg total).
• Always lock castors other than when moving or relocating
the bed.
• Do not jump on or abuse the bed.
• Do not constantly push the buttons on the controller when
not for intended use.
• Use the controller only for adjusting the bed frame for
intended use - not for entertainment.
• Lubricate moving parts using a non-corrosive lubricant every
6 months or as required. Avante recommends the use of
INOX.
• Beds should be positioned with clearance from walls and
other objects so as not to cause damage.
• Do not rock or tilt the frame.
Page 4

FEATURES
PRODUCT FEATURES
• Stylish modern living design
• Adjustable head and foot parts
• Head tilt function supporting
neck muscles
• Massage function
• Wireless multifunction remote
control
• USB charging ports
• Under-bed lighting
FRAME DESIGN FEATURES
• Whisper quiet, low voltage, DC
lift system provides smooth and
efficient operation.
• Long lasting steel support.
• Superior steel foundation.
• Powder coated steel.
• Designed to lift up to 200kg total
weight
• Gravity fall motors.
• Can suit any adjustable bed
mattress.
• Wall aligned technology.
Raised Position with
Head and Foot Up
Head Tilt Function
Page 5

UNPACKING YOUR BASE
Page 6
1. Open the carton box & remove the protective plastic.
2. Locate box of parts, remove
zip ties.
3. Locate hand controller,
remove zip tie and protective
plastic.

ASSEMBLING
(CASTORS)
Page 7
1. Turn your ErgoAdjust Delux base on its side.
2. Locate the four castors from the box of parts; before screwing in,
ensure all castors are in a locked position.
3. Screw in the castors into each hole at the corners of the bed as
shown below.

ASSEMBLING
(MATTRESS BARS)
Page 8
1. Turn the base back to a flat position, with castors now attached.
2. Locate the mattress bars; attach each mattress bar as shown below.

HAND CONTROL OVERVIEW
The remote should look like the one to the right. The remote keys have
backlight for assisting operation at night.
Please note—to transfer between saved positions, return the bed to
FLAT position FIRST, before selecting next position.
Pairing Button
Zero Gravity
Position
Anti-Snore
Position
Memory Position
Underbed Light
Head Up Head Down
Foot Up Foot Down
Flat Position
Raise Bed Height
Lower Bed Height
Massage Time
Switch
Head Massage
Foot Massage
Head Tilt Up Head Tilt Down
Turn Massage
On and Off
Page 9
Massage Type
Switch ERGOADJUST DELUX
HAND CONTROLLER

STEPS OF RE-PROGRAMMING
PRESET POSITION
1. Adjust the bed into desired
position.
2. Choose the pre-set position that
you would like to change ( Zero
Gravity or Anti Snore).
3. Press and hold the chosen pre-set
button and the flat position button
simultaneously for 5 seconds, until
the backlight begins to flash. The
current position of the bed is now
saved as a custom position under
the pre-set button.
SET UP MEMORY POSITION
1. Adjust the bed into desired position.
2. Press and hold the “Memory” button and the flat position button
simultaneously for 5 seconds, until the backlight begins to flash. The
current position of the bed is now saved as a memory position
PRESS AND HOLD
TO CHANGE PRE-SET POSITIONS
PRESS AND
HOLD
TO SET UP
MEMORY
POSITION
ERGOADJUST DELUX
HAND CONTROLLER
RE-PROGRAMMING HAND
CONTROL POSITIONS
Page 10

SYNCING
BASES
To Sync TWO bases to ONE remote
Requires Link Cable
1. Insert link cable end into each control box on the separate bases you wish to sync.
2. Once completed, either remote will then operate both bases.
To Sync ONE base ONLY
1. Insert 2 AAA Batteries into the hand
controller.
2. Connect power to the transformer.
3. Press the pair button on the control box
twice quickly (the blue pairing light will
turn on).
4. Press and hold the pair button on
remote control for 3 seconds. The back-
light will start flashing. The blue pairing
LED light on the control box will turn
green to indicate that pairing is
complete. If not successful, repeat the
above steps.
PRESS AND HOLD
ERGOADJUST DELUX
HAND CONTROLLER
Page 11

TROUBLESHOOTING
Below is a list of possible problems & their solutions should the
adjustable base fail to operate properly
PROBLEM SOLUTION
The base does not respond when
the remote is used.
Remote LED illuminates and
appears to be normal.
Perform any or all of the following:
• Check that the power cord is plugged
into a working & grounded electrical
outlet.
• Check that the light on the transformer
is on.
• Check the home’s circuit breaker &
fuses.
• Unplug the power cord from the outlet.
After one minute, plug it back in. Press
any button on the remote.
The remote does not work
or does not light up.
• Check the remote LED light is lighting
up when pressed. If not, please replace
2 x 1.5V AAA batteries.
Base stutters while in motion. • Clear any clutter or obstructions under
& around the adjustable base. Radio
frequency interference from other remotes
or electronic devises may affect normal
operation.
• Ensure the buttons on the remote are
being pressed firmly down when
operating the Head & Foot functions.
Page 12

TROUBLESHOOTING
PROBLEM SOLUTION
Massage motor/s seem
excessively loud during
operation.
• Hard surface flooring may cause added
vibration. Place carpet pieces or rubber
furniture cups under each leg or caster of
the bed.
• Check that the bed is not in direct contact
with a wall, or other object that may cause
vibration or noise.
• If adjustable base is installed on top of a
bed frame, check that the massage motors
are not causing the bed frame (or
components) to vibrate or rattle.
• If a headboard is utilised, please check that
the attachment hardware is tightened firmly.
USB and/or under-bed
lighting.
• Check to see if the cable has been pulled
out from control box. If so, plug back in.
• For USB, try using alternative devices and/
or cables. Please note: Generic cables may
not work and you may be required to utilise
genuine cables manufactured by your
devices company. The USB port is a SLOW
charging port and will not support Fast
Charge.
If you have followed the instructions outlined in this manual, and your problem
is persisting, please contact the retailer you originally purchased your bed from
or Avante Australia for further assistance.
Page 13

PRODUCT GUARANTEE
Congratulations on your purchase. Avante Australia is an
International Brand that uses technology, production facilities and
teams with over 20 years’ experience.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount
to a major failure.
Avante Australia proudly provides a full guarantee (10 years—applies to
frame, structure & electric motors only. All other electronic components &
upholstery are covered for 2 years). Please refer to www.avante.com.au for
details against faulty workmanship and/or faulty materials. During the
guarantee period, if we are satisfied there is a genuine fault, we will repair
or replace the product if its an option.
THE GUARANTEE DOES NOT EXTEND TO THE FOLLOWING:
• Fabric (including stains, soiling, burns and normal wear).
• Items upon inspection that are deemed unsanitary.
• Normal wear and tear, or damage caused by abuse.
• Clearance bedding sold in ‘as is’ condition.
• Failure to comply with manufacturer care and maintenance
instructions.
IN ORDER FOR THIS GUARANTEE TO BE VALID YOU MUST:
• Be the original purchaser.
• Provide a copy of the original store receipt.
• Not misuse the product (refer to care and maintenance and safety
sections).
Page 14

PRODUCT GUARANTEE
PLEASE TAKE CARE OF YOUR ERGOADJUST DELUX BED BY
TAKING THE FOLLOWING PRECAUTIONS:
• Legs and castors should be checked for tightness regularly.
• When transporting - do not over tighten when restraining.
• Maximum recommended weight limits; on a High Low Lift bed
200kg.
• Always lock castors other than when moving or relocating the bed.
• Do not jump on or abuse the bed.
• Do not constantly push the buttons on the controller when not for
intended use.
• Use the controller only for adjusting the bed frame for intended
use - not for entertainment.
• Lubricate moving parts using a non-corrosive lubricant every 6
months or as required. Avante recommends the use of INOX.
• Beds should be positioned with clearance from walls and other objects
so as not to cause damage.
We will not cover damage caused by neglect, mistreatment or general wear and
tear of the bed. Regular maintenance is required.
MAKING A CLAIM
To make a claim under this Guarantee please contact your bedding retailer
who will initiate the claim process with us. If this cannot be done, please
contact Avante Australia Pty Ltd directly via the details on the back of this
manual.
Avante Australia will require photos of the Mattress and Base support
system to be sent at the time of a claim being made. For details of how to
take acceptable photos please contact Avante Australia (contact details on
back page).
Page 15

NOTES
Page 16

NOTES
Page 17

Avante Australia Pty Ltd
Unit 2, 29-71 Saltwater Circuit
Narangba, QLD 4504
Phone: [phone]
Fax: [phone]
www.avante.com.au
