Avante LO-LO User manual

LO-LO ADJUSTABLE BED MANUAL

TABLE OF CONTENTS
Safety ………...……………………………….….….… 1
Introduction ………………...………………..………. 3
Care ……………………………………………...... 4
Features ...…………..………………..………..…….....5
Unpacking Your Base ………………….…..…........... 6
Attaching Castors and Retainer Bars ...………...…… 7
Hand Control Overview…………………..….…........ 8
Troubleshooting ..……………………………..…….. 9
Product Guarantee ………..………………….....……10
Notes …………………………………………………..12

SAFETY
ATTENTION: Important Safety Disclaimers
Read all instructions before using
your adjustable base. Save these instructions.
WARNING
Always unplug the base from electrical outlet before servicing any part of
the base. Unplug the base before cleaning. To safely disconnect, ensure
base is in a flat position with all motors off.
TRENDELENBURG FUNCTIONALITY: This adjustable bed is equipped with the
unique Trendelenburg and reverse Trendelenburg position. The Trendelenburg position
is when a person is placed on an incline where the head is in a lower position than the
feet. A reversed Trendelenburg position is when a person is placed on an incline where
the feet are in a lower position than the head. Be aware that Trendelenburg positions
can have an effect on people’s organs, blood circulation and airflow ( among other
things) and should only be used under direct instruction & consultation with medical
professional. Avante Australia Pty Ltd takes no responsibility for misuses of these posi-
tions.
TO REDUCE THE RISK OF SHOCK, FIRE OR INJURY: For optimal safety and
operation, plug the bed base into a surge protector (not included). Ensure to always un-
plug the base from the electrical outlet before servicing or cleaning any part of the base.
Keep the power cord away from heated surfaces. Discontinue use of the bed base and
contact a qualified service centre if it has a damaged cord or plug, if it is not working
properly, or it has been dropped into water. Only use this bed base for its intended use
as described in this manual. Do not use accessories/ attachments that are not recom-
mended by the manufacturer. Improper connection of the equipment can result in the
risk of electrical shock, electrical fire or fault if the plug does not fit your outlet. Contact
a qualified electrician to install a suitable outlet.
PETS AND CHILDREN: Dispose of all packing materials immediately after opening
as it may pose a risk to small children and pets. To avoid injury, it is not advised to al-
low children and small pets to play under the bed. Children should not operate the bed
base without adult supervision.
Page 1

SAFETY
• To reduce the risk of falls on height adjustable bases, the base should
always be in its lowest position for sleeping and resting. The high posi-
tion should only be used for carer’s access to the user, ease of entry
and exit of bed for the user and ease of making the bed.
• A minimum of 2 able and fit adults should be used when lifting or
moving the beds. It is recommended to use trolleys or other lifting/
moving devices where possible.
• Careless use of naked flames, cigarettes or other heat sources could set
fire to this product.
• Do not operate whilst any person is under the base whilst raising/
lowering or adjusting the bed.
• Care should be taken that no body parts are in or near the adjustable
frame while operating.
• Ensure the cabling of the bed is free from the mechanism.
• Don’t run over electrical cables when moving the bed.
• Do not manipulate or conduct electrical maintenance on the motors or
any of the beds electrical components or cables. Any electrical work
must be facilitated by a qualified tradesperson.
WARNING
• Stay clear of moving parts while in motion.
• Before adjusting, make sure children and pets are clear of moving
parts and are not under bed base.
• Do not allow children to operate bed base without adult supervision
Page 2

INTRODUCTION
Congratulations on the purchase of your new
LO-LO BED!
The Lo-Lo is a Mobility focused Adjustable bed that features Trendelen-
burg and reverse Trendelenburg positionings as well as sitting very low to
the ground in its lowest position. The Lo-Lo is ideal for those transition-
ing from/to a wheelchair.
Key Features:
• Hi-Lo Lift Function
• Low Point: 225mm (base only)
• High Point: 630mm (base only)
• Trendelenburg Positions
• Wired Hand Control with backlight
• 180kg weight rated
Page 3

CARE
GENERAL CARE INSTRUCTIONS
• Legs and castors should be checked for tightness regularly.
• When transporting - do not over tighten when restraining.
• Do not exceed the maximum weight limit for this bed (180kg
total).
• Always lock castors other than when moving or relocating
the bed.
• Do not jump on or abuse the bed.
• Do not constantly push the buttons on the controller when
not for intended use.
• Use the controller only for adjusting the bed frame for in-
tended use - not for entertainment.
• Lubricate moving parts using a non-corrosive lubricant every
6 months or as required. We recommend the use of INOX.
• Beds should be positioned with clearance from walls and ob-
jects so as not to cause damage.
• Do not rock or tilt the frame.
Page 4

FEATURES
PRODUCT FEATURES
• Stylish Modern Living Design
• Adjustable head and foot parts
• Close to ground at the lowest position
• Trendelenburg (and revers) positions
• Wired remote control with LED back
light.
• Self-Leveling castors
FRAME DESIGN FEATURES
• Whisper quiet, low voltage, DC lift
system provides smooth and efficient
operation.
• Long lasting steel support.
• Superior steel foundation.
• Powder coated steel.
• Designed to lift up to 180kg total
weigh
• Gravity fall motors.
• Can suit any adjustable bed mattress.
• Wall aligned technology.
Trendelenburg Position
Raised Position with
Head and Foot Up
Lower Position Close
to Ground
Page 5

UNPACKING YOUR BASE
1. Open the carton box & remove the protective plastic.
2. Cut the zip ties and located the mattress retainer bars and hand con-
troller
Step 1: Unpack the carton box
Step 2: Cut the zip ties Step 3: Locate the retainer bars and remote
Page 6

ATTACHING CASTORS AND RE-
TAINER BARS
1. Plug in Power and press the
button to extend out both front and back
legs;
2. Attach the leveling bar as shown on pho-
tos on left with provided bolt and bushes.
3. Insert the head & foot retainer bars locat-
ed at each ends of the bed and 4 side
bars located on left and right sides of the
bed.
Bolt and Bushes
Attach the level bar as shown
Insert the retainer bars
Page 7

HAND CONTROL OVERVIEW
To turn on hand control, firstly ensure the remote
is plugged into the control box underneath the
bed. The remote should look like the one to the
right. The remote keys have backlight for assisting
operation at night.
Please refer to the following diagram explaining
the functions.
Head Up Head Down
Foot Up Foot Down
Trendelenburg
Up
Trendelenburg
Down
Reversed
Trendelenburg
Up
Reversed
Trendelenburg
Down
Raise Bed
Height
Lower Bed
Height
Page 8

TROUBLESHOOTING
Below are a list of possible problems & their solutions should the ad-
justable base fail to operate properly
PROBLEMS SOLUTIONS
The base does not respond when the
remote is used.
Remote LED illuminates and appears
to be normal.
Perform any or all of the following:
• Check that the power cord is plugged into a
working & grounded electrical outlet.
• Check that the light on the transformer is on.
• Check the home’s circuit breaker & fuses.
• Unplug the power cord from the outlet. After
one minute, plug it back in . Press any button
on the remote.
The remote does not work
or does not light up.
• Check the remote LED light is lighting up
when pressed. If not, please check that the
power cord is plugged into a working &
grounded electrical outlet.
Base stutters while in motion. • Clear any clutter or obstructions under &
around the adjustable base. Radio frequency
interference from other remotes or electronic de-
vises may affect normal operation.
• Assure the keys on remote are being pressed
firmly down when operating the Head & Foot
buttons.
If you have followed the instructions outlined in this manual, and your problem
is persisting, please contact the retailer you originally purchased your bed from
or Avante Australia for further assistance.
Page 9

PRODUCT GUARANTEE
Congratulations on your purchase. Avante Australia is an Interna-
tional Brand that uses technology, production facilities and teams
with over 20 years’ experience.
Our goods come with guarantees that cannot be excluded under the Aus-
tralian Consumer Law. You are entitled to a replacement or refund for a
major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount
to a major failure.
Avante Australia proudly provides a full guarantee (10 years applies to
frame, structure & electric motors only. All other electronic components &
upholstery are covered for 2 years) please refer to our website for details
against faulty workmanship and/or faulty materials. During the guarantee
period, if the company is satisfied there is a genuine fault, it will repair or
replace the product at its option.
THE GUARANTEE DOES NOT EXTEND TO THE FOLLOWING:
• Fabric (including stains, soiling, burns and normal wear).
• Items upon inspection that are deemed unsanitary.
• Normal wear and tear, or damage caused by abuse.
• Clearance bedding sold in ‘as is’ condition.
• Failure to comply with manufacturer care and maintenance instruc-
tions.
IN ORDER FOR THIS GUARANTEE TO BE VALID YOU MUST:
• Be the original purchaser.
• Provide a copy of the original store receipt.
• Not misuse the product (refer to care and maintenance and safety sec-
tions).
Page 10

PRODUCT GUARANTEE
PLEASE TAKE CARE OF YOUR LO-LO BED BY TAKING THE
FOLLOWING PRECAUTIONS:
• Legs and castors should be checked for tightness regularly.
• When transporting - do not over tighten when restraining.
• Maximum recommended weight limits; on a High Low Lift bed
180kg.
• Always lock castors other than when moving or relocating the bed.
• Do not jump on or abuse the bed.
• Do not constantly push the buttons on the controller when not for in-
tended use.
• Use the controller only for adjusting the bed frame for intended use -
not for entertainment.
• Lubricate moving parts using a non-corrosive lubricant every 6
months or as required. We recommend the use of INOX.
• Beds should be positioned with clearance from walls and objects so as
not to cause damage.
We will not cover damage caused by neglect, mistreatment or general wear and
tear of the bed. Regular maintenance is required.
MAKING A CLAIM
To make a claim under this Guarantee please contact your bedding retailer
who will initiate the claim process with us. If this cannot be done, please
contact Avante Australia Pty Ltd directly via the details on the back of this
manual.
Avante Australia will require photos of Mattress and Base support system
to be sent at the time of a claim being made. For details of how to take ac-
ceptable photos please contact Avante Australia (contact details on back
page).
Page 11

NOTES
Page 12

NOTES
Page 13

Avante Australia Pty Ltd
Unit 2, 29-71 Saltwater Circuit
Narangba, QLD 4504
Phone: [phone]
Fax: [phone]
www.avanteaustralia.com.au
