Avanti SWP L02 CE-AECO User manual

AVANTI SERVICE LIFT
Installation manual
Model SWP L02 CE-AECO
Original instructions
Date of publication:
2nd Edition: June 2019
Revision 1: 17/06/2019
This manual covers products with Serial numbers from A2-L0001 AT00010650 SWP L02 CE-AECO Ed.02 R01 – Language: ENGLISH
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 1 6/20/2019 12:21:47 PM

CE certificate for SWP L02:
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 2 6/20/2019 12:21:47 PM

AECO certificate for SWP L02:
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 3 6/20/2019 12:21:48 PM

Date of publication:
2nd Edition: June 2019
Revision 1: 17/6/19
Manufacturer:
Avanti Wind Systems Technology, S.L.
Calle Ángeles (Los), Num. 88
Pol. Industrial Centrovía
50198 Muela (La) - (Zaragoza) - Spain
P: [phone]
F: [phone]
E: [e-mail]
I: www.avanti-online.com
Manufactured Under Process Patent NO.8,499,896.
® Registered in Europe
Sales & Service:
avanti-online.com/contact
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 4 6/20/2019 12:21:48 PM

5
Installation Manual
Page
1. Limited warranty .................................................... 7
2. Introduction ........................................................ 8
2.1 Observations ......................................................8
2.2 Symbols .........................................................8
2.3 Cautions .........................................................9
2.4 Terms and definitions .................................................9
2.5 WTG requirements.................................................. 10
2.5.1 Tower illumination .............................................. 10
3. Installation......................................................... 10
3.1 Cautions ....................................................... 10
3.2 Freight kit....................................................... 11
3.3 The wire ropes ................................................... 11
3.3.1 Tower top ................................................... 11
3.3.2 Guiding wire rope fixations ....................................... 13
3.3.3 Tower bottom ................................................ 14
3.3.4 Securing the guide wire rope - ground level ............................ 15
3.3.4.1 Guiding wire ropes in foundation floor........................... 15
3.3.4.2 Guiding wire ropes in beam ................................. 16
3.4 Electrical connections ............................................... 17
3.4.1 Power supply................................................. 17
3.4.2 Installation of main switch ........................................ 17
3.4.3 Supply cable ................................................. 17
3.4.4 Power connection ............................................. 17
3.5 Installation of traction and safety wire rope in lift.............................. 18
3.5.1 Traction wire rope installation ...................................... 18
3.5.2 Safety wire rope installation ....................................... 18
3.6 Securing the traction and safety wire rope .................................. 19
3.6.1 Traction wire rope counterweight ................................... 19
3.6.2 Safety wire rope push spring ...................................... 19
3.6.3 Traction and safety wire ropes grounding .............................. 19
3.7 Wire rope fix alignment............................................... 20
3.8 Installation of reflectors at platform levels . ................................. 21
3.9 Adjustment of top limit device .......................................... 21
3.10 Danger zone! sticker................................................ 21
3.11 Inspection before first use ............................................ 21
3.12 Disassembling.................................................... 22
Annex A: Installation Checklist ............................................. 23
Annex B: Torque values................................................... 27
Contents
Sales & Service:
avanti-online.com/contact
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 5 6/20/2019 12:21:48 PM

6
AVANTI Service Lift for Wind Turbines
Ed.Rev Notes
01.01 New document
02.01 Definitive (approved) edition. Option of 2 or 3 counterweights in the safety wire rope. Manufacturer updated.
Certificates updated.
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 6 6/20/2019 12:21:48 PM

7
Installation Manual
1) Avanti service lift (“Product”)
Avanti Wind Systems Technology, S.L. warrants
that commencing from the date of shipment to
the Customer and continuing for a period of the
longer of 365 days thereafter, or the period set
forth in the standard AVANTI warranty, the
Product1) described in this Manual will be free
from defects in material and workmanship
under normal use and service when installed
and operated in accordance with the provisions
of this Manual.
This warranty is made only to the original user
of the Product. The sole and exclusive remedy
and the entire liability of Avanti under this
limited warranty, shall be, at the option of
Avanti, a replacement of the Product (including
incidental and freight charges paid by the
Customer) with a similar new or reconditioned
Product of equivalent value, or a refund of the
purchase price if the Product is returned to
Avanti, freight and insurance prepaid. The
obligations of Avanti are expressly conditioned
upon return of the Product in strict accordance
with the return procedures of Avanti.
This warranty does not apply if the Product (i)
has been altered without the authorization of
Avanti or its authorized representative; (ii) has
not been installed, operated, repaired, or
maintained in accordance with this Manual or
other instructions from Avanti; (iii) has been
subjected to abuse, neglect, casualty, or
negligence; (iv) has been furnished by Avanti to
Customer without charge; or (v) has been sold
on an “AS-IS” basis.
Except as specifically set forth in this Limited
Warranty,
ALL EXPRESS OR IMPLIED CONDITIONS,
REPRESENTATIONS AND WARRANTIES,
INCLUDING, BUT NOT LIMITED TO, ANY
IMPLIED WARRANTY OR CONDITION OF
MERCHANTABILITY, FITNESS FOR A PAR-
TICULAR PURPOSE, NON-INFRINGEMENT,
SATISFACTORY QUALITY, COURSE OF DEAL-
ING, LAW, USAGE OR TRADE PRACTICE ARE
HEREBY EXCLUDED TO THE MAXIMUM
EXTENT PERMITTED BY APPLICABLE LAW
AND ARE EXPRESSLY DISCLAIMED BY
AVANTI. IF, PURSUANT TO ANY APPLICABLE
LAW, TO THE EXTENT AN IMPLIED WARRAN-
TY CANNOT BE EXCLUDED AS PROVIDED IN
THIS LIMITED WARRANTY, ANY IMPLIED
WARRANTY IS LIMITED IN TIME TO THE SAME
DURATION AS THE EXPRESS WARRANTY
PERIOD SET FORTH ABOVE. BECAUSE SOME
STATES DO NOT PERMIT LIMITATIONS ON
THE DURATION OF IMPLIED WARRANTIES,
THIS MAY NOT APPLY TO A GIVEN CUSTOM-
ER. THIS LIMITED WARRANTY GIVES CUS-
TOMER SPECIFIC LEGAL RIGHTS, AND
CUSTOMER MAY HAVE OTHER LEGAL
RIGHTS UNDER APPLICABLE LAWS.
This disclaimer shall apply even if the express
warranty fails of its essential purpose.
In any cases of dispute the English original shall
be taken as authoritative.
1. Limited Warranty
Ed.Rev Notes
01.01 New document
02.01 Definitive (approved) edition. Option of 2 or 3 counterweights in the safety wire rope. Manufacturer updated.
Certificates updated.
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 7 6/20/2019 12:21:48 PM

8
AVANTI Service Lift for Wind Turbines
2.2 Symbols
2.1 Observations
2. Introduction
Only trained people may use this lift.
This manual must be available to staff at all times during installation, maintenance and operation.
Additional copies are available from the manufacturer upon request.
All measurements are indicative only and subject to change without notice.
The pictures and sketches in this manual may not reflect the product aesthetics, colours,
arrangement precisely. This has no impact on the function or safety.
!
STOP
!

Symbol Signal word Meaning Possible injury if not observed
Safety instructions
DANGER!
IMMEDIATE or
possibly imminent
danger:
Death or severe injury!
DANGER!
IMMEDIATE or
possibly imminent
danger of hazardous
voltage:
Death or severe injury!
CAUTION! Potentially hazardous
situation:
Light injury or material damage.
Additional instructions
ATTENTION! Potentially dangerous
situation:
Damage to equipment or workplace
IMPORTANT! Useful tips for optimum
working procedure
None
VERSION!
Differentiation between CE
versions and AECO version.
Reference to written
specification/documentation
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 8 6/20/2019 12:21:49 PM

9
Installation Manual

2.3 Cautions
Use and daily inspection of the service lift shall only
be performed by person who has gone through the
relevant training associated with the Avanti service
lift use and daily inspection and is in possession of a
valid (non expired) certificate for the task.
Installation and maintenance of the service lift shall
only be performed by certified technicians.
Personnel must be at least 18 years of age. The staff
must be familiar with the relevant accident prevention
instructions and must have received proper
training in these.
Personnel are obliged to read and understand this
Installation Manual.
Personnel shall wear PFPE (safety helmet, full body
harness, shock absorber, lanyard and slider) at all
times, when using the lift.
A copy of the Installation Manual must be handed out
to the personnel involved and must always be avail-
able for reference.
If more than one person is entrusted with installation
tasks, the employer shall appoint a supervisor in
charge of the operation.
Self-locking nuts must be used at all times. The
screw must extend from the nut by at least half of the
thread diameter. The nut may not be used once it has
become possible to loosen by hand!
If any damage or faults are found during operation, or
if circumstances arise which may jeopardize safety:
immediately interrupt the work in progress and notify
the supervisor or employer!
All tests/repairs of electrical installations may only be
performed by AVANTI or certified technicians.
All repairs to the traction, braking and supporting
systems may only be performed by AVANTI or certi-
fied technicians.
If any supporting parts are repaired or replaced, the
operational safety of the system must be tested and
verified by AVANTI or certified technicians.
Only original fault-free parts may be used.
Use of non-original parts will render the manufac-
turer’s warranty void and any type approval
invalid. No modification, extension or reconstruction
of the service lift is allowed without AVANTI’s prior
written consent.
No warranty is provided against damage resulting
from reconstruction or modification of equipment
or use of non-original parts which are not
approved by AVANTI.
Service lift must be inspected by AVANTI or by
certified technician before first use.
Service lift must be inspected at least once a year
or after 60 hours of use (whichever occurs first) by
AVANTI or certified technicians.
Service lift is designed for a lifetime of 20 years
with an operating frequency of approximately 60
hours/year for the first year and the 10 hours/year
for the rest of the years (250 h in total).
Service lift may not be used by persons who are
under the influence of alcohol or drugs which may
jeopardize working safety.
The service lift shall not be used in case of fire in
the tower.
Service lift shall ONLY be used when the turbine is
not generating power.
All wind farm site specific rules must be followed.
Service lift shall not be used during inclement
weather, including wind speeds over 25 m/s (55.5
mph), electric storms, hurricanes, temperature out
of lift’s operating range (-25ºC to +60ºC), and any
other that jeopardize safe operation.
Personnel shall be equipped with a wired or wireless
two way communication device that shall be
connected to a location staffed by authorised
personnel. Personnel shall be equipped with portable
lights of minimum 200 lx 1) (i.e. headlamps).
Avoid injury – follow all instructions!
The tower owner must verify the need for
third party service lift inspections with the
local authority and comply with the
standards specified.
1) Optional for CE versions. Mandatory for
AECO version.
2.4 Terms and definitions
Terms Definitions
Certified technician Person who has received relevant training from Avanti or a qualified instructor associated
with the intended work and who holds valid certification (current) for the task in question.
User
Person who has received relevant training associated with using the Avanti service lift
and carrying out the corresponding daily inspections and who holds valid certification
(current) for the task in question.
Manual descent (also: descent
without electrical power)
Action performed to descend the cabin at a controlled speed without electrical power, by
releasing the traction system’s electromagnetic brake manually.
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 9 6/20/2019 12:21:49 PM

10
AVANTI Service Lift for Wind Turbines
2.5 WTG requirements
The gaps on the loading side of the service lift
shall conform to the applicable requirements of
5.11 of ASME A17.1-2013/CSA B44-131).
1) Optional for CE versions. Mandatory
for AECO version.
2.5.1 Tower illumination
The platform operating panels shall be properly
illuminated (e.g. an illumination of at least 50 lux
according to EN 50308).
The loading side of the platform holes shall be
properly illuminated.
The landing platform shall be properly illumi-
nated (e.g. an illumination of not less than 27 lx
at the standing surface according to A17.1,
5.11).
The tower shall provide emergency lighting in
case of power failure (e.g. an illumination of at
least 10 lux according to EN 50308).
3 Installation
3.1 Cautions
Please familiarise yourself with these
instructions and the User’s Manual before
installing the service lift. Ensure that all
specified parts are present before
commencing installation.
No warranty is provided against damage and injury
resulting from not following this “User’s, Maintenance
and Installation Manual” i.e. reconstruction or
modification of equipment or use of non-original parts
which are not approved by the manufacturer.
Prior to installation, ensure that:
• Building sections involved will be able to
withstand the service lift loads.
• All parts are available and fully functional.
• by checking references and by visual
inspection.
• Travel zone is protected by fences at each
platform.
• Walking way surfaces are dry and not slippery
The customer must define the maximum
allowable wind speed ensuring safe installation.
During installation tasks, personnel shall:
• Wear at least the following PFPE: fall arrest
equipment if falling height is higher than 2 m,
hand gloves, helmet, safety glasses, working
gear.
• Use a hand winch attachable to the ladder when
elevating heavy weights.
• Use a wire rope clamp or grip when lowering wire
ropes, in order to avoid the risk of personnel losing
the wire rope, and wire rope getting damaged or
person being hit. The clamp shall be secured to a
platform anchor point. The diameter of the clamps
or grips shall match the diameter of the wire ropes.
• Not work at different levels if tasks involve risk of
falling objects.
Electrical connection of the system
must be made in accordance with EN
60204-1 and EN 60204-32.
When plugging the service lift to the
power supply, ensure that supply
phases are correct!

Service lift
Less than or equal
to 65 mm (2.5 in.)
Between
90 mm (3.5 in.)
and 150 mm (6 in.)
Platform fence
Platform floor
Greater than or equal
to 25 mm (1 in.)
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 10 6/20/2019 12:21:49 PM

11
Installation Manual
3.2 Freight kit
The service lift shall be transported to destina-
tion inside a box.
1. Open the box.
2. Turn the service lift from horizontal to vertical
position by means of the freight kit.
3. By means of shackles and slings, attach the
lifting machinery (i.e. forklift, chain hoist, crane,
etc.) to the lifting eye.
4. Use the lifting machinery to lift the service lift
over the pallet level. One person is needed to
ensure the lifting process is being done properly.
5. In the picture below you can see the detail of
where the lift must lay during the lifting.
6. Place the lift inside the lift shielding at bottom
platform.
7. Remove the freigth kit.
3.3 The wire ropes
Carefully place the cabin in the tower. Do not
drag in order to avoid any damage on the
bottom of the cabin.
Wire rope lengths depend on the tower height
and should be specified when ordering. The
coils are marked with their length.
3.3.1 Tower top
The wire rope coils hang from the suspension
beam.
Attach the thimbled end of the wire ropes to the
beam by means of the 2T shackles . The nuts of
the shackles must be secured by means of
cotter pins.
1) Fit the top limit device on the traction wire
rope and to the guiding wire rope next to lift’s
door (Fig. 2 a, 2b and 2c). Do not tighten wire
locks in excess to prevent damaging the wires,
just make sure it does not slide when it is hit by
the lift’s top. Reference distance to top platform
is indicated in the integration drawing. Adjust if
necessary during inspection before first use.
Lifting eye
Transportation
bracket
Bottom
corner
protections
STOP
Ensure that lift emergency escape from
the lift to the tower ladder is possible.
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 11 6/20/2019 12:21:49 PM

12
AVANTI Service Lift for Wind Turbines
Tightening torque required: 6Nm for 8mm traction
rope grip plus half-bushings, 20 Nm for 12mm
guiding wire rope grip. See Annex B.
2 pieces protection bushing included in the top limit
device set must be installed only in the 8mm wire
rope. To install it, just put the 2 pieces together
around the wire rope in the position where the
wirelock are going to be fixed.
Apply the torques indicated with lubricated screws
(not dry). Only use lubricant type ‘Molykote G-Rapid
Plus’ or similar which ensures no damage to screws.
2) Uncoil wire ropes correctly (Fig. 3).
All wire ropes are evenly uncoiled as shown in
Fig 3 to prevent looping and kinks.
Ensure that no obstacles are in the way of the
service lift. Do not pull wire over edges.
3) The wires must be uncoiled carefully as descend-
ing them one by one to the bottom of the tower in a
controlled way.
Once the wires are securely attached to the top
suspension beam, take the tip of the first guiding
wire, pass it through its corresponding hole in the
yaw platform and manually lower it in a controlled
way while another technician in direct communica-
tion guide you from the ladder and help avoiding
obstacles if necessary.
When the first guiding wire is fully installed under
bottom platform (see section 3.3.4), repeat the
process with the other one.
Then descend successively the traction and the
safety wires and install them according to sections
3.5 and 3.6.
When descending wires keep the lowering
speed and direction always under control to
prevent it from causing damage to or becom-
ing blocked in one of the tower’s components.
Fig. 3
!
!
!
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 12 6/20/2019 12:21:50 PM

13
Installation Manual
3.3.2 Guiding wire rope fixations
The two 12mm wire ropes for guiding the lift
from the top beam at Yaw platform to the
tensioners at the basement are attached along
the tower by means of wirefixes at platforms
and additionally between platforms to ensure
optimal guiding as shown below for a typical
installation.
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 13 6/20/2019 12:21:50 PM

14
AVANTI Service Lift for Wind Turbines
3.3.3 Tower bottom
Holes in the bottom platform of the tower for wire
ropes bushings and trailing power cable hole are
positioned as shown in Fig. 4a and 4b.
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 14 6/20/2019 12:21:50 PM

15
Installation Manual
3.3.4 Securing the guiding
wire rope-ground level
Two possible options are shown depending on
the tower integration: attach the tensioner on
the basement foundation floor (fig. 5a) or on the
basement beam provided (fig. 5c).
Prior to installation, make sure the tension-
ers are in the position of minimum tension
(tensioning bolt fully backed out) in order
to be able to reach the required tension
value later on.
For easier tensioning, make sure the
threads of the tensioners are clean and
grease them prior to tighten.
Apply the torques indicated with lubricated
screws (not dry). Only use lubricant type
‘Molykote G-Rapid Plus’ or similar which
ensures no damage to the self-locking
nuts.
3.3.4.1. Guiding wire ropes in foundation floor
Mount the wire rope as shown in Fig. 5a follow-
ing the procedure below.
Fig. 5a
1. Drill 2 holes Ø18 x 130 mm in the concrete
foundation aligned with the 2 guiding wire
ropes holes of the bottom platform (see fig.
4b) and install the M16 threated rods
according to specific SWP Work Instruction.
See drawing below:
2. Fix the preassembled tensioner to the M16
threaded rods.
3. Feed the guiding wire rope around the fixing
bolt.
4. Pretension the wire rope by hand and fix with 2
wire rope grips. Torque the U-bolts of the 12mm
wire rope grips to 20Nm (see Annex B).
5. To make wirefixes adjustment easier,
pre-tension guiding rope to around 3kN in the
graduated scale by means of the tensioning
bolt.
6. Coil the excess of wire rope and fix with at
least 3 cable ties (see fig 5b).
Fig. 5b
7. Repeat the previous steps for the second
guiding wire rope.
8. After first run, when the wirefixes have been
installed/adjusted, tension the wire ropes to
their final tension (7 kN).
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 15 6/20/2019 12:21:50 PM

16
AVANTI Service Lift for Wind Turbines
3.3.4.2 Guiding wire ropes in beam
Mount wire ropes as shown in Fig. 6b following
procedure below.
1. Mount the preassembled tensioner on the
bottom beam.
2. Feed the guiding wire rope around the fixing
bolt.
3. Pretension the wire rope by hand and fix with
2 wire rope grips. Torque the 12mm wire rope
grips to U-bolts to 20Nm (see Annex B).
4. To make wirefixes adjustment easier,
pre-tension guiding rope to around 3kN in the
graduated scale by means of the tensioning
bolt.
5. To tension the wire rope: loosen the counter
nut, turn the tensioning bolt while holding the
counter nut loose. Secure the tensioning bolt
with the counter nut when desired tension
value is reached.
6. Coil the excess of wire rope and fix with at
least 3 cable ties (see fig 5d).
Fig. 5d
7. Repeat the previous steps for the second
guiding wire rope.
8. After first run, when the wirefixes have been
installed/adjusted, tension the wire ropes to
their final tension (7 kN).
Check the distance between the wire ropes
(1220 mm ± 2mm) so that the wire rope fix and
wire ropes are in the centre of the wire rope
guides.
Tension the guiding wire ropes after the first run
to their final tension (7kN).
!
!
Guiding wire rope
Tensioner spring
Graduated
scale
Wire rope
locks
Fixing bolt
Counter nut
Fastening bolt
Fig. 6b
Class 8.8
73243220300Bolt DIN 933 8.8 FVZ M20x30019
Class 8.873143216110Bolt DIN 931 8.8 FZV M16x11018
A2-7073120999Washer DIN 125A A2 M2017
A2-7073116999Washer DIN 125 A A2 M1626
A4-7071216999Lock nut DIN 985 A4 M1615
Steel Grade
1.7102
45515029Tensioner spring14
S235 JRG245512419Rigging screw13
S235 JRG2
45512398Housing12
35499407_P0135499407_P0111
MATERIAL
ARTICLE No.DESCRIPTIONQTYPOS
A
45512068Wire rope clip for 12mm22
S235 JRG2
45512067
Galv. thimble for 12 mm wire
11
35499407_P01
MATERIALARTICLE No.DESCRIPTIONQTYPOS
A
Denmark
Rønnevangs Allé6
DK-3400 Hillerød
AIP ApS
Stamp:
Edit by:
Constructor:
Title:
Replaced by:
Date:
Replaces:
Drw. no.
Valid from:
Rev.no.:
Release
Scale:
MPG
MPG
2014-01-15
2014-01-15
1 : 10 35499407
AD00082
Set Tensioner Short
01
Proj: Format:
A3
ISO-E
1 / 1
Sheet no.
A A
B B
C C
D D
E E
F F
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
THISDOCUMENTANDITSCONTENTSAREPROPRIETARYTOAIPApSANDPROTECTEDBYCOPYRIGHT.THEYARECONFIDENTIALANDMAYCONTAINLEGALLYPRIVILEGEDINFORMATION.
COPYING,SUBMITTINGTOTHIRDPARTIESORUSEINANYFORMANDFORANYPURPOSEOTHERTHANTHATORIGINALLYINTENDEDISPROHIBITEDWITHOUTTHEEXPRESSPREVIOUSWRITTENCONSENTOFAIPApS.
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 16 6/20/2019 12:21:51 PM

17
Installation Manual
3.4 Electrical connections
3.4.1 Power supply
The electrical connection of the traction
system must be made in accordance with
EN 60204-1.
The power supply must be protected by a
fuse and an earth leak circuit breaker
(30mA). Disconnect the main power supply
before handling power units. Verify that the
rated grid and motor voltages are identical.
The three-phase motor is supplied in a star
connection configuration.
Check the correct phase lay after first installation and
after each work at control box and/or power supply. In
case the lift travels up when the down button is
pushed, switch two phases on the power cable plug.
3.4.2 Installation of main switch
The main switch is installed on the bottom
platform fence (Fig 7).
Mount the send and call control boxes to the
platform fences and connect them to the main
switch control box according to the wiring
diagram supplied in the main control box of the
cabin.
1. Connect the power input cable to the WTG
electrical cabinet.
2. Connect the circuit to the plug available on
the power cable coiling bin under the platform.
3.4.3 Supply cable
1. The length of the cable depends on the
height of the tower. The power cable is marked
with its length.
2. Use heavy rubber cable strips for fastening
the supply cable to service lift.
3. An installed generator will have to provide at
least 2.5 times the output of the traction system.
3.4.4 Power connection
1. Push the EMERGENCY STOP button of the
cabin operation box.
2. Check that the various stop switch cables and
fall arrest device cable are connected to the
power cabinet according to colour code.
3. If cable coiling bin is used (Fig. 8):
3.1 Hang the cable collect bin underneath the
power cable hole of the bottom platform. Attach
the straps on the holes shown in Fig. 4.
3.2 Hang the bucket in the full length of the
webbing. Keep the webbing as long as possible.
3.3 Cut the transport strips and tape which hold
the wire rope inside the bin.
The plug and socket connection between the
lift and cable bin must be placed inside the
engine room.
4. Connect the power
cable outlet socket to the
service lift inlet plug using
cable stocking. Attach
shackle to the eyebolt on
the back of the service lift (Fig. 10).
5. Connect the power cable
plug to the grid (Pre-fuse 16A).
6. Pull the EMERGENCY STOP
button to deactivate. The wiring
diagram is found in the electrical
control box.
Fig. 10
Fig. 7
!
!
SWP L CE 690V 3 phases+gnd. 50 Hz Y I = 2.3A 1.5 kW 18m/min
SWP L CE 690V 3 phases+gnd. 60 Hz Y I = 2.8A 1.5 kW 18m/min
SWP L AECO 480V 3 phases+gnd. 60 Hz Y I = 4.1A 1.8 kW 21m/min
SWP L AECO 400V 3 phases+gnd. 60 Hz Y I = 5.1A 1.8 kW 21m/min
Control voltage: 230V
Power cable
inlet plug
Counterweight
traction wire
Cable collect
bin
Cable collect bin
suspension
straps
Spring safety
wire
Power cable
outlet socket
Cable
stocking
Fig.8
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 17 6/20/2019 12:21:52 PM

18
AVANTI Service Lift for Wind Turbines
3.5.2 Safety wire rope installation
1. Unlock the fall arrest device by pushing
up the black lever. Feed the safety wire rope
through the fall arrest device.
2. Like the traction wire rope, continue
feeding the wire rope underneath (round) the
back guide wheel and over the front guide
wheel.
3. Pull the safety wire rope to tighten it.
4. Feed wire rope through cabin bushings
and then through the platform floor towards
the basement.
5. Mount the wheels cover and top cover
plate back on the service lift.
Traction
wire rope
Fig. 12
Fig. 13a
Fig. 13b
Wear protective gloves when
handling wire ropes.
3.5.1 Traction wire rope installation
1. Remove top cover plate from the service
lift (see Fig.12). Remove wheels cover
inside the cabin (see Fig.13a and 13b).
2. Put the wire rope into the traction
system’s wire rope inlet opening.
3. Push the UP button on the cabin
operation control (manual control from
inside the cabin) and feed wire rope
through until the traction system starts
pulling. Ensure that the wire rope
can exit without obstruction!
4. Continue feeding the wire rope under-
neath (round) the back guide wheel and
over the front guide wheel.
5. Let the traction wire rope pass through
until it is slightly tightened.
6. Feed wire rope through cabin bushings
and then through the platform floor
towards the basement.
3.5 Installation of traction
and safety wire rope in lift
Safety
wire rope
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 18 6/20/2019 12:21:52 PM

19
Installation Manual
3.6 Securing the traction
and safety wire rope
The traction wire rope is fastened as described in
point 3.6.1 below and the safety wire rope is
fastened as shown in point 3.6.2.
Apply the torques indicated with lubricated
screws (not dry). Only use lubricant type
‘Molykote G-Rapid Plus’ or similar which
ensures no damage to screws.
3.6.1 Traction wire rope counterweight
An 11kg (25,25 lb) weight is mounted approximately
200mm (7,87 in) below the bottom platform on
the traction wire rope hold by means of two wire
rope grips torqued to 6 Nm (see Annex B).
Excess of wire rope is coiled with at least three
strips (see fig. 14a and 14b).
3.6.2 Safety wire rope push spring
Steps to install the push spring are detailed
below (see fig 15):
1. Feed the safety wire rope through the bottom
platform hole.
2. Ascend the service lift 50 cm.
3. Activate the fall arrest device.
4. Perform manual descent so that the weight of the
service lift is transmitted to the safety wire rope.
5. Compress the spring to 40 mm and fix with cable
ties.
6. Feed the safety wire rope through the compressed
spring.
7. Pull the safety wire rope downwards by hand as
much as possible.
8. Place and fasten the two wire rope grips (torqued
to 6Nm according to Annex B).
9. Cut the cable ties so that the spring decompresses
to 55 mm.
Optionally, the push
spring can be
replaced by two or
three 11 kg
counterweights
(depending on the
configuration) as
the used on the
traction wire rope.
3.6.3 Traction and safety wire ropes grounding
To allow the rotation of the traction wire rope and
provide the proper grounding of it, a “rotating
grounding unit” may be used. See picture below:
To install the rotating ground unit: prior to counter-
weight installation, insert the traction wire rope
through the unit and fix it in a suitable position below
the lower bracket by means of the two M8 screws in
the lower part of the unit. Torque required is 4Nm
(see Annex B).
The earthing cable is then
attached to the unit by
another M8 screw
located on the top of it.
Torque value is not
specified for this
screw, just ‘snug-tight’
required.
The safety wire rope‘s lower
end can be grounded by
simply connecting the
earthing cable to the wire
by means of an appropriate
bracket, similarly to the
top end of the wire ropes.
See picture to the right:
Ensure that counter-
weight and wire rope
coils can rotate freely.
Before fastening
the safety wire
rope carry out
the fall arrest
device test.
STOP
Fig. 14a
Fig. 14b
Fig. 15
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 19 6/20/2019 12:21:54 PM

20
AVANTI Service Lift for Wind Turbines
3.7 Wire rope fix alignment
Having mounted the service lift, the wire ropes,
and the power cable, adjust the wire rope fix
alignment during the first run.
The wirefixes are made of two parts. Theses
two-piece concept allows the wirefix to be installed
at any moment, without having to introduce it
through the bottom end of the wire rope but just
putting the 2 pieces together around the wire rope.
There are 2 installation windows located on
the rear of the service lift. These shall only be
used during installation and maintenance
tasks.
In order to avoid risks, turn the power supply
off from the service lift before opening the 2
installation windows. Do not turn the power
supply back on until the windows are closed.
Besides, in order to install/adjust wirefixes, the
lift’s door has to be opened. People have to
be always attached to the anchor point when
using the lift. Confirm you are properly
secured before opening the door.
STOP
STOP
STOP
Fig. 16 Rollers guiding system
The final position of the wire rope fixes shall be
adjusted with the help of the installation tool
(item number AT00011211, see Fig. 17) and
following the procedure below. The distance
between wirefixes is 1220 ± 2 mm.
1. Put the installation tool inside the lift and
ascend to the installation position of the first
pair of wirefixes.
2. Turn the operation selector to 0FF position,
push emergency stop switch, and then open
the two installation windows.
3. Install the first pair of wire fixes to the tower
structure using the holes provided.
4. Attach the left end of the installation tool to
the left guiding wire rope (see Fig. 18).
5. Attach the right end of the installation tool to
the right guiding wire rope (see Fig. 19).
6. Slide the installation tool downwards until it
contacts the wire rope fixes (see Fig. 20).
Fig. 17
Fig. 18
Fig. 19
Fig. 20
Aluminium
Two-piece
wirefix
Aluminium
Two-piece
wirefix
Two-piece
wirefix
Rollers
guide
AT00010650_Installation Manual SWP L CE AECO EN E2R1.indd 20 6/20/2019 12:21:55 PM
