Cabling Guide—MCC1 and SCC1
Media Gateway
Avaya™ S8700 Media Server with Avaya™ MCC1 or SCC1 Media Gateway
This cabling guide provides graphical representations on various cable connections for the Avaya™ MCC1 and
SCC1 Media Gateways used in an S8700 Multi-Connect configuration. Different ribbon cables are used and CAT5
Ethernet cables connect differently, depending on whether it is a new installation or a migration. See pages 2 and
3. For specific connectivity information, see pages 4 and 5.
Although the graphic shows an IPSI in a second port network in a MCC1 Media Gateway with multiple port
networks, each port network does not require an IPSI circuit pack. One IPSI can control the whole media gateway.
However, when there are remote port networks, you may need to put IPSIs in more than one port network in a
media gateway to reach the minimum number of IPSIs required in an S8700 Multi-Connect configuration.
Cable identification is shown in ‘‘Cables used with the MCC1 and SCC1 Media Gateways’’.
