Avaya S8730 Instruction Manual

Installing and Configuring the
Avaya S8700-Series Server
Release 5.0
03-300145
Release 5.0
January 2008
Issue 7

© 2008 Avaya Inc.
All Rights Reserved.
Notice
While reasonable efforts were made to ensure that the information in this
document was complete and accurate at the time of printing, Avaya Inc. can
assume no liability for any errors. Changes and corrections to the information
in this document may be incorporated in future releases.
For full legal page information, please see the documents,
Avaya Support Notices for Software Documentation, 03-600758, and
Avaya Support Notices for Hardware Documentation, 03-600759.
These documents can be accessed on the documentation CD and on the Web
site, http://www.avaya.com/support. On the Web site, search for the document
number in the Search box.
Documentation disclaimer
Avaya Inc. is not responsible for any modifications, additions, or deletions to
the original published version of this documentation unless such modifications,
additions, or deletions were performed by Avaya. Customer and/or End User
agree to indemnify and hold harmless Avaya, Avaya's agents, servants and
employees against all claims, lawsuits, demands and judgments arising out of,
or in connection with, subsequent modifications, additions or deletions to this
documentation to the extent made by the Customer or End User.
Link disclaimer
Avaya Inc. is not responsible for the contents or reliability of any linked Web
sites referenced elsewhere within this documentation, and Avaya does not
necessarily endorse the products, services, or information described or offered
within them. We cannot guarantee that these links will work all of the time and
we have no control over the availability of the linked pages.
Warranty
Avaya Inc. provides a limited warranty on this product. Refer to your sales
agreement to establish the terms of the limited warranty. In addition, Avaya’s
standard warranty language, as well as information regarding support for this
product, while under warranty, is available through the following Web site:
http://www.avaya.com/support.
Copyright
Except where expressly stated otherwise, the Product is protected by copyright
and other laws respecting proprietary rights. Unauthorized reproduction,
transfer, and or use can be a criminal, as well as a civil, offense under the
applicable law.
Avaya support
Avaya provides a telephone number for you to use to report problems or to ask
questions about your product. The support telephone number
is 1-800-242-2121 in the United States. For additional support telephone
numbers, see the Avaya Web site: http://www.avaya.com/support.

Installing and Configuring the Avaya S8700-Series Server January 2008 3
Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
How to use Avaya installation documents . . . . . . . . . . . . . . . . . . . . . 8
Pre-installation requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
PNC license settings for S8700-series Servers . . . . . . . . . . . . . . . . . 9
Preinstallation tasks to complete at the customer site . . . . . . . . . . . . . . . 9
Verifying that all the required equipment is on site . . . . . . . . . . . . . . . 9
Ensuring that the preinstallation tasks are complete . . . . . . . . . . . . . . 10
Equipment specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
About S8730 Server configurations . . . . . . . . . . . . . . . . . . . . . . . . . 13
About RAID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
About server port connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
S8700-series port connections . . . . . . . . . . . . . . . . . . . . . . . . . . 14
About modem connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Modem options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
About media gateways . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
About Processor Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
About software duplication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
About SSH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Chapter 2: SNMP configuration . . . . . . . . . . . . . . . . . . . . . . 23
Configuring the SNMP modules in the UPS . . . . . . . . . . . . . . . . . . . . . 23
Default UPS IP addresses for S8700-series Servers . . . . . . . . . . . . . . 24
Prerequisites for configuring the SNMP module . . . . . . . . . . . . . . . . 25
Administering the SNMP modules . . . . . . . . . . . . . . . . . . . . . . . . 26
Setting selected traps (alarming) . . . . . . . . . . . . . . . . . . . . . . . . 26
Configuring the SNMP subagent in the Avaya Ethernet switch (if used) . . . . . 27
Default IP addresses for the Ethernet switch . . . . . . . . . . . . . . . . . . 27
Preparing to configure the Ethernet switch . . . . . . . . . . . . . . . . . . . 28
Configuring the Ethernet switch . . . . . . . . . . . . . . . . . . . . . . . . . 29
Chapter 3: Communication Manager installation . . . . . . . . . . . . . 31
Clearing the ARP cache on the laptop . . . . . . . . . . . . . . . . . . . . . . . . 31
Applying power to the server . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Accessing the server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Configuring Telnet for Windows 2000 and Windows XP . . . . . . . . . . . . . . 32
Installing Avaya Communication Manager . . . . . . . . . . . . . . . . . . . . . 33
Contents

Contents
4Installing and Configuring the Avaya S8700-Series Server January 2008
Chapter 4: Server configuration . . . . . . . . . . . . . . . . . . . . . . 35
Opening the Maintenance Web Interface. . . . . . . . . . . . . . . . . . . . . . . 36
Copying files to the server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Creating a super-user login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Methods of Configuring a server . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Configuring the server manually . . . . . . . . . . . . . . . . . . . . . . . . . 37
Setting the date, time, and time zone. . . . . . . . . . . . . . . . . . . . . 37
Maintenance Web Pages configuration screens. . . . . . . . . . . . . . . 38
Ethernet interface assignments. . . . . . . . . . . . . . . . . . . . . . . . 40
Performing the manual configuration . . . . . . . . . . . . . . . . . . . . . . 40
Avaya Installation Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
About the Avaya Installation Wizard . . . . . . . . . . . . . . . . . . . . . 41
Running the Avaya Installation Wizard. . . . . . . . . . . . . . . . . . . . 42
Verifying the server connection to the customer LAN (if provided) . . . . . . . . 42
Configuring the modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Configuring memory for an S8720 Server . . . . . . . . . . . . . . . . . . . . . . 44
Ensuring ESS and LSP compatibility. . . . . . . . . . . . . . . . . . . . . . . . . 45
Enabling firewall settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Enabling network time servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Configuring the NIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Release the server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Configuring a second server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Interchanging servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Accessing the standby server . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Interchanging servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Performing an integrity check on the active server . . . . . . . . . . . . . . . 49
Chapter 5: IP interface translations . . . . . . . . . . . . . . . . . . . 51
Inputting initial system translations . . . . . . . . . . . . . . . . . . . . . . . . . 51
Adding media gateways . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Enabling the IPSI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Adding the IPSI to the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Enabling IPSI duplication (duplicated control network only) . . . . . . . . . . . 55
Setting the alarm activation level . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Saving translations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Chapter 6: IP interface configuration . . . . . . . . . . . . . . . . . . . 57
Connecting to the IPSIs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Contents
Installing and Configuring the Avaya S8700-Series Server January 2008 5
IPSI address configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Programming the IPSI for static addressing . . . . . . . . . . . . . . . . . 58
Setting the VLAN and diffserv parameters . . . . . . . . . . . . . . . . . . . . . 61
Programming the IPSI for DHCP addressing . . . . . . . . . . . . . . . . . . 62
Verifying connectivity to the server . . . . . . . . . . . . . . . . . . . . . . . . . 65
Verifying that the IPSIs are translated . . . . . . . . . . . . . . . . . . . . . . . . 65
Upgrading the IPSI firmware version (if necessary) . . . . . . . . . . . . . . . . 65
Enabling control of the IPSIs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Verifying the license status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Chapter 7: Postinstallation administration . . . . . . . . . . . . . . . . 67
Verifying translations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Setting rules for daylight savings time . . . . . . . . . . . . . . . . . . . . . . . 68
Setting locations (if necessary) . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Verifying the date and the time (main server only) . . . . . . . . . . . . . . . . . 70
Clearing and resolving alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Enabling and disabling the Ethernet switch ports . . . . . . . . . . . . . . . . . 71
Enabling alarms to INADS by way of a modem . . . . . . . . . . . . . . . . . . . 72
Enabling alarms to INADS by way of the SNMP module . . . . . . . . . . . . . . 73
Backing up files to the compact flash media . . . . . . . . . . . . . . . . . . . . 73
Before leaving the site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Chapter 8: Installation verification . . . . . . . . . . . . . . . . . . . . . 75
Testing the IPSI circuit pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Testing the license file . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
S8730 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
S8710 and S8720 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Additional server LED information . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Avaya C360 Ethernet switch LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . 80
UPS LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
TN2312BP IPSI LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Appendix A: Server access . . . . . . . . . . . . . . . . . . . . . . . . . 87
Accessing the command line interface of the server with SSH . . . . . . . . . . 87
Connecting to the server directly . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Connecting to the server remotely over the network . . . . . . . . . . . . . . . . 92
Connecting to the server remotely over a modem . . . . . . . . . . . . . . . . . 92

Contents
6Installing and Configuring the Avaya S8700-Series Server January 2008
Finding the IP address of the active server . . . . . . . . . . . . . . . . . . . 93
Accessing the Maintenance Web Interface . . . . . . . . . . . . . . . . . . . . . 93
Using the SAT command line prompt . . . . . . . . . . . . . . . . . . . . . . . . 94
Logins for Avaya technicians and BusinessPartners . . . . . . . . . . . . . . . 95
Configuring the network for Windows 2000 and XP . . . . . . . . . . . . . . . . 95
Setting the browser options for Internet Explorer 6.0 . . . . . . . . . . . . . . . 96
Appendix B: Installation troubleshooting . . . . . . . . . . . . . . . . . 97
Troubleshooting the installation of the server hardware . . . . . . . . . . . . . . 97
Troubleshooting the configuration of the server hardware . . . . . . . . . . . . 98
Troubleshooting the installation of the license file and
the Avaya authentication file . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Installing and Configuring the Avaya S8700-Series Server January 2008 7
Chapter 1: Introduction
Use these procedures to install Avaya Communication Manager and configure a new Avaya
S8700-series Server and the associated components in a fiber-connected (fiber-PNC) or an
IP-connected (IP-PNC) port network configuration.
To configure the server, use the Avaya Installation Wizard. To configure gateways and other
hardware components, use the following two administration interfaces:
●The Maintenance Web Interface
●The command line interface, either directly or through Secure Shell (SSH), Telnet, or a
terminal emulation program such as Avaya Native Configuration Manager.
This installation document includes the following information:
●Pre-installation requirements on page 9
●Configuring the SNMP modules in the UPS on page 23
●Server configuration on page 35
●IP interface translations on page 51
●IP interface configuration on page 57
●Postinstallation administration on page 67
●Installation verification on page 75
●Server access on page 87
●Installation troubleshooting on page 97
Audience
This documentation is for the following people who install and configure the server components:
●Trained field installation and maintenance personnel
●Technical support personnel
●Authorized business partners

Chapter 1: Introduction
8Installing and Configuring the Avaya S8700-Series Server January 2008
How to use Avaya installation documents
Use this document as a guide to install and configure Avaya servers. For information about a
particular task, use the index or the table of contents to locate the page on which the information
is described. You also need information from other Avaya documents. This section lists those
documents and tells you when to use them.
To complete this installation:
●In this document, see:
- Pre-installation requirements on page 9 first. This section describes the tasks that your
must complete at the site before you start the installation.
- Equipment specifications on page 10 for the technical specifications for the hardware.
●For how to install and connect the hardware, see Quick Start for Hardware Installation:
Avaya S8700-Series Server (555-245-701).
●Return to this document and see the remaining sections in the following sequence to
install the components of the server. If you are not to install certain components, skip the
procedures for those components.
- Configuring the SNMP modules in the UPS on page 23
- Server configuration on page 35
- IP interface translations on page 51
●See the appropriate sections in the following documents to install the port networks and
the media gateways:
- Installing the Avaya G650 Media Gateway (03-300144)
- Installation and Configuration for the Avaya G150 Media Gateway (03-300395)
- Quick Start for Hardware Installation: Avaya G250 Media Gateway (03-300433)
- Quick Start for Hardware Installation: Avaya G350 Media Gateway (03-300148)
- Quick Start for Hardware Installation: Avaya G450 Media Gateway (03-602053)
- Installing and Upgrading the Avaya G250 Media Gateway (03-300434)
- Installing and Upgrading the Avaya G350 Media Gateway (03-300394)
- Installing and Upgrading the Avaya G450 Media Gateway (03-602054)
- Quick Start for Hardware Installation: Avaya S8300 Server and Avaya G700 Media
Gateway (555-233-150)
- Installation and Upgrade for the Avaya G700 Media Gateway and Avaya S8300 Server
(555-234-100)
- Avaya IA 770 INTUITY AUDIX Messaging Application Administering the S8300 and
S8400 Servers to work with IA 770
●Return to this document and see:
- IP interface configuration on page 57 to program the IP interface.

Pre-installation requirements
Installing and Configuring the Avaya S8700-Series Server January 2008 9
- Postinstallation administration on page 67
- Installation verification on page 75
- Server access on page 87
- Installation troubleshooting on page 97 if problems occur during the installation.
Pre-installation requirements
This section describes the tasks that you must complete before you start the installation. You
complete certain tasks before you go on site and other tasks at the site.
PNC license settings for S8700-series Servers
For Communication Manager Release 4.0 and later releases, the two major types of port
network connectivity, IP-PNC and fiber-PNC (also called multiconnect), are both automatically
enabled in all licenses for S8700-series Server. As a result, unlike the license settings in
previous releases, platform 8 for IP-PNC and the Internet Protocol (IP) PNC feature attribute
are no longer needed and are not available as license options. For Release 4.0 and later
releases, you always select platform 6, multiconnect, in a license for an S8700-series Server.
Preinstallation tasks to complete at the customer site
Before you start the installation, you must:
●Verify that all the required equipment is on site
●Ensure that the preinstallation team completed the preinstallation tasks
●Install the DAL2 card, if used
Verifying that all the required equipment is on site
Compare the list of items that were ordered to the contents of the boxes to verify that you have
all the equipment. Your project manager can give you an inventory list. Do not rely on the
packing slips inside the boxes for the correct information.

Chapter 1: Introduction
10 Installing and Configuring the Avaya S8700-Series Server January 2008
Ensuring that the preinstallation tasks are complete
The preinstallation team completes the following tasks. If these tasks are not complete, do not
continue with the installation.
●Verify that the required number of open, customer-supplied, EIA-310D (or equivalent)
standard 19-in. (48-cm) 4-post equipment rack(s) is(are) properly installed and solidly
secured. Ensure that the screws that come with the racks are present. If you use a rack
cabinet, ensure that the cabinet has adequate ventilation.
●Verify that the rail kit to support the server is available to install.
●Verify that the rail kit that is required to support the UPS is installed on the rack or available
to install. For how to install the rails, see the documentation that comes with the rail kit.
●Verify that the equipment racks are grounded per local code. See Job Aid: Approved
Grounds (555-245-772).
●Verify that the customer-provided AC power to the rack is from a nonswitched outlet.
●Verify that cables for theTN2312BP (IPSI) circuit packs are labeled and run from the
control hardware rack to the port networks or that appropriate connectivity is provided.
Equipment specifications
The components of the S8700-series Server control network consist of two servers, one or two
Ethernet switches, and two UPSs. The physical specifications for the control network
components are shown in Table 1.
Table 1: Control network components specifications
Component
Dimensions
English
(height x width x depth
in inches)
Dimensions
Metric
(height x width x depth
in centimeters)
Height
(u)
Weight
(lb/kg)
Server
S8710, S8720, or
S8730
3.4 x 17.5 x 26 8.6 x 45 x 66 2 60/27
(loaded)
Ethernet switch:
C363T
C364T
1.75 x 17 x 14.4
1.75 x 17 x 14.4
4 x 43 x 37
4 x 43 x 37
1
1
11/5
11/5
UPS:
700 VA
1500 VA
3.5 x 17 x 19
3.5 x 17 x 24
9 x 43 x 48
9 x 43 x 61
2
2
34/15
50/23

Preinstallation tasks to complete at the customer site
Installing and Configuring the Avaya S8700-Series Server January 2008 11
Table 2 shows specifications for the S8710, S8720 and S8730 Servers.
.
Table 2: S8710, S8720 and S8730 Server features and specifications
Feature Description
Microprocessor S8710: 1 Intel Xeon
S8720: 1 AMD Opteron
S8730 1 Dual Core rev "F" AMD
Memory S8710: 512 MB
S8720: 1 GB
S8730: 4 GB
Drives (SCSI) Hard disk drive: 72 GB, 10,000 RPM
CD-ROM/DVD-ROM: 24x maximum
Diskette drive: 1.44 MB (3.5 in. [9 cm])
DAL2 hardware
duplication cards
Used for the hardware duplication configuration only. Not used
for the software duplication configuration.
Physical dimensions S8710/S8720:
Height: 3.4 inches [8.6 cm], 2 U)
Depth: 26 inches (66 cm)
Width: 17.5 inches (45 cm)
Maximum weight: 60 lb (27 kg)
S8730:
Height: 3.38 inches [8.59 cm], 2 U)
Depth: 26.01 inches (66.07 cm)
Width: 17.54 inches (44.54 cm)
Maximum weight: 60 lb (27.22 kg)
Integrated functions S8710/8720: 2 10/100/1000BaseT Ethernet connectors
S8730: 2 100/1000Gb Ethernet ports
Serial connector
iLO connector (unused)
Keyboard connector
Mouse connector
USB connectors:
S8710: 2
S8720: 3
S8730: 4
Video connector
VHDCI SCSI connector

Chapter 1: Introduction
12 Installing and Configuring the Avaya S8700-Series Server January 2008
Environmental specifications for the S8710, S8720 and S8730 are shown in Table 3.
.
Table 3: S8710/S8720/S8730 Server environmental specifications
Parameter Description
Air Temperature Ambient operating: 50°F to 95°F (10°C to 35°C)
Maximum wet bulb: 82.4°F (28°C)
NOTE: All temperature ratings shown are for sea level. An altitude
derating of 1.8°F per 1000 ft to 10,000 ft (1°C per 300 meters) is
applicable. No direct sunlight is allowed.
Humidity Operating: 10% to 90%
Nonoperating: 5% to 85% (S8730: 5% to 95%)
NOTE: The storage maximum humidity of 95% is based on a
maximum temperature of 113°F (45°C). The altitude maximum for
storage corresponds to a pressure minimum of 70 kPa.
Electrical input Rated input voltage:
S8710/8720:100 VAC to 240 VAC
S8730:100 to 132 VAC, 200 to 240 VAC
Rated input frequency: 50 Hz to 60 Hz
Rated input current:
S8710/8720: 6 A (110 V) to 3 A (220 V)
S8730:10 A at 100 VAC, 4.9 A at 200 VAC
Rated input power:
S8710/8720: 600 W
S8730:
980 W at 100V AC input
960 W at 200V AC input
BTUs per hour: 2050
Power supply output Rated steady-state power:
S8710/8720:400 W
S8730:
800 W at 100V AC input
850 W at 120V AC input
1000 W at 200V to 240V AC input
Maximum peak power:
S8710/8720: 400 W

About S8730 Server configurations
Installing and Configuring the Avaya S8700-Series Server January 2008 13
About S8730 Server configurations
The S8730 Server comes with the option of two hard disk drives. In configurations with two hard
drives, the RAID level 1 feature is enabled, so that disk mirroring automatically creates a
complete set of data on both disks.
For different configurations of the S8730 Server:
●If the server has only one hard drive, the drive should be in bay 1 (the leftmost bay)
●If the server has two hard drives, the drives should be in bay 1 and bay 2.
After installation, do not attempt to move a drive from one bay to the other. If movement of
drives is necessary, the server must be reinstalled.
About RAID
One or more hard drives may be added to an S8730 Server in order to take advantage of the
RAID level 1 feature, which provides disk mirroring. In this configuration, a customer’s data is
mirrored on two disks, thus increasing the availability of the system. Each of the disks is
independent of each other and contains a complete copy of the data. No administration is
necessary to activate the RAID feature. Once an additional hard drive is installed,
Communication Manager recognizes the additional hard drive and automatically activates
RAID.
Note:
Note: The RAID level 1 feature is only available on S8730 Servers.
About server port connections
The following section explains how to connect the Ethernet ports on the back of the server.

Chapter 1: Introduction
14 Installing and Configuring the Avaya S8700-Series Server January 2008
S8700-series port connections
The network cable connections depend on the type of server, type of memory duplication, and
the type of control network. All cables are CAT5 or better patch cables except for the fiber cable
that interconnects the DAL2 cards for hardware duplication.
●For a guide to connect the cables to the servers for hardware duplication on the S8730
Server, see Figure 1: Duplication and control network cabling for hardware duplication
(S8730) on page 15.
●For a guide to connect the cables to the servers for hardware duplication on the S8720 or
S8710 Server, see ,Figure 2: Duplication and control network cabling for hardware
duplication (S8720/S8710) on page 16.
●For a guide to connect the cables to the servers for software duplication on the S8730
Server, see Figure 3: Duplication and control network cabling for software duplication
(S8730) on page 17.
●For a guide to connect the cables to the servers for software duplication on the S8720 or
S8710 Server, see ,Figure 4: Duplication and control network cabling for software
duplication (S8720/S8710) on page 18.

About server port connections
Installing and Configuring the Avaya S8700-Series Server January 2008 15
Figure 1: Duplication and control network cabling for hardware duplication (S8730)
Note:
Note: These are typical Ethernet port assignments. The customer might specify
different assignments for Eth0, Eth2, Eth3, and Eth4.
Figure notes:
1. Eth0 — CNA (also LAN for nondedicated control network)
2. Eth2 — Server duplication link - duplication crossover cable
3. Eth3 — To an Ethernet switch and/or the corporate LAN for control network B (CNB)
4. Eth4 — To the customer LAN if the control networks are dedicated
5. Fiber duplication cable
hw8730h2 LAO 082807
DAL1 DUP MEMORY
RECEIVE MODE
LINC SYNC
TRANS MODE
LINC ACTIVE
1
2
UID
ILO 2
PCIe 1PCIe 2
3
4
5
DAL1 DUP MEMORY
RECEIVE MODE
LINC SYNC
TRANS MODE
LINC ACTIVE
1
2
UID
ILO 2
PCIe 1PCIe 2
3
4
5
1
2
1
3
2
4
5

Chapter 1: Introduction
16 Installing and Configuring the Avaya S8700-Series Server January 2008
Figure 2: Duplication and control network cabling for hardware duplication (S8720/S8710)
Note:
Note: These are typical Ethernet port assignments. The customer might specify
different assignments for Eth0, Eth2, Eth3, and Eth4.
Figure notes:
1. Eth0 — To an Ethernet switch and/or the corporate LAN for control network A (CNA)
2. Eth2 — Server Duplication Link
3. Eth3 — To an Ethernet switch and/or the corporate LAN for control network B (CNB)
4. Eth4 — To the customer LAN if the control networks are dedicated
5. Fiber duplication cable
2
3
iLO
VDCI
DAL1 DUP MEMORY
RECEIVE MODE
LINC SYNC
TRANS MODE
LINC ACTIVE
1
2
3
133 MGz
100 MGz
100 MGz
UID
2 1
2
3
iLO
VDCI
DAL1 DUP MEMORY
RECEIVE MODE
LINC SYNC
TRANS MODE
LINC ACTIVE
1
2
3
133 MGz
100 MGz
100 MGz
UID
2 1
1
2
h3df87h2 LAO 122206
3
2
5
4
1

About server port connections
Installing and Configuring the Avaya S8700-Series Server January 2008 17
Figure 3: Duplication and control network cabling for software duplication (S8730)
Note:
Note: These are typical Ethernet port assignments. The customer might specify
different assignments for Eth2, Eth3, and Eth4.
Figure notes:
1. Eth0 — Server Duplication Link - duplication crossover cable
2. Eth2 — To an Ethernet switch and/or the corporate LAN for control network A (CNA)
3. Eth3 — To an Ethernet switch and/or the corporate LAN for control network B (CNB)
4. Eth4 — To the corporate LAN if the control networks are dedicated.
1
2
UID
ILO 2
PCIe 1PCIe 2
3
4
5
1
2
UID
ILO 2
PCIe 1PCIe 2
3
4
5
1
2
hw8730s2 LAO 081607
1
3
2
4

Chapter 1: Introduction
18 Installing and Configuring the Avaya S8700-Series Server January 2008
Figure 4: Duplication and control network cabling for software duplication (S8720/S8710)
Note:
Note: These are typical Ethernet port assignments. The customer might specify
different assignments for Eth2, Eth3, and Eth4.
Figure notes:
1. Eth0 — Server Duplication Link
2. Eth2 — To an Ethernet switch and/or the corporate LAN for control network A (CNA)
3. Eth3 — To an Ethernet switch and/or the corporate LAN for control network B (CNB)
4. Eth4 — To the corporate LAN if the control networks are dedicated.
2
3
iLO
VDCI
1
2
3
133 MGz
100 MGz
100 MGz
UID
2 1
2
3
iLO
VDCI
1
2
3
133 MGz
100 MGz
100 MGz
UID
2 1
1
2
h3df87s2 LAO 122206
1
4
3
2

About modem connections
Installing and Configuring the Avaya S8700-Series Server January 2008 19
About modem connections
Note:
Note: You cannot connect USB modems to rotary lines. A touch tone line is required.
On S8700-series Servers, connect a USB modem to the USB port on each server.
CAUTION:
!
CAUTION: Once you connect the modems to the servers, do not unplug the modem USB
cable on the active server. If you must replace the modem, replace the modem
when the server is in standby mode.
Connecting to collocated servers
!Important:
Important: Both servers share one telephone line.
To connect modems to collocated servers:
1. Install two RJ11 jack outlets wired to a single (1-Measured Business) telephone line.
2. Use the modular telephone cord that is supplied with the modem to connect one RJ11 jack
to each modem.
3. Use the USB cable that is supplied with the modem to connect one modem to server 1.
4. Use the USB cable to connect the other modem to server 2.
Connecting to separated servers
!Important:
Important: Each server has a dedicated telephone line.
To connect to separated servers:
1. For a server in each location, install one RJ11 jack outlet that is wired to a single
1-Measured Business telephone line.
2. Use the modular telephone cord that is supplied with the modem to connect one RJ11 jack
to each server.
3. Connect each modem, using the USB cable, to the server at each location.

Chapter 1: Introduction
20 Installing and Configuring the Avaya S8700-Series Server January 2008
Modem options
You set the modem options when you configure the server. You do not set options on the
modems themselves.
About media gateways
In a new installation, the S8700-series Servers work with only the Avaya G650 Media Gateway.
In a migration, the S8700-series Servers work with Avaya MCC1 and SCC1 Media Gateways in
a fiber-PNC configuration and G600 or CMC1 Media Gateways in an IP-PNC configuration.
The servers also work with Avaya G150, G250, G350, G450 and G700 Media Gateways. These
gateways register with the server either through the Processor Ethernet interface or through a
TN799DP C-LAN circuit pack.
Media gateways usually are installed in the same equipment room as the server rack hardware
or control network. However, you can install the media gateways in another location, including
another state or country.
About Processor Ethernet
Like a C-LAN circuit pack, Processor Ethernet provides connectivity to IP endpoints, gateways,
and adjuncts. The PE interface is a logical connection in the Communication Manager software
that uses a port on the NIC in the server. No additional hardware is needed to implement PE.
Starting with Release 3.1 of Communication Manager, the PE interface is enabled on the
S8700-Series Server to allow enhanced flexibility to connect to gateways, endpoints, and
adjuncts.
The PE interface is always enabled on an S8700-series Server pair for registration by an ESS
or an LSP. However, the PE interface is not supported on duplex servers for registration by an
H.248 gateway, H.323 endpoints, or adjuncts.
