AVE COBRA HEAD 150 User manual

COBRA HEAD 150
User Manual

Table of Contents
Safety .......................................................................................2
Important Safety Instructions...........................................................3
Precautions......................................................................................4
Suspension......................................................................................4
Mounting..........................................................................................4
Description................................................................................5
Features ............................................................................5
Setup........................................................................................6
Power Linking .....................................................................6
Operation...........................................................................6
Menu Map..........................................................................7
DMX Channel......................................................................8
Specifications............................................................................8

Safety
Important Safety Information
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT OVEREXPOSE THIS FIXTURE
TO RAIN OR MOISTURE.
WARNING: CONNECT ONLY TO MAINS POWER SUPPLY WITH A PROTECTIVE EARTHING
CONNECTION.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE THE REAR COVER OR
ATTEMPT TO OPEN THE LIGHTING FIXTURE. THERE ARE NO USER-SERVICEABLE PARTS INSIDE. REFER
ALL SERVICING TO QUALIFIED PERSONNEL.
1. Read this manual carefully.
2. Keep this manual safe for future reference.
3. Follow all warnings and recommendations.
4. Do not operate or store near water.
5. Do not expose the fixture to dripping or splashing liquid, and ensure that no objects
containing liquid are placed on this fixture.
6. Clean only with a dry cloth.
7. Do not install or operate near any heat sources such as radiators, gas heaters, stoves, or
other heating apparatus.
8. Only use attachments and accessories specified by the manufacturer.
9. Do not block any ventilation openings, including sound ports.
10. Install in accordance with the manufacturer’s instructions.
11. Do not obstruct or remove the ground plug from the light, doing so may cause electric shock
resulting in serious injury or death.
12. Protect the power cord from being walked on, pinched, or rolled over.
13. Unplug the fixture during electrical storms and power outages.
14. Refer all servicing to a qualified service technician. Servicing is required when the fixture no
longer operates, fails to power on, or emits an electrical smell or sound.
15. To completely disconnect AC power from this fixture, the power supply cord must be
unplugged.

Precautions
If an AVE lighting fixture is used outdoors on a sunny day, ensure that it is in a shaded area and is
well ventilated to help prevent overheating.
Do not use AVE lighting fixtures in environments that are below 0°C OR exceed +40°C.
Suspension
Suspending any object is potentially dangerous and should only be attempted by qualified
individuals with thorough knowledge of the techniques and regulations for suspending objects. It is
the responsibility of the installer to ensure all fixtures and effects are installed correctly. AVE
strongly recommends inspecting installed systems every 6 months for signs of weakness or damage.
If any damage or weakness is detected then remedial action should be taken immediately. The user
is responsible for making sure the wall, ceiling, or structure is capable of supporting all objects
suspended overhead. Any hardware used to suspend a fixture not associated with AVE is the
responsibility of others.
Mounting
The Cobra Head 150 includes a hanging bracket that can be fitted using a hex tool (not included)
allowing you to hang the fixture upside down. It is strongly advised to install the safety loop and fit
an appropriate safety cable* when hanging the fixture.
*This is a secondary fall arrest; in the event the yoke or clamp fail, the fixture is safe from causing
serious injury or damage

Description
Give your mobile lighting system some punch with the compact AVE Cobra Head 150 LED moving
head. Fitted with a single 35W white LED light source, and a 12° beam angle to cut across your stage
or dance floor. The gobo wheel includes 7 fixed gobos + open for creating different patterns and
aerial effect. And an indexed colour wheel with of the 7 colours + open. The moving yoke has a wide
pan and tilt range with fast and smooth movement for creating subtle dynamics or energetic chase
effects.
The Cobra Head 150 can be mounted on a flat surface or upside down using the included hanging
bracket and safety loop. The digital display can also be inverted when hung making it easier to
navigate the menu.
Out of the box, the Cobra Head 150 has ‘Auto’ and ‘sound active’ modes for plug-and-play
operation. As well as master slave function which lets you create coordinated lighting shows
without the need for DMX. For use with other lighting fixtures the Cobra Head 150 can be connected
to a DMX controller and manually controlled/programmed with 9CH and 11CH control options.
Features
Compact LED moving head spot
Single 35W white LED light source
Fixed gobo wheel with 7 gobos + open
Indexed colour wheel with 7 colours + open
Wide pan and tilt ranges with smooth movement
3-Pin XLR connections for DMX control
Built-in Auto programs; Auto / Sound
Master / Slave operation
Mounts on any flat surface or upside down on a lighting rig
Supplied with;
oCobra Head 150 fixture
oMounting bracket (including safety loop)
oManual
oPower Cable

Setup
To set up your AVE Cobra Head 150 follow the below steps;
1. Mount the item on your lighting stand or on the floor
2. Connect the AC power cord from a grounded mains 240v power source
3. Power the fixture/s on from the mains socket
4. Select the desired operation mode and press ‘enter’
5. Wait approx. 10sec for the setting to take effect
Operation
To access the menus and functions of the Cobra Head 150, use the four (4) buttons located under
the main LCD control screen.
Button Label
Function
Menu
Press to access main menu, or change function once the fixture is on
Up
Cycles upwards through the menu and options
Down
Cycles downwards through the menu and options
Enter
Press to select a menu option or save a setting

Menu Map
Main Level
Program Level
Description
Addr
1 –512
DMX Address Value
Chnd
9Ch
9 Channel DMX Mode
11Ch
11 Channel DMX Mode
SLNd
NASt
Master
SLA 1
Slave 1
SLA 2
Slave 2
ShNd
Sh 1
Show 1
Sh 2
Show 2
Sh 3
Show 3
Sh 4
Show 4
Soun
On/Off
Sound Active (for Show 1 –4)
SenS
0 –100
Sound Sesitivity
bLnD
No / Yes
Blackout Mode
iPAn
Yes / No
Invert Pan
itLt
Yes / No
Invert Tilt
LED
On / Off
Digital Display On / Off
dISP
Yes / No
Invert Display
tESt
-
Auto Test All Functions
tENP
-
Displays Temperature of Fixture
rSEt
-
Resets Fixture
DMX Channels
9 CH Control
1 CH
0 - 255
Pan Movement
2 CH
0 - 255
Tilt Movement
3 CH
0 - 255
Pan / Tilt Speed
4 CH
0 - 255
Dimmer
5 CH
0 –7
8 –99
100 –149
150 –199
200 –245
246 - 255
No function
Strobe (slow > fast)
Strobe (fast > slow)
Strobe Effect 1
Strobe Effect 2
Strobe (max speed)
6 CH
0 - 255
Colour
7 CH
0 - 255
Gobo
8 CH
0 –7
8 –199
200 –255
No Function
Colour Auto Speed
Sound Control
9 CH
0 –255
Speed
11 CH Control
1 CH
0 - 255
Pan Movement
2 CH
0 - 255
Fine Pan
3 CH
0 - 255
Tilt Movement
4 CH
0 - 255
Fine Tilt
5 CH
0 –255
Pan / Tilt Speed
6 CH
0 - 255
Dimmer
7 CH
0 –7
8 –99
100 –149
150 –199
200 –245
246 - 255
No function
Strobe (slow > fast)
Strobe (fast > slow)
Strobe Effect 1
Strobe Effect 2
Strobe (max speed)
8 CH
0 - 255
Colour
9 CH
0 –255
Gobo
10 CH
0 –7
8 –199
200 –255
No Function
Colour Auto Speed
Sound Control
11 CH
0 - 255
Speed

Specifications
Light Source:
1x 35W White LED (50,000hr life expectancy)
Beam Angle:
12°
Gobo Wheel:
7 + open (fixed)
Colour Wheel:
7 + white split colours, scroll at variable speeds
Illuminace:
(12°): 2,400 lux @ 5m
Pan Range:
540°
Tilt Range:
270°
Strobe Rate:
0 –16Hz
DMX Channels:
9CH / 11CH
DMX Connectors:
3-Pin XLR
Power Consumption:
60W
Power Supply:
240V AC / 50Hz
Power Connectors:
IEC Mains
Dimensions:
194 x 151 x 285 mm
Weight:
3.0 kg
