AVE COBRA WASH 200 MK2 User manual

COBRA WASH 200 MK2
User Manual

Table of Contents
Safety .......................................................................................2
Important Safety Instructions...........................................................3
Precautions......................................................................................4
Suspension......................................................................................4
Mounting..........................................................................................4
Description................................................................................5
Features ............................................................................5
Setup........................................................................................6
Power Linking .....................................................................6
Operation...........................................................................6
Menu Map..........................................................................7
DMX Channel......................................................................8
Specifications............................................................................8

Safety
Important Safety Information
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT OVEREXPOSE THIS FIXTURE
TO RAIN OR MOISTURE.
WARNING: CONNECT ONLY TO MAINS POWER SUPPLY WITH A PROTECTIVE EARTHING
CONNECTION.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE THE REAR COVER OR
ATTEMPT TO OPEN THE LIGHTING FIXTURE. THERE ARE NO USER-SERVICEABLE PARTS INSIDE. REFER
ALL SERVICING TO QUALIFIED PERSONNEL.
1. Read this manual carefully.
2. Keep this manual safe for future reference.
3. Follow all warnings and recommendations.
4. Do not operate or store near water.
5. Do not expose the fixture to dripping or splashing liquid, and ensure that no objects
containing liquid are placed on this fixture.
6. Clean only with a dry cloth.
7. Do not install or operate near any heat sources such as radiators, gas heaters, stoves, or
other heating apparatus.
8. Only use attachments and accessories specified by the manufacturer.
9. Do not block any ventilation openings, including sound ports.
10. Install in accordance with the manufacturer’s instructions.
11. Do not obstruct or remove the ground plug from the light, doing so may cause electric shock
resulting in serious injury or death.
12. Protect the power cord from being walked on, pinched, or rolled over.
13. Unplug the fixture during electrical storms and power outages.
14. Refer all servicing to a qualified service technician. Servicing is required when the fixture no
longer operates, fails to power on, or emits an electrical smell or sound.
15. To completely disconnect AC power from this fixture, the power supply cord must be
unplugged.

Precautions
If an AVE lighting fixture is used outdoors on a sunny day, ensure that it is in a shaded area and is
well ventilated to help prevent overheating.
Do not use AVE lighting fixtures in environments that are below 0°C OR exceed +40°C.
Suspension
Suspending any object is potentially dangerous and should only be attempted by qualified
individuals with thorough knowledge of the techniques and regulations for suspending objects. It is
the responsibility of the installer to ensure all fixtures and effects are installed correctly. AVE
strongly recommends inspecting installed systems every 6 months for signs of weakness or damage.
If any damage or weakness is detected then remedial action should be taken immediately. The user
is responsible for making sure the wall, ceiling, or structure is capable of supporting all objects
suspended overhead. Any hardware used to suspend a fixture not associated with AVE is the
responsibility of others.
Mounting
The Cobra Wash 200mk2 includes a hanging bracket that can be fitted using a hex tool (not included)
allowing you to hang the fixture upside down. It is strongly advised to install the safety loop and fit
an appropriate safety cable* when hanging the fixture.
*This is a secondary fall arrest; in the event the yoke or clamp fail, the fixture is safe from causing
serious injury or damage

Description
The AVE Cobra Wash 200mk2 is a compact and high-output LED moving head wash fixture that
provides a vivid colour wash for your dance floor or stage area. Fitted with 7x 10watt LED diodes,
each with Hex Colour (RGBAW+UV) Technology allowing you to mix any colour you imagine. The
moving yoke has a wide pan and tilt range with smooth movement creating an amazing effect.
The Cobra Wash 200mk2 can be mounted on a flat surface or upside down using the included
hanging bracket and safety loop. The digital display can also be inverted when hung making it easier
to navigate the menu.
Out of the box, the Cobra Wash 200mk2 has ‘Auto’ and ‘sound active’ modes for plug-and-play
operation with an amazing visual effect. The master slave mode also lets you create coordinated
lighting shows without the need for DMX. For use with other lighting fixtures the Cobra Wash
200mk2 can be connected to a DMX controller and manually controlled/programmed via the 3-pin
DMX connectors.
Features
High-output 7x 10W LEDs
Hex Colour diodes (RGBAW+UV) for full colour spectrum mixing
Wide pan and tilt ranges with smooth movement
3-Pin XLR connections for DMX control
Built-in Auto programs; Auto / Sound
Master / Slave operation
Static colour settings
Mounts on any flat surface or upside down on a lighting rig

Setup
To set up your AVE Cobra Wash 200mk2 follow the below steps;
1. Mount the item on your lighting stand or on the floor
2. Connect the AC power cord from a grounded mains 240v power source
3. Power the fixture/s on from the mains socket
4. Select the desired operation mode and press ‘enter’
5. Wait approx. 10sec for the setting to take effect
Operation
To access the menus and functions of the Cobra Wash 200mk2, use the four (4) buttons located
under the main LCD control screen.
Button Label
Function
Menu
Press to access main menu, or change function once the fixture is on
Up
Cycles upwards through the menu and options
Down
Cycles downwards through the menu and options
Enter
Press to select a menu option or save a setting

Menu Map
Main Level
Program Level
Description
Addr
1 –512
DMX Address Value
Chnd
9Ch
9 Channel DMX Mode
15Ch
15 Channel DMX Mode
ShNd
Sh 1
Show 1
Sh 2
Show 2
Sh 3
Show 3
Sh 4
Show 4
SLNd
NASt
Master
SLA 1
Slave 1
SLA 2
Slave 2
Soun
On/Off
Sound Active (for Show 1 –4)
SEnS
0 –100
Sound Sensitivity
bLnD
On / Off
Boot Pause Mode
iPAn
Yes / No
Invert Pan
itLt
Yes / No
Invert Tilt
LED
On / Off
Digital Display On / Off
dISP
Yes / No
Invert Display
bALA
red
Manual Red Colour 0 - 255
Gree
Manual Green Colour 0 - 255
bLue
Manual Blue Colour 0 - 255
tESt
-
Auto Test All Functions
tENP
-
Displays Temperature of Fixture
rSEt
-
Resets Fixture
DMX Channels
9 CH Control
1 CH
0 - 255
Pan Movement
2 CH
0 - 255
Tilt Movement
3 CH
0 - 199
Dimmer
200 - 250
Strobe (slow > fast)
251 - 255
Full Brightness
4 CH
0 –255
Red
5 CH
0 - 255
Green
6 CH
0 - 255
Blue
7 CH
8 - 255
White
8 CH
0 - 255
Amber
9 CH
0 –255
UV
15 CH Control
1 CH
0 - 255
Pan Movement
2 CH
0 - 255
Fine Pan
3 CH
0 - 255
Tilt Movement
4 CH
0 - 255
Fine Tilt
5 CH
0 –255
Pan / Tilt Speed
6 CH
0 - 255
Dimmer
7 CH
200 - 250
Red
8 CH
251 - 255
Green
9 CH
0 –255
Blue
10 CH
0 - 255
White
11 CH
0 - 255
Amber
12 CH
8 - 255
UV
13 CH
0 - 7
No function
8 - 255
Colour Macro (32 presets)
14 CH
0 –7
No function
8 –131
Strobe (slow > fast)
132 –139
Open
140 - 181
Strobe Effect 1
182 –189
Open
190 –231
Strobe Effect 2
232 –239
Open
240 –247
Random Flash
248 - 255
Open
15 CH
0 –127
Sound Active Off
128 - 255
Sound Active On

Specifications
Light Source:
7 x 10W Hex-Colour LED Diodes
Diode Colour:
Red, Green, Blue, Amber, White, Ultra Violet
Pan Range:
540°
Tilt Range:
270°
Strobe Rate:
0 –10Hz
DMX Channels:
9CH / 15CH
DMX Connectors:
3-Pin XLR
Power Consumption:
90W
Power Supply:
240V AC / 50Hz
Power Connectors:
IEC Mains
Dimensions:
240 x 165 x 175 mm
Weight:
2.7 kg
