AVer SF2012H series Instruction manual

SF2012H IP Camera Series
SF2012H/SF2012H-B/SF2012H-C
SF2012H-D/SF2012H-DV
Quick User Guide

Table of Contents
I. Camera Introduction ...................................................................................................1
1. Box Type IP Camera(SF2012H)....................................................................1
1.1 Package Contents.......................................................................................1
1.2 Hardware Installation ..................................................................................2
1.3 Factory Default............................................................................................2
2. Bullet Type IP Camera (SF2012H-B).............................................................3
2.1 Package Contents.......................................................................................3
2.2 Hardware Installation ..................................................................................5
2.3 Factory Default............................................................................................7
3. Cube IP Cameras (SF2012H-C)....................................................................8
3.1 Package Contents.......................................................................................8
3.2 Hardware Installation ..................................................................................9
3.3 Factory Default............................................................................................9
4. Dome Type IP Camera.................................................................................10
4.1 Package Contents.....................................................................................10
4.1.1 SF2012H-D............................................................................................10
4.1.2 SF2012H-DV..........................................................................................11
4.2 Hardware Installation ................................................................................12
4.2.1 SF2012H-D............................................................................................12
4.2.2 SF2012H-DV..........................................................................................14
4.3 Factory Default..........................................................................................17
4.3.1 SF2012H-D............................................................................................17
4.3.2 SF2012H-DV..........................................................................................18
4.4 SD card Compatibility List.........................................................................19
II. Monitor Setting..........................................................................................................20
III. IP Assignment...........................................................................................................21

Using DHCP Server/Router Network........................................................................22
Using NON-DHCP Server/Router Network...............................................................23
IV. Connecting the IP Camera........................................................................................26
FCC NOTICE (Class B).....................................................................................................27
COPYRIGHT......................................................................................................................27
NOTICE..............................................................................................................................27
WARNING..........................................................................................................................27
Limited Warranty..............................................................................................................28
Governing Law and Your Rights .....................................................................................29

1
Before Installation
Before installation, please be sure to read this quick installation guide and user’s manual carefully to
complete the installation.
I. Camera Introduction
The following section introduces package contents, hardware installation, factory default reset, and SD
card Compatibility List of each type camera.
1. Box Type IP Camera (SF2012H)
1.1 Package Contents
Item Descriptions
1. SF2012H
2. Accessory pack
3. Ethernet cable
4. Power Adaptor(DC 12V/1A)
(Optiona)
5. CD (User’s Manual and Quick Guide
included)
**If any of the above items are missing, please contact your dealer immediately.

2
1.2 Hardware Installation
Connect the power adapter and connect the IP camera to local network with the Ethernet cable.
1.3 Factory Default
1. Please follow the below instructions if the user name, password, and IP address are lost.
2. First, unplug the power adapter. Then, press the button in the back of IP camera as shown in
figure.
3. Plug in the power adapter and do not release the button during the IP camera booting.
4. It will take around 30 seconds to boot the IP camera.
5. Release the button after the IP camera finishes booting.
6. Reconnect the IP camera with the default IP address (192.168.1.200), user name (admin), and
password (admin).
Reset button

3
2. Bullet Type IP Camera (SF2012H-B)
2.1 Package Contents
Item Descriptions
1. SF2012H-B
2. Stand
3. Accessory pack
4.. RJ45 socket
5. Ethernet cable
6. Power Adaptor(DC 12V/1A)
(Optiona)

4
Item Descriptions
7. CD (User’s Manual and Quick Guide
included)
**If any of the above items are missing, please contact your dealer immediately.

5
2.2 Hardware Installation
1. Connect a power adapter and IP camera to PC or local network.
2. I/O Control Instruction
I/O terminal connector – used in application, for e.g., motion detection, event triggering, alarm
notifications. It provides the interface to:
Digital Input (GND+Alarm) : An alarm input for connecting devices that can toggle between
an open and closed circuit, for
1. GND (Ground) : Initial state is LOW
2. Alarm : Max. 50mA, DC 3.3V
Example: PIRs, door/window contacts, glass break detectors, etc. When a signal is
received the state changes and the input becomes active.
Relay output (COM +N.O.) / (COM+N.C.) :An output to Relay switch, for example: LEDs,
Sirens, etc
1. N.C. (Normally Close): Max. 1A, DC24V or 0.5A, 1AC25V
2. COM: (Common)
3. N.O. (Normally Open): Max. 1A, DC24V or 0.5A, AC 125V
3.5mm Phone Jack (Audio Input, Red)
3.5mm Phone Jack (Audio Output, Green)
ALARM IN
RELAY OUT
Pink default setting wire

6
[Example]
RELAY INSTALLATION EXAMPLE 1
Trigger a “Normal OFF” (Normal Open) alarm siren on when event/motion occur:
RELAY INSTALLATION EXAMPLE 2
Trigger the “Normal ON” (Normal Close) indoor illumination off when event / motion occur:

7
2.3 Factory Default
1. Removing an Ethernet cable.
2. Plugging “a pink default cable” into “GND”.
3. Plug power cable.
4. When camera starts again, please remove the pink default cable and plug Ethernet cable for new
setting.
5. Release the button when camera finishes proceed.
6. Re-login the camera using the default IP (http://192.168.1.200), and user name (admin),
password (admin).

8
3. Cube IP Cameras (SF2012H-C)
3.1 Package Contents
Item Descriptions
1. SF2012H-C
2. Stand box
3. Ethernet cable
4. Power Adaptor(DC 12V/1A)
(Optional)
5. CD (User’s Manual and Quick Guide
included)
**If any of the above items are missing, please contact your dealer immediately.

9
3.2 Hardware Installation
1. Connect power adapter.
2. Connect IP camera to PC or network with Ethernet cable.
3. Set up the network configurations according to the network environment.
3.3 Factory Default
1. To recover the default IP address and password, please follow the following steps.
2. Remove power, and press and hold the button in the back of the IP camera.
3. Power on the camera. Don’t release the button during the system booting.
4. It will take around 30 seconds to boot the IP camera.
5. Release the button when camera finishes proceed.
6. Re-login the camera using the default IP (192.168.1.200), and user name (admin), password
(admin).
Connect Power adapter
Connect Ethernet cable
LED indicator
Reset button

10
4. ome Type IP Camera
4.1 Package Contents
4.1.1 SF2012H-D
Item Descriptions
1. SF2012H-D
2. Accessory pack
3. Ethernet cable
4.. RJ45 socket
5. Power Adaptor(DC 12V/1A)
(Optional)
6. CD (User’s Manual and Quick Guide
included)
**If any of the above items are missing, please contact your dealer immediately.

11
4.1.2 SF2012H-DV
Item Descriptions
1. SF2012H-DV
2. Accessory pack
3. Ethernet cable
4. RJ45 socket
5. Power Adaptor(DC 12V/1A)
(Optional)
6. CD (User’s Manual and Quick Guide
included)
**If any of the above items are missing, please contact your dealer immediately

12
4.2 Hardware Installation
4.2.1 SF2012H-D
1. Connect a power adapter and IP camera to PC or local network.
3. I/O Control Instruction
I/O terminal connector – used in application, for e.g., motion detection, event triggering, alarm
notifications. It provides the interface to:
Digital Input (GND+Alarm) : An alarm input for connecting devices that can toggle between an
open and closed circuit, for
1. GND (Ground) : Initial state is LOW
2. Alarm : Max. 50mA, DC 3.3V
Example: PIRs, door/window contacts, glass break detectors, etc. When a signal is
received the state changes and the input becomes active.
Relay output (COM +N.O.) / (COM+N.C.) :An output to Relay switch, for example: LEDs,
Sirens, etc
1. N.C. (Normally Close): Max. 1A, DC24V or 0.5A, AC125V
2. COM: (Common)
3. N.O. (Normally Open): Max. 1A, DC24V or 0.5A, AC125V
3.5mm Phone Jack (Audio Input, Red)
3.5mm Phone Jack (Audio Output, Green)
ALARM IN
RELAY OUT

13
[Example]
RELAY INSTALLATION EXAMPLE 1
Trigger a “Normal OFF” (Normal Open) alarm siren on when event/motion occur:
RELAY INSTALLATION EXAMPLE 2
Trigger the “Normal ON” (Normal Close) indoor illumination off when event / motion occur:

14
4.2.2 SF2012H DV
1. Connect a power adapter and IP camera to PC or local network.
2. 3-Axis Gimbals Adjustments
Once the users open the case, the gimbals adjustment offers the convenience method to install on
the wall. The pan, tilt, and rotation are provided in this model. The users can adjust the
gimbals with Pan 175 degrees, tilt 75 degrees, and rotation 180 degrees respectively.
3. I/O Interface
DI/DO
Audio Output
MIC IN
Video Out (BNC)

15
4. I/O Control Instruction
I/O terminal connector – used in application, for e.g., motion detection, event triggering, alarm
notifications. It provides the interface to:
Digital Input (GND+Alarm) : An alarm input for connecting devices that can toggle between an
open and closed circuit, for
1. GND (Ground) : Initial state is LOW
2. Alarm : Max. 50mA, DC 3.3V
Example: PIRs, door/window contacts, glass break detectors, etc. When a signal is
received the state changes and the input becomes active.
Relay output (COM +N.O.) / (COM+N.C.) :An output to Relay switch, for example: LEDs,
Sirens, etc
1. N.C. (Normally Close): Max. 1A, DC24V or 0.5A, AC125V
2. COM: (Common)
3. N.O. (Normally Open): Max. 1A, DC24V or 0.5A, AC125V
[Example]
RELAY INSTALLATION EXAMPLE 1
Trigger a “Normal OFF” (Normal Open) alarm siren on when event/motion occur:
ALARM IN
RELAY OUT

16
RELAY INSTALLATION EXAMPLE 2
Trigger the “Normal ON” (Normal Close) indoor illumination off when event / motion occur:
