AVer ED5000 User manual

ED5000
User Manual

FCC NOTICE (Class A)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Federal Communications Commission Statement
NOTE- This equipment has been tested and found to comply with the limits for a Class Adigital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by tuning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/television technician for help.
Class A ITE
Class A ITE is a category of all other ITE which satisfies the class A ITE limits but not the class B ITE
limits. Such equipment should not be restricted in its sale but the following warning shall be included in
the instructions for use:
Warning -This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
European Community Compliance Statement (Class A)
This product is herewith confirmed to comply with the requirements set out in the Council
Directives on the Approximation of the laws of the Member States relating to
Electromagnetic Compatibility Directive 2004/108/EC.
Warning - This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures to correct this
interference.
COPYRIGHT
©2014 AVer Information Inc. All rights reserved.
All rights of this object belong to AVer Information Inc. Reproduced or transmitted in any
form or by any means without the prior written permission of AVer Information Inc. is
prohibited. All information or specifications are subject to change without prior notice.
Trademark
“AVer” is a trademark owned by AVer Information Inc. Other trademarks used herein for
description purpose only belong to each of their companies.
NOTICE
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE. THE
INFORMATION CONTAINED HEREIN IS TO BE CONSIDERED FOR REFERENCE ONLY.

Table of Contents
PACKAGE CONTENTS.......................................................................................................1
CAMERA PARTS.................................................................................................................1
IP CAMERA INSTALLATION...............................................................................................2
MOUNT THE IPCAMERA ......................................................................................................2
EXTERNAL SPEAKER LINE INSTALLATION ...............................................................................3
USING THE IP CAMERA BROWSER INTERFACE............................................................4
LIVE VIEW..........................................................................................................................4
SYSTEM >GENERAL...........................................................................................................7
SYSTEM >GENERAL >MAINTENANCE...................................................................................7
TO UPGRADE THE IP CAMERA FIRMWARE.........................................................................8
SYSTEM >GENERAL >DATE &TIME.....................................................................................9
SYSTEM >GENERAL >SYSTEM LOG ..................................................................................10
SYSTEM >USER MANAGEMENT .........................................................................................11
SYSTEM >USER MANAGEMENT >ACCOUNT........................................................................11
To Create a User Account ........................................................................................11
To Delete or Edit a User Account..............................................................................12
SYSTEM >USER MANAGEMENT >CONNECTION...................................................................13
SYSTEM >NETWORK ........................................................................................................14

SYSTEM >NETWORK >SETTING........................................................................................14
SYSTEM >NETWORK >SERVER.........................................................................................16
SYSTEM >NETWORK >STEAMING......................................................................................17
SYSTEM >NETWORK >QOS.............................................................................................18
SYSTEM >NETWORK >OTHERS ........................................................................................19
SYSTEM >SECURITY ........................................................................................................21
SYSTEM >SECURITY >IPFILTER.......................................................................................21
TO ADD FILTER............................................................................................................21
SYSTEM >SECURITY >802.1X .........................................................................................23
SYSTEM >SECURITY >RTSPAUTH...................................................................................24
SYSTEM >IMAGE..............................................................................................................25
SYSTEM >IMAGE >OSD ..................................................................................................25
SYSTEM >IMAGE >PREFERENCE.......................................................................................26
SYSTEM >IMAGE >EXPOSURE ..........................................................................................27
SYSTEM >IMAGE >ADVANCED...........................................................................................29
SYSTEM >IMAGE >PRIVACY MASK ....................................................................................30
SYSTEM >VIDEO STREAM.................................................................................................31
SMART STREAM ...............................................................................................................33
SYSTEM >AUDIO..............................................................................................................34

SYSTEM >SD/MICROSD CARD >MANAGEMENT .................................................................35
SYSTEM >SD/MICROSD CARD >FILE SEARCH...................................................................36
APPLICATION >MOTION DETECTION...................................................................................37
TO SET THE MOTION DETECTION...................................................................................37
APPLICATION >IVA...........................................................................................................38
APPLICATION >IVA>CROSS DETECTION.......................................................................38
APPLICATION >IVA>TAMPERING..................................................................................40
APPLICATION >IVA>MISSING OBJECT..........................................................................41
APPLICATION >IVA>SUSPICIOUS OBJECT.....................................................................42
APPLICATION >TRACKING .................................................................................................43
EVENT SETTING ...............................................................................................................44
TO SETUP THE EVENT ..................................................................................................44
STATUS INFORMATION .......................................................................................................47

1
Package Contents
The following items are included in the package.
Microphone
TOP
(for wall mount)
ED5000
Software & Manual CD
Alignment Sticker
4 Screws
4 Plastic Anchors
Power Adapter
Power plug**
RJ-45 header
External speaker line
**The power plug will vary
depending on the standard power
outlet of the country where it is
sold.
Camera Parts
(2)
(3) (4)
(1)
(1) MIC
(2) Lens
(3) RJ45 Ethernet Port
(4) Power DC

2
IP Camera Installation
Mount the IP Camera
User can install the camera on the ceiling or on the wall. The following steps are describing how to
install the camera on the ceiling and wall.
1. Place the alignment sticker on the wall surface.
Then spot the mark and drill the 4 holes
indicated on the sticker.
[Note] If the camera is installed on ceiling, no need
to follow the arrow position on alignment sticker.
Microphone
TOP
(for wall mount)
2. Insert the 4 plastic anchors in the ceiling or
wall. Next, hook the Camera and use the
screws to secure the camera.
3. Connect the power and Ethernet to the
camera.
4. Next, adjust the focus manually.
Ethernet
Power
Adjust focus
5. After adjusting the focus, secure the cover
case of camera.

3
External Speaker Line Installation
1. Un-screw the screws as figure shown.
2. Open the black cover.
3. Connect the external speaker line to the
camera.
4. Close the black cover and screw it tight.
5. Finally, close camera case cover and security
it.

4
Using the IP Camera Browser Interface
The admin have the full access to the IP camera browser interface. The menu on the left, you can
expand and navigate to access all the features.
Open the IE browser and enter the IP address of IP camera to access the IP camera Web
configuration interface. In login dialog, enter the ID and Password (default is admin/admin).
Live View
In the Live View page, all three user levels can view and change the language setting, the IP camera
video stream setting, capture screen shot, record video, turn on/off 2-way talk, mic and volume, and
adjust the zoom and volume level.
(7)
(8)
(9)
(5)(6) (4) (3) (2)
(1)
(11)(10) (12) (13)
(14) (16)(15)
Name
Function
(1) Protocol Type
Select the protocol for the live view video stream.
(2) Language
Select the browser interface language.

5
Name
Function
(3) Display mode
The display modes are depended on the Stream mode that user
has selected; they will have different type of display modes
Stream mode
Display mode
Normal ceiling
Overview/Panoramic/Dual
Panoramic/Quad/Dual Panoramic
Quad ceiling
Area1/Area2/Area3/Area4/Overview
Wall mode
Panoramic
[Note] Stream mode setup is in System > Video Stream.
(4) Video screen
Change the video screen display.
Display the actual video pixel size.
Display the video screen in compact size.
Display the video on the entire screen. Press ESC to exit full
screen mode.
(5) Stream
Switch to view the different video stream. The number of video
streams are depended on Stream mode that user has selected.
Stream mode
Stream
Normal ceiling
1/2/5
Quad ceiling
1/2/3/4/5
Wall mode
1/2
(6) Direction buttons
Use to move the position of the view point while in zoom mode.
[Note] When object tracking is enabled, the PTZ function of upper
left channel is disabled.
(7) System/Application/
Event/Status Information
Set up IP camera’s configuration.
(8) Speed control
Set the speed when panning, tilting, or zooming.
(9) Logout
Exit the application
(10) Zoom control
Reset zoom level.
Increase zoom level.
Decrease zoom level.
(11) Capture
Capture and save the image on the screen in *.bmp format.

6
Name
Function
(12) Record
Start/stop audio and video recording. The recorded video will
be saved in *.mp4 format.
(13) 2-way talk
Enable/disable mic from IP camera browser side.
(14) Mic
Enable/disable mic from the IP camera side.
(15) Sound
Enable/disable audio from the IP camera side.
(16) Volume bar
Adjust the volume.

7
System > General
In this section, only admin level is authorized to configure the IP camera general settings. There are 3
tabs in General settings: Maintenance, Date & Time, and System Log.
System > General > Maintenance
In the Maintenance tab, the admin can easily backup and restore the IP camera setting, reboot the IP
camera, reset all the settings to factory default, and upgrade the IP camera firmware.
(1)
(2)
(3)
(4)
(5)
(6)
(7)
Name
Function
(1) Reboot
Restart the IP camera.
(2) Information
Displays the explanation of Reboot, Reset, and Factory default.
(3) Reset
Set all the configuration settings back to default except the user
management and network settings.
(4) Factory Default
Set all the configuration settings back to factory default.
(5) Export
Backup all the configuration settings.

8
Name
Function
(6) Import Settings
Restore or replace the current settings with the backup file.
(7) Firmware Upgrade
Upgrade the firmware to the latest version.
To Upgrade the IP Camera Firmware
1. Download the file from our
website and save it in your
computer hard disk.
2. Click Browse. Locate and
select the file and click Open.
3. Click Apply. Wait till you see the
massage “Firmware Upgrade
OK!!”. You may now click the IE browser refresh button or press F5.
The login page will appear.

9
System > General > Date & Time
In the Date & Time tab, admin can manually set the date and time setting or synchronize it with the
Internet time server or the computer date and time setting. This is used to record the time whenever
there is a significant occurrence listed in system log and is also used in event scheduling. After
completing the setting, click Save to apply the new setting and Cancel to keep the old setting.
(1)
(2)
(3)
(4)
Name
Function
(1) Current Date & Time
Display the current date and time setting.
(2) Date Format
Select the date display format.
(3) Time Zone
Set the local time zone.

10
Name
Function
(4) Setting Method
Select the date & time setting method.
Sync with current PC: obtain the date and time setting on the
current login computer.
Sync with NTP Server: obtain the date and time setting from NTP
server. In the drop-down list, select the NTP host name.
Manual: manually set the date and time. Click Now to set the date
base on the computer time setting and Done to close the date and
time interface.
System > General > System Log
In the System Log, admin can view and search the significant event occurred in the IP camera.

11
System > User Management
In User Management, only admin level is authorized to create, delete, and edit account to connect to
the IP camera and configure the client connection setting. There are 2 tabs in User Management
setting: Account and Connection.
System > User Management > Account
In Account page, admin can create, delete and set the access level of the user account.
To Create a User Account
1. Click System > User Management > Account tab.
2. Enter the User Name,User Info, and select the User Type. Then, click Create.
User Type
Access rights
Admin
Allow to access all the configuration pages.
Operator
Allow to preview live image, modify and adjust certain settings; except in
System > General, User Management, Network, and SD/microSD Card >
Management. As for the I/O Control, admin could enable/disable to allow
operator to access it.

12
User Type
Access rights
Viewer
Only allow to access the preview and status information pages.
3. Enter the same password in Password and Confirm Password column. Then click Add.
To Delete or Edit a User Account
Select the user account that you want to delete or edit.
Click Cancel to cancel the operation.
Click Modify to apply the new changes. Make sure to edit the account before clicking the
Modify button.
Click Remove to delete the account.

13
System > User Management > Connection
In Connection page, admin can set the total number of user for accessing the IP camera, and filtering
the IP address to allow or deny accessing the IP camera.
Http Connection: Select the connection type. For higher security data transmission level, select
http & https or http only. The authenticated and encrypted the data is over the SSL (Secure
Socket Layer).
Maximum Number of Clients: Select the max number of users to simultaneously access the IP
camera.

14
System > Network
In this section, only admin level is authorized to configure the Network settings.
System > Network > Setting
In Setting page, you can configure the type of network connection for IP camera and assign name for
the IP camera. Depending on the network connection, IP camera can be accessed from the computer
within the same local area network (LAN) or anywhere with Internet connection. After completing the
setting, click Save to apply the new setting and Cancel to keep the old setting.
(1)
(2)
(3)
Name
Function
(1) Device Name
Assign name for the IP camera.

15
Name
Function
(2) Network Type
Select the type of IP camera network connection.
DHCP:select this option to automatically obtain an IP address from the
DHCP server, whenever the IP camera is connected to the network.
You can use the IP camera UPnP Discovery software in the CD to
easily setup the IP camera network.
Static IP: select this option to manually assign a fix IP address to the
IP camera.
PPPoE: select this option to access the IP camera anywhere with
Internet connection. To use this option, this requires an account
provided by the ISP. Set this setting while connected to the LAN and
click Save. Connect the IP camera directly to DSL or cable modem.
(3) IPv6 Settings
Enable IPv6 support
Select “Manually set the IP address” to specify IP address manually.
