AVer MT300 User manual

MT300
Matrix Tracking Box
Quick Start Guide│快速使用指南
クイック・ガイド│Schnellanleitung
Guide Rapide│Guía rápida
Guida rapida│빠른 시작 가이드

English.............................................................................................1
繁體中文......................................................................................... 15
日本語 ............................................................................................15
Deutsch..........................................................................................22
Français.........................................................................................29
Español..........................................................................................36
Italiano ...........................................................................................43
한국어 ............................................................................................50

English-1
Package Contents
Tracking Box Unit
Power Adapter &
Power Cord
Cable Fixing Plate (x2)
Cable Ties
(x13)
3.0 x 5mm
Flat Head Screw
(x5)
3.0 x 5mm
Truss Head Screw
(x4)
M3 x 10mm Screws
(x4)
Rack Mount
Bracket (x2)
USB 3.0 Cable (x2)
Length: 1.5 m/4.92 ft
RS-422 Cable
Quick Start Guide
Warranty Card*
*Only for Japan
Optional Accessories
Server Rack Mount
3.0 x 5mm
Flat Head Screw (x3)
3.0 x 5mm
Truss Head Screw (x2)

English-2
Overview
1. Power Button
2. Reset Button
3. Status LEDs
4. HDMI Out Port*2
5. USB Out 3.0 Port (Type B)*2
(Only 1 USB output each time)
6. DC Power Jack
7. PoE+ Port IEEE 802.3AT
8. Ethernet Port
9. HDMI In Port*3
10. USB In 2.0 Port (Type A)*3
11. RS-422 Port
12. Kensington Lock
Dimensions
210.00mm
43.00mm
150.00mm

English-3
LED Indicator
STATUS (Power / System)
LED
Status
Orange (Solid)
Powered on but not Operating
Green (Solid)
Operating Successfully
Green (Flashing)
Firmware Updating
USB 1 / USB 2
LED
Status
Green (Solid)
Connected and Ready for UVC / UAC Streaming
Green (Flashing)
Streaming in UVC / UAC
LAN 1/ LAN 2
LED
Status
Green (Solid)
Ethernet Connected

English-4
Cable Fixing Plate Installation
1. Secure the cable fixing plates to the tracking box with 5 flat hat 30 x 5mm screws in the
package.
2. Plug in cables.
3. Use 13 cable ties in the package to secure
the cables and cable fixing plates.
P/N: 300AU8D0-EA9

English-5
Desk Mount Installation
1. Secure the mount brackets on the tracking box.
Screw: 4 truss head screws, 30 x 5mm
2. Install the mount brackets and the tracking box under the desk.
Screw: 4 screws, M3 x 10mm
Server Rack Mount Suggestions (Optional Accessories)
For details on optional accessories, consult your local dealer.

English-6
Connections
Front Panel
Rear Panel
Network

English-7
[Note]
Camera Connection: You can connect cameras to the tracking box using HDMI, USB, or via
Ethernet (LAN). The maximum numbers of simultaneous camera connections are as shown
below.
Connection Method
Maximum Number of cameras
HDMI In
3
USB In and Ethernet (LAN)
4

English-8
Web Setup
Access the Tracing Box via AVer IPCam Utility
1. Download the IPCam Utility from https://www.aver.com/download-center and run the IPCam
Utility.
2. Click Search, and all available devices will be listed on the screen.
3. Select the tracking box from the list, the device info will be displayed in the Settings field.
[Note]
The default network of the tracking box is Static IP (as shown below), and the default
ID/Password are admin/admin.
Network Port
Default IP Address
PoE+ Port (Recommend)
192.168.1.168
Ethernet Port
192.168.168.168
If you want to configure the network to DHCP, input the ID/Password in the Login field, select
the “device model” on the list, select “DHCP” and then click the Apply button.
The main web screen is displayed as below.

English-9
Or if you want to configure by yourself
1. Connect the tracking box to the network using the PoE+ port.
2. Set up your computer with static IP 192.168.1.x.
3. Type in 192.168.1.168 in your web browser to access the tracking box.
[Note]
The default network of the tracking box is Static IP, and the default ID/Password are
admin/admin.
If you want to use the Ethernet port of the tracking box, please refer to the information below
to set your computer IP.
Network Port
Default IP Address
Computer IP setting
PoE+ Port (Recommend)
192.168.1.168
192.168.1.x
Ethernet Port
192.168.168.168
192.168.168.x
The main web screen is displayed as below.

English-10
Appendix
CP10-MT Collaboration Controller
Quick Start Guide

English-11
Quick Guide
Package Contents
CP10-MT
Power Adapter & Power Cord*
Ethernet Cable Holder
* The power cord will vary depending on the standard power outlet of the country where it is sold.

English-12
Overview
DC 12V
PoE+
1. 10.1-inch Touch Screen
2. Microphone
3. Status LEDs
4. Speaker
5. Rubber Feet
6. Bracket for Ethernet Cable Holder*
7. Kensington Lock
8. Reset Button
9. Power Jack
10. PoE+ Port**
11. USB 2.0 Type A Port ***
12. PIR Sensor
* Please refer to Ethernet Cable Holder Installation for more details.
** Please use CAT 5e FTP cable (not included). Power over Ethernet plus (PoE+) is compatible
with IEEE 802.3at.
*** For diagnostics and Wi-Fi Dongle connection.

English-13
LED Indicator
LED
Status
Green (Solid)
Powered On

English-14
Power Connection
There are three ways to power the CP10-MT.
Using the supplied power adapter and power cord: Connect the CP10-MT to the wall outlet
using the supplied power adapter and power cord.
Wall outlet
PowerAdapter & Power Cord
DC 12V
PoE+
With a PoE+switch: Connect the CP10-MT to a PoE+ switch using a LAN cable. Please use
the PoE+ switch to ensure stable power supply.
PoE+ Switch
LAN Cable (not included)
DC 12V
PoE+
With a PoE+ injector*: Plug the power cord of the PoE+ injector into the wall. Connect the
PoE+ injector to the CP10-MT and to the network using LAN cables.
Wall outlet
LAN port
on the wall
LAN (not included)
LAN (not included)
DATAOUT
+POE port
DATAIN
port PoE+ injector with power cord
(optional)
DC 12VPoE+
* Please purchase PoE+ injector from AVer.

English-15
Ethernet Cable Holder Installation
The Ethernet Cable Holder can be used to protect the Ethernet cable from loosening from the PoE+
port. To install the Ethernet Cable Holder to the Bracket on the rear side of CP10-MT, press the
holder inward and then push down the holder into the Bracket.
Push
Press
inward
After installing the Ethernet Cable Holder to the Bracket on CP10-MT, you can start connecting the
Ethernet cable to the PoE+ port. To do this, 1) Press the holder then pull up the holder. 2) Plug the
Ethernet cable to the PoE+ port. 3) Press the holder and push down the holder.
Push
Press
inward
Plug in Ethernet cable
Press inward
Pull
(1) (2) (3)

English-16
FEDERAL COMMUNICATIONS COMMISSION
NOTE: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radiofrequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
WARNING:
This is a class A product. In a domestic environment this product may cause radio interference
in which case the user may be required to take adequate measures.
この装置は、クラス A 機器です。この装置を住宅環境で使用すると電波妨害を引き起こすことがあります。こ
の場合には使用者が適切な対策を講ずるよう要求されることがあります。
사용자안내문
이기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서 가정용 환경에서 사용하는 경우
전자파간섭의 우려가 있습니다.
※사용자 안내문은 "업무용 방송통신기자재"에만 적용됩니다.
기종별
사용자안내문
A급기기
(업무용 방송통신기자재)
이기기는 업무용(A 급) 전자파적합기기로서 판
매자 또는 사용자는 이점을 주의하시기 바라
며, 가정외의 지역에서 사용하는 것을 목적으로
합니다.
限用物質含有情況標示資訊參考下列網址：https://tw.aver.com/page/RoHS
Caution:
Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries According to the
Instructions.
COPYRIGHT
© 2022 AVer Information Inc. All rights reserved. | December 19, 2022
The information contained in this documentation is subject to change without notice.

English-17
