EZTouch Panel
Hardware User Manual
Revision 4
Manual Part Number EZ-TOUCH-M
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

WARNING!
Programmable control devices such as EZTouch Panels must not be used as stand-alone protec-
tion in any application. Unless proper safeguards are used, unwanted start-ups could result in
equipment damage or personal injury. The operator must be made aware of this hazard and appro-
priate precautions must be taken.
In addition, consideration must be given to the use of an emergency stop function that is indepen-
dent of the programmable controller.
The diagrams and examples in this user manual are included for illustrative purposes only. The
manufacturer cannot assume responsibility or liability for actual use based on the diagrams and
examples.
CAUTION
Do not press the EZTouch Panel touchscreen with any sharp objects. This practice may damage
the unit beyond repair.
Trademarks
This publication may contain references to products produced and/or offered by other companies.
The product and company names may be trademarked and are the sole property of their respective
owners. AVG disclaims any proprietary interest in the marks and names of others.
© Copyright 2000-2003, Autotech Technologies, L.P.
All Rights Reserved
No part of this manual shall be copied, reproduced, or transmitted in any way without the prior
written consent of Autotech Technologies, L.P. Autotech Technologies, L.P. retains the exclusive
rights to all information included in this document.
MANUFACTURED by AVG
4140 Utica Ridge Rd. • Bettendorf, IA 52722-1327
MARKETED by AUTOMATIONDIRECT.COM
3505 Hutchinson Road • Cumming, GA 30040
Phone: [phone] or 1-770-889-2858 • Fax: [phone] • www.Automationdirect.com
MAN-EZTCH-HDW, Rev 4, 07/03
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

i
WARNING/Caution ............................................................ inside front cover
Table of Contents ........................................................................................ i
Manual Revisions ....................................................................................... v
EU Information ........................................................................................... vi
1 GETTING STARTED .................................................................................1
Manual Organization .............................................................................. 1
Manual Sections Table ..................................................................... 1
Introduction ....................................................................................... 2
What you need to get started ................................................................. 3
Hardware .......................................................................................... 3
Software ............................................................................................ 3
Need Help? .............................................................................................3
Onscreen HELP ............................................................................... 3
Fly-Over HELP .................................................................................. 3
PLC HELP ........................................................................................ 3
Technical Support ............................................................................4
2 MODELS, FEATURES AND ACCESSORIES ............................................ 5
6-inch EZTouch Panel Models ............................................................... 5
8-inch, 10-inch, and 15-inch EZTouch Panel Models ........................... 6
Features ................................................................................................ 7
PLCs Supported by EZTouch Panels ....................................................8
Replacement and Optional Equipment ................................................. 9
PLC Cable Part Numbers ................................................................... 10
Programming Cable Part Number ..................................................... 10
3 SPECIFICATIONS .................................................................................. 11
All 6-inch Models .................................................................................. 11
8-inch and 10-inch Standard Bezel Models ....................................... 12
8-inch, 10-inch, and 15-inch Slim Bezel Models ................................ 13
4 INSTALLATION ................................................................................... 15
Mounting ............................................................................................. 16
Method 1. Stud Mounting ............................................................... 16
EZ-S6M-R, EZ-S6M-F, EZ-S6M-FH, EZ-S6K, EZ-S6C-F,
EZ-S6C-FH Dimensions & Cutout ..................................... 17
EZ-S6M-RS, EZ-S6M-FS, EZ-S6M-FSH, EZ-S6C-KS,
EZ-S6C-FS, EZ-S6C-FSH Dimensions & Cutout ............ 18
EZ-S8C-F and EZ-S8C-FH Dimensions & Cutout ................. 19
EZ-S8C-FS and EZ-S8C-FSH Dimensions ............................ 20
EZ-S8C-FS and EZ-S8C-FSH Cutout ..................................... 21
EZ-T10C-F and EZ-T10C-FH Dimensions & Cutout .............. 22
EZ-T10C-FS, EZ-T10C-FSH, EZ-T10C-FSD, EZ-T10C-FSE,
EZ-T10C-FSM, and EZ-T10C-FSP Dimensions ................ 23
TABLE OF CONTENTS
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

ii
TABLE OF CONTENTS
EZ-T10C-FS, EZ-T10C-FSH, EZ-T10C-FSD, EZ-T10C-FSE,
EZ-T10C-FSM, and EZ-T10C-FSP Cutout ........................ 24
EZ-T15C-FS, EZ-T15C-FSH , EZ-T15C-FSD, EZ-T15C-FSE,
EZ-T15C-FSM, and EZ-T10C-FSP Dimensions ................ 25
EZ-T15C-FS, EZ-T15C-FSH , EZ-T15C-FSD, EZ-T15C-FSE,
EZ-T15C-FSM, and EZ-T10C-FSP Cutout ........................ 26
Method 2. DIN Clips ...................................................................... 27
Connections and Wiring ..................................................................... 29
Wiring Diagram ............................................................................. 29
Power Terminal ............................................................................. 30
PLC Port ........................................................................................ 30
COM1 Port ..................................................................................... 31
Option Card Installation ................................................................ 32
Allen-Bradley Data Highway Plus Option Card ...................... 33
EZ Ethernet Option Card ......................................................... 34
EZ Ethernet Option Card Outline Drawing ......................... 35
Generic DeviceNet I/O Option Card ........................................ 36
Generic Ethernet/IP Option Card ............................................. 37
Modicon Modbus Plus Option Card ........................................ 38
Generic Profibus-DP Option Card .......................................... 39
Communications Setup ...................................................................... 41
Clock ............................................................................................. 41
COM1 ............................................................................................. 42
Contrast ......................................................................................... 43
Touchpad Test ............................................................................... 43
Display Test ................................................................................... 44
Exit ............................................................................................. 44
Reboot ........................................................................................... 44
5 MAINTENANCE .................................................................................... 45
Shutting Off Power to EZTouch Panel ................................................. 45
Lithium Battery Replacement .............................................................. 47
Gasket Replacement .......................................................................... 48
Panel Status Indicator Light ................................................................ 48
RAM Upgrade ....................................................................................... 49
FLASH Program Backup ..................................................................... 50
Fuse Reset .......................................................................................... 50
Fluorescent Backlight Bulb Replacement .......................................... 50
Precautions .......................................................................................... 51
Touchscreen/Chemical Compatibility ................................................ 52
Standard Bezel .............................................................................. 52
Slim Bezel ...................................................................................... 52
Touchscreen Cleaning ........................................................................ 54
6 TROUBLESHOOTING .......................................................................... 55
Warranty Repairs ........................................................................... 57
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

iii
APPENDIX A (PLC Cable Wiring Diagrams) ........................................... A-1
Allen-Bradley SLC500, 5/01, /02, /03 DH-485/AIC
(P/N EZ-DH485-CBL) ................................................................... A-2
Allen-Bradley SLC DF1 RS-232C (P/N EZ-SLC-232-CBL) .............. A-3
Allen-Bradley Micrologix 1000/1200/1500 RS-232C
(P/N EZ-MLOGIX-CBL) ................................................................. A-3
Allen-Bradley PLC5 DF1 RS-232C (P/N EZPLC5-232-CBL) ........... A-3
DirectLogic PLC RJ-12, DL05, DL105, DL205, DL350, and DL450,
RS-232C (P/N EZ-2CBL) ............................................................. A-4
DirectLogic PLC VGA 15-pin, 250, RS-232C (P/N EZ-2CBL-1) ........ A-4
DirectLogic PLC RJ-11, 340, RS-232C (P/N EZ-3CBL) .................... A-4
DirectLogic PLC 15-pin D-SUB, DL405, RS-232C
(P/N EZ-4CBL-1) .......................................................................... A-5
DirectLogic PLC 25-pin D-SUB, DL405, 350, 305 DCU, and all DCMs
RS-232C (P/N EZ-4CBL-2) .......................................................... A-5
General Electric 90/30 and 90/70 15-pin D-SUB, RS-422A
(P/N EZ-90-30-CBL) ..................................................................... A-6
Mitsubishi FX Series 25-pin, RS-422A (P/N EZ-MITSU-CBL) ........... A-6
Mitsubishi FX Series 8-pin MINI-DIN, RS-422A
(P/N EZ-MITSU-CBL-1) ................................................................ A-7
Modicon Modbus RS-232 ................................................................... A-7
Wiring Diagram for the 984 CPU, Quantum 113 CPU ................ A-7
Wiring Diagram for AEG Modicon MICRO Series: 110 CPU 311-xx,
110 CPU 411-xx, 110 CPU 512-xx, 110 CPU-612-xx .............. A-8
Modicon Modbus with RJ45 ............................................................... A-8
Omron C200, C500, RS-232C (P/N EZ-OMRON-CBL) .................... A-9
Omron CQM1 and CPM1 .................................................................... A-9
Siemens S7 MPI Adaptor, RS-232C (P/N EZ-S7MPI-CBL) ............. A-10
EZTouch RS-422A/RS-485A Wiring Connections for
DirectLogic PLCs ....................................................................... A-11
EZTouch RS-422A Wiring Connections for Allen-Bradley SLC
503/504, RS-232C Port .............................................................. A-12
INDEX ............................................................................................. I-1
TABLE OF CONTENTS
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

iv
This page intentionally left blank.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

v
Manual Revisions
Manual Part Number: EZ-TOUCH-M
Manual Title: EZTouch Panel Hardware User Manual, Revision 4
The following table provides you with update information. If you call technical support with a
question about this manual, please be aware of the revision number.
MANUAL REVISIONS
Revision Date Effective Pages Description of Changes
Original
Release
11/2000 Cover
Warning/Copyright
i–iv
1–40
Appendix
Inde x
Original Release of Manual
Maintenance
Release 1
04/2001 Warning/Copyright, pp. 4,
6, 7, 9, 21, 22, 32, 39
Appendix, pages 45-46
Miscellaneous clerical changes.
Cable wiring diagram added.
Revision 1 3/2002 All 6" Slim Bezel Models added. AB
DH+ option card added. EZEthernet
option card added. Siemens PLC
Cable added. EZTouch Panel RS-
422A wiring connections added.
Mounting options for 8- and 10-inch
models changed.
Revision 2 9/2002 Pages i-iv, 2, 3, 5, 6, 8-
13, 15, 16, 18, 20, 21,
23-25, 28, 31, 37, 40-46
Inde x
8-, 10-, and 15-inch Slim Bezel
Models added. Touchscreen
chemical compatibility table added
(for Slim Bezel models)
Revision 3 02/2003 Pages i-vi, 1, 2, 6, 8, 10,
13, 15, 23-26, 29, 30,
32-39, 43, A-8, A10, A-
11, Index
Modicon Modbus Plus, Generic
Devicenet I/O, Generic Ethernet/IP,
Ge neri c Prof ib us-D P o pti on card
information added. Added wiring
diagram for Omron PLC. Added RS-
485A wiring diagram for DirectLogic
PLCs.
Revision 4 07/2003 Pages i, iii, v, vi, 8, 17,
18, A-1, A-7–A-12
Added wiring diagrams for Modicon
ModBus RS-232, minor changes to
outline dimensions, changed OMRON
wiring diagram for CQM1 and CPM1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

vi
EU Information
The EZTouch Panel is manufactured in compliance with European Union (EU) Directives and
carries the CE mark. The EZTouch Panel has been tested under CE Test Standard #EN55011,
and is listed under UL File #E209355. The following information is provided to comply with EU
documentation requirements.
Please NOTE: Products with CE marks perform their required functions safely
and adhere to relevant standards as specified by EU directives provided they
are used according to their intended purpose and that the instructions in this
manual are adhered to. The protection provided by the equipment may be
impaired if this equipment is not used in accordance with this manual. Only
replacement parts supplied by Automationdirect.com or its agents should be
used.
EU INFORMATION
Technical
Support
Consult EZTouch Programming Software Help or you may find answers to
your questions in the operator interface section of our web site @
www.Automationdirect.com. If you still need assistance, please call our
technical support at 1-770-844-4200 or FAX us at 1-770-886-3199.
Environmental
Specifications
Operating Temperature
6" Monochrome/6" Color ......................................................... 0 to 45 °C
8" Color ................................................................................. 0 to 40 °C
10" Color ................................................................................. 0 to 50 °C
15" Color ................................................................................. 0 to 45 °C
Storage Temperature
6" Mono ........................................................................... –20 to +60 °C
6" Color ........................................................................... –25 to +60 °C
8" Color ........................................................................... –20 to +60 °C
10" Color ........................................................................... –25 to +60 °C
15" Color ........................................................................... –25 to +60 °C
Operating Humidity ....................................10–95% R.H., noncondensing
Air Composition .......................................... No corrosive gases permitted
No preventative maintenance is required. The EZTouch Panel touchscreen
should be cleaned as needed with warm, soapy water. See Chapter 5, Mainte-
nance, for a list of compatible/incompatible chemicals and compounds.
Preventative
Maintenance
and Cleaning
SELV Circuits All electrical circuits connected to the communications port receptacle are
rated as Safety Extra Low Voltage (SELV).
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1
EZ-TOUCH-M Revision 4
1 GETTING STARTED
The table, below provides an overall description of the topics covered within this manual.
Getting Started Provides Manual Organization, and lists what you need
to get started, hardware and software. Discusses how
to get help with questions or problems you might
encounter through Onscreen Help and Technical
Support.
Models, Features,
and Accessories
2
1
Provides you with a table listing the various models,
their part numbers and special features. Lists the
important features of all EZTouch Panels. Lists the
PLCs supported by the panels, by brand, model and
protocol. Lists the replacement and optional equipment
available, including memory cards, PLC cables and
programming cable.
3Specifications Specifications for each model provide detailed informa-
tion. Included are display size, brightness and pixels;
CPU type; service power requirements; operating and
storage temperatures; available memory; serial
communications specs; dimensions, weight, etc.
Installation
4
Shows the mounting and cutout dimensions for the
panel models. Tells you how to connect the unit to
power supply, programming computer, printer, and a
PLC. Special option card connector instructions are also
provided.Shows the setup screens displayed after initial
powerup of the panel. Describes each setup screen and
how to use it to set up your panel.
Provides instructions on battery replacement, gasket
replacement, memory upgrade (FLASH and RAM),
Fuse Reset, and fluorescent backlight replacement.
Discusses precautions and cleaning necessary to
ensure longevity of the panel.
5Maintenance
6Troubleshooting Aids in diagnosing problems you might encounter when
installing or operating your EZTouch Panel. Provides
steps to take to isolate and correct problems.
Chapters
Manual Organization
Appendix A PLC Cable Wiring Diagrams are provided.
A
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2EZ-TOUCH-M Revision 4
1 GETTING STARTED
There are two manuals that you will need to use the EZTouch Panel — this
manual, the EZTouch Panel Hardware User Manual, and the EZTouch Panel
Programming Software User Manual (included with P/N EZ-TOUCHEDIT, EZ-
Touch Programming Software). Don’t worry — you won’t be bouncing back
and forth between them — and we’ll always let you know exactly where the
information is that you will need for the next step.
These manuals will take you through the steps necessary to get your EZTouch
Panel up and running in the shortest possible time. Although your familiarity
with programmable graphic operator interface devices will determine how quickly
you move through the steps — it’s as easy as 1 — 2 — 3. The flow chart below
will show you where you need to go, and — how to get there from here!
EZTouch Programming Software is a user-friendly Windows-based program
that allows you to design screens for the EZTouch Panel series of operator
interfaces. To install EZTouch Panel Programming Software, run the install
program from the CD and follow the onscreen prompts. For more information,
please refer to the EZTouch Programming Software Manual.
You can start designing your screen off-line immediately after install-
ing EZTouch Programming Software — you don’t need to have the
hardware installed!
This manual will provide you with the instructions you need to install the EZ-
Touch Panel. Included are mounting diagrams for both Stud Mounting (page
16) and DIN Clip Mounting (page 27). Connections and wiring requirements
are provided beginning on page 29. Option Card connector information is
provided beginning on page 32. Panel Setup instructions begin on page 41.
For Maintenance information, see Chapter 5 (page 45) and for Troubleshoot-
ing, refer to Chapter 6 (page 55).
You may design your screen on-line or off-line (without connection to an EZ-
Touch Panel). When designing screens with EZTouch Programming Software,
you will program objects on the EZTouch Panel providing a graphical interface
designed to interchange and display data from a PLC by merely viewing or
touching the screen — all unique to your particular application. For instruc-
tions on how to design screens, refer to the EZTouch Panel Programming Soft-
ware User Manual.
Easy as 1 - 2 - 3
1
2
3
Install
Software
Install
Hardware
Design
Screens
Introduction
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

3
EZ-TOUCH-M Revision 4
1 GETTING STARTED
Hardware
• EZTouch Panel (6" Monochrome, 6" Color, 8" Color, or 10" Color,
including 6", 8", and 10" Slim Bezel Models, 15" Slim Bezel Model,
and Option Card models)
• 24 Volt Power Supply (24 VDC with 1.5A switching supply is
recommended) (1.5 Amp Slo-Blo input power fuse is also
recommended)
• RS-232C Programming Cable (P/N EZTOUCH-PGMCBL)
• RS-232C PLC Interface Cable (see page 10 for part numbers)
• PC requirements:
— IBM or compatible PC (486 or better) with a mouse
and separate serial port
— VGA display with at least 800 x 600 resolution (1024 x 768
recommended)
— Standard Windows 98/NT4.0/ME/2000®/XP Home/XP Pro
Requirements
— CD ROM Drive
Software
• EZTouch Programming Software (P/N EZ-TOUCHEDIT)
Onscreen HELP
One of the most important features of the EZTouch Programming Software is
the availability of context sensitive onscreen help. To access the Help win-
dows, simply press the F1 function key while on the topic where you need
help. For example, if you need help while working with screens, hit the F1
function key while in that area and a popup window will be displayed. Also,
most dialog boxes contain a Help button, you may click on it to get help, too!
Fly-Over HELP
When the mouse cursor comes to rest over any tool bar or object button for a
short while, a small window will appear containing a brief description of the
function of that particular button. The window will disappear as soon as the
cursor has been moved off the button.
PLC HELP
If you need help with the PLC to EZTouch Panel Interface, consult the EZ-
Touch Panel Programming Software Help. Each PLC Driver has a Help Topic
that lists the error messages and provides an explanation for each. Also pro-
vided are PLC to EZTouch Panel wiring diagrams.
What you need to get started:
Need HELP?
Help is never more than a mouse click or a key press away!
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4EZ-TOUCH-M Revision 4
1 GETTING STARTED
Technical Support
Although most questions can be answered with EZTouch HELP or the manu-
als, if you are still having difficulty with a particular aspect of installation or
screen design, technical support is available at 1-770-844-4200 or FAX us at
1-770-886-3199. Visit our website at www.Automationdirect.com.
PLEASE NOTE: Chapter 6, Troubleshooting, at the end of this
manual should be able to help you with most problems you might
encounter.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

5
EZ-TOUCH-M Revision 4
Models
2 MODELS, FEATURES AND ACCESSORIES
The EZTouch Panel is an intelligent, programmable, flat panel display. It has
been designed to interchange and display graphical data from a PLC by
merely viewing or touching the screen.
The EZTouch Panel is available in a variety of models to suit your applica-
tion. Refer to the table below for a list of part numbers, descriptions and
options for all 6-inch Models (including Option Board Models and Slim Bezel
Models.) See next page for 8-, 10-, and 15-inch Models.
6-inch EZTouch
Panel Models Part Number Description
User
Memory
Field
Expandable
User RAM?
Nonvolatile
Flash Backup
Card Option
for Program
Backup?
PLC Drivers
Supported? *
EZ-S6M-R 6" Monochrome
Touch Panel
256K No No See Note #1
EZ-S6M-RS 6" Monochrome
Touch Panel
with Slim Bezel
256K No No See Note #1
EZ-S6M-F 6" Monochrome
Touch Panel
512K Yes — to 1 or
1.5 MEG
Yes All, plus
EZ Ethernet
EZ-S6M-FH 6" DH+ Mono
Touch Panel
512K Yes — to 1 or
1.5 MEG
Yes All, plus Allen-
Bradley DH+
and Remote I/O
EZ-S6M-FS 6" Monochrome
Touch Panel
with Slim Bezel
512K Yes — to 1 or
1.5 MEG
Yes All, plus
EZ Ethernet
EZ-S6M-FSH 6" DH+ Mono
Touch Panel
with Slim Bezel
512K Yes — to 1 or
1.5 MEG
Yes All, plus Allen-
Bradley DH+
and Remote I/O
EZ-S6C-K 6" Color
Touch Panel
512K Yes — to 1 or
1.5 MEG
Yes See Note #2
EZ-S6C-KS 6" Color
Touch Panel
with Slim Bezel
512K Yes — to 1 or
1.5 MEG
Yes See Note #2
EZ-S6C-F 6" Color
Touch Panel
512K Yes — to 1 or
1.5 MEG
Yes All, plus
EZ Ethernet
EZ-S6C-FH 6" DH+ Color
Touch Panel
512K Yes — to 1 or
1.5 MEG
Yes All, plus Allen-
Bradley DH+
and Remote I/O
EZ-S6C-FS 6" Color
Touch Panel
with Slim Bezel
512K Yes — to 1 or
1.5 MEG
Yes All, plus
EZ Ethernet
EZ-S6C-FSH 6" DH+ Color
Touch Panel
with Slim Bezel
512K Yes — to 1 or
1.5 MEG
Yes All, plus Allen-
Bradley DH+
and Remote I/O
* List of PLC Drivers supported is provided on page 8 of this manual.
Note #1: Supports all drivers in list, but NO OPTION BOARDS.
Note #2: Supports AutomationDirect (DirectLogic) Serial Drivers including H2-WPLC-XX.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6EZ-TOUCH-M Revision 4
In the table below are the 8-, 10-, and 15-inch EZTouch Panel models including the Slim
Bezel Models and Models with the A-B Data Highway Plus (and Remote I/O), DeviceNet I/O,
Ethernet/IP, Modicon ModBus Plus, or Profibus-DP Network interface module (option card)
installed. If using an option board connector, you cannot use the PLC port at the same time
to connect to another type PLC. The panel supports only one PLC driver at a time.
8-inch, 10-inch, and 15-inch EZTouch Panel Models
2 MODELS, FEATURES AND ACCESSORIES
Part Number Description
User
Memory
Field Expandable
User RAM?
Nonvolatile
Flash
Backup
Card Option
for Program
Backup? PLC Drivers Supported? *
EZ-S8C-F 8" Color Touch Panel 512K Yes — to 1 or 1.5 MEG Yes All, plus EZ Ethernet
EZ-S8C-FS 8" Color Touch Panel with
Slim Bezel
512K Yes — to 1 or 1.5 MEG Yes All, plus EZ Ethernet
EZ-S8C-FH 8" DH+ Color Touch Panel 512K Yes — to 1 or 1.5 MEG Yes All, plus Allen-Bradley DH+ and
Remote I/O
EZ-S8C-FSH 8" DH+ Color Touch Panel
with Slim Bezel
512K Yes — to 1 or 1.5 MEG Yes All, plus Allen-Bradley DH+ and
Remote I/O
EZ-T10C-F 10.4" Color Touch Panel 512K Yes — to 1 or 1.5 MEG Yes All, plus EZ Ethernet
EZ-T10C-FH 10.4" DH+ Color Touch
Panel
512L Yes — to 1 or 1.5 MEG Yes All, plus Allen-Bradley DH+ and
Remote I/O
EZ-T10C-FS 10.4" Color Touch Panel
with Slim Bezel
512K Yes — to 1 or 1.5 MEG Yes All, plus EZ Ethernet
EZ-T10C-FSH 10.4" DH+ Color Touch
Panel with Slim Bezel
512K Yes — to 1 or 1.5 MEG Yes All, plus Allen-Bradley DH+ and
Remote I/O
EZ-T10C-FSD 10.4" DeviceNet I/O Color
Touch P anel with Slim Bezel
512K Yes — to 1 or 1.5 MEG Yes All, plus DeviceNet I/O
EZ-T10C-FSE 10.4" Ethernet/IP Color
Touch P anel with Slim Bezel
512K Yes — to 1 or 1.5 MEG Yes All, plus Ethernet/IP
EZ-T10C-FSM 10.4" Modbus Plus Color
Touch P anel with Slim Bezel
512K Yes — to 1 or 1.5 MEG Yes All, plus Modbus Plus
EZ-T10C-FSP 10.4" Profibus-DP Color
Touch P anel with Slim Bezel
512K Yes — to 1 or 1.5 MEG Yes All, plus Profibus-DP
EZ-T15C-FS 15" Color Touch Panel with
Slim Bezel
1024K Yes — to 1.5 or 2 MEG Yes All, plus EZ Ethernet
EZ-T15C-FSH 15" DH+ Color
Touch P anel with Slim Bezel
1024K Yes — to 1.5 or 2 MEG Yes All, plus Allen-Bradley DH+ and
Remote I/O
EZ-T15C-FSD 15" DeviceNet I/O Color
Touch P anel with Slim Bezel
1024K Yes — to 1.5 or 2 MEG Yes All, plus DeviceNet I/O
EZ-T15C-FSE 15" Ethernet/IP Color
Touch P anel with Slim Bezel
1024K Yes — to 1.5 or 2 MEG Yes All, plus Ethernet/IP
EZ-T15C-FSM 15" Modbus Plus Color
Touch P anel with Slim Bezel
1024K Yes — to 1.5 or 2 MEG Yes All, plus Modbus Plus
EZ-T15C-FSP 15" Profibus-DP Color
Touch P anel with Slim Bezel
1024K Yes — to 1.5 or 2 MEG Yes All, plus Profibus-DP
* List of PLC Drivers supported is provided on page 8 of this manual.
