Avisaro 4.0 Sky User manual

Jump to: Table of Content
2022/04/11
Page: 1
Avisaro 4.0 Product Series
Quick Guide
4..20mA Data Logger & Gateway
‘4.0 Sky’
( “M47724”/ “C47724”)
Version / Date: 2022/04/11

Jump to: Table of Content
2022/04/11
Page : 2
1TABLE OF CONTENT
2 This document ......................................................................................................................................5
2.1 history of changes.........................................................................................................................5
2.2 Audience .......................................................................................................................................5
2.3 Location.........................................................................................................................................5
2.4 Language Versions ........................................................................................................................5
2.5 Other documents..........................................................................................................................5
2.6 Active Links ...................................................................................................................................5
2.7 Document creation .......................................................................................................................5
2.8 Imprint and contact ......................................................................................................................6
3 Enclosure and User Controls.................................................................................................................7
3.1 Start and stop operation...............................................................................................................7
3.2 LED Blink-Codes.............................................................................................................................7
3.3 Real-Time Clock.............................................................................................................................7
3.4 Enclosure “4.0 Sky” with WAGO connector..................................................................................8
4 USB Storage Stick..................................................................................................................................9
4.1 Filesystem and Storage size ..........................................................................................................9
4.2 Formatting.....................................................................................................................................9
4.3 Choosing the right memory stick..................................................................................................9
4.4 Recommended Memory Sticks ...................................................................................................10
4.4.1 Recommended....................................................................................................................10
4.4.2 Not recommended..............................................................................................................11
5 Interface description and Pin Layout..................................................................................................12
5.1 Micro-USB Client.........................................................................................................................12
5.2 Analog 4..20mA current loop interface ......................................................................................12
5.2.1 Default 20mA settings.........................................................................................................12
5.2.2 2-wire and 3-wire setup considerations .............................................................................12
5.2.3 WAGO –4x current loop 4..20mA (“M47724” / “C47724”) ...............................................13
6 Configuration: ‘PC Companion Software’ ...........................................................................................14
6.1 How to configure Avisaro “Series 4.0” products ........................................................................14
6.2 Concept of operation..................................................................................................................14

Jump to: Table of Content
2022/04/11
Page: 3
6.3 Detailed documentation.............................................................................................................14
6.4 “PC Companion Software” Installation.......................................................................................15
6.5 Driver installation........................................................................................................................15
6.6 Initial Set-Up ...............................................................................................................................16
6.7 Using the PC Companion Tool.....................................................................................................16
6.8 Global Hardware Setup...............................................................................................................17
6.8.1 Global HW settings ⇨System functions.............................................................................17
6.8.2 Global HW settings ⇨Networking .....................................................................................17
6.8.3 Global HW settings ⇨Interfaces (Digital)...........................................................................17
6.8.4 Global HW settings ⇨Interfaces (Analog)..........................................................................17
6.8.5 Global HW settings ⇨Sensors............................................................................................17
6.9 Interfaces ⇨4..20mA / 0..10V....................................................................................................18
6.9.1 Sample Rate ........................................................................................................................18
6.9.2 Stream to.............................................................................................................................18
6.9.3 Graphic display....................................................................................................................18
6.10 Data Processing ⇨4..20mA / 0..10V ..........................................................................................19
6.10.1 Storage Format ...................................................................................................................19
6.10.2 Storage endpoint ................................................................................................................20
6.10.3 Network endpoint...............................................................................................................20
6.11 Data Endpoints ⇨USB Stick .......................................................................................................21
6.11.1 “Create new file” policy ......................................................................................................21
6.12 Data Endpoints ⇨Network endpoint.........................................................................................22
6.12.1 Data Endpoints ⇨Network endpoint ⇨Protocol..............................................................23
6.13 Data Endpoints ⇨Cloud Settings ...............................................................................................24
6.13.1 Data Endpoints ⇨Cloud Settings ⇨Mode.........................................................................25
6.13.2 Data Endpoints ⇨Remote firmware update......................................................................25
7 Firmware and Configuration Update..................................................................................................27
7.1 Configuration Update .................................................................................................................27
7.1.1 Introduction ........................................................................................................................27
7.1.2 Via “PC Companion” Software............................................................................................27
7.1.3 Via USB Stick .......................................................................................................................27
7.2 Firmware Update ........................................................................................................................28
7.2.1 Introduction ........................................................................................................................28

Jump to: Table of Content
2022/04/11
Page : 4
7.2.2 Via USB stick........................................................................................................................29
7.2.3 Via “PC Companion” Software............................................................................................29
7.2.4 Via FTP server / internet .....................................................................................................29
8 Declarations ........................................................................................................................................31
8.1 EC/EU Declaration of Conformity ...............................................................................................31
9 Contact and Support...........................................................................................................................32

Jump to: Table of Content
2022/04/11
Page: 5
2THIS DOCUMENT
2.1 HISTORY OF CHANGES
The document version equals the document date in the format yyyy.mm.dd.
Version
Description
2022/03/28
Added “configuration via USB stick” / Firmware 2.66 and higher
2021/06/14
Multiple additions and first public release
2021/05/02
Initial version extracted from existing documents
2.2 AUDIENCE
Intended reader of this document are technical personnel installing, configuring, and using the Avisaro
device.
2.3 LOCATION
Check for the latest document version the following link:
Link: https://www.avisaro.de/files/Avisaro/40_Docu/M47724-C47724-QuickGuide.pdf
2.4 LANGUAGE VERSIONS
This document is available in English language only.
2.5 OTHER DOCUMENTS
“Technical User Manual 4.0” contains all of this and more information.
Link: https://www.avisaro.com/en/40-ENG-Documentation.html
2.6 ACTIVE LINKS
This PDF contains active links. By 'clicking', e.g. in the table of contents, you can get to the appropriate
paragraph or by 'clicking' on the "Go to:" in the header you can get back.
2.7 DOCUMENT CREATION
This document was created using the “Avisaro Document Builder”. Single text blocks are merged into
targeted documents. Thus, text blocks can be reused in several places, yet no need to update them
manually when changes occur.

Jump to: Table of Content
2022/04/11
Page : 6
We point this out because:
Advantage is that compact and targeted documents are available. Disadvantage is that in rare occasions,
a paragraph might have comments which do not fit to 100% in the place it is used.
2.8 IMPRINT AND CONTACT
This document is provided by:
Avisaro AG
Grosser Kolonnenweg 18 E
30163 Hannover
Germany
Web: www.avisaro.com
Email: [email protected]om

Jump to: Table of Content
2022/04/11
Page: 7
3ENCLOSURE AND USER CONTROLS
3.1 START AND STOP OPERATION
The Avisaro 4.0 starts with operation right after power on if an USB stick is inserted. Also, after re-
inserting a USB stick, the operation starts automatically.
3.2 LED BLINK-CODES
There is one multicolor LED to signal states of the Avisaro device.
Code
What is means
Action
Green & blue fading
All is fine
Idle state, no data arriving
None
Green flashing
Data are coming in
(RS232, CAN interface)1)
None
Yello constant
All is fine, USB stick is
checked after mounting
None
Red flashing
No USB stick
or button was pushed
Insert USB stick
Or press button again
Red (about 2sec)
than blue (about
2sec)
Logger restarts.
This should not happen
during normal operation
Check power supply
1) On analog loggers (e.g. 4…20mA) and similar interfaces, data are read continuously, thus no green
flashing is shown
3.3 REAL-TIME CLOCK
A battery buffered internal real time clock is available for time stamping data, start and stop network
upload and others controls. The battery is a rechargeable “memo-buf” cell - specifically designed for RTC
operations. During regular operation, the battery is recharged over a 48h period. During non-operating
times (= supply power off) , the date and time settings are maintained.
If the Avisaro device is networked, a network time server (SNTP) can be used to set time and date
automatically.
If a Avisaro GPS receiver is connected, the RTC can be set using satelite time.
It is possible to define time zones settings.

Jump to: Table of Content
2022/04/11
Page : 8
3.4 ENCLOSURE “4.0 SKY”WITH WAGO CONNECTOR
Front with slot for USB stick. Matches are shown
just for size reference:
Reverse side shows the two WAGO connectors
for data and power:
Optional, a DIN rail fitting is available:
WAGO connector are great with single wires. The
Clamps are included in most of our products

Jump to: Table of Content
2022/04/11
Page: 9
4USB STORAGE STICK
4.1 FILESYSTEM AND STORAGE SIZE
Commercially available USB 2.0 / 3.0 memory sticks can be used. It is recommended to exclude branded
products - no "promotional items" with your own logo imprint.
There are no speed requirements. Memory sticks that are advertised as particularly fast offer no (!)
advantage in the Avisaro data logger. Typically these optimizations are designed for cameras etc..
Memory sizes from 4 to 256 GByte are supported. As file system FAT or FAT32 (preferred) is used. NTSF
or others are not supported.
Memory sticks are typically not in the scope of delivery - each application typically has different
requirements.
4.2 FORMATTING
Usually, sticks come pre-formatted, so you don’t have to do anything. Even larger than 32GByte sticks
are preformatted with FAT32.
Sticks equal or smaller than 32 GByte can be formatted with Windows Operating system as it is. Use
“FAT32” as the desired format.
Windows Operating System does not allow to format sticks larger then 32 GByte with the FAT32 file
system. Usually, sticks come pre-formatted, so you don’t have to do anything. If there is a need to
reformat a stick, the Avisaro Device can be used. Please refer to later chapter “Configuration: PC
Companion Software” .. “USB Storage” ether in this document, or in the overall “User Manual Serie 4.0”
document.
Alternatively, third party tools for Windows can be used to format large USB sticks. Please note: Avisaro
can not support those third party tools within our technical support via telephone or email.
4.3 CHOOSING THE RIGHT MEMORY STICK
For industrial use, special parameters may have to be observed:
The temperature range should be considered. There are "industrial grade" memory sticks available -
often designed as "SLC" version - which are also suitable for harsh environments.
The mechanical dimension should also be considered. It is disadvantageous if the stick protrudes openly
from the housing and could be knocked off. In this case short sticks are recommended. If the logger is
installed protected, then a longer stick is easier to use.

Jump to: Table of Content
2022/04/11
Page : 10
The appropriate memory size also depends on the intended use. Due to the technology, memory sticks
with an extremely high capacity are typically less robust than smaller memory sizes. The loggers have a
"ring memory" that can be optionally activated. If the memory stick becomes full (approx. less than
100MB free memory) the oldest files are deleted - this is a useful setting for some applications.
4.4 RECOMMENDED MEMORY STICKS
It is difficult to recommend consumer grade USB sticks as detailed technical information are not
published.
Nevertheless, we try (please check for updated documentation often, link found in previous chapters):
Last updated: April 5th, 2022
4.4.1 Recommended
Manufacturer
Model
Capacity
Technology
Remarks
SanDisk
Ultra Fit
16 GB
Consumer
SanDisk
Ultra
32 GB
Consumer
Intenso
Slim Line
8 GB
Consumer
Kingston
Data Traveler 2
16 GB
Consumer

Jump to: Table of Content
2022/04/11
Page: 11
Innodisk
USB Drive 3SE
4-32 GB
Industrial
SLC Technology
4.4.2 Not recommended
Manufacturer
Model
Capacity
Technology
Remarks
Verbatim
Slider
Store N Go
8 GB
Consumer
Stick failures after
short period of
time

Jump to: Table of Content
2022/04/11
Page : 12
5INTERFACE DESCRIPTION AND PIN LAYOUT
5.1 MICRO-USB CLIENT
The Micro-USB client interface is used for configuration only.
USB in “4.0 Sky” products USB Client in “4.0 Silver” products
Most Avisaro devices are powered through the Mico-USB client port, however only for configuration. A
stable regular operation is not guaranteed. Use the regular power supply for normal operation.
A “Micro USB” cable is used. As those cable are widely available, this cable is not part of scope of
delivery to avoid electronic waste.
Heads-up: There are sometimes Micro USB cable which only do power supply, but not data. Those are
used i.e. with mobile phones. If the Avisaro device is powered, but no data connection to the PC –just
choose a different USB cable.
5.2 ANALOG 4..20MACURRENT LOOP INTERFACE
The analog 20mA interface is a differential current input with an internal resistance of 49.9 Ohms. This
allows to interface industrial standard 4…20mA sensors to the data logger.
5.2.1 Default 20mA settings
Input resistor: 49.9 Ohm
Measurement range: 0 .. 20 mA
To avoid sensor signal clipping, the voltage levels of analog channels must be kept within the range:
negative Pin Voltage ≥ 0V
positive Pin Voltage ≤ 3V referenced to GND
5.2.2 2-wire and 3-wire setup considerations

Jump to: Table of Content
2022/04/11
Page: 13
•Use external power –the data logger does not provide current sourcing
•Tie “-“ of the ADC channel to Signal Ground if 2 wire setup is used
•ADC channels are isolated
5.2.3 WAGO –4x current loop 4..20mA (“M47724” / “C47724”)
Please note:
There was a firmware bug which resulted in switched polarity and incorrect readings. Make sure to
update to a firmware larger to 2.65. Check chapter firmware update in this document for details.
Connector
Interface
Pin
Signal
Direction
WAGO A
ADC3 & ADC4
4..20mA
1
ADC3 - mA (+)
2
ADC3 - mA (-)
3
ADC4 - mA (+)
4
ADC4 - mA (-)
5
n.c.
6
Analog Reference GND
Signal GND
WAGO B
ADC1 & ADC2
4..20mA
1
ADC1 - mA (+)
2
ADC1 - mA (-)
3
ADC2 - mA (+)
4
ADC2 - mA (-)
5
VCC (6..32V)
Power
6
GND
Power & Signal
Cables are connected with the WAGO 734 series connectors. In most product configurations, those
adapters are shipped with the box. Check the 'scope of delivery' list.

Jump to: Table of Content
2022/04/11
Page : 14
6CONFIGURATION:‘PC COMPANION SOFTWARE’
6.1 HOW TO CONFIGURE AVISARO “SERIES 4.0” PRODUCTS
The basic principle of how to configure the Avisaro “Series 4.0” products is:
1) Download and install the “Avisaro PC Companion Software”.
2) Connect the Avisaro device via USB cable.
3) Choose the correct COM port and click on “connect”.
4) The software presents all the settings you can make and guides you to avoid conflicting
configurations.
5) Click on “save configuration” to store changes in the Avisaro device.
6) Reboot the Avisaro Device so that the new configuration takes effect.
Details are described further down in this document.
6.2 CONCEPT OF OPERATION
The Avisaro 4.0 is divided into sections:
Data are received through an “Interface” and then forwarded to the “Data Processing” section. All
formatting happens here and then data is forwarded to the “Data Endpoint”.
6.3 DETAILED DOCUMENTATION
This current document shows only selected parts of the full “Avisaro PC Companion Software”user
manual. The motivation is to keep this document as compact as possible.
Please find the extensive “Avisaro PC Companion Software” document in the support section of the
Avisaro website:
German: https://www.avisaro.de/de/40_Dokumentation.html
English: https://www.avisaro.com/en/40-ENG-Documentation.html

Jump to: Table of Content
2022/04/11
Page: 15
6.4 “PC COMPANION SOFTWARE”INSTALLATION
Download the latest version from:
German site: https://www.avisaro.de/de/40-PC-Software.html
English site: https://www.avisaro.com/en/40-ENG-PC-Software.html
Please check the section “DRAFT version” only if advised by Avisaro Support.
There are two version available:
•Install: this runs a Windows installer. You need admin rights to run.
•Direct: this contains a folder with all files. You can run the *.exe directly from there.
Windows warns the user before installing or using software downloaded from the Internet. So if you
click on “Avisaro_40_Companion_v2.56_Setup.exe”, the warning will occur:
After a click on “More Info”, the box shows:
Select “Run anyway” to continue.
6.5 DRIVER INSTALLATION
If you connect the Avisaro Device to the PC using a Micro USB cable, a virtual COM port driver is
installed. If this driver does not install automatically, you can download and install this manually:
http://www.avisaro.de/de/40-PC-Treiber.html (German site)
http://www.avisaro.com/en/40-ENG-PC-Driver.html (English site)

Jump to: Table of Content
2022/04/11
Page : 16
6.6 INITIAL SET-UP
After starting the companion software, the
virtual COM port number needs to be entered.
You can find this number in the Windows
“Device Manager”.
This setting is stored for future use.
Click on ‘open COM port’ – which will turn green
if successful. You can use the “check” button to
verify that the connection is alive.
You can use the “Check” button to verify the
connection to the Avisaro Device. It should light
up green when clicked.
The baudrate setting for “if connected through
real RS22.. “ can be ignored. This setting is used
only in special projects and not scope of this
document.
All settings are deactivated if there is no Avisaro Device attached.
6.7 USING THE PC COMPANION TOOL
Click on “Write Config” to transmit changes in the PC tool to the Avisaro device. Click on “Read Config”
to display the currently stored values (if you navigate between options, the latest settings are read of
course automatically).
Most settings become active only after reboot. This can be done in Commands ⇨Device Control:
Reboot Device.

Jump to: Table of Content
2022/04/11
Page: 17
6.8 GLOBAL HARDWARE SETUP
Hardware modules are enabled/disabled in
this setting. Of course –only those interfaces
who are physically there can be activated.
Please check device serial number for details.
In most cases, devices are shipped with
proper settings on this page.
6.8.1 Global HW settings ⇨System functions
Don’t touch those settings unless advised by technical support team from Avisaro.
6.8.2 Global HW settings ⇨Networking
Activate the network interface which is physically present.
6.8.3 Global HW settings ⇨Interfaces (Digital)
Activate the digital interface which is physically present.
6.8.4 Global HW settings ⇨Interfaces (Analog)
Activate the analog interface which is physically present.
6.8.5 Global HW settings ⇨Sensors
Activate the sensor which is physically present.

Jump to: Table of Content
2022/04/11
Page : 18
6.9 INTERFACES ⇨4..20MA/0..10V
The analog interfaces for 4..20mA and 0..10V
are managed in the same settings page.
6.9.1 Sample Rate
Select the desired sample rate in samples per seconds (hz).
6.9.2 Stream to
In this point of time, only “Analog data (generic)” can be selected.
6.9.3 Graphic display
The graphic display shows the readings from the ports. This is designed to check the proper function
during setup.

Jump to: Table of Content
2022/04/11
Page: 19
6.10 DATA PROCESSING ⇨4..20MA/0..10V
Settings for collection 0..10V or 4..20mA
analog data.
6.10.1 Storage Format
Storage format ⇨
OFF
This is the default setting.
…

Jump to: Table of Content
2022/04/11
Page : 20
4x Current (mA)(NMEA)
Storage format example with the setting above:
2022/03/02,15:45:33,332, $20MA, 9.979 mA, 0.761 mA, 0.001 mA,-0.001 mA
2022/03/02,15:45:34,331, $20MA, 9.980 mA, 0.730 mA,-0.001 mA, 0.001 mA
2022/03/02,15:45:35,330, $20MA, 9.980 mA, 0.742 mA,-0.001 mA, 0.000 mA
2x Current (mA)(NMEA)
Storage format example with the setting:
2022/03/02,16:41:24,795, $20MA, 6.924 mA,-0.501 mA
2022/03/02,16:41:25,795, $20MA, 6.874 mA,-0.461 mA
2022/03/02,16:41:26,795, $20MA, 6.882 mA,-0.452 mA
6.10.2 Storage endpoint
Fixed for now to „Generic file”
6.10.3 Network endpoint
Network endpoint ⇨
