AVT MAGIC ACip3 User manual

MAGIC ACip3
MAGIC ACip3 2M
High-quality IP and E1 Audio Codec
Hardware Manual

2
A publication of
AVT Audio Video Technologies GmbH
Nordostpark 91
90411 Nuernberg
Germany
Phone [phone]
Telefax [phone]
© AVT Audio Video Technologies GmbH
All Rights reserved. Reproduction in
whole or in parts is prohibited without the
written consent of AVT GmbH.
Subject to changes.
Release date: January 2019

3
INDEX
1Introduction ....................................................................................................... 4
1.1 Conventions .................................................................................................. 5
1.2 Safety ............................................................................................................ 5
1.3 General safety requirements ........................................................................ 6
1.4 Construction.................................................................................................. 7
1.5 Functionality ................................................................................................. 8
2Putting MAGIC ACip3 into operation ................................................................. 9
2.1 Mounting ...................................................................................................... 9
2.2 Connection to the mains voltage ................................................................ 10
2.3 Operational elements at the front side....................................................... 11
2.4 Front status LEDs ........................................................................................ 11
2.5 Wiring.......................................................................................................... 12
2.6 Proper disposal ........................................................................................... 12
3Interfaces ......................................................................................................... 13
3.1 LAN interfaces ............................................................................................ 14
3.2 E1 interface (only MAGIC ACip3 2M) ......................................................... 14
3.3 TTL/Relay interface ..................................................................................... 15
3.4 RS232 interfaces ......................................................................................... 16
3.5 Audio interfaces.......................................................................................... 17
3.5.1 Headphone interface ......................................................................... 17
3.5.2 Analogue Audio interfaces................................................................. 17
3.5.3 Digital AES Audio interfaces............................................................... 18
3.6 Power supply............................................................................................... 19
3.6.1 AC power supply interface................................................................. 19
3.6.2 Additional DC power supply connection............................................ 19
3.7 SD Card Slot................................................................................................. 19
4Technical Data.................................................................................................. 20
5General ............................................................................................................ 23
5.1 Order numbers............................................................................................ 23
5.2 Scope of delivery......................................................................................... 23
5.3 Declaration of conformity........................................................................... 23
6Service Information.......................................................................................... 24
6.1 Software and firmware updates ................................................................. 24
6.2 Support ....................................................................................................... 24
6.3 Repairs ........................................................................................................ 24

4
1INTRODUCTION
The MAGIC ACip3 is a pure IP Audio Code and provides three Ethernet interfaces
which can be used for Audio over IP transmissions, to control the system with the
Windows PC software or to integrate it into a network management system via
SNMP. Alternatively, MAGIC ACip3 2M provides an E1 interface in order to
implement the classic feed via 2 Mbit networks.
The Audio programmes can – flexibly and freely assignable – be fed in or given out,
respectively, via an analogue and two digital stereo interfaces (1 x Stereo analogue
XLR, 2 x Stereo digital AES SUB-D 15-pin). Furthermore, both systems provide a
headphones interface for audio monitoring. For external signalling and switching
commands six programmable TTL interfaces and six relays are available.
The systems support the G.711, G.722, ISO/MPEG Layer 2, Opus coding algorithms
and PCM 16/20/24 Bit in the standard delivery version. Optionally, the Audio
Codecs can be upgraded with Enhanced apt-X 16/24 Bit, AAC-LD/AAC-ELD and AAC-
LC+V1/V2.
MAGIC ACip3 and MAGIC ACip3 2M are designed as 19” system with integrated
wide area power supply and provide optionally an external redundant power
supply. The systems feature a signal processor-based hardware platform without
fan.
Via LAN, two operating modes are available: the system can be used for dial-up
AoIP connections according to the EBU Tech 3326 standard or IP Leased Line
connections. In AoIP mode, the system can register at 5 different SIP servers and
automatically accept incoming calls from this SIP server. Audio connections in IP
Leased Line and in AoIP dial-up Mode can be established with the Secure Streaming
functionality for a highly reliable transmission. With this feature, a connection can
be established via two independent IP links to ensure highest reliability. It is
possible to use either one or two Ethernet interfaces for this functionality.
In case that no connection at all can be established, it is also possible to play an
emergency programme from an SD card. With the Backup Upgrade a main and a
backup connection can be configured.
The systems encode one stereo programme in the standard version and can
optionally be upgraded to a second stereo programme by software activation (2-
Channels Upgrade Package).
The Audio Codecs can be operated via the front panel or even more comfortably via
the Windows PC Software supplied with the delivery.
Via the Ember+ protocol 64 inputs and 64 outputs can be programmed, an easy
communication between Audio Codec and e.g. DHD or LAWO mixing consoles is
possible.
With the optional Distribution Upgrade MAGIC ACip3 can be used as Audio
contribution codec for Studio-Transmitter-Links. 10, 20 or up to 50 participants can
dial into a central codec via SIP. In the integrated access protection list up to 50
participants can be entered.

5
1.1 Conventions
In this manual the following conventions are used as text markers:
The TIP symbol marks information which facilitates the operation of the system in
its daily use.
The Note symbol marks general notes to observe.
The Attention symbol marks very important advice that is absolutely to observe. In
case of non-observance malfunctions and even system errors are possible.
1.2 Safety
The unit described has been designed to the latest technical parameters and
complies with all current national and international safety requirements. It
operates on a high level of reliability because of long-term experience in de-
velopment and constant and strict quality control in our company.
This manual contains basic safety instructions that must be observed during
configuration and operation. It is essential that the user reads this manual before
the system is used and that a current version of the manual is always kept close to
the equipment.

6
1.3 General safety requirements
To keep the technically unavoidable residual risk to a minimum, it is absolutely
necessary to observe the following rules:
•Transport, storage and operation of the unit must be under the
permissible conditions only.
•Installation, configuration and disassembly must be carried out only by
trained personal based on the respective manual.
•The unit must be operated by competent and authorised users only.
•The unit must be operated in good working order only.
•The device must be protected from water.
•The device may only be installed in indoor rooms.
•The device may only be cleaned with a dry cloth.
•Any conversions or alterations to the unit or to parts of the unit (including
software) must be carried out by trained personnel authorised by the ma-
nufacturer. Any conversions or alterations carried out by other persons
lead to a complete exemption of liability.
•Only specially qualified personnel are authorised to remove and override
safety measures, and to carry out the maintenance of the system.
•External software is used at one’s own risk. Use of external software can
affect the operation of the system.
•Use only tested and virus-free date carriers.

7
1.4 Construction
MAGIC ACip3 and MAGIC ACip3 2M can be controlled via the front keypad and the
graphic display. Five LEDs give information about the status and connections. A
headphone interface is also on the front.
The other interfaces of the system (3 LAN interfaces, Audio interfaces, RS232 and
GPIO interfaces as well as power supply connections, SD card slot and for the 2M
version E1 interface) are on the rear side.
MAGIC ACip3 Front View
MAGIC ACip3 Rear View
MAGIC ACip3 2M Front View
MAGIC ACip3 2M Rear View

8
1.5 Functionality
MAGIC ACip3 encodes the audio signal at the analogue or digital AES/EBU inputs,
according to the configured algorithm, with the specified data rate and outputs it
via the configured IP line interface (and E1 line interface with MAGIC ACip3 2M). In
addition, you can key in PAD data, which is applied to one of the RS232 interfaces,
into the encoded audio signal.
The complete signal processing is taken over by three digital signal processors. In
this way the following functions are realized
DSP1:
•G.711 Codec
•G.722 Codec
•ISO/MPEG Layer 2, Layer 3
•MPEG 4: AAC-LD, AAC-ELD, HE-AAC-LC (V1 und V2)
•Opus
•Control of the complete system (Keypad, display, relays, TTL, RS232)
DSP2:
•apt-X Codec
DSP3:
•Second apt-X Codec
The configuration and operation can be carried out via the front keypad and the
illuminated display.
Configuration and control are especially comfortable with the Windows PC software
which is included in delivery and which communicates with the system via one of
the LAN interfaces. As a special feature the system offers an NTP synchronization of
the audio transmission.

9
2PUTTING MAGIC ACIP3 INTO OPERATION
2.1 Mounting
With its dimensions of (width x height x depth) 434 mm x 44.5 mm (1 U) x 260 mm
the MAGIC ACip3 system can either be used as desktop device or mounted into a
19-inch rack. Corresponding 19“mounting brackets are included in delivery. When
mounting the unit please keep in mind that the bending radius of the connected
cables is always greater than the minimum allowed value.
When the MAGIC ACip3 Audio Codec is installed, please make sure that there is
sufficient ventilation: it is recommended to keep a spacing of ca. 3 cm from the
openings. In general, the ambient temperature of the system should be within the
range of +5 °C and +45 °C. These thresholds are specially to observe if the system is
inserted in a rack. The system works without ventilation.
The system temperature can be indicated on the display under MENU > STATUS
INFORMATION > DEVICE TEMPERATURE or in the software under Extras > System
Monitor > System Temperature.
During operation humidity must range between 30% and 85%.
Incorrect ambient temperature and humidity can cause functional deficiencies.
Improper use of the unit can lead to a loss of warranty claim.

10
2.2 Connection to the mains voltage
MAGIC ACip3 must be earthed. The earthing can be carried out via the earthing
screw on the back side of the unit.
MAGIC ACip3 may only be used with the included power cable. The power cable
must not be replaced by an inadequately dimensioned power cable.
MAGIC ACip3 may only be operated with one of the included power supplies listed
below:
• Sunny Model SYS1541-2412 (100-240 Vac; max. 1,0 A; 50-60 Hz / 12 Vdc; 2,0 A
(EN60950 – LPS))
• Sunny Model SYS1357-2412 (100-240 Vac; max. 1,0 A; 50-60 Hz / 12 Vdc; 2,0 A
(EN60950 – LPS))
After plugging the power cable and switching on the device, the unit boots in a few
seconds.
A +12 V DC voltage can be supplied to the +12 V socket, which takes over the
backup operation in case of failure of mains voltage.

11
2.3 Operational elements at the front side
The system has an illuminated graphical display with a resolution of 160 x 32 pixel
and 19 operating buttons.
On the right next to the display there are two softkeys whose current functions are
indicated on the display. In the middle there are two cursor buttons
(upwards/downwards), two buttons for accepting/dropping calls as well as an OK
button. The numerical pad supports in addition to the numerical characters 0...9,
the ’*’- and ’#’-key. For text entries the numerical pad can also be used as a normal
keypad.
2.4 Front status LEDs
The system has five LEDs for status indication at the front side.
•POWER green
Permanent green: when system is ready for operation.
•SYNC green or red flashing
Provides a common signal based on the status of INFO 1 and INFO 2.
Permanent green:One codec connection: INFO1 or INFO2 lights green
Permanent green: Two codecs connections: INFO1 and INFO2 lights green
Flashes red: One codec connection: INFO1 or INFO2 flashes red
Flashes red: Two Codecs connections: INFO1 or INFO2 or both flash red.
•ALARM red or red flashing
Permanent red: in case of System alarms: Hardware alarms such as
Ethernet 1, 2 or 3 interface error, DSP1 or 2 error, overheating etc.
Flashes red: in case of Application alarms: AES/EBU interfaces are
configured as interfaces for Codec 1 or Codec 2 and AES/EBU input signal
is missing
•INFO 1/2 green or red flashing
Bi-directional connection
Permanent green: Codec 1/2 is connected, and Decoder 1/2 is
synchronized
Flashes red: Codec 1/2 is connected, but Decoder 1/2 is not synchronized.
Unidirectional connection
Permanent green: Encoder 1/2 is connected

12
2.5 Wiring
The figure below shows the systems’ wiring.
The system offers three LAN interfaces, which can be used for Audio transmission.
The example applications show a unidirectional Audio transmission, a bidirectional
transmission as leased line connection between two devices and an IP dial-up
connection.
2.6 Proper disposal
All electrical and electronic equipment must be disposed separately
from general household waste via authorised collection points or
disposal companies. Proper disposal and separate collection of old
appliances serves to prevent potential damage to the environment
and health. The device contains valuable raw materials that can be
reused. Therefore, return the appliance to an appropriate collection
point.
Detailed information on the disposal of your old appliances can be obtained from
your local authority, your waste disposal service, the specialist dealer where you
purchased the product or your sales contact.
These statements apply only to equipment installed and sold in the countries of the
European Union. Countries outside the European Union may have different
regulations for the disposal of electrical and electronic equipment.
Always recycle packaging material and electrical appliances or their components
through authorised collection points or disposal companies.

13
3INTERFACES
Five LEDs give information about the status and connections at the front side. A
headphone interface is also on the front.
The other interfaces of the system (3 LAN interfaces, Audio interfaces, RS232 and
GPIO interfaces as well as power supply connections, SD card slot)are on the rear
side.
MAGIC ACip3 Front View
MAGIC ACip3 Rear View
MAGIC ACip3 2M provides an additional E1 interface at the rear side.
MAGIC ACip3 2M Front View
MAGIC ACip3 2M Rear View

14
3.1 LAN interfaces
The LAN 1, LAN 2 and LAN 3 interfaces can be used for Audio over IP transmissions,
for system control via Windows PC management software and for integration into a
network management system via SNMP. RJ-45 sockets are used for the LAN
interfaces.
Pin assignment: LAN Interfaces
Socket: RJ-45
Pin
Signal
Electrical characteristics
1
TX+
Data out +
Recommendation: IEEE 802.3/Ethernet
Data rate (Auto neg.): 10/100 Mbit/s
Recommended cable: CAT5 or higher
Max. cable length: 100m
2
TX-
Data out -
3
RX+
Data in +
4
not used
5
not used
6
RX-
Data in -
7
not used
8
not used
3.2 E1 interface (only MAGIC ACip3 2M)
A symmetrical E1 interface is optionally available for classic audio feed via 2 Mbit
networks. The pin assignment is shown below.
Pin assignment: E1 Interface
Socket: RJ-45
Pin
Signal
Electrical characteristics
1
RXD b
Data in b
Recommendation: G.703/G.704
Data rate: 2.048 Mbit/s
Max. cable length: 100m
CLK: TTL input
2
RXD a
Data in a
3
not used
4
TXD b
Data out b
5
TXD a
Data out a
6
not used
7
CLK in b
8
CLK in a

15
3.3 TTL/Relay interface
The TTL/relay interface is realised as a 25-pin socket. It provides six TTL
inputs/outputs as well as six relay contacts, which offer the NC and the NO
function.
Pin assignment: TTL/Relay interface
Socket: SUB-D 25-pin
Pin
Signal
Electrical characteristics
1
GND
TTL interface:
Maximum voltage: 3,3 V
Maximum current: 10 mA
Relay interface:
Maximum voltage: 48 V
Maximum current: 200 mA
2
TTL 1
input/output
3
TTL 2
input/output
4
TTL 3
input/output
5
RELAY 1 (COMMON)
6
RELAY 2 (NC)
7
RELAY 2 (NO)
8
RELAY 3 (COMMON)
9
RELAY 4 (NC)
10
RELAY 4 (NO)
11
RELAY 5 (COMMON)
12
RELAY 6 (NC)
13
RELAY 6 (NO)
14
TTL 4
input/output
15
TTL 5
input/output
16
TTL 6
input/output
17
RELAY 1 (NC)
18
RELAY 1 (NO)
19
RELAY 2 (COMMON)
20
RELAY 3 (NC)
21
RELAY 3 (NO)
22
RELAY 4 (COMMON)
23
RELAY 5 (NC)
24
RELAY 5 (NO)
25
RELAY 6 (COMMON)
NO = normally closed contact
NC = normally open contact

16
3.4 RS232 interfaces
Besides the Audio transmission additional data for RDS can be typed in per stereo
program via two separate RS232 interfaces.
Pin assignment: DATA/CONTROL & DATA/PAD interface
Socket: SUB-D 9-pin
Pin
Signal
Electrical characteristics
1
not used
Level: V.24 (RS232)
Data rate: max. 115200 Baud
Scope: max. 15 m (RS232)
Protocol: 1 Start bit
8 Data bits
1/2 Stop bit
Parity adjustable
2
TXD RS232 Data (a)
3
RXD RS232 Data (b)
4
not used
5
GND
6
not used
7
not used
8
not used
9
not used
a = ATTENTION: on this pin the MAGIC ACip3 sends data
b = ATTENTION: on this pin the MAGIC ACip3 receives data

17
3.5 Audio interfaces
3.5.1 Headphone interface
For Audio monitoring a headphone interface is provided, integrated as Stereo
6.3 mm jack.
3.5.2 Analogue Audio interfaces
The MAGIC ACip3 incorporates an analogue stereo input and output (Audio 1,
Audio 2).
Two XLR sockets are available for the input and two XLR plugs for the output. The
pin configuration of socket and plug are displayed below.
Pin assignment: Analogue Audio input
Socket: 3-pin XLR
Pin
Signal
Electrical characteristics
1
GND
Ground
+
-
2
A
3
B
Pin assignment: Analogue Audio output
Socket: 3-pin XLR
Pin
Signal
Electrical characteristics
1
GND
Ground
+
-
2
A
3
B

18
3.5.3 Digital AES Audio interfaces
The MAGIC ACip3 provides two digital stereo AES inputs and outputs.
A 15-pin SUB-D socket contains the digital AES interfaces. The pin configuration of the
15-pin SUB-D socket can be seen below.
Pin assignment: Digital Audio interface AES
Socket: SUB-D 15-pin
Pin
Signal
Electrical characteristics
1
AES 1 IN +
IEC 958
2
AES 1 IN -
3
AES 2 IN +
4
AES 2 IN -
5
AES 1 OUT +
6
AES 1 OUT -
7
AES 2 OUT +
8
AES 2 OUT -
9
GND
10
CLOCK IN/OUT
11…15
GND

19
3.6 Power supply
3.6.1 AC power supply interface
100 V – 230 V AC, 50/60 Hz, auto adjusting, max. 30 W
3.6.2 Additional DC power supply connection
A DC voltage of +12V can be fed to the additional power supply input.
Pin assignment: Additional power supply
Socket: KYCON KPJ-S3
Pin
Signal
Electrical characteristics
1
GND
Voltage: +12V
Power: max. 30W
2
+12V
3
not used
3.7 SD Card Slot
A slot for a standard SD/SDHC card with max. 32 GByte is available at the back of
the system.

20
4TECHNICAL DATA
Coding algorithms:
•G.711
•G.722
•PCM 16/20/24 Bit
•ISO/MPEG Layer 2
•Opus
Optional:
•ISO/MPEG Layer 3
•MPEG4 AAC-LD/ELD
•MPEG4 AAC-LC
•MPEG4 HE-AACv1/v2
•Enhanced apt-X 16/24 Bit
Line interfaces:
•3 x Ethernet 10/100 Mbit/s
•1 x E1 (only MAGIC ACip3 2M)
Control interfaces:
•3 x Ethernet 10/100 Mbit/s
•6 x Relays
•6 x TTL Input/Output
