MAGIC Audio Codec
MAGIC DC7 XIP/XIP RM
MAGIC AC1 XIP/XIP RM
Hardware/Software Manual
Preliminary

.

MAGIC Audio Codec
Hardware/Software Manual
MAGIC DC7 XIP/XIP RM
MAGIC AC1 XIP/XIP RM
To get always information on the latest software
please register on our Homepage:
http://www.avt-nbg.de
First click on the menu item Service and then select
Software Registration. Please select as product
MAGIC DC7 XIP
or
MAGIC AC1 XIP
and enter your contact details. You need to indicate a
valid email address at least.

A publication of
AVT Audio Video Technologies GmbH
Nordostpark 12
90411 Nuernberg, Germany
Phone [phone]
Telefax [phone]
Printed in Germany, August.2012
© AVT Audio Video Technologies GmbH
All Rights reserved. Reproduction in
whole or in parts is prohibited without the
written consent of Audio Video
Technologies GmbH.
Subject to changes.
Release date: (08.12)

.

Content
INTRODUCTION 11
SAFETY 13
Introduction 13
General saftey requirements 13
Text Conventions 13
1CONSTRUCTION15
2 SYSTEM DESCRIPTION 17
2.1 Functionality 17
2.2 AutoDynamicSync (ADS) 18
3 PUTTING THE MAGIC DC7/AC1 XIP INTO OPERATION 19
3.1 Mounting 19
3.2 Connection to the mains voltage 19
3.3 Earthing of the system 20
3.4 Operational elements on the front side 20
3.5 Operating modes of the system 21
3.5.1 ISDN operation 21
4 WINDOWS PC SOFTWARE 23
4.1 Hardware requirements 23
4.2 User Registration 23
4.3 Installing the Windows PC Software 23
4.4 Software update from the internet 24
4.5 Operation via the Windows PC Software 25
4.5.1 The MAGIC DC7/AC1 XIP main window 25
4.5.2 Connection status 26
4.5.3 Operating elements 27
4.5.3.1 Audio mixer to select sources and output equipment 33
4.5.3.2 Telephone book 35
4.6 Menu File 37
4.6.1 Submenu Phone Book 37
4.6.2 Submenu Operation Settings Presets 38
4.6.3 Submenu User Transmission Modes 38
4.6.4 Submenu System Settings 38

4.6.5 System Log File 39
4.6.6 Submenu Exit 40
4.7 Menu Configuration 41
4.7.1 Submenu Control Interface 41
4.7.2 Submenu MAGIC DC/AC1 XIP 44
4.7.2.1 Operation Settings 44
4.7.2.1.1 Line Interface 44
4.7.2.1.2 SIP Parameters 53
4.7.2.1.3 Data Interfaces 54
4.7.2.1.4 Backup 55
4.7.2.1.5 Functions in the main window with activated backup 57
4.7.2.1.6 Security 59
4.7.2.1.7 ISDN Transmission Modes 59
4.7.2.1.8 X.21 Transmission Modes 59
4.7.2.1.9 LAN Tranmsission Modes 59
4.7.2.2 Transmission 60
4.7.2.2.1 Transmission Modes 61
4.7.2.2.2 User Defined 65
4.7.2.3 System Settings 69
4.7.2.3.1 General 69
4.7.2.3.2 Audio Interface 71
4.7.2.3.3 Headset Interface 73
4.7.2.3.4 Relay/TTL 75
4.7.2.3.5 Remote Control 81
4.7.2.3.6 Quick Dial 83
4.7.2.4 Date and Time 84
4.7.2.5 Login 85
4.7.3 Submenu Presets 87
4.7.3.1 Save as ... 87
4.7.3.2 Manage Presets 87
4.7.3.3 Activate a Preset 89
4.8 Menu Administration 90
4.8.1 Submenu Registration 90
4.8.2 Submenu USB Dongle Information 91
4.8.3 Submenu Remote Control 92
4.8.4 Submenu File System 93
4.8.5 Submenu System Panel 94
4.8.6 Submenu Firmware Download 95
4.8.7 Submennu Create 15-kHz Telephone Mixer Presets 96
4.8.8 Submenu Set Factory Settings 97
4.9 Menu Extras 98
4.9.1 Submenu System Monitor 98
4.9.2 POP-UP Message History 101
4.9.3 Submenu Audio Mixer 102
4.9.4 Relay/TTL Control Flag 103

4.9.5 Submenu S
0
Monitor 104
4.10 Menu Help 105
4.10.1 Submenu About MAGIC DC7/AC1 XIP 105
5 OPERATION VIA DISPLAY AND KEYPAD 107
5.1 Basic configuration 107
5.1.1 Keypad lock 107
5.1.2 Setting the menu language 107
5.1.3 Setting the Audio interface: Analogue or digital (optional) 108
5.2 Working with the MAGIC DC7/AC1 XIP ISDN 109
5.2.1 Calling a partner 109
5.2.2 Using both B channels 109
5.2.3 The Status display - Operation during a connection 110
5.2.4 Dropping a connection 111
5.2.5 Accepting a call 111
5.3 Comfort Functions 112
5.3.1 Redailing 112
5.3.2 Using the phone book 112
5.3.3 Working with Presets 113
5.3.4 Configuration of the Audio sources 114
6 OPTION: MAGIC DC7/AC1 KEYPAD 117
6.1 MAGIC DC7/AC1 Keypad Basic 117
6.2 Functions of the Keypad 118
6.3 MAGIC DC7/AC1 Keypad Advanced 120
6.4 Functions of the Keypad 121
6.5 ISDN alarm messages in the display 124
7 OPTION: MIXER TOOL PLUG-IN 125
8 OPTION: REMOTE CONTROL SOFTWARE & ISDN MONITOR PLUG-
IN 127
8.1 Remote configuration of a MAGIC DC7/AC1 XIP System 127
8.2 The integrated S0 Monitor 130
9 OPTION: MAGIC DC7/AC1 XIP LAN 133
10 OPTION: SECURITY 135
A1 THE AUTODYNAMICSYNC PROCEDURE 137
A2 LIST OF THE TRANSMISSION MODES 139
A3 TROUBLE SHOOTING 141

A4 INTERFACES 143
A4.1 MAGIC DC7/AC1 XIP 143
A4.2 Network interfaces 144
A4.2.1 S0 interface 144
A4.2.2 LAN interface 144
A4.3 Control and data interfaces 146
A4.3.1 CTRL/DATA/TTL/RELAY interface 146
A4.3.2 Assignment of the CTRL/DATA/TTL/RELAY adapter cable 147
A4.4 Audio interfaces 148
A4.4.1 Analogue Audio interface 148
A4.4.2 Digital AES/EBU Audio interface 148
A4.5 Headset/Micro Audio interface 149
A4.6 Power supply interface 150
A4.7 MAGIC DC7/AC1 XIP RM 151
A4.7.1 DATA/CONTROL & DATA/PAD interface 151
A5 TECHNICAL DATA MAGIC DC/AC1 XIP 153
A6 TECHNICAL DATA MAGIC DC7/AC1 KEYPAD 157
A6.1 Keypad 157
A6.2 LCD Display 157
A6.3 Connecting cable 157
A6.4 Connection to power supply (1) 158
A6.5 Connection to MAGIC DC7/AC1 (2) 158
A6.6 Data connection to Keypad (3) 158
A6.7 External power supply 159
A7 GENERAL 161
A7.1 Order numbers 161
A7.2 Scope of delivery 163
A7.3 Declaration of conformity 163
A8 SERVICE INFORMATION 165
A8.1 Software Updates 165
A8.2 Support 165
A8.3 Repairs 165
INDEX 167
DECLARATION OF CONFORMITY 175

PAGE 11
Introduction
INTRODUCTION
The MAGIC DC7/AC1 XIP system is implemented as portable audio codec
with an external power supply plug and has analogue and optional digital
AES/EBU Audio interfaces.
The variation MAGIC DC7/AC1 XIP RM however is realised as 19“ system
and has an integrated power supply.
Available as a special version is the unit MAGIC AC1 XIP TI (allthough as
RM-Version). In contrary to the standard systems this unit has a special signal
processing module, that makes the usage of the highly efficient HE-AAC-V2
algorithm possible. But with that system an ISO/MPEG Layer 2/3 encoding
is no longer possible. However, an ISO/MPEG Layer 2/3 Decoding will still
be supported continues. A typical practise case for that system is the transmis-
sion of highquality audio signals over for example UMTS-networks.
All systems have an ISDN, an X.21 and a LAN interface, which can be used
for the upcoming standard Audio over IP as well as for system control.
The configuration of the systems can be carried out via the Windows applica-
tion software included in delivery or via the front keypad of the unit. Optio-
nally there are two variations of MAGIC DC7/AC1 Keypad with different
functional ranges for separate operation without PC available.
English
German
Menu
Select
System Settings
System Settings
Language
Sprache
Cap
Ok
Save Settings?
Yes
No
Operation Settings
Select
Operation Mode
ISDN
LAN
Audio
Audio Settings
Audio
Audio Input
Audio Output
Analogue
Digital
PRETALK Interface
No System
Telephone
7-kHz G.722 Auto
15-kHz 1B Auto
15-kHz 2B Auto

PAGE 12
Introduction
Handset
Headset
Phantom Power
Mikrophone Limiter
Delete
Opt.
ON AIR
HOLD
PRETALK
Select...
Call!
Beendet
Line
Ring tone
Search
Name
New Entry
Edit
Display
Delete Entry
Save as Quick Dial
Presets
Preset
Load
New
Save
Delete
Ring tone
Signal processing
Keypad 9600, no
Status information
Login
Shift
Automatic Answering
Mikrophone Amplifying
Ratio RX/TX
Sources Headset
Sources Audio Output 1
Sources Audio Output 2
Sources Transmission Signal1
Sources Transmission Signal 2
Headset Monitor
Load Audio Preset
Save Audio Preset
Mode
ON
OFF
DCK
Standard Preset
Basic Settings
Load Basic Settings
LAN Settings
DHCP
IP Adresse
sub-net mask
Default Gateway
DNS Server IP ADR
Steuer Port
Audio Port

PAGE 13
Safety
SAFETY
Introduction
The unit described has been designed to the latest technical parameters and
complies with all current national and international safety requirements. It
operates on a high level of reliability because of long-term experience in de-
velopment and constant and strict quality control in our company.
In normal operation the unit is safe.
However - especially if daily routine and technichal errors coincide - some po-
tential sources of danger for person, material and optimal operation remain.
This manual therefore contains basic safety instructions that must be obser-
ved during configuration and operation. It is essential that the user reads this
manual before the system is used and that a current version of the manual is
always kept close to the equipment.
General saftey requirements
To keep the technically unavoidable residual risk to a minimum, it is absolu-
tely necessary to observe the following rules:
– Transport, storage and operation of the unit must be under the permissible
conditions only.
– Installation, configuration and disassembly must be carried out only by
trained personal on the basis of the respective manual.
– The unit must be operated by competent and authorised users only.
– The unit must be operated in good working order only.
– Any conversions or alterations to the unit or to parts of the unit (including
software) must be carried out by trained personnel authorised by the ma-
nufacturer. Any conversions or alterations carried out by other persons
lead to a complete exemption of liability.
– Only specially qualified personnel is authorised to remove and override
safety measures, and to carry out the maintenance of the system.
– External software is used at one’s own risk. Use of external softwarecan af-
fect the operation of the system.
– Use only tested and virus-free date carriers.
Text Conventions
In this manual the followin conventions are used as text markers:

PAGE 14
Sicherheit
Accentuation: productnames or important terms
LCD Text : Labelling on the front display of the system
PC Text: Labelling in the PC Software
Chosen main operating mode
TIP
The symbol TIP marks information which facilitates the operation of the sy-
stem in its daily use.
NOTE
The symbol Note marks general notes to observe.
ATTENTION The symbol Attention marks very important advice that is absolutely top ob-
serve. In case of non-observance malfunctions and even system errors are
possible.
Operating Mode
!

PAGE 15
Safety
1 CONSTRUCTION
The functions of the MAGIC DC7 XIP are implemented in a single unit. The
MAGIC AC1 XIP is additionally equipped with a module for MPEG Coding.
The system is designed for mounting in a half 19" rack (1 U).
Optionally, a MAGIC Audio Codec DUAL 19“ Mounting Kit (ID: 800212) is
available for the installation of two MAGIC DC7/AC1 XIP systems next to
each other.
The MAGIC AC1 XIP RM version is carried out as 19’’ x 1 U unit and has an
integrated power supply.
FIG. 1 FRONT SIDE: MAGIC AC1 XIP
FIG. 2 FRONT SIDE: MAGIC AC1 XIP RM

PAGE 16
Safety

PAGE 17
System description
2 SYSTEM DESCRIPTION
The functional elements of the system are pictures in Fig. 3.
FIG. 3 FUNCTIONAL ELEMENTS OF THE MAGIC DC7/AC1 XIP
2.1 Functionality
The MAGIC DC7/AC1 XIP system incorporates an ISDN telephone interface
as well as an X.21 network interface and an additional LAN interface. The
operating mode can be configured by software. If the ISDN interface is used,
depending on the operating mode two independent channels are available
that can be used independently from each other.
The complete signal processing is taken over by two digital signal processors.
In this way the following functions are realized.
DSP1:
– G.711 Audio encoding and decoding
– G.722 Audio encoding and decoding
– ISO/MPEG Layer II/III Decoder
– digital Audio router, digital Audio mixer (optional)
– Signalling management (J.52, proprietary modes)
– Control of the complete system (Keypad, display, relays, TTL, RS232)

PAGE 18
System description
DSP2:
– ISO/MPEG Layer III encoder (only for MAGIC AC1 XIP)
– ISO/MPEG Layer II encoder (only for MAGIC AC1 XIP)
–standard
Via the main Audio channel the high quality Stereo or Mono Audio signal is
inserted or output analogue or digitally. At the same time, the command
channel can be used in parallel. If the optionally digital AES/EBU Audio in-
terface is used, two seperate Sample Rate Converters are available for auto-
matic clock synchronisation. For external clocking a clock input and a clock
output are available.
Additionally, the Audio Codec incorporates a Headset interface for stereo
tone or Dual Channel tone with a microphone input, Limiter and 12 V phan-
tom power which can be switched off.
By the integrated Audio router all input and output signals can be configured
freely. If you use the optional Software Plug In MAGIC DC7/AC1 Mixer Tool,
all signals can be mixed in a flexible way.
The configuration and operation can be carried out via the front keypad and
the illuminated display.
Configuration and control is especially comfortable with the MAGIC
DC7/AC1 XIP Windows PC software which is included in delivery and
which communicates with the system via the RS232/LAN interface.
The basic operating functions like accepting a call, dropping a connection and
establishing a connection with a pre-programmed number can be carried out
via six programmable TTL contacts. Two relays are available for status indi-
cation.
Optionally, the system can also be operated seperatly via the MAGIC
DC7/AC1 Keypad that can be connected to the RS232 interface instead of the
PC Software.
2.2 AutoDynamicSync (ADS)
The systems MAGIC DC7 XIP and MAGIC AC1 XIP actively support the user
in the synchronisation of the Audio signal, even when it is unknown which
Audio Codec is used at the remote station.
With the new function AutoDynamicSync (ADS) the system can synchronize
itself to most Audio codecs from all kind of producers. For further details
have a look CHAPTER A1, Page 137.

PAGE 19
Putting the system into operation
3 PUTTING THE MAGIC DC7/AC1 XIP INTO
OPERATION
3.1 Mounting
With its dimensions (W ×H ×D) of 220 mm ×44,5 mm (1 U) ×220 mm the
MAGIC DC7/AC1 XIP System can be used either as desktop device or moun-
ted in 19 inch racks. Corresponding 19“ mounting brackets are included in de-
livery. Optionally, a mounting kit (order number 800212) to install two MA-
GIC DC7/AC1 XIP next to each other
1
is available.
Dimensions of the RM variation are (W ×H ×D) 440 mm ×44,5 mm (1 U) ×
220 mm. For that system 19“ mounting brackets are included in delivery too.
When mounting the unit please keep in mind that the bending radius of the
connected cables is always greater than the minimum allowed value.
When the MAGIC DC7/AC1 XIP Audio Codec is installed, please make sure
that there is sufficient ventilation: it is recommendedto keep a spacing of ca. 3
cm from the openings. In general, the ambient temperature of the system
should be within the range of +5°C and +45°C. These threshold are especially
to observe if the system is inserted in a rack. The system works without ven-
tilation.
During operation humidity must range between 5% and 85%.
3.2 Connection to the mains voltage
The system can be operated with mains voltage in the range from 90 V to
253 V via the external power supply included in delivery respectively with
the internal power supply. The line frequency can vary from 45 Hz to 65 Hz.
The maximum power consumption is 15W. The rack must be earthed accor-
ding to the VDE regulations. The earthing can be carried out via the earthing
screw on the back side of the unit.
The unit does not have a circuit closer and a circuit breaker. After plugging in
the external power supply the system boots within a few seconds. In stand-by
mode the AVT logo is shown on the display
2
.
1
Likewise the MAGIC DC7/AC1 XIP can be combined with the product MAGIC TH2/MAGIC
TH2 POTS.
TIP
The temperature of the system can be indicated on the display ( Menu Status
information
)
ATTENTION Incorrect ambient temperature and humidity can cause functional de-
ficiencies
Operation outside the threshold values indicated above leads to a loss of war-
ranty claim.
!

PAGE 20
Putting the system into operation
3.3 Earthing of the system
For EMC reasons an earthing via the earthing screw must be carried out in eit-
her case.
3.4 Operational elements on the front side
The system has an illuminated graphical display with a resolution of 160 x 32
pixel and 19 operating buttons.
On the right next to the display there are two softkeys whose current
functions are indicated on the display. In the middle there are two cursor but-
tons (upwards/downwards), two buttons for accepting/dropping calls as
well as an
OK button. The numerical pad supports in addition to the numerical
characters
0...9 , the ’ * ’- and ’ # ’-key. For text entries the numerical pad can also
be used as a normal keypad.
During a connection additional functions are possible that are explained in
chapter 5 - “Operation via display and keypad“.
The operation is similar to standard mobile telephones.
FIG. 4 OPERATIONAL ELEMANTES ON THE FRONT SIDE
2
Depending on the delivery status all menus are possibly displayed in German. The configuration
of the menu language is described in CHAPTER 5.1.2.
ATTENTION Earthing
A lacking earthing can cause functional deficiencies within the unit. Because
of the “pending“ potential, unlike the protective earth conductor potential,
slight electric shocks can occur by touching the rack. These are absolutely not
dangerous, however they can be avoided totally by earthing.
!
Softkeys
Establish connection/
Accept call/
Drop/
Main menu
Keypad for dailing/
text entry
B-Kanal
shift
(only ISDN)
Confirm
Graphical
display Status window/
Mute
Mikrophone level
up/down
Ratio RX/TX
up/
down
cursor buttons/
Headset level
up/down
_
+
_
+
Mixer Preset shift
entry/
Mikrophone
