Avtech DG103 Operating instructions

- 1 -
AV TECH CORPORATION
DG103 Easy repair manual
Date: 2015/05/19
Verson 1.0
Producer:

- 2 -
Tools Introduction(工具介紹)………………………………………………………………….3
Component drawing(零件位置圖)…………………………………………………………….4
Block diagram(零件方塊圖)…………………………………………………………………..5
Easy installation(簡易接法)……………………………………………………………………6
Measurement methods–Multimeter(簡易量測方式-三用電表)……………………………….7
Repair flow chart(維修流程圖)………………………………………………………………..8
Dismantling process explanation(拆解說明)………………………………………………….9
Check the voltage-is there short circuit (短路量測方式)…………………………………..10
Repair Check point(維修確認點)……………………………………………………………..11
Repair material BOM list(維修物料清單)…………………………………………………….12
Quickly repair(簡易維修)……………………………………………………………………..13
Check the IR-cut module and LED board status 確認切換模組及燈板狀況…………………18
Quickly repair for LED Board(燈板簡易維修)………………………………………………..19
Solve power issue,when power can not Successfully open(解決電源無法正常開啟問題)……20

- 3 -
Equipment&Tools Introduction(工具介紹)
三用電表(Multimeter)
烙鐵(Soldering iron)
示波器(Oscilloscope)
Suggestion:40MHz or 100MHz
螢幕(Monitor)
變壓器 DC 12V(Adapter DC 12V)

- 4 -
Component drawing(零件位置圖)
Sensor Board(TOP) Sensor Board(Bottom)
LED Board(TOP) LED Board(Bottom)

- 5 -
Block diagram(零件方塊圖)
LED Board
Top Bottom
Main Board(Senor Board)
TOP Bottom

- 6 -
Easy installation(簡易接法)
Only see the video output
Through the HDVR Can be control camera
HDMI Monitor
SDI to HDMI Converter
Power IN DC 12V
AVTECH AVT Serial HDVR
Monitor

- 7 -
Measurement methods–Multimeter
(簡易量測方式-三用電表)
Sensor Board
GND
Black probe touch GND
黑色探棒接地
Red probe touch Measuring point
紅色探棒接 測點
Change to the DC 20 voltage profile
切換到 DC 20V 檔位進行量測

- 8 -
Repair flow chart(維修流程圖)
No Video
Check power
Costomer used issue
客戶使用問題 是否維修 待議
Costomer use
Power check
Range
11.5-13.5V
Check DC12V
Check DC3V8
Check DC3V3
Check 1V5
RMA repair to
AVTECH
DC 12V
DC 3V8
DC 3V3
DC 1V5
DC 1V2
Over power range
Check 1V2
Refurbished
客戶自行整新出貨
visual investigation
Change bad material
直接更換零件
Have see the bad issue

- 9 -
Dismantling process explanation(拆解說明)
Pull out the connector
Pull out the cable
Remove the screw

- 10 -
Check the voltage-is there short circuit
(短路量測方式)
1.Use the multimeter and switch to the diode stalls.
使用三用電表並切換到二極體檔進行量測
Multimeter OFF Multimeter switch to the diode stalls
2.Do not used any power in the camera.(Please reference to voltage measurement point)
過程中不要輸入任何電源(量測零件可參考電壓量測點)
Ex:
OK NG
Short-circuit approach,please reference repair flow chart measurement voltage,if the material are
short-circuit ,do not used the same material on the board.
短路處理方式，依照電壓更換相對應零件，過程中拆下零件就必須量測確認是否短路，才可以上件，避
免重覆零件燒毀。
Do not used power
請勿使用電源

- 11 -
Repair Check point(維修確認點)
U201 DC1V5
U301 DC3V3
R702 DC12V
C504 DC3V8
U302 DC3V3
UT01 DC1V2

- 12 -
Repair material BOM list(維修物料清單)
Sensor Board
Location Part Number Part Name
Q701 PQ2SB1132SO89 P2SB1132(SOT89)
R704 PR472/0402-00 P4K7(0402)
Q702 PQBTA1576SC70 PBTA1576S3(SC70)
IC501 PU-FR9801-110 PFR9801S6CTR(SOT23-6)
L502 PL4U7/2512-00 P4.7uH(2512)/GNR2512PL
U301 PUAT5231330C0 PAT5231-3.3KE(SOT25) 3.3V
U302 PUAT5231330C0 PAT5231-3.3KE(SOT25) 3.3V
LT301 PB601/1005-00 P600(1005)/FBMA-11-100505-601A03T
300mA
LT302 PB601/1005-00 P600(1005)/FBMA-11-100505-601A03T
300mA
LT303 PB601/1005-00 P600(1005)/FBMA-11-100505-601A03T
300mA
U201 PUAT5231150C0 PAT5231-1.5KE(SOT25) 1.5V
UT01 PUAT5231120C0 PAT5231-1.2KE(SOT25) 1.2V
IC3 PUHT66F30-2E1 PIC-MCU HT66F30(SSOP16) 燒錄
LED Board
Location Part Number Part Name
D13.D16 D22 D24 D27 D32 D35
D11 D12 D14 D15 D17 D21 D23
D25 D26 D31 D33 D34
PDIR850ND5-9D PLED IR 5mm 850nM 70d<AV0327>(14
mil)(WATER CLEAR)
IR-CUT module
Part Number Part Name
POIRCUT010-00 PIR-CUT M12 02305226-0001

- 13 -
Quickly repair(簡易維修)
DC 12V
請依照圖片標示位置進行量測
Please follow the picture indicate the location to measurement.
若無電壓值請進行更換零件動作
If there have no voltage ,please change material.
Test sequence 測試順序
Q701->R704->Q702
Q701 DC12V
R704 DC12V
Q702 DC10V

- 14 -
DC 3V8
請依照圖片標示位置進行量測
Please follow the picture indicate the location to measurement.
若無電壓值請進行更換零件動作
If there have no voltage ,please change material.
Test sequence 測試順序
IC501->L502
IC501 Pin6 DC4V
IC501 Pin1 DC9V
L502 DC3V8

- 15 -
DC 3V3
請依照圖片標示位置進行量測
Please follow the picture indicate the location to measurement.
若無電壓值請進行更換零件動作
If there have no voltage ,please change material.
Test sequence 測試順序
U301->U302->LT301->LT302->LT303
U301 Pin1 DC3V8
U301 Pin5 DC3V3
U302 Pin1 DC3V8
U302 Pin5 DC3V3
LT303 DC3V3
LT302 DC3V3
LT301 DC3V3

- 16 -
DC 1V5
請依照圖片標示位置進行量測
Please follow the picture indicate the location to measurement.
若無電壓值請進行更換零件動作
If there have no voltage ,please change material.
Test sequence 測試順序
U201
U201 Pin1 DC3V8
U201 Pin5 DC1V5

- 17 -
DC 1V2
請依照圖片標示位置進行量測
Please follow the picture indicate the location to measurement.
若無電壓值請進行更換零件動作
If there have no voltage ,please change material.
Test sequence 測試順序
UT01
UT01 Pin1 DC3V3
UT01 Pin5 DC1V2

- 18 -
Check the IR-cut module and LED board
status 確認切換模組及燈板狀況
Check the LED module status 確認 LED 狀況
Check the IR Cut module status 確認 IR-Cut 模組狀況
Main board and LED Board
need to combine Find the Light sensor location
Blank the light sensor
And see the LED status
Blank the light sensor The picture are B/W mode
and LED turn on

- 19 -
Quickly repair for LED Board(燈板簡易維修)
NG OK
OK NG
If the measured value of 1 indicates diode is damaged.
若量測數量為 1表示零件已經損壞
Please change diode materila.
請更換零件
Some LED part damage
Multimeter switch to the diode stalls
切換到二極體檔位
Measurement diode
量測二極體兩端

- 20 -
Check the IR-CUT status 檢測 IR-CUT 問題
If installation of AVTECHAVT series can be directly reply to the factory setting.
若有裝設 AVTECH AVT 系列 可直接透過 HDDVR 進行回覆出廠設定動作
Check the day night mode status (If see different status please change IR-CUT module.)
Night mode Day mode
Setting ADVANCED CONFIG Select DCCS mode and SETUP mode
Enter 6.SYSTEM setting
Enter 5.FACTORY setting and
select OFF to NO
Enter 1.SAVE/EXIT
