AWA TFTD51 User manual

20.1"TFT LCDTV & MONITOR
English

Table of Contents
Important Safety Information

Control and Function 
Front and Side View
Rear View

Accessories

Features of the Remote Control Unit
Loading the Batteries
Reception Range of Remote Control Unit

Connection
Connecting VHF and UHF Antennas
Connecting a VCR (Composite Video)
Connecting a VCR (S-VIDEO)
Connecting a DVD Player (Component Video)
Connecting a DTV Receiver
Connecting a PC (RGB)

Remote Controller Key Functions

OSD Menu Structure

Picture Menu

Sound Menu

TV-Channel Menu

Function Menu

Pc Menu

OSD Menu

Teletext Operating

Compatible Display Monitor Specification

Troubleshooting

Specification
1

4
4
5

6

7
7
7

8
8
9
10
11
12
13

14

16

17

18

19

20

21

22

23

25

26

27
...................................

...........................................
......................................
.................................................

......................................................

..........................
.....................................
................

.......................................................
.....................
...................
............................
...........
..............................
..................................

.............................

............................................

.....................................................

.....................................................

...............................................

...................................................

..........................................................

........................................................

..............................................

....................

.................................................

.....................................................

Important Safety Information
-1-
Always be careful when using your LCD TV. To reduce the risk of fire, electrical shock, and other injuries,
keep these safety precautions in mind when installing, using, and maintaining your machine.
Read all safety and operating instructions before operating your LCD TV.
Keep the safety and operating instructions for future reference.
Read all warnings on the LCD TV and in the operating instructions.
WARNING
This is Class B product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
FCC NOTICE
This device has been tested and found to comply with the limits for a Class B device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a commercial, industrial or business environment. This equipment can generate, use and radiate radio
frequency energy and, if not installed and used in accordance with the instruction, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures :
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Changes or modification not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
Connecting of peripherals requires the use of grounded shielded signal cables.
WARNING
WARNING: To reduce the risk of electric shock do not remove cover or back. No
user-serviceable parts inside. Refer servicing to qualified service personnel.
The lightning flash with
arrow-head within a triangle
is intended to tell the uesr
that parts inside the product
are a risk of electric shock to
persons.
The exclamation point within
a triangle is intended to tell
the user that important
operating and servicing
instructions are in the papers
with the appliance.

Important Safety Information
-2-
Important Safeguards forYou andYour New Device
Always be careful when using your LCD TV.To reduce the risk of fire, electric shock, and other injuries,
keep these safety precautions in mind when installing, using, and maintaining your LCD TV.

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions

5. Do not use this device near water.

6. Clean only with a dry cloth.

7. Do not block any of the ventilation openings.

8. Install according to the manufacturer's instructions.Do not install near heat sources such as
radiators, heat registers, stoves, or any other apparatus (including amplifiers) that produces heat.

9. Do not defeat the safety purpose of the polarised or grounding type plug. A polarised plug has two
blades, one wider than the other. A grounding type plug has two blades and a third grounding
prong.The wide blade or the third prong is provided for your safety.When the plug provided does
not fit into your outlet, consult an electrician to replace the obsolete outlet.

10. Protect the power cord from being walked on or pinched, particularly at the plugs, convenience
receptacles, and the point where they exit from the device.

11. Use only attachments/accessories specified by the manufacturer.

12. Use only with a cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the device.When using a cart, use caution
when moving the cart/device combination to avoid injury from tip-over.
13. Unplug this device during lightning storms or when not used for long
periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required
when the device has been damaged in any way, such as when the power supply cord or plug is
damaged; liquid has been spilled or objects have fallen into the device; the device has been
exposed to rain or moisture, does not operate normally, or has been dropped.

15. Do not place this device on a slippery or tilted surface, or on an unstable cart, stand, tripod,
bracket, or table.The device may slide or fall, causing serious injury to a child or adult and serious
damage to the device.

16.When mounting the device, follow the manufacturer's instructions, and use a mounting accessory
recommended by the manufacturer.


Important Safety Information
-3-
17. Avoid overhead power lines. Do not place an outside antenna system in the vicinity of overhead
power lines or other electric light or power circuits, or where it could fall into such power lines or
circuits.When installing an outside antenna system, be extremely careful not to touch the power
lines or circuits.Contact with such lines can be fatal.

18. If an outside antenna or cable system is connected to 
the device, be sure the antenna or cable system is 
grounded so as to provide some protection against 
voltage surges and built-up static charges. Article 
810 of the U.S. National Electrical Code, ANSI/NFPA 
70 provides information with regard to proper 
grounding of the mast and supporting structure, 
grounding of the lead-in wire to an antenna discharge 
unit, size of grounding conductors, location of 
antenna-discharge unit, connection to grounding 
electrodes, and requirements for the grounding 
electrode.

19. Never push objects of any kind through the openings into this device as they may touch dangerous
voltage points or short out parts and cause a fire or electric shock. Never spill liquid of any kind on
the device.

20. If you make adjustments yourself, adjust only the controls covered in the operating instructions.
Adjusting other controls may result in damage, and will often require extensive work by a
qualified technician to restore the LCD TV to normal.

21.When replacement parts are required, be sure the service technician uses replacement parts
specified by the manufacturer that have the same characteristics as the original part.
Unauthorised substitutions may result in fire, electric shock, or other hazards.

22. Upon completion of any service or repair to this device, ask the service technician to perform
routine safety checks to determine that the device is in proper operating condition.

23. CAUTION regarding Placement
To maintain proper ventilation, be sure to leave a space around the unit (from the largest outer
dimensions including projections) equal to or greater than:
Left and right Panels :10cm
Rear Panel : 10cm
Top Panel : 50cm
The ventilation should not be impeded by covering the ventilation slots with items,
such as newspapers, table-cloths, curtains, etc.
No naked flame sources, such as lighted candles, should be placed on the apparatus.


Control and Function
-5-
1. DC INPUT(12V)
Connect the female end of the adapter DC12V out to the DC input
receptacle on the LCD TV.
Then, adapt plug the male end of the power cord to an AC outlet.

2.PC RGB(D-sub 15pin) 
Input an analog RGB signal from your PC.

3.SCART or RCA VIDEO 
Connect the end of SCART or RCA (Yellow, White, Red) cable to the terminals 
on the back of the LCDTV.

4. S-VHS
Input an S-VHS signal from VCR or DVD players.

5.Component Input(Y,Pb,Pr) 480i,480p,720p,1080i 
Input a video signal from a DVD player or DTV receiver.

6. Component Audio(L,R)
Input a audio signal from a DVD player or DTV receiver.

7. PC AUDIO 
Input an audio signal from your PC receiver.

8. Headphone Audio Output
Audio signal output to external audio Headphone.

9.TUNER
RF Antenna Input

CAUTION
Be sure to turn off the power of your computer before connecting the monitor.
*RearView
1 2 3 4 5 6 7 8 9
*SCART
*RCA

Accessories
-6-
*Standard Accessories
*Option Accessories

Features of the Remote Control Unit
-7-
*Installing Batteries
*Reception Range of Remote Control Unit
* Open the battery compartment cover on the
back of the remote control and insert the
batteries with correct polarity, match "+" with
"+",and match "-" with"-"

* Install two 1.5V "AAA" batteries.
Don't mix used batteries with new batteries.
30 30
5m(Front)
Left Front
20 20
Upper
Lower

Connection
-8-
*ConnectingVHF and UHF Antennas
Connecting an Outdoor Antenna
For the best reception, we recommend you use an outdoor antenna. Severely
weathered antennas and antenna cables can reduce the signal quality. Before making
any connections, inspect all antenna hardware; any service center can explain the
various outdoor antennas available to you.
300-Ohm Flat wire
1. Connect the 300-ohm flat wire to the screws on the 300-ohm adapter.
2. Push the end of 300- to 75-ohm adapter into the 75-ohm antenna jack.
75-Ohm Coaxial cable
1. Connect the 75-ohm coaxial cable directly to the 75-ohm antenna jack.
Connecting a CATV Cable
If you subscribe to a CATV system, make the antenna connection as described below.
1. Remove the 300-ohm to 75-ohm adapter or the cable from the TV, if attached.
2. Connect the CATV cable (75-ohm coaxial cable) to the antenna jack.

Connection
-9-
Connect SCART cable (not supplied) to the SCART jack on 
the LCD TV
and the SCART output jack on the external equipments.
(DVD/VCR, etc.,)
1.Turn on your external equipments (DVD/VCR. etc.,)
and press the play button.
2.Turn on the LCD TV and press the TV/AV button
on the LCD TV remote control.
3. Select the AV mode.
*Connecting aVCR(Composite Video)
*SCART
*RCA
Back panel of the TV
Back panel of the TV
To play DVD/VCR :

Remote Controller Key Functions
-15-
16.MTS Button
Selects the language durind dual language Broadcast,
selects sound output.

17.PREVIEW Button
Go back to previous TV channel

18.TTX Button
Select Teletext display/Return to TV picture display.

19.RED/GREEN/YELLOW/CYAN Button
Change to associated page in the display block according 
to the acquisition mode while teletext operating.
*INPUT :
Selects the AV source of sub picture in PIP mode.
*SIZE :Selects the size of the sub picture
*POSITION:Selects a position of PIP screen.

20.MIX Button
TO display the teletext page simultaneously with the 
actual broadcast.

21.INDEX Button
Return to index page in teletext mode.

22.LIST/FLOF Button
Press the LIST / FLOF button to change LIST and FLOF.

23.STORE Button
Memorize the change by holding down the STORE button

24.HOLD Button
Toggle hold on or off for current display page In teletext 
mode.

25.SIZE Button
Page expend in teletext mode.

26.REVEAL Button
Reveal hidden text, such as Solutions of Riddles or 
puzzles in teletext mode.

27.SUBPAGE
Select Sub page in teletext mode.
*When using the remote control aim it at the remote control sensor on the TV
17
18
23
27
22
26
19
16
20
24
21
25

OSD Menu Structure
-16-
* OSD (On Screen Display) menu allows user to control or adjust various features and settings in 
accordance with his/her preferences.

* Press the Menu button on the Remote Control Unit, you may see the OSD menu.
