AXIOMTEK eBOX560-500-FL Series User manual

eBOX560-500-FL Series
Embedded System
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
Copyright 2019 Axiomtek Co., Ltd.
All Rights Reserved
Dec 2019, Version A2
Printed in Taiwan

iii
Safety Precautions
Before getting started, please read the following important safety precautions.
1. The eBOX560-500-FL does not come equipped with an operating system. An operating
system must be loaded first before installing any software into the computer.
2. Be sure to ground yourself to prevent static charge when installing the internal
components. Use a grounding wrist strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
3. Disconnect the power cord from the eBOX560-500-FL before making any installation. Be
sure both the system and the external devices are turned OFF. Sudden surge of power
could ruin sensitive components. Make sure the eBOX560-500-FL is properly grounded.
4. Make sure the voltage of the power source is correct before connecting the equipment to
the power outlet.
5. Turn OFF the system power before cleaning. Clean the system using a cloth only. Do not
spray any liquid cleaner directly onto the screen.
6. Do not leave this equipment in an uncontrolled environment where the storage
temperature is below -40℃or above 80℃. It may damage the equipment.
7. Do not open the system’s back cover. If opening the cover for maintenance is a must,
only a trained technician is allowed to do so. Integrated circuits on computer boards are
sensitive to static electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
Before handling a board or integrated circuit, touch an unpainted portion of the
system unit chassis for a few seconds. This will help to discharge any static electricity
on your body.
When handling boards and components, wear a wrist-grounding strap, available from
most electronic component stores.
8. CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS

iv
Classification
1. Degree of production against electric shock : not classified
2. Degree of protection against the ingress of water : IP40
3. Equipment not suitable for use in the presence of a flammable anesthetic mixture with air
or with oxygen or nitrous oxide.
4. Mode of operation : Continuous

v
General Cleaning Tips
You may need the following precautions before you begin to clean the computer. When you
clean any single part or component for the computer, please read and understand the details
below fully.
When you need to clean the device, please rub it with a piece of dry cloth.
1. Be cautious of the tiny removable components when you use a vacuum cleaner to
absorb the dirt on the floor.
2. Turn the system off before you start to clean up the component or computer.
3. Never drop the components inside the computer or get circuit board damp or wet.
4. Be cautious of all kinds of cleaning solvents or chemicals when you use it for the sake of
cleaning. Some individuals may be allergic to the ingredients.
5. Try not to put any food, drink or cigarette around the computer.
Cleaning Tools:
Although many companies have created products to help improve the process of cleaning
your computer and peripherals users can also use household items to clean their computers
and peripherals. Below is a listing of items you may need or want to use while cleaning your
computer or computer peripherals.
Keep in mind that some components in your computer may only be able to be cleaned using a
product designed for cleaning that component, if this is the case it will be mentioned in the
cleaning.
Cloth: A piece of cloth is the best tool to use when rubbing up a component. Although
paper towels or tissues can be used on most hardware as well, we still recommend you
to rub it with a piece of cloth.
Water or rubbing alcohol: You may moisten a piece of cloth a bit with some water or
rubbing alcohol and rub it on the computer. Unknown solvents may be harmful to the
plastics parts.
Vacuum cleaner: Absorb the dust, dirt, hair, cigarette particles, and other particles out of
a computer can be one of the best methods of cleaning a computer. Over time these
items can restrict the airflow in a computer and cause circuitry to corrode.
Cotton swabs: Cotton swaps moistened with rubbing alcohol or water are excellent tools
for wiping hard to reach areas in your keyboard, mouse, and other locations.
Foam swabs: Whenever possible it is better to use lint free swabs such as foam swabs.
Note: We strongly recommended that you should shut down the system before you
start to clean any single components.
Please follow the steps below:
1. Close all application programs
2. Close operating software
3. Turn off power switch
4. Remove all device
5. Pull out power cable

vi
Scrap Computer Recycling
If the computer equipment’s needs the maintenance or are beyond repair, we strongly
recommended that you should inform your Axiomtek distributor as soon as possible for the
suitable solution. For the computers that are no longer useful or no longer working well, please
contact your Axiomtek distributor for recycling and we will make the proper arrangement.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Intel®and Pentium®are registered trademarks of Intel Corporation.
MS-DOS, Microsoft C and QuickBasic are trademarks of Microsoft Corporation.
Windows 8.1, Windows 10, Linux and other brand names and trademarks are the
properties and registered brands of their respective owners.

vii
Table of Contents
Disclaimers.............................................................................................................ii
Safety Precautions................................................................................................iii
Classification......................................................................................................... iv
General Cleaning Tips ........................................................................................... v
Scrap Computer Recycling................................................................................... vi
CHAPTER 1 INTRODUCTION .......................................................................1
1.1 General Description...........................................................................1
1.2 System Specifications.......................................................................2
1.2.1 CPU ...................................................................................................................2
1.2.2 I/O System ........................................................................................................2
1.2.3 System Specification.......................................................................................3
1.2.4 Driver CD Content............................................................................................3
1.3 Dimensions ........................................................................................4
1.3.1 System Dimension...........................................................................................4
1.3.2 Wall mount Bracket Dimension......................................................................5
1.3.3Din-rail mount Bracket Dimension.................................................................6
1.3.4VESA mount Bracket Dimension....................................................................7
1.4 I/O Outlets......................................................................................... 8
1.5 Packing List........................................................................................9
CHAPTER 2 HARDWARE INSTALLATION.................................................11
2.1Installing the 2.5” SATA Device ......................................................11
2.2Installing the Express Mini Card..................................................... 13
2.3Installing the SO-DIMM Memory .....................................................15
CHAPTER 3 JUMPER SETTING & CONNECTOR......................................17
3.1 Jumper & Connector Location........................................................ 17
3.2 Jumper Setting Summary................................................................19
3.2.1Restore BIOS Optimal Defaults (JP1) ..........................................................19
3.2.2 AT/ATX Quick Switch ....................................................................................20
3.3 Connectors.......................................................................................21
3.3.1 DC Power Jack w/ Screw (CN14)..................................................................22
3.3.2Ethernet Port (LAN1/LAN2) ...........................................................................22
3.3.3HDMI Connector (CN15)................................................................................22
3.3.4COM Serial Port Connector ..........................................................................23
3.3.5USB 3.0 Connector ........................................................................................24
3.3.6System Power Switch....................................................................................25
3.3.7System Reset Switch.....................................................................................25
3.3.8Express Mini Card Slot..................................................................................26
3.3.9Power and HDD LED Indicator .....................................................................26
CHAPTER 4 BIOS SETUP UTILITY ............................................................27
4.1 Starting............................................................................................. 27
4.2 Navigation Keys............................................................................... 27
4.3 Main Menu........................................................................................ 28

viii
4.4 Advanced Menu................................................................................ 29
4.5 Chipset Menu ...................................................................................39
4.6 Security Menu .................................................................................. 46
4.7 Boot Menu ........................................................................................47
4.8 Save & Exit Menu............................................................................. 48
APPENDIX A WATCHDOG TIMER..............................................................51
About Watchdog Timer ................................................................................... 51
How to Use Watchdog Timer.......................................................................... 51
Sample Program.............................................................................................. 51

eBOX560-500-FL Series User’s Manual
Introduction
1
CHAPTER 1
INTRODUCTION
This chapter contains general information and detailed specifications of the eBOX560-500-FL.
The Chapter 1 includes the following sections:
General Description
System Specifications
Dimensions
I/O Outlets
Packing List
Model List
1.1 General Description
The eBOX560-500-FL is an embedded system that supports Intel®CoreTM i7-6600U
3.4 GHz/ Celeron®3955U 2.0 GHz onboard to support Windows 8.1, Windows 10,
AXVIEW 2.0 and Linux, suitable for the most endurable operation.
It features fan less design with full feature I/O, one 260-pin unbuffered SODIMM
socket for one channel DDR4-2133 MHz memory, and enhanced system
dependability by built-in Watchdog Timer.
Features
1. 6th generation Intel® CoreTM i7-6600U 3.4 GHz / Celeron®3955U 2.0 GHz
2. Maximum up to 16 GB SO-DIMM DDR4- 2133 MHz memory capacity
3. Fan-less design with compact size
4. Supports 4 USB 3.0 ports
5. Supports 1 RS-232/422/485 and 1 RS-232
6. Supports 2 10/100/1000Mbps Ethernet ports
(One port support Wake on LAN,PXE Boot ROM with i219LM)

eBOX560-500-FL Series User’s Manual
Introduction
2
7. Supports ATX power button
8. Supports Reset button
9. Two HDMI
10. One 2.5” SATA HDD drive bay
11. One PCI Express Mini Card Slots w/ mSATA supported.
12. Watchdog timer
13. 12V DC power input
14. Two Antenna openings
15. One AT/ATX mode quick switch
16. Option Wall / VESA / DIN Rail Mounting Kits
Reliable and Stable Design
The eBOX560-500-FL adopts the advanced cooling system and supporting the mSATA,
which makes it especially suitable for vibration environments, best for industrial
automation, digital signage and gaming application.
Embedded O.S. Supported
The eBOX560-500-FL not only supports Windows 8, Windows 8.1, and Windows 10 but
also supports embedded OS, such as Windows 7 Embedded, Windows 8 Embedded,
Windows 10 IoT and Linux.
Various Storage devices supported
For storage device, the eBOX560-500-FL supports one 2.5" SATA storage drive bay and
one mSATA device.
1.2 System Specifications
1.2.1 CPU
CPU
Intel®CoreTM i7-6600U 3.4 GHz / Celeron®3955U 2.0 GHz
Chipset
Intel®Braswell quad-cord SoC
BIOS
American Megatrends Inc. UEFI (Unified Extensible Firmware Interface)
BIOS.
System Memory
One 260-pin unbuffered DDR4-2133 MHz SO-DIMM socket, max. up to 16
GB
1.2.2 I/O System
One jumper-less RS-232/422/485 9-pin D-Sub male connector (COM1)
One RS-232 9-pin D-Sub male connector (COM2)
Two HDMI for display (FHD)
Two RJ-45 connectors for 10/100/1000 Base-T Ethernet ports (i210AT & i219LM)
Four USB 3.0 connectors
One PCI Express Mini Card Slots w/ mSATA supported.
One Reset switch
One ATX Power switch
Two SMA type connector opening for Antenna

eBOX560-500-FL Series User’s Manual
Introduction
3
12 VDC Power jack connector
Two Indicators LED (System Power, HDD Active)
One AT/ATX Quick switch
1.2.3 System Specification
Watchdog Timer
1~255 seconds or minutes; up to 255 levels.
Power Supply
Input : 12VDC
Operation Temperature
-10℃~+50℃(-14°F~+122°F), with W.T. SSD & Memory
Storage Temperature
-40℃~ 80℃(-40 ºF ~ 176ºF)
Humidity
10% ~ 90% (non-condensation)
Vibration Endurance
3Grm w/ SSD (5-500Hz, X, Y, Z directions)
Weight
0.8 kg(1.76lb) without package
1.67 kg(3.68lb) with package
Dimensions
141.5 mm(5.57”) (W) x 106 mm(4.17”) (D) x 55 mm(217”) (H)
1.2.4 Driver CD Content
Driver
Chipset
Ethernet
Graphic
USB 3.0 hot fix for Windows 8.x
ME
Manual
User Manual
Quick Manual
Note: All specifications and images are subject to change without notice.

eBOX560-500-FL Series User’s Manual
Introduction
4
1.3 Dimensions
The following diagrams show you dimensions and outlines of the eBOX560-500-FL.
1.3.1 System Dimension

eBOX560-500-FL Series User’s Manual
Introduction
5
1.3.2 Wall mount Bracket Dimension
Instruction
Step 1: Screw the two pieces of wall-mount kits to the bottom plate of the device. Total four
screws (metric 3 x6) are required.
Step 2: Use the device, with wall mount plate attached, as a guide to mark the correct
locations of the four screws.
Step 3: Insert a tapping-screw (thread diameter less than 4mm) head through middle of the
keyhole-shaped aperture on the plate, and then slide the device downwards. Tighten the
screw head for added stability.

eBOX560-500-FL Series User’s Manual
Introduction
6
1.3.3 Din-rail mount Bracket Dimension
Instruction
Step 1: Screw the Din rail mount Bracket to the bottom plate of the device. Total of four
screws (metric 3 x6) are required.
Step 2: Screw the Din rail bracket (722C9000300E) and the Din rail mount bracket together.
Total four screws (Flat Head M3 x4) are required.
Step 3: Users can install the eBOX560 in din-rail bracket through din-rail bracket kit.

eBOX560-500-FL Series User’s Manual
Introduction
7
1.3.4 VESA mount Bracket Dimension
Instruction
Step 1: Please refer to above photo to screw the VESA mount bracket kit with the bottom
plate of the device. Total four screws (metric 3 x6) are required.
Step 2: Insert four screws into the VESA hole of monitor and reserved a gap about
1.2~1.5mm.
Step 3: Users can hang the eBOX560 through VESA bracket on the monitor.

eBOX560-500-FL Series User’s Manual
Introduction
8
1.4 I/O Outlets
The following figures show you I/O outlets on front view of the eBOX560-500-FL.
Front View drawing
Rear View drawing

eBOX560-500-FL Series User’s Manual
Introduction
9
1.5 Packing List
The package bundled with your eBOX560-500-FL should contain the following items:
eBOX560-500-FL System Unit x 1
eBOX560-500-FL Quick Installation Guide x 1
DVD x 1 (For Driver and Manual)
Screws Pack x 1
Pre-installed Foot pad x 4
Optional 12V/60W adapter
Optional Power cord
Optional DDR4 SO-DIMM Memory
Optional Wall-mount kit
Optional VESA / DIN-Rail kit
Optional Antenna
Optional Mini Card module
Optional 2.5" SATA Storage
Optional mSATA
If you cannot find this package or any items are missing, please contact Axiomtek distributors
immediately.

eBOX560-500-FL Series User’s Manual
Introduction
10
This page is intentionally left blank.

eBOX560-500-FL Series User’s Manual
Hardware Installation
11
CHAPTER 2
HARDWARE INSTALLATION
The eBOX560-500-FL is convenient for your various hardware configurations, such as HDD
(Hard Disk Drive), SSD (Solid State Drive) or PCI Express Mini Card modules. The chapter 2
will show you how to install the hardware.
2.1 Installing the 2.5”SATA Device
Step 1 Turn off the system, and unplug the power adaptor.
Step 2 Turn the system upside down to locate screws at the bottom, loosen
screws.
Step 3 Remove the bottom cover.
Step 4 Please find the HDD bracket location then loosen four screws of HDD
bracket to take out it.
Step 5 Please prepare the following items to assemble HDD.

eBOX560-500-FL Series User’s Manual
Hardware Installation
12
Step 6 Fasten total four screws to fix HDD/SSD.
※Please notice that you should base on the photo to check the direction of HDD.
Step 7 Lock the HDD and fasten screws then connect SATA & Power cables.
Step 8 Please fasten screws of HDD bracket to complete first HDD installation.
