CAPA318 3.5”Board
Introduction 1
Chapter 1
Introduction
The CAPA318, a 3.5”board, supports Intel®Pentium®N4200 and Celeron®N3350. It delivers
outstanding system performance through high-bandwidth interfaces, multiple I/O functions for
interactive applications and various embedded computing solutions.
The CAPA318 comes with one 204-pin unbuffered SO-DIMM socket for single channel DDR3L
1600MHz memory, maximum memory capacity up to 8GB. There are two Gigabit/Fast
Ethernet ports, one SATA port with transfer rate up to 6Gb/s, two USB 3.0 and two USB 2.0
high speed compliant, and built-in HD audio codec that can achieve the best stability and
reliability for industrial applications. Additionally, it provides you with unique embedded
features, such as two serial ports (RS-232) and 3.5”form factor that applies an extensive array
of PC peripherals.

CAPA318 3.5”Board
2 Introduction
1.1 Features
Intel®Pentium®quad core N4200 (1.1GHz) and Celeron®dual core N3350 (1.1GHz)
1 DDR3L SO-DIMM supports up to 8GB memory capacity
2 USB 3.0 ports and 2 USB 2.0 ports
2 COM ports
2 PCI-Express Mini Card
+12V only DC-in supported
1.2 Specifications
CPU
Intel®Pentium®quad core N4200 1.1GHz.
Intel®Celeron®dual core N3350 1.1GHz.
Thermal Solution
Passive.
Operating Temperature
-20°C~+70°C.
BIOS
American Megatrends Inc. UEFI (Unified Extensible Firmware Interface) BIOS.
64Mbit SPI Flash, DMI, Plug and Play.
PXE Ethernet Boot ROM.
System Memory
One 204-pin unbuffered DDR3L SO-DIMM socket.
Maximum up to 8GB DDR3L 1600MHz memory.
Onboard Multi I/O
Controller: ITE8528.
Serial Ports: Two RS-232 ports.
Serial ATA
One SATA-600 connector.
mSATA supported.
USB Interface
Two USB 3.0 ports on the rear I/O.
Two USB 2.0 ports in 2x5-pin internal wafer connector.
Display
One 15-pin D-Sub as VGA connector. The resolution is up to 1920x1200.
One 2x20-pin connector for 18/24-bit single/dual channel LVDS and one 8-pin
inverter connector. LVDS resolution is up to 1920x1200 in 24-bit dual channels.

CAPA318 3.5”Board
Introduction 3
Watchdog Timer
Timeout value range is 1~65535 seconds.
Ethernet
Two RJ-45 LAN ports: Intel®i211AT supports 1000/100/10Mbps Gigabit/Fast
Ethernet with Wake-on-LAN and PXE Boot ROM.
Audio
HD audio compliant with Realtek ALC662.
Line-out and line-in/MIC-in via internal box header.
Expansion Interface
One full-size PCI-Express Mini Card socket with PCI-Express and USB support and
complies with PCI-Express Mini Card Spec. V1.2.
One full-size PCI-Express Mini Card socket with SATA and USB support.
Power Input
One 2x2-pin connector.
+12V DC-in only.
Auto power on function supported.
Power Management
ACPI (Advanced Configuration and Power Interface).
Form Factor
3.5”form factor.
Note
All specifications and images are subject to change without notice.
1.3 Utilities Supported
Chipset and graphics driver
Ethernet driver
Audio driver
Serial IO driver
Trusted Execution Engine

CAPA318 3.5”Board
4 Introduction
This page is intentionally left blank.

CAPA318 3.5”Board
Board and Pin Assignments 5
Chapter 2
Board and Pin Assignments
2.1 Board Dimensions and Fixing Holes
Top View

CAPA318 3.5”Board
6 Board and Pin Assignments
Bottom View
Side View

CAPA318 3.5”Board
Board and Pin Assignments 7
2.2 Board Layout
Top View
Side View

CAPA318 3.5”Board
8 Board and Pin Assignments
Bottom View

CAPA318 3.5”Board
Board and Pin Assignments 9
2.3 Jumper and Switch Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. Below illustration
shows how to set up jumper.
Properly configure jumper and switch settings on the CAPA318 to meet your application
purpose. Below you can find a summary table of jumpers, switch and onboard default settings.
Note
Once the default jumper or switch setting needs to be changed, please do it under
power-off condition.
Jumper and Switch
Description
Setting
JP1
LVDS +3.3V/+5V/+12V Voltage Selection
Default: +3.3V
1-2 Close
JP2
Restore BIOS Optimal Defaults
Default: Normal Operation
1-2 Close
SW1
Auto Power On
Default: Disable
1-2 Close

CAPA318 3.5”Board
10 Board and Pin Assignments
2.3.1 LVDS +3.3V/+5V/+12V Voltage Selection (JP1)
This is a 2x3-pin (pitch=2.0mm) jumper. The board supports voltage selection for flat
panel displays. Use these jumpers to set LVDS connector (CN5) pin 1~6 VCCM to +3.3V,
+5V or +12V. To prevent hardware damage, before connecting please make sure that
the input voltage of flat panel is correct.
2.3.2 Restore BIOS Optimal Defaults (JP2)
This is a 1x3-pin (pitch=2.0mm) jumper. Put jumper clip to pin 2-3 for a few seconds then
move it back to pin 1-2. Doing this procedure can restore BIOS optimal defaults.
2.3.3 Auto Power On (SW1)
If SW1 is enabled for power input, the system will be automatically power on without
pressing soft power button. If SW1 is disabled for power input, it is necessary to
manually press soft power button to power on the system.
Function
Setting
+3.3V level (Default)
1-2 close
+5V level
2-4 close
+12V level
5-6 close
Function
Setting
Normal (Default)
1-2 close
Restore BIOS optimal defaults
2-3 close
Function
Setting
Disable auto power on (Default)
1-2 close
Enable auto power on
2-3 close

CAPA318 3.5”Board
Board and Pin Assignments 11
2.4 Connectors
Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table of connectors on the hardware.
Connector
Description
CN1
USB 2.0 Wafer Port 3 and 4
CN2
Front Panel Connector
CN3
Inverter Connector
CN4
I2C Connector
CN5
LVDS Connector
CN6
SMBus Connector
CN9
SATA Power Connector
CN11
Digital I/O Connector
CN12
COM2 Wafer Connector]
CN13
Audio Connector
CN14
Audio Jack
FAN1
Fan Connector
COM1
COM1 Connector
SATA1
SATA Connector
USB1
USB 3.0 Port 1 and 2
VGA1
VGA Connector
ATX1
ATX Power Connector
LAN1~2
Ethernet Port 1 and 2
SCN1
Full-size PCI-Express Mini Card and mSATA Connector
SCN2
Full-size PCI-Express Mini Card Connector
SCN3
SIM Card Slot
SDIMM1
DDR3L SO-DIMM Connector

CAPA318 3.5”Board
12 Board and Pin Assignments
2.4.1 USB 2.0 Wafer Connector (CN1)
This 2x5-pin (pitch=2mm) wafer which is compliant with Hirose DF11-xdp-2dsa and a
Universal Serial Bus (USB) connector for installing versatile USB 2.0 compliant interface
peripherals.
2.4.2 Front Panel Connector (CN2)
Power Status
Pin 1 and pin 2 are for power status button; letting user know the power status of this
board.
Power LED
Pin 4 connects anode (+) of LED and pin 3 connects cathode(-) of LED. The power LED
lights up when the system is powered on.
Power On/Off Button
Pin 5 and 6 connect the power button on front panel to CPU board, which allows users to
turn on or off power supply.
System Reset Switch
Pin 7 and 8 connect the case-mounted reset switch that reboots your computer without
turning off the power switch. It is a better way to reboot your system for a longer life of
system power supply.
HDD Activity LED
This connection is linked to hard drive activity LED on the control panel. LED flashes
when HDD is being accessed. Pin 9 and 10 connect the hard disk drive to the front panel
HDD LED, pin 9 is assigned as cathode(-) and pin 10 is assigned as anode(+).
Pin
Signal
Pin
Signal
1
USB VCC
(+5V_SBY)
2
USB VCC
(+5V_SBY)
3
USB #3_D-
4
USB #4_D-
5
USB #3_D+
6
USB #4_D+
7
GND
8
GND
9
GND
10
GND
Pin
Signal
Pin
Signal
1
PWR-
2
PWR+
3
PWRLED-
4
PWRLED+
5
PWRSW-
6
PWRSW+
7
HW RST-
8
HW RST+
9
HDDLED-
10
HDDLED+

CAPA318 3.5”Board
Board and Pin Assignments 13
2.4.3 Inverter Connector (CN3)
This is a DF13-8P-1.25C 8-pin (pitch=1.25mm) connector for inverter. We strongly
recommend you to use the matching DF13-8P-1.25C connector to avoid malfunction.
8 1
2.4.4 I2C Connector (CN4)
This connector is a 3-pin (pitch=1.25mm) for I2C interface.
Pin
Signal
1
VBL1 (+12V level)
2
VBL1 (+12V level)
3
VBL2 (+5V level)
4
VBL_ENABLE
5
GND
6
GND
7
GND
8
VBL Brightness Control
Pin
Signal
1
I2C_CLK_SBY
2
I2C_DAT_SBY
3
GND

CAPA318 3.5”Board
14 Board and Pin Assignments
2.4.5 LVDS Connector (CN5)
This board has a 2x20-pin (pitch=1mm) connector for LVDS LCD interface. It is strongly
recommended to use the matching JST SHDR-40VS-B connector for LVDS interface.
Pin 1~6 VCCM can be set to +3.3V, +5V or +12V by setting JP1 (see section 2.3.1).
18-bit single channel
Pin
Signal
Pin
Signal
1
VCCM
2
VCCM
3
VCCM
4
VCCM
5
VCCM
6
VCCM
7
N.C
8
N.C
9
GND
10
GND
11
N.C
12
N.C
13
N.C
14
N.C
15
GND
16
GND
17
N.C
18
N.C
19
N.C
20
N.C
21
GND
22
GND
23
Channel A D0-
24
N.C
25
Channel A D0+
26
N.C
27
GND
28
GND
29
Channel A D1-
30
N.C
31
Channel A D1+
32
N.C
33
GND
34
GND
35
Channel A D2-
36
Channel A CLK-
37
Channel A D2+
38
Channel A CLK+
39
GND
40
GND
