AXIOMTEK MANO321 Series User manual

MANO321 Series
Intel®Celeron Processor J6412
Mini ITX Motherboard
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness, or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, ortransmitted, in any
form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without
the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery and dispose of used ones.
©Copyright 2022 Axiomtek Co., Ltd.
All Rights Reserved
February 2022, Version A1
Printed in Taiwan

iii
ESD Precautions
Computer boards have integrated circuits sensitive tostatic electricity. To prevent chipsets from
electrostatic discharge damage, please take care of the following jobs with precautions:
◼Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
◼Before holding the board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. It discharges static electricity from your body.
◼Wear a wrist-grounding strap, available from most electronic component stores, when
handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Intel®and Celeron®are trademarks of Intel Corporation.
Windows®is a trademark of Microsoft Corporation.
AMI is a trademark of American Megatrend Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Other brand names and trademarks are the properties and registered brands of their respective
owners.

iv
Table of Contents
Disclaimers ......................................................................................................ii
ESD Precautions............................................................................................. iii
Section 1 Introduction .............................................. 1
1.1 Features ................................................................................................1
1.2 Specifications ........................................................................................2
1.3 Utilities Supported .................................................................................3
1.4 Block Diagram.......................................................................................4
Section 2 Board and Pin Assignments..................... 5
2.1 Board Layout.........................................................................................5
2.2 Rear I/O.................................................................................................7
2.3 Jumper Settings ....................................................................................8
2.3.1 COM1 Data/Power Select (JP1) ...............................................................9
2.3.2 COM2 ~ COM6 Data/Power Select (JP2 ~ JP6) .......................................9
2.3.3 LVDS VDD Select (JP11)..........................................................................9
2.3.4 Clear CMOS (JP12) ...............................................................................10
2.3.5 AT/ATX Power Mode Select (JP13) ........................................................10
2.4 Connectors..........................................................................................11
2.4.1 COM1 D-Sub Connector (CN1) ..............................................................12
2.4.2 COM Headers (CN2~CN6).....................................................................12
2.4.3 Front Panel Header (CN10)....................................................................13
2.4.4 Digital IO Header (CN11)........................................................................13
2.4.5 SPI Header (CN12) ................................................................................14
2.4.6 VGA Header (CN14)...............................................................................14
2.4.7 SATA 3.0 Connectors (CN15) .................................................................14
2.4.8 PCI-Express x4 Slot (CN16)...................................................................15
2.4.9 Ethernet Ports (CN17 and CN18) ...........................................................16
2.4.10 Audio Jack (CN19) .................................................................................17
2.4.11 PCI-Express Mini Card Connector (CN20)..............................................17
2.4.12 USB3.2 Gen1 Stack Ports (CN21 and CN22) .........................................18
2.4.13 HDMI Connector (CN23) ........................................................................18
2.4.14 USB 2.0 Headers (CN24 and CN25) ......................................................18
2.4.15 ATX Power Input Connector (CN26) .......................................................19
2.4.16 I2C Connector (CN27)............................................................................19
2.4.17 SMBus Connectors (CN28) ....................................................................19
2.4.18 LVDS Signal Connector (CN29)..............................................................20
2.4.19 eDP Connector (CN50) ..........................................................................21
2.4.20 SATA Power Connector (CN51) ..............................................................22
2.4.21 Audio Header (CN52).............................................................................22

v
2.4.22 LVDS Backlight Control Header (CN55)..................................................22
2.4.23 DC Jack Power Connector (DCJACK1) ..................................................22
2.4.24 CMOS Battery Connector (BAT1) ...........................................................23
2.4.25 SIM Card Slot (SCN1)............................................................................23
2.4.26 M.2 Key B Connector (SCN2).................................................................24
Section 3 AMI BIOS Setup Utility ........................... 25
3.1 Starting................................................................................................25
3.2 Navigation Keys ..................................................................................25
3.3 Main Menu ..........................................................................................27
3.4 Advanced Menu ..................................................................................28
3.5 Chipset Menu ......................................................................................42
3.6 Security Menu .....................................................................................50
3.7 Boot Menu...........................................................................................51
3.8 Save & Exit Menu................................................................................52
Appendix A Watchdog Timer .................................... 53
A.1 About Watchdog Timer........................................................................53
A.2 Sample Program .................................................................................53
Appendix B Digital I/O............................................... 55
B.1 About Digital I/O ..................................................................................55
B.2 Sample Program .................................................................................55

vi
This page is intentionally left blank.

MANO321 Mini ITX Motherboard
Introduction 1
Section 1
Introduction
The MANO321 Mini-ITX motherboard supports the Intel® Celeron Processor J6412. With two
DDR4 3200MHz memory support, this motherboard is built to perform best stability and
reliability for industrial applications.
It comes with one SATA 3.0, four USB 3.2 GEN1, four USB 2.0 and six serial ports (two
RS-232/422/485, four RS-232) providing robust storage and I/O options. Users also can
increase board functionality with PCI-Express x4 and full type PCI-Express Mini Card slot. The
high quality MANO321 allows four display interfaces via VGA, HDMI, LVDS and eDP in
quadruplicate views, making it an ideal solution for gaming, workstation, digital signage,
medical and other IoT&M2M applications.
1.1 Features
⚫Intel Celeron® J6412 Processor (Elkhart Lake)
⚫2 DDR4 3200MHz memory with maximum capacity up to 32 GB
⚫1 M.2 Key B type 2242/3042/3052
⚫1 full type PCI Express mini card
⚫4 USB 3.2 Gen 1 and 4 USB 2.0
⚫1 SATA-600

MANO321 Mini ITX Motherboard
2 Introduction
1.2 Specifications
⚫CPU
◼Intel®Elkhart Lake for Intel Celeron® J6412 Processor (TDP:10W).
⚫BIOS
◼AMI BIOS via SPI interface.
⚫System Memory
◼Two 260-pin SO-DIMM sockets.
◼Maximum up to 32GB DDR4 memory.
◼Support 3200MHz.
⚫Onboard Multi I/O
◼Six serial ports:
- COM1~COM2 supports RS-232/422/485; COM3~COM6 supports RS-232 only.
- COM1 on the rear I/O; COM2~COM6 in box headers.
⚫USB Interface
◼Four USB 3.2 Gen 1 ports (on the rear I/O).
◼Four USB 2.0 in 2x4-pin header (internal).
⚫Ethernet
◼LAN1 & LAN2: 1000/100/10Mbps Gigabit/Fast Ethernetsupports Wake-on-LAN, PXE
with RTL8111H.
⚫Serial ATA
◼One SATA 3.0 port (6Gb/s).
⚫Audio
◼Realtek Codec ALC897.
◼Support Line-out (on the rear I/O).
◼Support Line-in/MIC-in/Line-out/Speaker in box header (internal).
⚫Display
◼Intel®Integrated Graphics:
- One HDMI connector. Resolution max. up to 4096x2160 @24Hz.
- One VGA header. Resolution max. up to 1920x1200
- One 18/24-bit dual channel LVDS and one 8-pin inverter connector. LVDS
resolution is max. up to 1920x1200.
- One Embedded DisplayPort (eDP) with resolution max. up to 4096x2304
@60Hz; co-layout with LVDS (optional).
⚫Expansion Interface
◼One PCI-Express Mini Card.
◼One PCI-Express x4 slot.
◼One SIM card slot co-lay with MiniPCIE and M.2 Key B socket (Default is M.2 Key B,
by BOM option).
◼One M.2 Key B type 2242/3042/3052 includes PCIe x2, PCIe + SATA3.0, PCIe +
USB 3.2 GEN1 interfaces by BOM option. Default is PCIe + SATA3.0.

MANO321 Mini ITX Motherboard
Introduction 3
⚫Power Input
◼One 12V ATX 4-pin power input connector.
◼One 9~20V DC jack power input connector.
⚫Operating Temperature
◼0°C ~ 60°C.
⚫Storage Temperature
◼-40°C ~ 85°C.
⚫Form Factor
◼Mini ITX (6.7”x 6.7”, 17.0cm x 17.0cm).
Note
All specifications and images are subject to change without notice.
1.3 Utilities Supported
⚫Chipset driver
⚫Graphics driver
⚫Intel ME driver
⚫Ethernet driver
⚫Audio driver

MANO321 Mini ITX Motherboard
4 Introduction
1.4 Block Diagram

MANO321 Mini ITX Motherboard
Board and Pin Assignments 5
Section 2
Board and Pin Assignments
2.1 Board Layout
Top View

MANO321 Mini ITX Motherboard
6 Board and Pin Assignments
Bottom View

MANO321 Mini ITX Motherboard
Board and Pin Assignments 7
2.2 Rear I/O
Jumpers/Headers/Connectors
1
4-pin ATX Power Input Connector (CN26)
17
PCI-Express x4 Slot (CN16)
2
LVDS VDD Select Jumper (JP11)
18
I2C Header (CN27)
3
LVDS Signal Header (CN29)
19
SPI Header (CN12)
4
LVDS Backlight Control Header (CN55)
20
Audio Header (CN52)
5
AT/ATX Power Mode Select Jumper
(JP13)
21
CMOS Battery Connector (BAT1)
6
Clear CMOS (JP12)
22
COM1 Data/Power Select Jumper
(JP1)
7
DDR4 SO-DIMM Connectors (DIMM1,
DIMM2)
23
VGA Header (CN14)
8
SMBus Header (CN28)
24
M.2 Key B Connector (SCN2)
9
COM2~COM6 Headers (CN2~CN6)
25
SIM Card Slot (SCN1)
10
SATA 3.0 Connector (CN15)
26
eDP Connector (CN50)
11
SATA Power Connector (CN51)
27
DC Jack Power Connector (DCJACK1)
12
Front Panel Header (CN10)
28
HDMI Connector (CN23)
13
COM2~6 Data/Power Select Jumper
(JP2~JP6)
29
COM1 D-Sub Connector (CN1)
14
Digital I/O Connector (CN11)
30
USB 3.2 Gen1 Stack Ports (CN21,
CN22)
15
USB 2.0 Header (CN24, CN25)
31
Ethernet Ports (CN17, CN18)
16
PCI-Express Mini Card Connector (CN20)
32
Audio Jack (CN19)

MANO321 Mini ITX Motherboard
8 Board and Pin Assignments
Note
To identify the first pin of a header or jumper, please refer to the following
information:
⚫Usually, there is a thick line or a triangle near the header or jumper pin 1.
⚫Square pad, which you can find on the back of the motherboard, is usually
used for pin 1.
2.3 Jumper Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on
2 jumper pins to close. And remove jumper clip from 2 jumper pins to open. The following
illustration shows how to set up jumper.
Before applying power to MANO321 Series, please make sure all the jumpers are in factory
default position. Below you can find a summary table of all jumpers and onboard default settings.
Note
Once the default jumper setting needs to be changed, please do it under power-
off condition.

MANO321 Mini ITX Motherboard
Board and Pin Assignments 9
Jumper
Description
Setting
JP1 ~ JP6
COM Data/Power Select
Default: RS-232 Data
3-5 Close
4-6 Close
JP11
LVDS VDD Select
Default: +3.3V Level
1-2 Close
JP12
Clear CMOS
Default: Normal Operation
1-2 Close
JP13
AT/ATX Power Mode Select
Default: ATX Mode
1-2 Close
2.3.1 COM1 Data/Power Select (JP1)
This is a 3x2-pin (pitch=2.00mm) jumper. The COM1 port has +5V power capability on
DCD and +12V on RI by setting JP1.
2.3.2 COM2 ~ COM6 Data/Power Select (JP2 ~ JP6)
This is a 3x2-pin (pitch=2.00mm) jumper. The COM2~6 port has +5V power capability on
DCD and +12V on RI by setting JP2~JP6.
2.3.3 LVDS VDD Select (JP11)
The motherboard supports voltage selection for flat panel displays. Use this 2x3-pin
(pitch=2.0mm) jumper to set up VDD power of the LVDS connector. To prevent hardware
damage, before connecting please make sure that the input voltage of LVDS panel is
correct.
Function
Setting
Power: Set COM pin 1 to +5V
1-3 close
Data: Set COM pin 1 to DCD
(Default)
3-5 close
Power: Set COM pin 9 to +12V
2-4 close
Data: Set COM pin 9 to RI
(Default)
4-6 close
Function
Setting
Power: Set COM pin 1 to +5V
1-3 close
Data: Set COM pin 1 to DCD
(Default)
3-5 close
Power: Set COM pin 8 to +12V
2-4 close
Data: Set COM pin 8 to RI
(Default)
4-6 close
Function
Setting
+3.3V level (Default)
1-2 close
+5V level
2-4 close
+12V level
5-6 close

MANO321 Mini ITX Motherboard
10 Board and Pin Assignments
2.3.4 Clear CMOS (JP12)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear
the CMOS memory of date, time, and system setup parameters by erasing the CMOS
RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which
includes system setup information such as system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Remove the onboard battery.
3. Move the jumper clip from pins 1-2 (default) to pins 2-3. Keep the clip-on pins 2-3
for about 5~10 seconds, then move the clip back to pins 1-2.
4. Re-install the battery.
5. Plug the power cord and turn ON the computer.
6. Hold down the <Del> key during the boot process and enter BIOS setup to re-enter
data.
2.3.5 AT/ATX Power Mode Select (JP13)
This 3-pin (pitch=2.0mm) jumper allows you to select AT or ATX power mode.
Function
Setting
Normal operation (Default)
1-2 close
Clear CMOS
2-3 close
Function
Setting
ATX mode (Default)
1-2 close
AT mode
2-3 close

MANO321 Mini ITX Motherboard
Board and Pin Assignments 11
2.4 Connectors
Signals go to other parts of the system through connectors. Loose or improper connection might
cause problems, please make sure all connectors are properly and firmly connected. Here is a
summary table showing connectors on the hardware.
Connector
Description
CN1
COM1 D-Sub Connector
CN2~CN6
COM2~COM6 Headers
CN10
Front Panel Header
CN11
Digital I/O Header
CN12
SPI Header
CN14
VGA Header
CN15
SATA 3.0 Connector
CN16
PCI-Express x4 Slot
CN17, CN18
Ethernet Ports
CN19
Audio Jack
CN20
PCI-Express Mini Card Connector
CN21, CN22
USB 3.2 Gen 1 Stack Ports
CN23
HDMI Connector
CN24, CN25
USB 2.0 Headers
CN26
4-pin ATX Power Input Connector
CN27
I2C Header
CN28
SMBus Header
CN29
LVDS Signal Header
CN50
eDP Connector
CN51
SATA Power Connector
CN52
Audio Header
CN55
LVDS Backlight Control Header
DCJACK1
DC Jack Power Connector
BAT1
CMOS Battery Connector
SCN1
SIM Card Slot
SCN2
M.2 Key B Connector

MANO321 Mini ITX Motherboard
12 Board and Pin Assignments
2.4.1 COM1 D-Sub Connector (CN1)
This connector is a standard D-Sub connector for COM1 serial port interface which is
selectable for RS-232/422/485 mode by BIOS setting (see section 4.4). The pin
assignments of RS-232/422/485 are listed in table below.
Note
[*]: Pin 1 of COM1 can be DCD/+5V and pin 9 of COM1 can be RI/+12V by
selecting JP1 (see section 3.3.1).
2.4.2 COM2~COM6 Headers (CN2~CN6)
The motherboard comes with four 2x5-pin (pitch=2.00mm) headers for COM2~COM6
serial port interfaces. It has power capability on DCD# and RI# pins by setting jumper
JP2~JP6.
COM2~COM6:
Note
[*]: COM 2 is RS232/422/485, COM3 ~ COM6 only support RS232.
[**]: Pin 1 of COM2&6 can be DCD/+5V and pin 8 of COM2&6 can be RI/+12V
by selecting JP2~JP6 (see section 3.3.2).
Pin
RS-232
RS-422
RS-485
1
DCD#
TX-
Data-
2
RXD
TX+
Data+
3
TXD
RX+
N/C
4
DTR#
RX-
N/C
5
GND
GND
GND
6
DSR#
N/C
N/C
7
RTS#
N/C
N/C
8
CTS#
N/C
N/C
9
RI#
N/C
N/C
Pin
Signal
Pin
Signal
1
DCD
2
DSR
3
RX
4
RTS
5
TX
6
CTS
7
DTR
8
RI
9
GND
10
NC

MANO321 Mini ITX Motherboard
Board and Pin Assignments 13
2.4.3 Front Panel Header (CN10)
The CN10 is a 2x7-pin (pitch=2.54mm) header. It includes Power-on, Reset, HDD LED
and Power LED connections, allowing user to connect the PC case’s front panel switch
functions.
Power LED
Pin 1 connects anode (+) of LED and pin 5 connects cathode (-) of LED. The power LED
lights up when the system is powered on.
External Speaker and Internal Buzzer
Pin 2, 4, 6 and 8 connect the case-mounted speaker unit or internal buzzer. While
connecting the board to an internal buzzer, please set pin 2 and 4 closed; while
connecting to an external speaker, you need to set pins 2 and 4 opened and connect the
speaker cable to pin 8(+) and pin 2(-).
Power On/Off Button
Pin 9 and 10 connect the power button on front panel to the board, which allows users to
turn on or off power supply.
System Reset Switch
Pin 11 and 12 connect the case-mounted reset switch that reboots your computer without
turning off the power switch. It is a better way to reboot your system for a longer life of
system power supply.
HDD Activity LED
This connection is linked to hard drive activity LED on the control panel. LED flashes
when HDD is being accessed. Pin 13 and 14 connect the hard disk drive to the front panel
HDD LED, pin 13 is assigned as cathode (-) and pin 14 is assigned as anode (+).
2.4.4 Digital IO Header (CN11)
The CN11 is a 2x5-pin (pitch=2.00mm) header for digital I/O interface.
Pin
Signal
Pin
Signal
1
PWRLED+
2
EXT SPK-
3
GND
4
Buzzer
5
PWRLED-
6
N.C.
7
N.C.
8
EXT SPK+
9
PWRSW-
10
PWRSW+
11
HW RST-
12
HW RST+
13
HDDLED-
14
HDDLED+
Pin
Signal
1
5V
2
DO0
3
DI0
4
DO1
5
DI1
6
DO2
7
DI2
8
DO3
9
DI3
10
GND

MANO321 Mini ITX Motherboard
14 Board and Pin Assignments
2.4.5 SPI Header (CN12)
The CN12 is a 2x5-pin (pitch=2.00mm) header for SPI interface.
2.4.6 VGA Header (CN14)
The CN14 is a 2x8-pin (pitch=2.00mm) header for VGA interface.
2.4.7 SATA 3.0 Connectors (CN15)
These Serial Advanced Technology Attachment (Serial ATA or SATA) connectors are for
SATA 3.0 interfaces allowing up to 6.0Gb/s data transfer rate. They are computer bus
interfaces for connecting to devices such as hard disk drives.
Pin
Signal
1
NC
2
WP
3
VCC
4
GND
5
CS
6
CLK
7
MISO
8
MOSI
9
HD
Pin
Signal
Pin
Signal
1
VGA_RED
2
+5V
3
VGA_GRN
4
GND
5
VGA_BLUE
6
NC
7
NC
8
VGA_5VDDA
9
GND
10
HSYNC_C
11
GND
12
VSYNC_C
13
GND
14
5VDDCLK
15
GND
16
NC
Pin
Signal
1
GND
2
SATA_TX+
3
SATA_TX-
4
GND
5
SATA_RX-
6
SATA_RX+
7
GND
