AXIOMTEK NA363R User manual

NA363R
Network Appliance
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
AXIOMTEK Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
AXIOMTEK does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. AXIOMTEK does not make
any commitment to update the information in this manual.
AXIOMTEK reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of AXIOMTEK Co., Ltd.
Copyright 2019 AXIOMTEK Co., Ltd.
All Rights Reserved
June 2019, Version A1
Printed in Taiwan

iii
Safety Approvals
CE Marking
FCC Class A
FCC Compliance
This equipment has been tested and complies with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. If not installed and used in
accordance with proper instructions, this equipment might generate or radiate radio frequency
energy and cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measurers:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Shielded interface cables must be used in order to comply with emission limits.

iv
Safety Precautions
Before getting started, read the following important cautions.
1. Be sure to ground yourself to prevent static charge when installing the internal
components. Use a grounding wrist strap and place all electronic components in any
static-shielded devices. Most electronic components are sensitive to static electrical
charge.
2. Disconnect the power cords from the NA363R Series before making any installation. Be
sure both the system and the external devices are turned OFF. Sudden surge of power
could ruin sensitive components. Make sure the NA363R Series is properly grounded.
3. Do not open the system’s top cover. If opening the cover for maintenance is a must, only
a trained technician is allowed to do so. Integrated circuits on computer boards are
sensitive to static electricity. To avoid damaging chips from electrostatic discharge,
observe the following precautions:
Before handling a board or integrated circuit, touch an unpainted portion of the
system unit chassis for a few seconds. This will help to discharge any static
electricity on your body.
When handling boards and components, wear a wrist-grounding strap, available
from most electronic component stores.
Trademarks Acknowledgments
AXIOMTEK is a trademark of AXIOMTEK Co., Ltd.
IBM, PC/AT, PS/2, VGA are trademarks of International
Business Machines Corporation.
Intel®and Pentium®are registered trademarks of Intel Corporation. MS-DOS, Microsoft C
and QuickBASIC are trademarks of Microsoft Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

v
Table of Contents
Disclaimers.............................................................................................................ii
Safety Approvals...................................................................................................iii
Safety Precautions ............................................................................................... iv
CHAPTER 1 INTRODUCTION .......................................................................1
1.1 General Description...........................................................................1
1.2 Features..............................................................................................1
1.3 Specifications ....................................................................................2
1.3.1 System ..............................................................................................................2
1.3.2 Mechanical / Environmental ...........................................................................3
1.4 Dimensions and Outlines..................................................................4
1.5 I/O Outlets ..........................................................................................5
1.5.1 Front Panel for NA363R...................................................................................5
1.5.2 Rear Panel for NA363R....................................................................................7
CHAPTER 2 HARDWARE DESCRIPTION....................................................9
2.1 Checklist.............................................................................................9
2.2 Memory Module (UDIMM/RDIMM) and HDD .....................................9
2.3 Board Layout.................................................................................... 11
2.4 Jumper Settings............................................................................... 13
2.4.1 Clear CMOS Jumper (JP2) ............................................................................13
2.4.2 LAN Bypass Control Selection (JP7, JP8, JP9) ..........................................14
2.4.3 TACT SW1 Selection (JP6)............................................................................15
2.5 Connectors.......................................................................................16
2.5.1 LCM Connector..............................................................................................17
2.5.2 Digital Input / Output Connector (DIO1) ......................................................17
2.5.3 Serial Port2 Connector (COM2)....................................................................18
2.5.4 FAN Connector (FAN1, FAN2, FAN3) ...........................................................18
2.5.5 Serial ATA Connector: (SATA1, SATA2, SATA3, SATA4)...........................18
2.5.6 SATA Power Connector: (CN2, CN3) ...........................................................19
2.5.7 Mini Card Connector (CN5)...........................................................................19
2.5.8 Mini Card Connector (CN6)...........................................................................20
2.5.9 Case Open Connector (CN7) ........................................................................21
2.5.10 DC-In Power Jack (CN11)..............................................................................21
2.5.11 4P Wafer Power Input Connector (ATX2)....................................................21
2.5.12 Power Switch Connector desktop system (ATX1) .....................................21
2.5.13 Serial Port for Console (COM1)....................................................................22
2.5.14 USB port Connector (USB1).........................................................................22
2.5.15 LED1~11 .........................................................................................................23
2.5.16 Front Panel Bezel Connector (JP1)..............................................................24
CHAPTER 3 AMI BIOS SETUP UTILITY.....................................................25
3.1 Starting............................................................................................. 25
3.2 Navigation Keys............................................................................... 25
3.3 Main Menu........................................................................................ 26
3.4 Advanced Menu................................................................................27
3.5 IntelRCSetup ....................................................................................52

vi
3.6 Security Menu .................................................................................. 58
3.7 Boot Menu ........................................................................................59
3.8 Save & Exit Menu............................................................................. 63
APPENDIX A LAN BYPASS CONFIGURATION .........................................71
About LAN Bypass ..........................................................................................71
LAN Bypass Register Configuration ..............................................................72
APPENDIX B WDT TIMER FOR SYSTEM RESET......................................77
APPENDIX C LAN MODULE EXPANSION .................................................79
LAN Bypass Control Jumper (JP2/JP3) .........................................................80
APPENDIX D WARNING..............................................................................89

NA363R Series Network Appliance User’s Manual
Introduction
1
CHAPTER 1
INTRODUCTION
This chapter contains general information and detailed specifications of the NA363R Network
Appliance Server. Chapter 1 contains the following sections:
General Description
Features
Specifications
Dimensions and Outlines
I/O Outlets
1.1 General Description
The NA363R is a 1U rack mount network security hardware platform for VPN, firewall and
other network security applications, which consists can support of Intel®ATOM C3000 family
processors. This platform supports the 1U rack mount form factor, and the system supports
DDR4 U-DIMM/R-DIMM memory up to maximum 128 GB. In the meantime, the platform also
can support 6 Gigabit LAN ports which can provide best throughput. For the purpose to store
event log data, it can deploy two 2.5’’ SATA3 HDD, and one mSATA. This platform can be
easily enabled through application programs to make a user-friendly appliance for customers,
and provide the highest ever performance of encryption and decryption.
1.2 Features
Low power and high performance for network security field applications. NA363R series
supports Intel®ATOM C3000 family processors.
Supports six 10/100/1000Mbps Ethernet ports
Supports BIOS redirected to COM port features
Supports two 2.5” SATA Hard Disk
Supports one mSATA
Support 4 U-DIMM/R-DIMM, up to 128GB memory
Reasonable computing performance and throughput for processor and LAN ports
Suitable for Network Appliance; VPN, network bandwidth controller, firewall and UTM

NA363R Series Network Appliance User’s Manual
Introduction
2
1.3 Specifications
1.3.1 System
System CPU
Intel®C3000 family processors. (C3558/C3758 in default, other sku for optional)
BIOS
AMI SPI flash BIOS
System Memory
Four DDR4 U-DIMM/R-DIMM, non-buffer non-ECC/ECC memory, up to 128GB
Storage Interface
Two 2.5” SATA3 HDD
One mSATA
Expansion Slot
Two PCI Express Mini Card Socket
One Full size, Support USB & M-SATA(default)
One Full size, Support USB & PCIe(default)
One NIC module for optional (C3758/C3958 support only ,due to PCIe lens limitation)
Network Interface
Six 10/100/1000Mbps Ethernet (Intel®i210)
Two groups LAN by pass support latch relay for optional (One pair in default)
Watchdog Timer
Two pairs LAN by pass :8 levels,1-64 seconds
One for system reset: 255 levels,1-255 sec
USB
Two USB2.0 ports in the front side
Console
RS-232 Console port is the front side(RJ-type)
Power
AC/DC 120W open frame
OS Compatibility
Yocto, Linux, Windows Server 2012 R2, Windows Server 2016.

NA363R Series Network Appliance User’s Manual
Introduction
3
1.3.2 Mechanical / Environmental
Form Factor
1U Rack mount
LED
Power, HDD, Link/Act with transfer rate(LAN ports)
LAN by pass LED and programmable LED
Operation Temperature
0°C ~ 45°C (32°F ~ 113°F)
Storage Temperature
-20°C ~ 70°C (-4°F ~ 158°F)
Humidity
10% - 95% RH, non-condensing
Chassis Material
Steel
Dimensions
44mm (1.73”) (H) x 430mm (16.93”) (W) x 250mm (9.84”)(D)
Weight (Net/Gross)
3.5 kg/ 4.5 kg
NOTE: All specifications and images are subject to change without notice.

NA363R Series Network Appliance User’s Manual
Introduction
4
1.4 Dimensions and Outlines
NA363R

NA363R Series Network Appliance User’s Manual
Introduction
5
1.5 I/O Outlets
Locate the front panel I/O outlets on the NA363R Series server to connect serial and Ethernet
interface devices.
1.5.1 Front Panel for NA363R
RJ45 LAN ports
Power LED (Green)
LED light up when the server is powered on to perform diagnostic tests and proper
operation checking.
HDD LED (Green)
LED flashes when HDD is transmitting or receiving data.
Programmable LED GPIO1, GPIO2, GPIO3, GPIO4 (Green)
The LEDs are controlled by programmable GPIO. A sample code will be provided
that allow users to define their own function.
“Default” Tact Switch
The sample code will be provided that allows users to define their own function. For
example, when the system has any problems, this switch can support to reset it to
the customer’s OS default settings if our customer’s OS supports this application.
“Reset” Tact Switch
It is for reset the system to reboot your computer instead of turning OFF the power
switch. It is a better way to reboot your system for a longer life of the system’s power
supply.
Console Port
This is a Cisco RJ-type connector console port for command line interface and
diagnostic support by P.O.S.T (Power On Self Test).
USB2.0 Ports
Two USB 2.0 ports supported.
LAN bypass LED(BP1/BP2)
While running the LAN By-Pass function, the LED always lights up.
(Default one pair only, two pairs for optional)
LCM&Keypad
USB2.0 Console
Antenna
NIC module for optional

NA363R Series Network Appliance User’s Manual
Introduction
6
Transfer Rate for LAN port
The double-color LED light indicates 10/100/1000Mbps transfer rate.
LED Light Color
Transfer Rate
Dark
10Mbps
Green
100Mbps
Orange
1000Mbps
If the LED is dark and Active/Link LED is lighting on flashing, the transfer rate
should be 10Mbps.
When the green-color LED light is radiating, the transfer rate should be
100Mbps.
When the orange-color LED light is radiating, the transfer rate should be
1000Mbps.
When this LED and Link/Active LED both are dark, no networking devices are
attached.
Active/Link LED for LAN Port
The orange LED is on when the LAN port connection is working.
The LED flashes when transmitting or receiving any signals to or from the
appliance.
The LED is dark when the appliance is off.
Note: Optional LAN module LED definition in Appendix C.

NA363R Series Network Appliance User’s Manual
Introduction
7
1.5.2 Rear Panel for NA363R
Power Supply
System power use power cord to connect the power supply to AC Inlet with power
switch.
System Fans(smart fan)
These are fans for cooling down system temperature.
System Fan System Fan AC Inlet/Switch
VGA (optional)

NA363R Series Network Appliance User’s Manual
Introduction
8
This page is intentionally left blank.

NA363R Series Network Appliance User’s Manual
Hardware Description
9
CHAPTER 2
HARDWARE DESCRIPTION
The NA363R Series are convenient for your various hardware configurations. The chapter 2
will help you get familiar with the hardware.
2.1 Checklist
The package bundled with your NA363R should contain the following items:
The NA363R network appliance hardware platform
power cord x 1
Mounting screws for disk drive
cable kits (1 x SATA cable, 1 x SATA power cable )
Plastic stand for stack–up x 4
Rack mount ear kit
NOTE: Please use VGA module for graphic mode OS installation.
If you cannot find this package or any items are missing, please contact AXIOMTEK
distributors immediately. If you order any optional components, the package might contain
those additional hardware or documents accordingly.
2.2 Memory Module (UDIMM/RDIMM) and HDD
The main board supports four DDR4 UDIMM/RDIMM socket. Maximum memory capacity is
up to 128GB ECC/Non-ECC unbuffered memory.
The following steps show you how to install the memory modules:
1 Push down each side of the DIMM socket.
2 Align the memory module with the socket that notches of memory module must match
the socket keys for a correct installation.
3 Install the memory module into the socket and push it firmly down until it is fully seated.
The socket latches are levered upwards and clipped on to the edges of the DIMM.
4 Install any remaining DIMM modules.

NA363R Series Network Appliance User’s Manual
Hardware Description
10
Connects SATA cable and SATA power cable from HDD to SATA connector (SATA1/SATA2)
and SATA power connector (CN2/CN3) together then installs HDD by HDD rack and screws
properly

NA363R Series Network Appliance User’s Manual
Hardware Description
11
2.3 Board Layout
Component Side

NA363R Series Network Appliance User’s Manual
Hardware Description
12
Bottom Side

NA363R Series Network Appliance User’s Manual
Hardware Description
13
2.4 Jumper Settings
This section provides the information about jumpers and connectors of NA363R Series.
Proper jumper settings configure the main board in this appliance to meet your application
purpose. We are herewith listing a summary table of all jumpers and default settings for
onboard devices, respectively.
Jumper
Definition
Jumper Settings
JP2
Clear CMOS Setting
1-2：Normal (Default)
2-3：Clear CMOS
JP4
Reserved
1-2：Normal (Default)
JP6
TACT SW1 Low Button
Function Selection
1-2：Power button function
2-3：Reset button function
4-5：GPI function
JP7
JP8
JP9
LAN Bypass Trigger When
Power On
(1-2)/(1-2)/(1-2)：
Bypass as same as Power Off status
(2-3)/ (1-2)/(1-2)：
Bypass Disable(Default)
(2-3)/(2-3)/ (1-2)：
Bypass Enable
JP10
Reserved
1-2：Normal (Default)
2.4.1 Clear CMOS Jumper (JP2)
You may need to use this jumper is to clear the CMOS memory if incorrect settings in the
Setup Utility.
Description
Function
Jumper Setting
COMS Clear
Normal (Default)
JP2
Clear CMOS
JP2

NA363R Series Network Appliance User’s Manual
Hardware Description
14
2.4.2 LAN Bypass Control Selection (JP7, JP8, JP9)
Description
Function
Jumper Setting
LAN Bypass Trigger when Power
On
Mother board/SEGN1 ~2
Bypass as same as Power Off
status
JP7
JP8
JP9
Mother board/SEGN1 ~2
Bypass Disable(Default)
JP7
JP8
JP9
Mother board/SEGN1 ~2
Bypass Enable
JP7
JP8
JP9
NOTE: When the system is turned on, you can select LAN bypass function by
Jumper and Bios when power on state, when enter the OS; you can select
LAN pass function at power on/ off state by software.
