PL-81850
Network Application Platform
User Manual
Desktop Intel® Denverton-NS™ Processor Network System, eight Copper GbE,
DDR4, mSATA, eMMC, mini-PCIe, PCIe, Bypass

Copyright © WIN Enterprises, Inc. PL-81850 1
Revision Histor
Revision Description Date B
1.0 Initial Release 10 24 17 S. Koots

2 PL-81850 Copyright © WIN Enterprises, Inc.
Preface
Cop right
©2017 WIN Enterprises, Inc. All rights reserved Worldwide. All information contained in this document
provided in good faith and is protected by copyright laws worldwide and no part of this document may be
reproduced or transmitted in any form or by any means, electronic or mechanical, without the express
written permission of WIN Enterprises, Inc. All other trademarks are acknowledged as the property of their
respective owners.
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is
subject to change without notice. All information listed in this user manual, including but not limited to
product specifications or drawings, is subject to change without prior notice. WIN Enterprises, Inc. provides
no warranty in any form with regard to this document and information contained herein and hereby
expressly disclaims any expressed or implied warranties of merchantability or fitness for any particular
purpose with regard to any of the foregoing and WIN Enterprises, Inc. assumes no liability for any
damages incurred directly or indirectly from any kinds of errors or omissions contained herein or for
discrepancies between the product and this document. In no event shall WIN Enterprises, Inc. be liable for
any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise,
arising out of or in connection with this document or any other information contained herein or the use
thereof.
Hazardous substance-Free (RoHS) Compliant
This product is designed and developed using hazardous substance-free components and parts and totally
RoHS (Restriction of Hazardous Substances Directive 2002 95 EC) compliant.
Certification
WIN Enterprises, Inc.
is certified to ISO 9001-2015 standards.
Electrostatic Sensitive Device

Copyright © WIN Enterprises, Inc. PL-81850
3
Table of Contents
Revision Histor ..................................................................................................................... 1
Preface................................................................................................................................... 2
Table of Contents ................................................................................................................... 3
1. Introduction ....................................................................................................................... 4
Features: ................................................................................................................................ 4
Features:..................................................................................................................................4
Package Contents.....................................................................................................................4
Specifications...........................................................................................................................5
Ordering Information ...............................................................................................................6
1.1. Hardware Briefing .............................................................................................................7
Front View ...........................................................................................................................7
Rear View.............................................................................................................................7
2. Motherboard Information .................................................................................................. 8
2.1. Functional Diagram ...........................................................................................................8
2.2. Internal Jumper & Connectors...........................................................................................9
3. Hardware Setup................................................................................................................ 11
3.1. System Overview.............................................................................................................11
4. BIOS Setup ....................................................................................................................... 13
4.1. Main................................................................................................................................15
4.2. Advanced ........................................................................................................................16
4.3. Chipset............................................................................................................................18
4.4. Security ...........................................................................................................................19
4.5. Boot ................................................................................................................................19
4.6. Save & Exit ......................................................................................................................21
Contact Information ............................................................................................................. 22

4
Copywrite © WIN Enterprises, Inc. PL-81850
?
1. Introduction
The PL-81850 is a high-performance desktop networki
ng system based on Intel®
Denverton-NS ™ Processor. This new generation platform provides high performance from a
2/4 SoC processor, that supports up to 20 PCIe lanes with exible network expansion.
The PL-81850 is an enhancement in computing performance and system responsiveness with
the Intel® Denverton-NS™ processor, coupled with four DDR4 ECC SODIMMs (up to 2133
MHz) and yielding a maximum memory capacity of up to 32GB. PL-81850 is able to support
miniPCIe x3, (mini-PCIe to VGA / miniPCIe for Wi-Fi / miniPCIe for mSATA), 1 x RJ45 Console
port. 2x USB 3.0, and LEDs for Power/HDD/Bypass LEDs / LAN active & Link status, and 2 pair
Bypass LAN port functions.
PL-81850 supports 1 x mSATA Slot; and 1 x 2.5" SATA HDD for basic network storage
applications.
Features
Intel® Denverton-NS™ Processor
DDR4 ECC 1866/2133 MHz memory, max support 32GB
Max 8x GbE ports
Expansive I/O with USB 3.0, 2.5” SATA HDD,
mSATA socket and Console port
2 pairs Bypass
miniPCIe x3 (for VGA, for Wi-Fi, for mSATA)
?ntel® Quick Assist for Cryptographic Hardware Acceleration
Package Contents
1 x PL-81850 unit
1 x power cord
1 x CD (Manual, Quick Installation Guide, Utility Driver)
1 x External Power Source

Copyright © WIN Enterprises, Inc. PL-81850 5
Specifications
CPU Intel® Denverton-NS™ Processor
Processor S stem
BIOS AMI® UEFI BIOS
Technolog
ECC DDR4 1866 2133 MHz SODIMM memory
Memor
Capacit Up to 32GB
Expansion Mini-
PCIe slot1x mini-PCIe socket (half-size) for WIFI
1x mini-PCIe socket (half-size) for VGA module
GbE Ethernet
LAN1~4: Intel I210-
AT via PCIex1
LAN5~8: Marvell 88E1543 via SGMII
Ethernet
LAN B pass Two pairs of Gen3 Bypass in LAN5~8 (latch Relay)
SATA 1 x mSATA Slot or
internal 2.5”SATA HDD (Optional)
Storage
eMMC eMMC 5.0 (build option)
USB Two external USB3.0
Two internal USB 2.0 with pin header
I/O
Serial One RJ45 Console port (COM1)
One internal pin header (COM2)
Power Suppl
Watt 60W power adaptor (Level 6)
Form Factor
Desktop
LED
One Power LED (Green)
One HDD LED (Red)
One Bypass LED (Yellow)
Six pairs LEDs for six Ethernet ports Active Link
status (Green)
Dimension
(W x D x H) 270mm (W) x 152mm (D) x 44mm (H)
Mechanical and
Environmental
Operating Operating: 0 ~ 40°C ( 32 ~ 104°F )

6 PL-81850 Copyright © WIN Enterprises, Inc.
Temperature
Storage
Temperature -20 ~ 75°C (-4 ~ 167°F)
Humidit
10 ~ 85% relative humidity, non-operating,
non-condensing
Weight
1pc Box, 4kgs,
Certification
CE FCC
Ordering Information
PL-8185A Desktop Intel Denverton-NS 4C,C3558 (16W) 2.2GHz processor,
DDR4, 8 Copper GbE, mSATA,eMMC, miniPCIe, USB3.0, Bypass,
PL-8185B
Desktop Intel Denverton-NS 2C,C3338 (8.65W) 1.5GHz processor,
DDR4, 8 Copper GbE, mSATA, eMMC, miniPCIe, USB3.0, Bypass
* Note: Specifications subject to change without prior notice.

Copyright © WIN Enterprises, Inc. PL-81850 7
1.1. Hardware Overview
Front View
1. LAN active link status indicators 2. Bypass HDD Power indicators
Rear View
1. Power Switch 2. DC-in Jack
3. ATX Power Switch 4. Micro USB2.0 console (Optional)
5. 1 x RJ45 Console 6. 2 x USB3.0
7. Reset button 8. 8 X GbE LAN Ports

8 PL-81850 Copyright © WIN Enterprises, Inc.
2. Motherboard Information
2.1. Functional Diagram
The block diagram indicates the data flow among components on the motherboard. Please refer to the
following figure for your motherboard’s layout design.

Copyright © WIN Enterprises, Inc. PL-81850 9
2.2. Internal Jumper & Connectors
Item Description Item Description Item Description
CN1 DDR4_SODIMM CN2 PCIEx4 SLOT CN3 MINI-PCIE_VGA
CN4 MINI-PCIE_WIFI CN5 RJ45_1X4 CN6 MCU PIN HEADER
CN7 RJ45_1X4 CN8 RJ45_1X2 CN9 RJ45_1X2
CN10 USB3.0 Connector CN11 SATA3.0 CN12 COM2 BOX HEADER
CN13 PS2 KB MS CN14 Micro USB2.0 CN15 KEYPAD
CN16 LCM CN17 GPI 1X5 PIN HEADER CN18 GPO 2X5 PIN HEADER
CN19 LPC PIN HEADER CN20 LED PIN HEADER CN21 FAN_3P
CN22 FAN_3P CN23 FAN_3P CN24
DC Switch PIN
HEADER
CN25 12V DC-IN CN26 DC JACK CN30 VR13 PIN HEADER
CN32 ATX Switch CN33 ATX Switch PIN HEADER CN34 DC JACK
CN35 SATA_PWR PIN HEADER CN36 DDR4_SODIMM

10 PL-81850 Copyright © WIN Enterprises, Inc.
1-2 Enable
JP1 CLEAR CMOS 2-3 Disable
1-2 Enable
JP2 BYPASS1 2-3 Disable
1-2 Enable
JP3 BYPASS2 2-3 Disable
1-2 Enable
JP4 AT OR ATX 2-3 Disable
1-2 - H W Reset
JP5 H W OR S W RESET
2-3 - S W Reset

Copyright © WIN Enterprises, Inc. PL-81850 11
3. Hardware Setup
3.1. S stem Overview
Item Description
1
8x GbE LAN onboard
LAN 1~4 Intel i210
LAN 5~8 Marvell 88E1543 (2 pairs of LAN bypass)
2
CPU with heat-sink
Denverton-NS C3338 1.5Ghz TDP 8.75W
Denverton-NS C3538 2.1Ghz TDP 15 W
Denverton-NS C3558 2.2Ghz TDP 16 W
3 Mini-PCIe Socket
VGA Module R478(full-size)
4 Memor
DDR4 SO-DIMM Socket
5 S stem Cooling
6 LED indicators
Power HDD Bypass LEDs LAN active & Link status
7 mSATA Socket
Storage half-size

12 PL-81850 Copyright © WIN Enterprises, Inc.
8 Mini-PCIe Socket
WiFi Module (half-size)
9 eMMC 5.0
Storage 8GB

Copyright © WIN Enterprises, Inc. PL-81850 13
4. BIOS Setup
Follow steps below to enter the BIOS setup utilit :
1. Connect a computer keyboard and Display to the device.
2. Power on the device.
3. Press the <Delete> key during the boot-up.
4. Then the BIOS main screen shows.
Operation instructions:
Arrow key [<--] [-->]: Navigate through setup screens, e.g. [Main], [Advanced], [Chipset], [Boot],
[Securit ], [Save & Exit] and [Server Mgmt]
Arrow key [↑] [↓]: Highlight an item opUon on a setup screen
[Enter]: select the highlighted item option or enter the sub-menu under the highlighted
item option
[ESC]: exit the current screen
[+] [-] = to adjust values for the selected setup item option
The following sections describe the BIOS setup. BIOS settings of this module can be viewed and set via
BIOS settings. It is strongly recommended that only users with profound experiences are allowed to
change the default BIOS settings.
► Main BIOS Information
BIOS Vendor
Core Version
Compliancy
Project Version
Build Date and Time

14 PL-81850 Copyright © WIN Enterprises, Inc.
Memor Information
Total Memory
► System Date
► System Time
► Access Level
► Advanced
► Platform Function
► NCT6791D Super IO Configuration
► NCT6791D HW Monitor
► Serial Port Console Redirection
►
NVMe Configuration
►
USB Configuration
► CPU Configuration
► CSM Configuration
► IntelRC Platform Harcuver
RC Revision 0.133.4.42
Processor BSP Revision 506F1
Microcode Revision 00000014
► Relax Securit Configuration
► Processor Configuration
► Server ME Configuration
► North Bridge Chipset Configuration
► South Bridge Chipset Configuration
Securit Password Description
► Setup Administrator Password
► User Password
Boot Boot Configuration
► Setup Prompt Timeout
► Bootup NumLock State
Boot Option Priorities
► Boot Option #1
► Boot Option #2
► Save & Exit Save Options
Save Changes and Reset
Discard Changes and Reset
Default Options
Restore Default
Boot Override
UEFI: Built-in EFI Shell

Copyright © WIN Enterprises, Inc. PL-81850 15
UEFI: SanDisk, Partition 1
4.1. Main
Feature Options
BIOS Information
BIOS Vendor Info only
Core Version Info only
Compliancy Info only
Project Version Info only
Build Date and Time Info only
Memor Information
Total Memory Info only
System Date Weekday, MM DD YYYY
System Time HH MM SS
Access Level Info only

16 PL-81850 Copyright © WIN Enterprises, Inc.
4.2. Advanced
Feature Description
Watch Dog Function
Watch Dog Node
Watch Dog Timer
Watch Dog Count
Lan Module Function
LanB pass V3 Function
LanBypass1 Control
Poweroff1
LanBypass2 Control
Platform Function
Poweroff2
Super IO Chip NCT6791D
Serial Port 1 Configuration
NCT6791D Super IO
Configuration Serial Port 2 Configuration
PC Health Status
System Temperature
CPU Temperature
AUX Temperature
NCT6791D HW Monitor
System Fan

Copyright © WIN Enterprises, Inc. PL-81850 17
CPU Fan
Aux Fan
CPUVCORE
+12V
+5V
+3.3V
VDIMM
NVMe Configuration NVMe Controller and Drive information
USB Configuration
USB Controllers
USB Devices
Legacy USB Support
XHCI Hand-off
USB Mass Storage
Driver Support
USB hardware dela s and time-outs
USB transfer time-out
Device reset time-out
USB Configuration
Device power-up delay
Socket 0 CUP Information
CPU Power Management
Active Processor
Intel Virtualization Technology
CPU Configuration
VT-d
Compatibilit Support Module Configuration
CSM Support
GateA20 Active
INT19 Trap Response
Boot Option filter
Option ROM execution
Network
Storage
Video
CSM Configuration
Other PCI devices

18 PL-81850 Copyright © WIN Enterprises, Inc.
4.3. Chipset
Feature Description
Platform Info only
RC Revision Info only
Processor BSP Revision Info only
Relax Securit Configuration Enable Enable
North Bridge
Integrated Graphics Device
Primary Display
RC6 (Render Standby)
GTT Size
Aperture Size
DVMT Total Gfx Mem
North Bridge
PAVP Enable
South Bridge
PCI Express Configuration
SATA Drives
USB Configuration
South Bridge
State After G3
