DATASHEET
AXIS T95A Series Dome Housing
Protect your Axis PTZ and PTZ dome network cameras.
> Heaters and fans
included
> Indoor and outdoor
> IP66-rated protection
> Operating conditions
down to -30°C
(-22°F)*
The AXIS T95A series is an innovative and rugged dome
housing made of die-cast aluminum that protects
Axis PTZ and PTZ dome network cameras from water,
dust, sunlight and low temperatures.
The housing is suitable for both indoor and outdoor
installation with IP66 weatherproof protection rating.
AXIS T95A Series Dome Housing has a top opening system designed to give easy access to the camera,
all cabling and connections, enabling comfortable installation and easy maintenance of the network
camera.
AXIS T95A is supplied with a removable sunshield,
fan-assisted heaters and power connections for all
supported Axis network cameras. The package includes
1 clear and 1 smoked dome bubble with superior optical
clarity, designed for cameras with 35x zoom.
The pre-mounted heaters and fans allow the cameras
to operate in temperatures down to -30°C (-22°F),
depending on the network camera model.
*Depending on network camera
model.

General
Models AXIS T95A00 Dome Housing (5010-001), 110/240V AC
AXIS T95A10 Dome Housing (5010-101), 24V AC
Supported
cameras
AXIS 213 PTZ, AXIS 214 PTZ, AXIS 215 PTZ, AXIS 231D+,
AXIS 232D+ and AXIS 233D Network Cameras
Casing Die-cast aluminum
Epoxypolyester powder painting. Color: White grey RAL9002
Removable sunshield in ABS. Color: White grey RAL9002
Power AXIS T95A00
Input 100/240V AC, 50/60 Hz
Output 24V DC, max 1,5 A or 12V DC, 3 A
AXIS T95A10
Input 24V AC - Requires 24V AC mains adapter (5000-001)
Output 24V AC or 12V DC, 2 A
Environment Indoor/outdoor
Operating
conditions
AXIS 213 PTZ: -20 to 35°C (-4 to 95°F)
AXIS 214 PTZ: -25 to 40°C (-13 to 104°F)
AXIS 215 PTZ: -25 to 40°C (-13 to 104°F)
AXIS 231D+/232D+: -20 to 50 °C (-4 to 122°F)
AXIS 233D: -30 to 45°C (-22 to 113°F)
Protection rating IP66 according to EN 60529
Approvals CE according to EN 61000-6-3, EN 60950, EN 50130-4
Height
(with sunshield)
335 mm (13.2’’)
Diameter
(with sunshield)
351 mm (13.8’’)
Height
(without sunshield)
335 mm (13.2’’)
Diameter
(without sunshield)
322 mm (12.7’’)
Weight 3.8 kg (8.3 lb.)
Accessories
(included)
Sunshield, thermostat controlled heaters and fans, smoked and
clear dome bubble, Installation Guide
Technical specications – AXIS T95A Series Dome Housing
www.axis.com
©2008-2009 Axis Communications AB. AXIS COMMUNICATIONS, AXIS, ETRAX, ARTPEC and VAPIX are registered trademarks or trademark applications of
Axis AB in various jurisdictions. All other company names and products are trademarks or registered trademarks of their respective companies. We reserve
the right to introduce modications without notice.
36048/EN/R1/0908
More information and a configuration tool is available at
www.axis.com/accessories
Dimensions
244mm
(9.6”)
110mm
(4.3”)
190mm
(7.5”) 345mm (13.6”)
230mm
(9.1”)
576mm
(22.7”)
77mm
(3.0”)
69mm
(2.7”)
230mm
(9.1”)
298mm
(11.7”)
335mm
(13.2”)
182mm
(7.2”)
140mm
(5.5”)
351mm
(13.8”)
91mm
(3.6”)
150mm
(5.9”)
AXIS T95A Series Dome Housing
22 SEP, 2008
Doc no. 33078
244mm
(9.6”)
110mm
(4.3”)
190mm
(7.5”) 345mm (13.6”)
230mm
(9.1”)
576mm
(22.7”)
77mm
(3.0”)
69mm
(2.7”)
230mm
(9.1”)
298mm
(11.7”)
335mm
(13.2”)
182mm
(7.2”)
140mm
(5.5”)
351mm
(13.8”)
91mm
(3.6”)
150mm
(5.9”)
AXIS T95A Series Dome Housing
22 SEP, 2008
Doc no. 33078
244mm
(9.6”)
110mm
(4.3”)
190mm
(7.5”) 345mm (13.6”)
230mm
(9.1”)
576mm
(22.7”)
77mm
(3.0”)
69mm
(2.7”)
230mm
(9.1”)
298mm
(11.7”)
335mm
(13.2”)
182mm
(7.2”)
140mm
(5.5”)
351mm
(13.8”)
91mm
(3.6”)
150mm
(5.9”)
AXIS T95A Series Dome Housing
22 SEP, 2008
Doc no. 33078
Brackets
Wall bracket Ceiling/parapet bracket Extension bracket
Bracket accessories
Base bracket Corner bracket Pole bracket
