Axis P55 & Q60 HD network/IP PTZ cameras with Dotworkz D2 Outdoor Housing -
10 minute installation guide
www.dotworkz.com 866.575.4689
innovative remote video solutions
Using the included Axis
Torx screw driver unscrew
all 8 bottom Torx screws (4
“outside” ones for the main
cover plus 4 for smaller
cables latch cover).
Attach the Axis P55 or Q60
series camera collar to the
Dotworkz universal camera
mounting plate, making sure
to line up correctly and tight-
ening lock washers securely.
Connect BROWN wire to
(-) negative and RED to (+)
positive on the MVP terminal.
The BLACK wire is not used
so we recommend isolating
it with electrical tape.
Run CAT5 cable through exist-
ing D2 cable gland; Remove
the plug and install an included
second cable gland, making
sure to seal it tight. Note: if
using conduit be sure sealing
to avoid water moisture.
After unscrewing, remove
P55 or Q60 series camera
cover and open smaller cable
latch. Set aside the main
lower camera shroud as it is
not going to be needed.
You will need to use the 1.5
and the 0.75 inches stand-
offs on the 4 brass inserts
on top of the D2 enclosure -
DO NOT over tighten or cross
thread the standoffs.
Have a qualified electri-
cian connect an external
power source to D2 terminal
power block. See manual for
more details.
Attach the Dotworkz 5502-491
patch cable that will provide
camera power; attach the
RG45 connector of a CAT5
Ethernet cable to the camera;
Feed both cables out their
respective slots.
Twist-lock camera into collar
while applying down pressure;
line up the diamond mark as
in this picture; Secure the
camera plate to the standoffs
using included 832 pan
head screws.
Make sure to have only one
cable per gland and tighten
them really shut to com-
pletely seal D2 enclosure
from the outside.
Securely close the cable
latch using the Torx screw
driver again.
Remove the terminal block
from Dotworkz 5502-491
cable: you will only use
BROWN and RED wires.
Check camera install by care-
fully closing the D2 camera
hatch and verifying clearance
between camera and D2
lens: should be enough space
between the clear dome and
the camera to move freely.
Close the enclosure and
tighten all screws using
a philips screw driver.
The D2 can be mounted
directly to a wall or to a pole
mount adapter.
Make sure to create a “U”
shape drip loop with the
cables to prevent water
from pooling and possibly
seeping inside.
Axis Technology,
Dotworkz Durability
Dotworkz has created a quick “how-
to” guide on proper installation of
the Axis P5512, P5522, P5532,
P5534, Q1755, Q6032, Q6034,
Q6035 HD cameras with the
Dotworkz D2 rugged IP66 camera
enclosures. Guide includes step-by-
step photos, procedures and tips for
a fast and simple set up.
The Dotworkz housings are the #1
choice available to protect Axis HD
cameras. An IP66 rating assures
that the cameras and all other
sensitive electronic equipment are
safe from environmental conditions,
and secure from malicious vandals.
Dotworkz enclosures are the durable
solution for protecting Axis cameras
from the harshest conditions.
Prepare the camera Install Axis collar
Correct poles
IP68 Cable glands
Remove shroud
Mount the standoffs
External power source
Connect cables
Secure camera
Tighten cable glands
Reassemble latch cover
Using Dotworkz cable
Check camera fit
Close the D2 Leave a drip loop
All the parts and tools
Note: Please read both Axis and Dot-
workz manuals before beginning. Photo
of hardware and components needed
to install Axis P55 & Q60 into the D2
outdoor enclosure system.
