Axis P551X SERIES User manual

MANUAL RE-PAINT
AXIS P551X/-E
Network Dome Cameras

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 2(23)
- 2 -
1 Table of Contents
1Table of Contents ________________________________________________________ 2
2Introduction ____________________________________________________________ 3
3Influence on Warranty and Product performance ______________________________3
3.1 Product Warranty_________________________________________________________ 3
3.2 Product Performance ______________________________________________________ 3
4Tools Required __________________________________________________________ 3
5Repaint instruction for P551X-E series ______________________________________ 4
5.1 Repainting of the Chassis___________________________________________________ 4
5.1.1 Removal of weather shield _______________________________________________________4
5.1.2 Removal of the Dome Module Ass _________________________________________________5
5.1.3 Removal of the Push-pull Connector Housing ________________________________________6
5.1.4 Removal of the Chassis Hook _____________________________________________________7
5.1.5 Removal of the Screws Bayonett __________________________________________________7
5.1.6 Create a masking box for the Chassis and position the unit ______________________________8
5.1.7 Masking of the Chassis __________________________________________________________9
5.2 Repainting of the Dome Module Ass_________________________________________ 10
5.2.1 Removal of the Dome Module Bracket & the Dome with sealing ________________________10
5.2.2 Removal of the dome sealing ____________________________________________________12
5.2.3 Mask Gore filters. _____________________________________________________________12
6Repaint instruction for P551X series _______________________________________ 13
6.1 Repainting of the Chassis__________________________________________________ 13
6.1.1 Removal of the Chassis Hook and Lid _____________________________________________14
6.1.2 Removal of the Screws Bayonett _________________________________________________14
6.1.3 Create a masking box for the Chassis and position the unit _____________________________16
6.1.4 Masking of the Chassis _________________________________________________________16
6.2 Repainting of the Dome Module Ass_________________________________________ 18
6.2.1 Removal of the Dome Module Bracket & the Dome with sealing ________________________18
6.2.2 Removal of the dome sealing ____________________________________________________19
7APPENDIX: Assembly drawings and overview of products _____________________ 20
7.1 Assembly drawings of P551X-E series _______________________________________ 20
7.1.1 Main Assembly _______________________________________________________________20
7.1.2 Weather Shield Assembly _______________________________________________________21
7.1.3 Dome Module Assembly________________________________________________________21
7.2 Assembly drawings of P551X series _________________________________________ 22
7.2.1 Main Assembly _______________________________________________________________22
7.2.2 Dome Module Assembly________________________________________________________22
8Revision History________________________________________________________ 23

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 3(23)
- 3 -
2 Introduction
This document describes the way to operate when Re-painting a P551X / -E Network Dome
Camera. Any attempt to carry out a Re-painting operation on the camera, should only be
made after reading this document thoroughly.
To prevent damage to sensitive components, proper ESD protection must be carried out
while handling of the parts is only allowed in dust free environment.
3 Influence on Warranty and Product performance
3.1 Product Warranty
Any aftermarket modifications, which are not approved by Axis Communications AB, made
on Axis Network Dome cameras will void the Product warranty. Therefore, please note that
any deviation from the re-paint instructions described in this document will void the Product
warranty.
3.2 Product Performance
Axis Communications AB will only guarantee the product specifications and performance of
the camera in its original form.
4 Tools Required
Torx Screwdriver, (T8, T10, T20)
Screwdriver Flat > 6 mm width
Carton box min 190x190x140 mm
Knife for cutting in carton

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 4(23)
- 4 -
5 Repaint instruction for P551X-E series
To repaint the P551X-E series Dome Network Camera, the camera will have to be divided into thee
parts: Weather Shield, Chassis and Dome Module. Each part is then stripped from components or
masked to enable the repainting. Before the painting, crucial parts of the camera are masked to
ensure the fit and function when the camera is reassembled again.
To prevent damage to sensitive components, proper ESD protection must be carried out while
handling of the parts is only allowed in dust free environment.
Please follow the workflow as described below. Any deviations from the proposed instruction will void
the Product warranty.
5.1 Repainting of the Chassis
Please note that the original surface finish of the chassis is Powder coating.
5.1.1 Removal of weather shield
Tool: Screwdriver Torx20
Torque (when refitting): 2 Nm
Put the weather shield to the side for painting.
Screws (3x)
T20

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 5(23)
- 5 -
5.1.2 Removal of the Dome Module Ass
Step 1
Remove the four Antiloss screws that hold the Dome module ass. Remove the Dome module ass.
Tool: Screwdriver Torx20
Torque (when refitting): 2 Nm
When refitting, Please note:
1) The Max tightening torque must not exceed 2 Nm
Antiloss Screws
(4x)

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 6(23)
- 6 -
5.1.3 Removal of the Push-pull Connector Housing
Step 1
Remove the two screws that hold the Push-pull connector housing and remove the housing.
Tool: Screwdriver Torx8
Torque (when refitting): 0,3Nm
Screws (3x)
Push Pull Housing

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 7(23)
- 7 -
5.1.4 Removal of the Chassis Hook
Step 1
Remove the three screws that hold the Chassis hook.
Tool: Screwdriver Torx20
Torque (when refitting): 2,4Nm
When refitting, Please note:
Please note the maximum torque of 2,4 Nm.
5.1.5 Removal of the Screws Bayonett
Remove the three Bayonett screws.
Tool: Screwdriver, Minus Bit
Torque (when refitting): 1,8Nm
When refitting, Please note:
Please note the maximum torque of 1,8Nm.
Screws (3x)
Chassis hook
Screw Bayonett (3x)

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 8(23)
- 8 -
5.1.6 Create a masking box for the Chassis and position the unit
Cut a circular hole with diameter 147 mm in the middle of the 190x190 mm side of the box.
It is of highest importance that no paint particles are escaping inside the camera!
Place the
camera in the
hole as in
Cut hole diameter
147 mm

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 9(23)
- 9 -
5.1.7 Masking of the Chassis
In order to maintain the fit and function of the camera, some parts of it need to be masked before
painting. This applies to parts like threaded screw holes, assembly surfaces as well as electrical
connectors.
Step 1
Mask all the 19 threaded screwholes and the connector together with the corresponding slot on the
top surface of the chassis.
One easy way, to mask all above mentioned features, is to attach a mask with a diameter of 90mm in
one piece all over them, as shown in the picture below.
Connector with slot in chassis
One of 16 threaded screwholes

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 10(23)
- 10 -
5.2 Repainting of the Dome Module Ass
When repainting the Dome Module ass, the Cover is the part to repaint. Please follow each step
described below. As mentioned earlier, the proper masking before painting is of highest importance in
order to ensure good fit and function when reassembling the camera again. Please note that any
deviation from the steps described below will void the product warranty.
Please note that the original surface finish of the Dome cover ring is PC+ASA. Please use compatible
paint.
5.2.1 Removal of the Dome Module Bracket & the Dome with sealing
Remove the eight screws that hold the Dome module bracket. Remove the Dome Module bracket
together with the Dome with sealing.
Tool: Screwdriver Torx T10
Torque (when refitting): 0,25 Nm
Mask, 90mm in diameter

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 11(23)
- 11 -
When refitting, Please note:
1) Please note the maximum torque of 0,25Nm.
2) The screws are self threading in the plastic. It is important that the screws thread enter the plastic in
the same position as in the original mounting. Turn the screws anti-clockvise to get the feeling where
the original thread start.
Dome Module bracket)
Screws (8x)
Dome with Sealing
Built-in washer on Dome Module Bracket (4x)

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 12(23)
- 12 -
5.2.2 Removal of the dome sealing
The dome sealing ring is easilly removed by hand from the cover.
5.2.3 Mask Gore filters.
Thre are four holes at the flange of the Cover that must be masked. The ventilation will be distroyed if
the holes not are properly masked.
Dome sealing ring
Cover
Gore-filter. Needs to be masked

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 13(23)
- 13 -
6 Repaint instruction for P551X series
To repaint the P551X series Dome Network Camera, the camera will have to be divided into three
parts: Chassis, Ass Lid and Dome Module. Please refer to chapter 7.2 for an assembly overview. Each
part is then stripped from components to enable the repainting. Before the painting, crucial parts of the
camera are masked to ensure the fit and function when the camera is reassembled again.
To prevent damage to sensitive components, proper ESD protection must be carried out while
handling of the parts is only allowed in dust free environment.
Please follow the workflow as described below. Any deviations from the proposed instruction will void
the Product warranty.
6.1 Repainting of the Chassis
Please note that the original surface finish of the Chassis is Powder coating.
Step 1 (Removal of Dome Module Ass)
Remove the four screws (M4x17 ANTILOSS) that hold the Dome module ass and remove the Dome
module ass. See picture below.
Tool: Screwdriver Torx20
Torque (when refitting): 4Nm
When refitting, Please note:
Please note the maximum torque of 4Nm.
Anti Loss Screws (4x)

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 14(23)
- 14 -
6.1.1 Removal of the Chassis Hook and Lid
Step 1
Remove the three screws that hold the Chassis hook.
Tool: Screwdriver Torx20
Torque (when refitting): 2,4Nm
When refitting, Please note:
Please note the maximum torque of 2,4 Nm.
6.1.2 Removal of the Screws Bayonett
Remove the three Bayonett screws.
Tool: Screwdriver, Minus Bit
Torque (when refitting): 1,8Nm
Screw (5x)
Chassis hook
Lid

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 15(23)
- 15 -
When refitting, Please note:
Please note the maximum torque of 1,8Nm.
Screw Bayonett (3x)

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 16(23)
- 16 -
6.1.3 Create a masking box for the Chassis and position the unit
Cut a circular hole with diameter 147 mm in the middle of the 190x190 mm side of the box.
It is of highest importance that no paint particles are escaping inside the camera!
6.1.4 Masking of the Chassis
In order to maintain the fit and function of the camera, some parts of it need to be masked before
painting. This applies to parts like threaded screw holes, assembly surfaces as well as electrical
connectors.
Place the
camera in the
hole as in
Cut hole diameter
147 mm
Place the Lid
as in the
picture.

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 17(23)
- 17 -
Step 1
Mask all the 16 threaded screwholes and the connector together with the corresponding slot on the
top surface of the chassis.
One easy way, to mask all above mentioned features, is to attach a mask with a diameter of 90mm in
one piece all over them, as shown in the picture below.
Mask, 90mm in diameter
One of 16 threaded
screwholes

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 18(23)
- 18 -
6.2 Repainting of the Dome Module Ass
When repainting the Dome Module ass, the Cover is the part to repaint. Please follow each step
described below. As mentioned earlier, the proper masking before painting is of highest importance in
order to ensure good fit and function when reassembling the camera again. Please note that any
deviation from the steps described below will void the product warranty.
Please note that the original surface finish of the Dome cover ring is PC+ASA. Please use compatible
paint.
6.2.1 Removal of the Dome Module Bracket & the Dome with sealing
Remove the eight screws that hold the Dome module bracket. Remove the Dome Module bracket
together with the Dome with sealing.
Tool: Screwdriver Torx T10
Torque (when refitting): 0,25 Nm
When refitting, Please note:
1) Please note the maximum torque of 0,25Nm.
2) The screws are self threading in the plastic. It is important that the screws thread enter the plastic in
the same position as in the original mounting. Turn the screws anti-clockvise to get the feeling where
the original thread start.
Dome Module bracket)
Screws (8x)
Dome with Sealing
Built-in washer on Dome Module Bracket (4x)

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 19(23)
- 19 -
6.2.2 Removal of the dome sealing
The dome sealing ring is easilly removed by hand from the cover.
Dome sealing ring
Cover

AXIS 66583 REV: 2
COMMUNICATIONS AB MANUAL RE-PAINT INST AXIS P551X/-E DATE: 2016-04-07
Author: Sven Svensson PAGE: 20(23)
- 20 -
7 APPENDIX: Assembly drawings and overview of
products
7.1 Assembly drawings of P551X-E series
7.1.1 Main Assembly
