AXISQ60-EPTZDomeNetworkCameras
Outdoor,high-speedPTZdomes:AXISQ6042-E/Q6044-E/Q6045-E
AXISQ60-Ecamerasaretop-of-the-line,outdoor-readypan/tilt/zoom(PTZ)domesthatprovide
exceptionalcoverageofwideareasandgreatdetailwhenzoomingin.Designedforeasyin-
stallationandreliableoperationoutdoors,theyareidealforcitysurveillanceandairports,train
stations,harborsandstadiums.
AXISQ6045-Eoffersarichviewingexperi-
encewithHDTV1080pand20xopticalzoom.
AXISQ6044-EprovidesHDTV720pand30xoptical
zoom.AXISQ6042-EsupportsfullframerateExtended
D1resolutionand36xopticalzoom.
AXISQ60-Ecamerasarevandal-resistant(IK10)and
haveshockdetection,surgeprotection(railwaystan-
dards),andprotectionagainstdust,rainandsnow(IP66
andNEMA4X).Theycanoperateintemperaturesrang-
ingfrom-50°Cto50°C(-58°Fto122°F).Thecameras’
ArcticTemperatureControlensuressafestart-upin
extremecold.AXISQ6042-EandAXISQ6044-Esup-
portelectronicimagestabilization—usefulforget-
tingsmoothervideoinwindyconditions.Infog,
AXISQ6044-Ecanprovideclearervideowithitsauto-
maticdefogfunctionality.
ThePTZdomessupportautotrackingandActiveGate-
keeper,andhavesubstantialcapacityforthird-partyin-
telligentvideoapplications.AXISQ6045-Eoffersaddi-
tionalbuilt-inanalyticssuchashighlightcompensation,
objectremovedandenter/exitdetection.
AXISQ60-Ecamerashaveabuilt-inmemorycardslotfor
localstorageofrecordings.Thecamerasarepoweredby
HighPoweroverEthernetusingthesuppliedHighPoE
midspan.
DATASHEET
>UptoHDTV1080p
>Upto36xoptical
zoom
>Outdoor-readyand
ArcticTemperature
Control
>Vandal-resistantand
shockdetection
>Automaticdefog
(AXISQ6044-E)
>HighPoE
Note:Mountingbracketsaresold
separately.

High-performanceoutdoor-readyPTZdomes
TherobustAXISQ60-EPTZdomesaredesignedforround-the-clockpan/tilt/zoomoperationinoutdoorenvironments.
Thecamerascanbeautomaticallydirectedto256presetpositionsusingguardtour.Withendless360°pan,theyenable
surveillanceofanextremelywidearea.Highzoom,incombinationwithhighresolution,enablesdetailedsurveillanceat
greatdistances.AXISQ60-Ecamerashavefastandprecisepan/tiltperformance.Theycanalsotilt20°abovethehorizon,
whichmakesitpossibleforthecamerastoseehigherthantheirmountingposition.Thiscanbeuseful,forexample,ata
stadiumwherethereisaneedtolookupatthestands.
TheimagesaboveshowtheeldofviewandlevelofdetailprovidedbythethreeAXISQ60-EPTZdomes.
SnapshotsofHDTV1080pviewsfromAXISQ6045-E:atleft,wideview;atright,20xzoomed-inviewwherethelicenseplateofacar275m(900ft.)awaycanberead.
GreatdetailwithHDTV
Amongthethreecameras,AXISQ6045-Eprovidesthewidest
eldofview—witha62.98°horizontalangleofview.Inaddi-
tion,AXISQ6045-Eoffersthehighestlevelofdetailasitdelivers
HDTV1080pperformanceincompliancewiththeSMPTE274Mstandard
regardinga1920x1080pixelresolution,fullframerateat25/30frames
persecond,HDTVcolordelityanda16:9format.
HDTV1080pprovidesmorethandoublethenumberofpixelsas
HDTV720p(1280x740p).WhileAXISQ6045-Ehas20xopticalzoom,
thecombinationofthezoomfactorandHDTV1080pallowsthelicense
plateofavehicletobereadsome275m(900ft)away—atafurther
distancethanwithAXISQ6044-E,whichhas30xopticalzoom,and
AXISQ6042-E,whichhas36xopticalzoom.
AXISQ6044-Ealsooffersawidehorizontalviewingangleat62.9°.The
camera’s30xopticalzoom,incombinationwithHDTV720p,provides
superbzoomed-inviews,enabling,forinstance,thelicenseplateofa
vehicletobereadupto245m(800ft)away.AXISQ6042-Eoffers
ExtendedD1resolution(736x576in50Hz,752x480in60Hz)andcan
enableavehicle’slicenseplatetobereadsome190m(620ft)away.
AllthreePTZdomessupportH.264MainProleforefcientcompression
ofvideothatmaintainsimagequalitywhileatthesametimeminimizing
bandwidthuseandstoragespace.Thecamerasofferday/nightfunction-
ality,enablingexcellentcolorvideoduringdaytime,andclearblackand
whitevideoinlowlight.

ElectronicimagestabilizationinAXISQ6042-Eand
AXISQ6044-E
Cameraswithhighzoomaresensitivetovibrationsfromwindandtrafc.AXISQ6042-EandAXISQ6044-Esupport
electronicimagestabilization(EIS),whichreducestheeffectsofcameravibration.Inwindyconditions,EISprovides
clearer,moreusefulvideoandhelpsreducethesizeofvideoles,whichleadstolowerbandwidthandstorageuse.
Undervibratingconditions:atleft,imagewithoutEIS;atright,asnapshotfromavibratingAXISQ6044-EwithEISactivated.
AutomaticdefogwithAXISQ6044-E
AXISQ6044-Esupportsautomaticdefog,whichwhenactivated,automaticallydetectsfoginthesceneanddigitallylters
itoutofviewtoprovideclearervideo.
ImagesfromAXISQ6044-E:atleft,withoutautomaticdefog;atright,withautomaticdefogactivated.
DimensionsOptionalaccessories
1.AXIST91A
2.SmokedDomeD
3.AxisHighPoE
midspans
4.AXIST8129PoE
Extender
5.AXISP8221
6.AXIST8310
7.RJ45IP66-rated
cableswith
premounted
connector(CAT6)

TechnicalSpecications-AXISQ60-EPTZDomeNetworkCameras
ModelsAXISQ6042-E50Hz,AXISQ6042-E60Hz
AXISQ6044-E50Hz,AXISQ6044-E60Hz
AXISQ6045-E50Hz,AXISQ6045-E60Hz
Camera
ImagesensorAXISQ6042-E:1/4”ExViewHADprogressivescanCCD
AXISQ6044-E:1/3”progressivescanCCD
AXISQ6045-E:1/3”progressivescanCMOS
LensAXISQ6042-E:f=3.3–119mm,F1.4–4.2,autofocus
Horizontalangleofview:57.2°–1.7°
AXISQ6044-E:f=4.4–132mm,F1.4–4.6,autofocus
Horizontalangleofview:62.9°–2.2°
AXISQ6045-E:f=4.45–89mm,F1.6–2.9,autofocus
Horizontalangleofview:62.98°–3.49°
DayandnightAutomaticallyremovableinfrared-cutlter
Minimum
illumination
AXISQ6042-E:Color:0.5luxat30IREF1.4,
B/W:0.008luxat30IREF1.4
AXISQ6044-E:Color:0.2luxat30IREF1.4,
B/W:0.04luxat30IREF1.4
AXISQ6045-E:Color:0.6luxat30IREF1.6,
B/W:0.04luxat30IREF1.6
ShuttertimeAXISQ6042-E:1/30000sto1.5s(50Hz),1/30000sto
0.5s(60Hz)
AXISQ6044-E:1/10000sto1/4s
AXISQ6045-E:1/33000sto1/3s(50Hz),1/33000sto
1/4s(60Hz)
Pan/Tilt/ZoomE-ip,256presetpositions,Tourrecording,Guardtour,Control
queue,On-screendirectionalindicator
Pan:360°endless,0.05°–450°/s;Tilt:220°,0.05°–450°/s
AXISQ6042-E:36xopticalzoomand12xdigitalzoom,
total432xzoom
AXISQ6044-E:30xopticalzoomand12xdigitalzoom,
total360xzoom
AXISQ6045-E:20xopticalzoomand12xdigitalzoom,
total240xzoom
Video
Video
compressionH.264MainandBaselineProles(MPEG-4Part10/AVC)
MotionJPEG
ResolutionsAXISQ6042-E:ExtendedD1736x576to176x144(50Hz),
ExtendedD1752x480to176x120(60Hz)
AXISQ6044-E:1280x720(HDTV720p)to320x180
AXISQ6045-E:1920x1080(HDTV1080p)to320x180
FramerateH.264:Upto25/30fps(50/60Hz)inallresolutions
MotionJPEG:Upto25/30fps(50/60Hz)inallresolutions
VideostreamingMultiple,individuallycongurablestreamsinH.264and
MotionJPEG
Controllableframerateandbandwidth
VBR/CBRH.264
ImagesettingsWidedynamicrange(WDR),Manualshuttertime,Compression,
Color,Brightness,Sharpness,Whitebalance,Exposurecontrol,
Exposurezones,Backlightcompensation,Finetuningofbehavior
atlowlight,Rotation,Textandimageoverlay,32individual3D
privacymasks,ImagefreezeonPTZ
AXISQ6042-E:Electronicimagestabilization
AXISQ6044-E:Electronicimagestabilization,Automaticdefog
AXISQ6045-E:Highlightcompensation
Network
SecurityPasswordprotection,IPaddressltering,HTTPSaencryption,
IEEE802.1Xanetworkaccesscontrol,Digestauthentication,User
accesslog
Supported
protocolsIPv4/v6,HTTP,HTTPSa,SSL/TLSa,QoSLayer3DiffServ,FTP,
CIFS/SMB,SMTP,Bonjour,UPnPTM,SNMPv1/v2c/v3(MIB-II),
DNS,DynDNS,NTP,RTSP,RTP,TCP,UDP,IGMP,RTCP,ICMP,
DHCP,ARP,SOCKS,SSH,NTCIP
Systemintegration
Application
Programming
Interface
OpenAPIforsoftwareintegration,includingVAPIX®
andAXISCameraApplicationPlatform;specicationsat
www.axis.com
AXISVideoHostingSystem(AVHS)withOne-ClickCamera
Connection.
ONVIFProleS,specicationatwww.onvif.org
IntelligentvideoVideomotiondetection,Autotracking,ActiveGatekeeper,
AXISCameraApplicationPlatformenablinginstallationof
additionalapplications
AXISQ6044-E:Automaticdefog
AXISQ6045-E:Basicanalytics(nottobecomparedwith
third-partyanalytics):Objectremoved,Enter/exitdetector,Fence
detector,Objectcounter,Highlightcompensation
EventtriggersVideomotiondetection,Shockdetection,Fan,Heater,
Temperature,Manualtrigger,Autotracking,Moving,PTZpreset,
Edgestorageevents,AXISCameraApplicationPlatform
AXISQ6045-E:Enter/exit,Fencedetector,Objectremoved
EventactionsFileupload:FTP,HTTP,networkshareandemail
Notication:email,HTTPandTCP
PTZpreset,Guardtour,Autotracking,Day/nightmode,Video
recordingtoedgestorage,Pre-andpost-alarmvideobuffering
Built-in
installationaids
Pixelcounter
General
CasingIP66-,NEMA4X-andIK10-ratedmetalcasing(aluminum),
polycarbonate(PC)cleardome,sunshield(PC/ASA)
Memory512MBRAM,128MBFlash
PowerHighPoweroverEthernet(HighPoE),max.60W
AXIST8124HighPoE60WMidspan1-port:100–240VAC,
max.74W
ConnectorsRJ45for10BASE-T/100BASE-TXPoE
RJ45Push-pullConnector(IP66)included
EdgestorageSD/SDHC/SDXCslotsupportingmemorycardupto64GB(card
notincluded);supportforrecordingtonetworkshare
(network-attachedstorageorleserver)
Operating
conditions-50°Cto50°C(-58°Fto122°F)
ArcticTemperatureControlenablescamerastart-upat
temperaturesaslowas-50ºC(-58ºF)
Humidity10–100%RH(condensing)
Storage
conditions-50°Cto50°C(-58°Fto122°F)
ApprovalsEN55022ClassA,EN61000-3-2,EN61000-3-3,EN61000-6-1,
EN61000-6-2,EN55024,EN50121-4,IEC62236-4,
FCCPart15SubpartBClassA,ICES-003ClassA,VCCIClassA,
C-tickAS/NZSCISPR22ClassA,KCCKN22ClassA,KN24,
IEC/EN/UL60950-1,IEC/EN/UL60950-22,IEC/EN60529IP66,
NEMA250Type4X,NEMATS-2-2003v02.06,subsection2.2.7,
2.2.8,2.2.9;IEC62262IK10,IEC60068-2-1,IEC60068-2-2,
IEC60068-2-78,IEC60068-2-14,IEC60068-2-30,
IEC60068-2-6,IEC60068-2-27,IEC60068-2-60,ISO4892-2
Midspan:EN60950-1,GS,UL,cUL,CE,FCC,VCCI,CB,KCC,UL-AR
Weight3.7kg(8.2lb.)
Included
accessories
AXIST8124HighPoE60WMidspan1-port,RJ45Push-pull
Connector(IP66),Sunshield,InstallationGuide,Installationand
ManagementSoftwareCD,Windowsdecoder1-userlicense
Video
management
software
AXISCameraCompanion(included),AXISCameraStation
andvideomanagementsoftwarefromAxis’Application
DevelopmentPartners(notincluded).Formoreinformation,see
www.axis.com/products/video/software
WarrantyAxis3-yearwarrantyandAXISExtendedWarrantyoption,see
www.axis.com/warranty
a.ThisproductincludessoftwaredevelopedbytheOpenSSLProjectforuseinthe
OpenSSLToolkit.(www.openssl.org),andcryptographicsoftwarewrittenbyEric
Young([email protected]).
Moreinformationisavailableatwww.axis.com
