Axminster AP254PS13 User manual

AT254PS13
Panel Saw
AT: 13/01/2021
BOOK VERSION: 5
Code 107715
Original Instructions

Index of Contents
2
EU Declaration of Conformity 02
What’s Included 03-04-05
General Instructions for 230V Machines 06
Specific Safety Precautions 06-07
Specifications 07
Assembly
Main Saw Body 08-09-10-11
Side Access Door knob 11
Rear Extension Table 11
Side Extension Table 11-12
Crown Guard 12-13
Sliding Table 14-15-16-17
Rip Fence 17-18
Micro Adjuster 19
Mitre Fence 19-20
Mounting Plate 20
Machine Footprint 21-22
Illustration and Parts Description 23-24-25-26-27
Positioning the Machine 28
Setting Up the Machine 28-29-30-31
Operating Instructions 32-33-34
Changing the Saw Blade 35-36
Routine Maintenance 36-37-38
Wiring Diagram 38
Exploded Diagrams/Lists 39-40-41-42-43-44-45-46-47-48
Notes 49-50
The symbols below advise the correct safety procedures when using this machine.
Fully read manual
and safety instructions
before use
Eye protection
should be worn
Ear protection
should be worn
HAZARD
Dust mask
should be worn
Cert No: P250/230
Axminster Tool Centre Ltd
Axminster Devon
EX13 5PH UK
axminstertools.com
Type Panel Saw
Model AP254PS13 and conforms to the machinery example for which the
EC Type-Examination Certificate No BM 50439320, AE 50451697
has been issued by Laizhou Futian Machinery Co., Ltd.
at: Fenghuang Science and Technology Park, Development Zone Laizhou, Shandong
261400 Shandong China (Mainland)
and complies with the relevant essential health and safety requirements.
2006/42/EC
2006/95/EC
EN 60204-1:2018
EN ISO 19085-5:2017
EN ISO 19085-1:2017
declares that the machinery described:-
This machine complies with the following directives:
EU Declaration of Conformity
06/42/EC - Annex I/05.2006
EN IEC 61000-3-2:2019
EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-3:2013
Signed
Andrew Parkhouse
Operations Director Date: 11/11/2019

What’s Included
3
Quantity Item Part Model Number
AP254PS13
1 Main Saw Assembly (upper chassis
with motor, table, saw blade and
NVR switch fitted) 1
2 Side Panels and Front and Back Panels 2
4 Lower Leg Columns 3
1 Side Table Extension 4
1 Rear Extension Table 5
1 Extension Support Arm 6
1 Rip Fence Rail 7
1 Micro Adjuster 8
1 Rip Fence Assembly 9
1 Sliding Table Assembly 10
1 Sliding Table Extension 11
1 Riving Knife 12
1 Crown Guard 13
1 Mitre Fence Assembly 14
1 Mitre Fence Extension 15
2 Operating Wheels with
(Square Keys) in packet 16
1 100mm Dust Extraction Moulding 17
1 100mm Extraction Flexible Hose 18
1 50mm Crown Guard Flexible Hose 19
2 100mm Hose Clips 20
2 50mm Hose Clips 21
1 Hose Support Bracket 22
1 Workpiece Support Shoe 23
1 Sliding Table Fence Assembly 24
1 Sliding Table Operating Handle 25
1 Distance Stop Assembly 26
1 Sliding Table Supporting Leg 27
1 Overhead Clamp 28
2 Steel Shafts for (Overhead Clamp)
1 Push Stick 29
1 Mounting Plate 30
Fixing:
20 M8 x 20mm Hex Bolts,Washer, Nuts A
4 M8 x 25mm Hex Bolts,Washer, Nuts
3 M8 x 25mm Square Head Bolts,Washers B
1 Blade Locking Bar C
2Rip Fence Capping Plates D
2 Fence rail Capping Plates
8 Small Phillips Screws for (Capping Plates) E
Spanners
1 10-13mm
2 13-15mm
1 14-17mm
1 24mm
1 Hex Keys 2.5-3-4-5mm
1 Instruction Manual
Main saw assembly Panel saw parts contained inside main saw frame
1
Continues Over....

What’s Included
4
11
23 10
19
9 7
8
30
16
6
2
27
17
13
2
2
28
3
5
4
22
24
26
12
14
15

What’s Included
5
Eight small Phillips screws for mounting
the capping plates above.
12 26 8
25
23
18
20
21
14
15
D

General Instructions for 230V Machines
6
The following suggestions will enable you to observe
good working practices, keep yourself and fellow
workers safe and maintain your tools and equipment
in good working order.
This machine is supplied with a moulded 16 Amp. Plug
and 3 core power cable. Before using the tool inspect
the cable and the plug to make sure that neither are
damaged. If any damage is visible, have the tool
inspected/repaired by a suitably qualified person. If it is
necessary to replace the plug, it is preferable to use an
‘unbreakable’ type that will resist damage on site. Only
use a 16 Amp plug, and make sure the cable clamp is
tightened securely. Fuse as required. If extension leads
are to be used, carry out the same safety checks on them,
and ensure that they are correctly rated to safely supply
the current that is required for your machine.
If the machine gets wet; dry it off as soon as possible
with a cloth. Do not use 230V a.c. powered tools in damp
locations and do not trail extension cables across wet
areas. Keep the tools clean, do not use any solvents or
cleaners, as these may cause damage to any plastic parts
or to the electrical components.
Keep the work area as uncluttered as is practical, this
includes personnel as well as material.
Under no circumstances should CHILDREN be allowed
in work areas.
It is good practice to leave the machine unplugged until
work is about to commence, also make sure to unplug
the machine when it is not in use, or unattended. Always
disconnect by pulling on the plug body and not the
cable. Once you are ready to commence work, remove
any tools used in the setting operations (if any) and
place safely out of the way. Re-connect the machine.
Carry out a final check e.g. check the cutting tool, drill bit
etc., are securely tightened in the machine, check you
have the correct speed and function set, check that the
power cable will not‘snag’etc.
Make sure you are comfortable before you start work,
Good Working Practices/ Safety
Mains Powered Tools
Work Place/Environment
Mains Powered Tools Primary Precautions
WARNING! KEEP TOOLS AND EQUIPMENT
OUT OF THE REACH OF YOUNG CHILDREN
balanced, not reaching etc. If the work you are carrying
out is liable to generate flying grit, dust or chips, wear the
appropriate safety clothing, goggles, gloves, masks etc. If
the work operation appears to be excessively noisy, wear
ear-defenders. If you wear your hair in a long style,
wearing a cap, safety helmet, hairnet, even a sweatband,
will minimise the possibility of your hair being caught
up in the rotating parts of the machine, likewise,
consideration should be given to the removal of rings
and wristwatches, if these are liable to be a ‘snag’hazard.
Consideration should also be given to non-slip footwear,
etc. If you are allowing another person to use the
machine, ensure that they are suitably qualified to use it.
Do not use the machine if you are tired, your attention is
wandering or you are being subjected to distraction. A
deep cut, a lost fingertip or worse is not worth it!
Check that cutters, drills etc., are the correct type and
size, are undamaged and are kept clean and sharp, this
will maintain their operating performance and lessen the
loading on the machine. Above all, OBSERVE…. make
sure you know what is happening around you, and USE
YOUR COMMON SENSE.
Make sure the saw blade is the correct type for the job in
hand.
Do not force the saw, if the saw begins to ‘stall’you are
‘forcing the cut’ or over working the saw. Ensure that
the saw blade is clean and sharp. Resin build up on
the blades will increase the friction of the saw passing
through the timber, and cause over heating of the blade,
blunt teeth will work harder tearing the fibre of the
timber as opposed to shearing it, also with subsequent
overheating. Both faults unnecessarily load the machine
beyond normal usage, and shorten its longevity.
Do not use blades that are damaged in any way.
Do not remove the blade guard.The design of the riving
knife on the machine will not allow for slotting or‘blind’
grooving, so there is no reason to remove the guard.
There is adequate clearance under the guard for the
capacity of the machine.
Do not use any blades that cut a smaller kerf than the
riving knife thickness. Make sure the riving knife is
correctly adjusted to the blade and is securely fastened.
If the table insert becomes damaged or broken, and will
not support the timber ‘up close’ to the blade, replace it.
Specific Safety Precautions

Specific Safety Precautions
7
Do not start the saw with the workpiece touching the
blade.
FOR YOUR OWN SAFETY NEVER
OPERATE THE TABLE SAW WITHOUT
THE RIVING KNIFE IN PLACE!
Do not commence sawing until the blade has run up to
full speed. After switching off, never try to slow the saw
down more quickly by applying side pressure (with a
piece of wood?) to the blade. Apply the old joiner’s adage
of never getting hands within one handbreadth of the
blade. Leave the machine disconnected from the mains
supply until you are about to commence work.
Always disconnect the machine if you are leaving it
unattended.
Never leave the vicinity of the machine unless the blade
has come to a complete stop.
Do not attempt to carry out any maintenance, corrective
work, setting up etc., unless the machine is disconnected
from the mains supply. If any tools have been used
during setting up procedures, make sure they are
removed from the machine and stowed safely away.
Do not attempt to carry out cross cutting operations
‘freehand’, always use the mitre fence for small material
and the sliding carriage for larger workpieces. Unless you
are an experienced machine operator, do not attempt to
‘rip’ freehand, always use the guiding facility of the rip
fence. It is perfectly acceptable to support, guide, and
feed the timber with your hands whilst ripping stuff of
some length, however, as you approach the blade ensure
that the push stick is to hand, and that you use it.
Remember the emphasis of the ‘push’ should be between
the blade and the fence and close to the fence. Use your
free hand to support and guide the material on the
offside of the saw blade and at least 100mm away from
it. If the timber does not extend to at least 100mm to the
offside of the saw blade, the material possibly does not
need guiding or supporting.
Check (especially on site), that there are no foreign
objects e.g. old nails, screws, small stones etc embedded
in the material you are about to cut. If necessary take a
wire brush to the timber before working.
Code 107715
Model AP254PS13
Rating Professional
Power 2.2kW 230V 1ph
Blade Dia/Bore 254 x 30 mm
Blade Speed 3,500 rpm
Blade Tilt 0°-45°
Max Depth of Cut @ 45˚ 60 mm
Max Depth of Cut @ 90˚ 80 mm
Max Width of Cut with Fence 600 mm
Max Ripping Width 600 mm
Table Size Main 760 x 350 mm, side ext 760 x 300 mm
Table Height 865 mm
Sliding Table Size 1,300 x 238 mm
Dust Extraction Outlet 100 mm
Min Extraction Airflow Required 850 m³/hr
Overall L x W x H 3,210 x 3,720 x 1,120 mm
Weight 155 kg
Specification

Assembly
8
PLEASE NOTE: Some of this assembly
procedure is best accomplished by two
persons, some of the items are heavy and
awkward, and a mishandling error could
cause injury. Please think about what you are doing,
your capabilities and your personal safety.
Unpack all the boxes, see fig 01-02-03 and check all the
components against the ‘What’s Included’ list. If any
parts or components are missing, please contact our
customer service department using the procedures
and telephone numbers listed in our catalogue, and
you will be dealt with quickly and efficiently.
Fig 01-02-03
Remove the polyurethane block from around
the motor assembly, see image above.
Remove all the components from inside the saw frame
PLEASE NOTE: The panel saw comes 80% assembled,
in order to reduce the footprint of the machine for
packaging, several items are dismounted from the
machine and need to be re-affixed. Please check all
the boxes, packets etc, to make sure that all the parts have
been accounted for.
Having unpacked the boxes, (please dispose of any
unwanted packaging responsibly), put the parts and
components where by they are readily to hand. Break
down the main box by knocking the sides away (be
careful of exposed nails etc.), but leave the machine
sitting on its pallet. Remove the protective grease film
that is coating all the unpainted parts of the machine.
Use a proprietary de-greasing agent. Unfortunately, this
cleaning process is always a bit ‘mucky’. You are advised
to wear overalls or coveralls etc., during the process.
After cleaning, lightly coat the exposed metal surfaces
with ‘anti rust’ oil spray to prevent any rusting.
Main Saw Body
Identify the side, back and front panels (2), lower leg
columns (3), dust extraction moulding (17) and M8 x
20mm Hex bolts, washer and nuts (A).
1. Locate the four leg columns (3), place a column on top
of the upper legs on the man saw assembly (1). Using
four M8 bolt,wahers and nuts (A) secure the columns in
position, see fig 01-02.
Fig 01-02
3
A

Assembly
9
Fig 06-07
2. Introduce the front panel (2) between the two col-
umns to the front of the saw body. Line up the holes and
lightly secure with M8 bolts (A). Repeat the procedure for
the back and one of the side panels, see fig 03-04-05.
Fig 03-04-05
3. Locate the dust extraction moulding (17). Remove the
screws, washers and nuts from the moulding, see fig 06.
Inset the moulding through the machined hole in the
back panel, line up the holes and secure using the fixing
you just removed, see fig 07.
Front panel
Back panel
Side panel
2
4. Locate the 100mm extraction flexible hose (18) and
hose clips (20), see fig 08. Slide one of the clips over one
end of the hose, introduce the hose over the extraction
moulding (17) and tighten the clip to secure the hose in
place, see fig 09. Fig 08-09
18
20
5. Insert the remaining clip (20) over the opposite end
of the hose. Introduce the hose over the saw assembly’s
dust housing outlet and tighten the clip to secure the
assembly in place, see fig 10-11-12.
NOTE: You will need to squeeze the end of the hose
to enable you to fit it over the saw’s dust outlet as it’s
oval in shape. Fig 10-11-12
17
Screw/washer
Continues Over....
Continues Over....

Assembly
10
Fitting the Operating Wheels
8. Locate the two operating wheels (16) and the square
keys. Remove the protective cap from one of the drive
shafts and remove the Hex screw/washer, place safely
aside, see fig 14-15.
Fig 14-15
Drive shaft
Protective cap
9. Insert one of the square keys into the machined slot
on the drive shaft, see fig 16. Line up the machined key
slot to the centre of the hand wheel (16) with the key
and slide the wheel onto the drive shaft. Replace the Hex
screw/washer you removed earlier and tighten securely,
see fig 17-18. Repeat for the other operating wheel.
Hex screw/washer
Fig 16
Square key
Fig 17-18
16
Machined key slot
6. Locate the remaining side panel (2) and four M8 Hex
bolts,washers and nuts (A) and secure in place, see fig 13.
7. Go round and securely tighten all the bolts.
Fig 13
2

Assembly
11
Side Access Door Knob (If not already assembled)
11. Introduce the threaded knob through the pre-drilled
hole in the side access door, slot the washer over the
thread and secure the knob in place with the nut, see fig
20-21.
Fig 20-21
12. Locate the rear extension table (5) and two
M8x20mm Hex bolts and washers (A). Lift the table up,
line up the pre-drilled holes with the threaded holes to
the rear of the main saw table (1). Introduce a bolt with a
washer through one of the holes in the rear table (5) and
screw it into the threaded hole in the main table. Lightly
finger tighten. Repeat the process for the remaining bolt/
washer. Place a straight edge across both tables and
gradually tighten the bolts until both tables are level, see
fig 22-23.
Fig 22-23
13. Locate the side extension table (4) and four
M8x25mm Hex bolts and washers (A). Lift the table up,
line up the pre-drilled holes with the threaded holes to
the side of the main saw table (1). Introduce a bolt with
a washer (A) through one of the holes in the side table
(4) and screw it into the threaded hole in the main table.
Lightly finger tighten. Repeat the process for the remain-
ing bolts/washers. Place a straight edge across both
tables and gradually tighten the bolts until both tables
are level, see fig 24-25-26.
Rear Extension Table
5
5
1
Straight edge
Side Extension Table
10. With everything secure, with assistance
tip the main saw over towards its blind face
until it is resting on the pallet.With its legs on
the floor lift the machine upright, see fig 19.
Fig 19
A
Fig 24-25-26
4
1
Continues Over....

Assembly
12
M8x20mm bolts/washers
Straight edge
14. Locate the crown guard assembly (13), riving knife
(12), 50mm flexible hose (19), the two 50mm hose clips
(21) and the hose support bracket (22). Remove the two
Phillips screws holding the inner guard assembly and
place safely aside, see 27-28.
Crown Guard
Fig 27-28
15. Loosen the two bolts holding the mounting plates.
Lower the riving knife (12) down between the mounting
plates, set the riving knife close to the blade and check
the clearance between the blade. It should have a gap of
(MIN 3mm - MAX 8mm), tighten the two bolts to secure
the setting, see fig 29-30-31-32. Fig 29-30-31-32
12
Mounting plate
Rear mounting plate
3-8mm Gap
between the
riving knife
and the blade
Clearance
Inner guard
Phillips screw
16. Locate the crown guard assembly (13) and loosen
the clamping knob. Introduce the slot to the rear of the
guard over the riving knife and slot the pin bolt into the

Assembly
13
curved slot in the riving knife.Tighten the clamping
knob, see fig 33-34.
Fig 3-34
Curved slot
13
12
Clamping knob
17. Place a 50mm hose clip (21) over the end of the hose
(19), see fig 35. Insert the hose over the extraction outlet
on the crown guard (13) and tighten the clip, see fig 36.
NOTE: DO NOT OVER TIGHT AS THE CROWN GUARD IS
PLASTIC AND LIABLE TO BREAK!
Fig 35-36
21
19
Extraction outlet
18. Place the remaining clip over the opposite end of the
hose. Insert the hose over the 50mm inlet on the 100mm
extraction moulding (17) and tighten the clip, see fig 37.
Fig 37
19. Locate the hose support bracket (22). Remove the
bolt/washer and nut, line up the hole in the bracket with
the mounting hole to the end of the side extension table
(4) and secure with the fixings you just removed, see fig
38. Slot the hose (19) onto the bracket, see fig 39.
Fig 38-39
22
19
4
20. Replace the inner guard assembly.
Continues Over....

Assembly
14
Fig 40-41
Fig 42
Sliding Table
NOTE: YOU WILL REQUIRE HELP FOR THIS
NEXT STEP!
6
Bolt/washer
Fig 43-44
‘T’ bolt
Support bracket
10
24. Open the side access door to gain access to the
support brackets and using the supplied spanner (E)
securely tighten the two‘T’ bolt nuts, see fig 45-46.
Fig 45-46
10
Spanner (E)
You will require the following: the sliding table extension
support arm (27), sliding table assembly (10), sliding table
fence (24), sliding table extension (11), mitre fence (14)
for sliding table, workpiece support shoe (23).
21. Remove the four bolts and washers from the bottom
corner of the main saw table’s frame, see fig 40. Locate
the extension support arm (6), line up the holes in the
support bracket with the holes in the saw frame and
secure with the bolts/washers you removed earlier, see
fig 41.
22. Loosen the two‘T’ bolts/nuts and washers from the
angled support brackets on the main saw (1), see fig 42.
23. With assistance, insert the first ‘T’ bolt into the
machined slot to the end of the sliding table assembly
(10). Slide the table on and repeat the process to the
opposite end of the main saw table (1), see fig 43-44.
Position the sliding table (10) so its over hangs equally
to both end of the main table (1).

Assembly
15
25. Locate the sliding table extension (11), line up the
two ‘T’ bolts on the extension table with the ‘T’ slots to
the side of the sliding table (10) and slide on the
extension table, see fig 47. Open up the supporting arm
(6), insert the extension table mounting bracket onto
the threaded pin/bolt on the supporting arm, see fig 48.
Using a spanner turn the bolt beneath the supporting
arm (6) to lock the two components together, see fig 49.
Lock the extension table (11) in place with the two lift
and shift handles, see fig 50.
Fig 47-48-49-50
26. Locate the sliding table supporting leg (27), loosen
the square bolt on top of the leg support. To the
underside of the sliding table (10), Insert the square bolt
into the ‘T’ slot to the end of sliding table assembly. Ro-
tate the leg, clockwise to secure the leg in position,
see fig 51.
27. Using a Hex key loosen the Hex screw to the centre of
the leg and adjust the leg until the foot is resting on the
floor, retighten the screw, see fig 52-53.
Fig 51-52-53
28. Put to hand the sliding table fence assembly (24),
remove both the steel clamping knob (A) and butterfly
knob(B) with washers from the fence and place to one
side. Lower the fence on top of the table extension (11),
insert the larger threaded pin into one of the pre-drilled
holes to the corners of the table extension (11). Insert
the other between the centre column of the table then
replace the clamping knobs and washers you removed
earlier, see fig 54-55-56-57-58. NOTE: Don’t tighten at
this point.
11
6
‘T’ Bolt
Threaded pin/bolt
Mounting bracket
11
Square bolt
10
‘T’ Slot
27
Hex screw
Foot
Lift & shift handles
Continues Over....

Assembly
16
Fig 54-55-56-57-58
Fig 59-60
A B
24
Large threaded pin
29. Lift-up the 90˚ stop located to the corners of the
extension table, push the fence up against the stop,
see fig 59. Slide the fence (24) near the blade but not
touching, see fig 60 and tighten both knobs (A) and (B).
90˚ Stop
Blade
30. Locate the distance stop assembly (26). Loosen the
butterfly clamping knob beneath the fence assembly (24)
and pull out the telescopic fence section out. Loosen the
clamping handle on the distance stop (26), insert the ‘T’
bolt into the ‘T’ slot to the centre of the fence assembly
and slide the distance stop on, see fig 61-62.
Fig 61-62
26
Telescopic fence
Butterfly clamping knob
31. Locate the Workpiece support shoe (23), insert the
‘T’ bolt into the ‘T’ slot to the left side of the sliding table
(10), slide the shoe on and clamp in place with the
clamping knob, see fig 63. Fig 63
23
‘T’ Slot
‘T’ Bolt

Assembly
17
32. Loosen the‘T’ bolt in the sliding table’s operating
handle (25). Insert the ‘T’ bolt into the ‘T’ slot into the
opposite end of the table and secure in place, see
fig 64-65.
Fig 64-65
33. Locate the overhead clamp and shaft (28). Remove
the mounting bar (a) from the sliding table.Slide the
shaft with the ‘T’ bolt into the ‘T’ slot to the centre of the
table and secure in place by rotating the shaft. Insert one
of two pre-drilled holes in the overhead clamp assembly
down over the shaft and lock in place with the clamping
knob, see fig 66-67.
Fig 66-67
25
‘T’ Bolt
‘T’ Slot 10
28
Shaft with ‘T’
mounting bolt
Clamping knob
You will require the following: the rip fence (9), rip fence
rail (7), micro adjuster (8), capping plates (D), small Phillips
screws (E) and the three M8x 25mm square head bolts/
washer/nuts (B).
34. Put to hand the fence rail (7) and square bolts (B).
Remove the washers and nuts and place safely aside.
Insert the square bolts into the machined holes to the
front of the main saw table (1) and replace the washers/
nuts you removed earlier. (Leave the bolts loose for the
next stage), see fig 68-69.
Rip Fence
Fig 68-69
35. Attach the capping plates (D) to the fence rail (7) as
shown in fig 70. Introduce the furthest right hand square
bolt (B) into the channels ‘T’ slot to the side of fence rail
(7) and slide on. Repeat for the remaining bolts, see fig
71-72. Fig 70-71-72
7
B
Capping plate
B
1
D
E
Channels ‘T’ Slot
a
Loosen the
grub screws
Continues Over....

Assembly
18
36. Reach under the table’s edge and lightly tighten all
the nuts. Re-attach the capping plate (D), see fig 73-74.
37. Locate the rip fence assembly (9) and lower the
clamping assembly over the fence rail (7). Raise the
clamping handle and slide the rip fence up against the
blade, see fig 75.
38. Look at the‘RED’ line on the magnifying glass to
check it’s set to ‘0’ on the scale, see fig 76. If the scale is
out of alignment, loosen the fence rail (7) and tap the
side until the scale reads ‘0’ then re-secure the fence rail,
see fig 77-78.
Fig 73-74
Fig 75
Fig 76-77-78
Rip fence scale
out of alignment
Scale aligned with
the ‘RED’ index line
Capping plate
39. Raise the clamping handle again and position the rip
fence so it’s in line with the edge of the main table’s ‘T’
slot, push the handle down to lock in place. If the fence
is out of alignment, loosen the four cap head bolts (a) on
top of the clamping assembly, see fig 79, adjust the rip
fence until its in alignment with the edge of the main
tables ‘T’ slot. Once complete tighten the cap head bolts
(a), see fig 80. Fig 79-80
Tables ‘T’ slot

Assembly
19
a
40. Locate the micro adjuster (8). Remove the rip fence
assembly from the fence rail (7) and remove the capping
plate from the left side of the fence clamping assembly,
see fig 81.
41. There are two Phillips screws through the micro
adjuster’s mounting bracket with square nuts on them.
Undo the nuts sufficiently to allow them to slide into the
‘T’ slot channel to the side of the rip fence assembly, see
fig 82. Position as required, normally slightly to the right
of the rip fence then tighten the two Phillips screws to
secure the assembly, see fig 83. Replace the capping
plate.
NOTE: making sure the pinion engages into the rack
beneath the fence rail (7).
Micro Adjuster
Fig 81-82-83
Capping plate
Square nuts
‘T’ Slot channel
Pinion
Phillips screw
8
Mitre Fence assembly for sliding Table
42. Locate the mitre fence housing (14), mitre fence
extension (15), locking knob, clamping handle and
workpiece clamp shaft. Replace the mounting bar (a) as
shown in step 33. Insert the Overhead clamp shaft into
the mitre fence housing and secure with a countersink
Hex screw, see fig 84. Lower the mitre fence housing on
top of the mounting bar to the right side of the sliding
table (10). Line up the threaded pre-drilled holes,
introduce the locking knob through the centre hole in
housing (14) and lightly tighten, see fig 85. Insert the
clamping handle through the machined cutout slot in
the housing and into the mounting bar, see fig 86.
Fig 84-85
8
14
Mounting bar
Overhead clamp shaft
Hex countersink screw
Hex key
Locking knob
Continues Over....

Assembly
20
43. Locate the overhead clamp assembly (28), insert
either mounting hole down over the shaft and lock in
place with the clamping knob, see fig 87.
Fig 86
Clamping handle
Machined slot
Fig 87
44. Put to hand the mitre fence extension (15), remove
the two locking knobs then introduce the threaded bolts
through the two pre-drilled holes in the mitre fence
housing (14) and tighten securely with the locking knobs,
see fig 88.
Fig 88
15
28
45. Adjust the mitre fence assembly until it reads ‘zero’
on the sliding tables scale.
46. Locate the mounting plate (30) and the remaining
four M8 bolts/washers. Line up the pre-driled holes in
the plate with the threaded holes to the front of the
panel saw frame and secure with the M8 bolts and
supplied spanner, see fig 89-90.
Fig 89-90
30
M8 Bolts/washers
