Axon TASER Bolt 2 Energy Weapon User manual

TASER Bolt 2 Energy Weapon
User Manual
Model TS1022
IMPORTANT SAFETY INSTRUCTIONS
Read all warnings and instructions. Save these instructions.
The most up-to-date warnings and instructions are
available at www.axon.com
MMU0080 Rev: A
April 2022
For more cartridges or fresh batteries, go to buy.taser.com

Contents
i
1 Chapter 1: Warnings
1Important Safety and Health Information
1LASER Information
3 Chapter 2: Ownership
4 Chapter 3: General Information
4What Is the TASER Bolt 2 Energy Weapon?
4Neuro Muscular Incapacitation (NMI)
4Basic Bolt 2 Electrical Theory
6 Chapter 4: TASER Bolt 2 Energy Weapon and Cartridge Features
6Safety Switch
7Safety Cap
7Safety Cap Leash
9Power Supply
10 Firing Button
10 Spark Duration
11 Electrodes
11 LASER and LED Flashlight
11 The TASER Bolt 2 Cartridge
11 Avoiding Unintentional Discharge
12 ProtectiveAnti-FelonIdentication(AFID)Tags
12 Loading a Cartridge
13 Unloading a Cartridge
14 Practicing with the Bolt 2 Energy Weapon
15 Aiming and Probe Placement
15 Using the Bolt 2 Energy Weapon
15 Deployment Instructions for Self-Defense.
16 “Silence is Golden”
16 PotentialCausesofReducedorNoEectiveness

ii
TASER Bolt 2 Energy Weapon User Manual
Contents
16 What if I Miss?
17 Contact Stun Backup
17 TASER Safe Escape Policy
18 Chapter 5: Smart Device Application
18 The Axon Protect Application
18 Installing Axon Protect
19 Uninstalling Axon Protect
19 Stopping False Alarms
19 Using Training Mode
20 Chapter 6: Maintenance and Care
20 General Concepts
20 Function Test
21 Changing the Batteries
22 Chapter 7: Additional Items
22 Troubleshooting
22 Legality
22 Warranty
22 Warnings
23 Medical Research
23 Radio Waves
23 FederalCommunicationsCommission(FCC)Statement
23 Compliance Marks

1
Chapter 1: Warnings
Important Safety and Health Information
These safety warnings posted at www.axon.com are for your protection as well as the safety of others.
Disregarding this information could result in death or serious injury.
! WARNING
Read and Obey
SignicantdierencesexistbetweendierentTASEREnergyWeaponmodels.Donotuse
or attempt to use any energy weapon model unless you have read, understood, and are
following all current instructions, warnings, and relevant TASER training materials before
using TASER energy weapons. Failure to do so could increase the risk of death or serious
injury to the user or others.
Obey Applicable Laws
Useofenergyweaponsmustbelegallyjustiedandcomplywithapplicablefederal,state,
and local laws and regulations.
Store in a Secure Location
Energy weapons and cartridges are weapons and, as with any weapon, follow safe
weapon-handling practices and store your energy weapon securely. Store energy
weapons, cartridges, and accessories in secure locations inaccessible to children and
other unauthorized persons to prevent inappropriate access or use.
For a complete list of product warnings, go to www.axon.com.
LASER Information
The energy weapon uses a Class 2 LASER as an aiming aid. LASERs can cause serious eye injury,
including permanent vision loss.

2
TASER Bolt 2 Energy Weapon User Manual
Chapter 1: Warnings
! WARNING
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 2 LASER PRODUCT
! WARNING
AVOID EXPOSURE – LASER RADIATION IS EMITTED
FROM THIS APERTURE
! CAUTION
Theuseofcontrolsoradjustmentsorperformanceofproceduresotherthanthosespeciedherein
may result in hazardous radiation exposure.

3
Chapter 2: Ownership
Donotpointtheenergyweaponatanylawenforcementocerordoanythingthatwouldcauselaw
enforcementocerstofeelthreatenedbyyouruseoftheenergyweapon.BecausetheTASERenergy
weaponisabletoincapacitateaperson,lawenforcementocersmaybejustiedtouselethalforce
to protect themselves.
Do not give a TASER energy weapon away as a gift or sell it without providing the new owner’s name,
email address, and phone number to customer service at [email protected]. For more information,
see Legality (Chapter7).
TakingaTASER-brandenergyweaponoutoftheUnitedStates(US)withouttheproperexportlicense
isprohibitedbylaw(similarprohibitionsmayexistinothercountries).
Check with TSA or any other relevant agency for the most recent regulations to determine whether
you are permitted to travel aboard a commercial airplane with a TASER energy weapon. Check local
laws to determine whether you may possess or carry a energy weapon in your destination.
It is recommended that you carry the Bolt 2 energy weapon only in a manufacturer approved holster
orcarryingcase.DonotcarryuncoveredBolt2cartridgesinyourpocketsastheycanberedby
electrostaticdischarge(staticelectricity).

4
Chapter 3: General Information
What Is the TASER Bolt 2 Energy Weapon?
The TASER Bolt 2 is a self-defense energy weapon manufactured by Axon Enterprise, Inc. TASER-brand
energyweaponsaredesignedtousepropelledwiresordirectcontacttoconductenergytoaectthe
sensory and/or motor functions of the nervous system.
The Bolt 2 energy weapon uses a replaceable cartridge containing compressed nitrogen to deploy two
small probes that are attached to the Bolt cartridge by insulated conductive wires with a maximum
lengthof15feet(4.6m).TheBolt2energyweapontransmitselectricalpulsesalongthewiresand
intothebody,whichifusedsuccessfullywillaectthesensoryandmotorfunctionsoftheperipheral
nervous system to immobilize the body.
The Bolt 2 energy weapon has an estimated useful life of two years.
Neuro Muscular Incapacitation (NMI)
TASER technology is designed to use electrical pulses similar to those in your body’s nervous system
to cause stimulation that aects the sensory and motor nerves. Neuro Muscular Incapacitation
(NMI)occurswhenanenergyweaponisabletocauseinvoluntarystimulationofboththesensory
nerves and the motor nerves to render an attacker temporarily unable to control movement.
It is not dependent on pain and can be eective on subjects with a high level of pain tolerance.
Previousgenerationsof stun gunscouldprimarilyaectthesensorynervesonly,resultinginpain
compliance. An attacker with a very high tolerance to pain (e.g., a drug abuser, person in serious
psychologicaldistress,oratrained,focusedghter)maynotbeaectedbythepainormightbeable
toghtthroughthepainofatraditionalstungun.
AnenergyweaponmaycauseNMIifprobesarewithinsucientproximitytocompleteacircuit,the
probeshaveasucientspread,andanadequatecircuitiscompletedandmaintained.
Basic Bolt 2 Electrical Theory
Electricitymustbeabletoowbetweentheprobesortheelectrodestodeliveranelectricalcharge
and will generally follow the path of least resistance.
Thegreaterthespreadbetweentheprobesonthetarget,generallythegreatertheNMIeectiveness.
Electricity will generally not pass to others in contact with the subject unless contact is made directly
between or on the probes or the wires are touched.
Exposuretowaterwillnotincreasethepowertothesubject(theelectricalchargeisxedinsidethe

5
TASER Bolt 2 Energy Weapon User Manual
Chapter 3: General Information
TASERenergyweapon,andwillnotincreasesignicantlyevenwithenvironmentalchanges).
Medicalstudieshavefoundthatmodernpacemakersandimplantedcardiacdebrillatorswithstand
externalelectricaldebrillatorsthatarestrongerthantheTASERconductedenergypulses.Formore
information go to www.axon.com.

6
Chapter 4: TASER Bolt 2 Energy Weapon and
Cartridge Features
Safety Switch
Thesafetyswitchisdesignedtominimizethepossibilityofinadvertentactivationoftheringbutton.
When the safety switch is in the forward position, the energy weapon is ARMED, and an LED illuminates
to indicate power to the energy weapon. Be sure to slide the safety switch all the way forward.
Smart Probe
AFIDs
Safety Cap
Blast Door LASER Sight
Safety Switch Firing Button
LED Flashlight
Battery Door
Safety switch
Safety switch in the
rearward(SAFE)
position
Theringbuttonisnot
illuminated
Safety switch in the
forward(ARMED)
position.
TheLEDonthering
button illuminates
when the weapon
is armed. The
illumination fades after
3–6seconds.

7
TASER Bolt 2 Energy Weapon User Manual
Chapter 4: TASER Bolt 2 Energy Weapon and Cartridge Features
IftheBolt2safetyswitchisleftintheforward(ARMED)positionformorethan20minutes,thesystem
will shut down to preserve battery life.
Tore-armtheBolt2energyweapon,movethesafetyswitchtotherearward(SAFE)position,then
backtotheforward(ARMED)position.
Safety Cap
The Bolt 2 energy weapon has a safety cap that covers the cartridge for added safety in carrying and
storage.Whenthesafetyswitchisshiftedtotheforward(ARMED)position,thesafetycapispushed
otheweapon.
Tore-placethesafetycap,rstshiftthesafetyswitchtotherearward(SAFE)position.
Be sure to not touch the ring button when putting the safety cap back on the Bolt 2 energy
weapon.
Safety Cap Leash
The optional safety cap leash can keep the safety cap tethered to the Bolt 2 energy weapon while
allowingthesafetycaptobepoppedothefrontoftheweaponwhenthesafetyswitchisshiftedto
theforward(ARMED)position.Theleashattachestothecapandtheweaponwithanadhesive.You
must remove a backing from the adhesive parts of the leash before attaching it to the safety cap and
weapon.
1 Conrmthattheweaponisunloaded.SeeUnloading a Cartridge for more information.
2 Put the safety cap on the energy weapon.
3 Remove the adhesive backing from the wing-shaped part of the leash by pulling on the two
tabs.
