Axor One 45712 7 Series Manual

INSTALLATION
ZH ⁄ 用户手册 ⁄ 组装说明 02
EN ⁄ Instructions for use ⁄ Assembly instructions 03
Lesezeichen
中文 02
English 03
AXOR One
45713X X7
AXOR One
45712XX7

02
ZH
安装 (参见第页 04)
安全技巧
装配时为避免挤压和切割受伤, 必须戴上手套.
本产品只允许作为洗浴, 卫生和洁身之用.
不得让儿童和肢体, 精神和⁄或意识有障碍的成人在不受监管的情况下使用淋
浴系统. 受酒精或毒品影响的人员不得使用淋浴系统.
冷热水管间过大的压力差必须予以平衡.
安装提示
⁄ 安装前必须检查产品是否受到运输损害. 安装后将不认可运输损害或表面损
伤.
⁄ 管道和阀门必须根据通用标准进行安装, 冲洗和检查.
⁄ 请遵守当地国家现行的安装规定.
技术参数
工作压强: 最大 1 MPa
推荐工作压强: 0,1 - 0,5 MPa
测试压强: 1,6 MPa
(1 MPa = 10 bar = 147 PSI)
热水温度: 最大 60°C
热力消毒: 70°C ⁄ 4 分钟
⁄ 自动防止回流
⁄ 该产品专为饮用水设计!
符号说明
请勿使用含有乙酸的硅胶!
调节 (参见第页 10)
安装完成后必须检查调温器的出水温度. 如在取水处测量所得的温度
与调温器上设定的温度有偏差, 那么必须进行调整.
安全功能 (参见第页 10)
恒温阀芯的安全功能可以预先设定所希望的最高出水温度, 例如最高
温度为42℃
保养 (参见第页 14)
单向阀必须在符合国家或当地的法律的情况下按照EN 806-5定期检查
(至少一年一次).
大小 (参见第页 12)
流量示意图 (参见第页 13 )
备用零件 (参见第页 16)
XX = 颜色代码
00 = 镀铬
34 = Brushed Black Chrome
67 = Matt Black
99 = Polished Gold-Optic
选装附件 (参见第页 16 )
不在供货范围内
⁄ 加长 25 mm #45790000
清洗 (参见第页 17 )
操作 (参见第页 11 )
问题 原因 补救
⁄龙头出水量小 ⁄ 水压不足 ⁄ 检查总水压
⁄ 调压器过滤网脏污 ⁄ 清洁龙头前面和恒温阀芯的过滤网.
⁄ 花洒滤网有垃圾堵塞 ⁄ 清洗花洒和软管间的过滤网
⁄串水, 在龙头关闭的状态下, 热水被强迫流入冷水管
路, 或者相反.
⁄ 单向阀有垃圾堵塞或漏水 ⁄ 清洗单向阀, 如有必要则更换新的
⁄龙头出水温度和温度设定的不符 ⁄ 恒温阀芯未被调节 ⁄ 调节恒温器
⁄ 热水温度过低 ⁄ 将热水温度从42ºC升高到60ºC
⁄水温无法调节 ⁄ 恒温阀芯表面结垢 ⁄ 更换-恒温阀芯
⁄使用恒温龙头后, 燃气热水器不工作 ⁄ 过滤网有垃圾堵塞 ⁄ 清洗过滤网⁄更换过滤网
⁄ 单向阀装反 ⁄ 正确安装单向阀
⁄ 手持花洒的流量限制器没有去除 ⁄ 去除流量限制器

03
EN
ASSEMBLY (see page 04 )
SAFETY NOTES
Gloves should be worn during installation to prevent crushing and cutting injuries.
The product may only be used for bathing, hygienic and body cleaning purposes.
Children as well as adults with physical, mental and⁄or sensoric impairments must
not use this product without proper supervision. Persons under the influence of
alcohol or drugs are prohibited from using this product.
The hot and cold supplies must be of equal pressures.
INSTALLATION INSTRUCTIONS
⁄ Prior to installation, inspect the product for transport damages. After it has been
installed, no transport or surface damage will be honoured.
⁄ The pipes and the fixture must be installed, flushed and tested as per the applicable
standards.
⁄ The plumbing codes applicable in the respective countries must be observed.
TECHNICAL DATA
Operating pressure: max. 1 MPa
Recommended operating pressure: 0,1 - 0,5 MPa
Test pressure: 1,6 MPa
(1 MPa = 10 bar = 147 PSI)
Hot water temperature: max. 60°C
Thermal disinfection: 70°C ⁄ 4 min
⁄ Safety against backflow
⁄ The product is exclusively designed for drinking water!
SYMBOL DESCRIPTION
Do not use silicone containing acetic acid!
ADJUSTMENT (see page 10)
After the installation, the output temperature of the thermostat must be
checked. A correction is necessary if the temperature measured at the output
differs from the temperature set on the thermostat.
SAFETY FUNCTION (see page 10 )
The desired maximum temperature for example max. 42º C can be pre-set
thanks to the safety function.
MAINTENANCE (see page 14 )
The check valves must be checked regularly according to EN 806-5 in
accordance with national or regional regulations (at least once a year).
DIMENSIONS (see page 12)
FLOW DIAGRAM (see page 13 )
SPARE PARTS (see page 16 )
XX = Colors
00 = Chrome Plated
34 = Brushed Black Chrome
67 = Matt Black
99 = Polished Gold-Optic
SPECIAL ACCESSORIES (see page 16 )
order as an extra
⁄ extension 25 mm #45790000
CLEANING (see page 17)
OPERATION (see page 11)
FAULT CAUSE REMEDY
⁄ Insufficient water ⁄ Supply pressure inadequate ⁄ Check water pressure (If a pump has been installed check
to see if the pump is working).
⁄ Regulator filter dirty ⁄ Clean filter in front of the mixer and on the MTC-thermo car-
tridge
⁄ Shower filter seal dirty ⁄ Clean filter seal between shower and hose
⁄ Crossflow, hot water being forced into cold water pipe, or
vice versa, when mixer is closed
⁄ Backflow preventers dirty or leaking ⁄ Clean backflow preventers, exchange if necessary
⁄ Spout temperature does not correspond with temperature
set
⁄ Thermostat has not been adjusted ⁄ Adjust thermostat
⁄ Hot water temperature too low ⁄ Increase hot water temperature to 42 ºC to 60 ºC
⁄ Temperature regulation not possible ⁄ thermo cartridge calcified ⁄ Exchange thermo cartridge
⁄ Instantaneous heater didn't work with thermostat ⁄ Filters are dirty ⁄ Clean the filter ⁄ exchange filter
⁄ check valve hasn't moved back ⁄ Exchange check valves
⁄ Flow limiter in handshower isn’t removed ⁄ Remove flow limiter

04
Armaturenfett
Grease
䀵滑油
SW 17 mm
1 mm
SW 4 mm
SW 12 mm
(4 Nm)
1.
2.
AXOR One
45710187
Silicone
06
BAXOR One
457120 07
05
AAXOR One
457120 07
07
CAXOR One
457120 07
06 + 07
DAXOR One
457120 07
08
EAXOR One
457130 07
09
FAXOR One
457130 07
3
6
1
4
7
2
5
Montage Montage A

05
1.
2.
1.
2.
1.
2.
SW 4 mm
(2 Nm)
M5x55
M5x25 SW 4 mm
(1 Nm)
AXOR One
45712X X 7
SW 4 mm
(5 Nm)
M5x10
CLICK
A
3
6
9
12
1
4
7
10
2
5
8
11
Montage A

06
SW 4 mm
(5 Nm)
M5x10
1.
2.
SW 19 mm
(8 Nm)
SW 10 mm
(8 Nm)
SW 19 mm
SW 10 mm
AXOR One
45712X X 7
1.
2.
1.
2.
SW 4 mm
(5 Nm)
M5x10
SW 4 mm
(2 Nm)
M5x55
CLICK
B
3
6
9
12
1
4
7
10
13
2
5
8
11
14
Montage B Montage C

07
SW 4 mm
(5 Nm)
M5x10
1.
2.
1.
2.
M5x25 SW 4 mm
(1 Nm)
1.
2.
SW 6 mm
SW 4 mm
(2 Nm)
M5x55
AXOR One
45712X X 7
CLICK
C
3
6
9
12
1
4
7
10
13
2
5
8
11
Montage C

08
1.
2.
SW 4 mm
(5 Nm)
M5x10
AXOR One
45713X X7
1.
2.
1.
2.
SW 4 mm
(2 Nm)
M5x55
M5x25 SW 4 mm
(1 Nm)
CLICK
E
3
6
9
12
1
4
7
10
13
2
5
8
11
Montage E Montage F

09
1.
2.
SW 6 mm
SW 4 mm
(5 Nm)
M5x10
AXOR One
45713X X7
1.
2.
1.
2.
SW 4 mm
(2 Nm)
M5x55
M5x25 SW 4 mm
(1 Nm)
CLICK
F
3
6
9
12
1
4
7
10
13
2
5
8
11
14
Montage F

10
SW 4 mm
1.
1.
1.
2.
2.
2.
例如 42°C
for example 42° C
TX20
SW 4 mm
(1 Nm)
1.
2.
TX20
(0,8 Nm)
1.
2. CLICK
1
1 2 3
4 5 6
7 8 9
10 11 12 13
2 3
BedienungJustierung Safety Function

11
1.
2.
> 40°C
Bedienung

12
AXOR One
45713X X7
67
25
135135
120
270
AXOR One
45712X X 7
67
25
135135
120
270
Maße Durchflussdiagramme

13
1200
DN 15 DN 15
DN 15
DN 15
4,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
5,0
bar
0,45
0,00
0,05
0,10
0,15
0,20
0,25
0,30
0,35
0,40
0,50
036912151821242730
Q = l/min
MPa
00,1 0,2 0,3 0,4 0,5
Q = l/sec
2
1
1+2
2
1
1200
DN 15 DN 15
DN 15
DN 15
2
3
14,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
5,0
bar
0,45
0,00
0,05
0,10
0,15
0,20
0,25
0,30
0,35
0,40
0,50
036912 15 18 21 24 27 30
Q = l/min
MPa
00,1 0,2 0,3 0,4 0,5
Q = l/sec
2 3
1
1+2+3
1+2
AXOR One
45713X X7
AXOR One
45712X X 7
Durchflussdiagramme

14
SW 4 mm
(5 Nm)
SW 4 mm
(5 Nm)
Armaturenfett
Grease
䀵滑油
SW 12 mm
SW 4 mm
SW 4 mm
1.
2.
SW 12 mm
(4 Nm)
1.
1. 2.
2.
1.
2.
SW 4 mm
(5 Nm)
1 2 3
4 5 6
7 8 9
10 11 12
13 14 15
WartungWartung

15
1.
2.
SW 4 mm
(1 Nm)
CLICK
16 17 18
19 20
Wartung

16
+
45790XX0
(25 mm)
98127000
(11x 2)
98390000
(26x1,5)
98128000
(13x2)
98282007
98368000
98368000
98913000
97980000
92614000
98210000
(57x2)
92541X X0
98210000
(57x2)
92613X X0
92600XX0
92541X X0
92599XX0
95758000
95758000
95758000
98368000
(M28x1, 5)
SW 19 mm
98536000
SW 17 mm
M5x55
SW 4 mm
97664000
(M5x25)
SW 4 mm
98932000
TX20
M5x10
SW 4 mm
AXOR One
45713X X7
98127000
(11x 2) 98128XX0
(13x2)
97980000
98210000
(57x2)
92541X X0
98210000
(57x2)
92612XX0
92600XX0
92541X X0
92599XX0
98137000
(17x1,5) 98219000
(21x1, 5)
98390000
(26x1,5)
98282007
98368000
98913000
92614000
95758000
95758000
M5x55
SW 4 mm
98536000
SW 17 mm
98368000
(M28x1, 5)
SW 19 mm
M5x10
SW 4 mm
97664000
(M5x25)
SW 4 mm
98932000
TX20
AXOR One
45712X X 7
Serviceteile SonderzubehörServiceteile Reinigung

17
CLEANING RECOMMENDATION FOR HANSGROHE PROD-
UCTS
Today, modern sanitary and kitchen tapware, showers, accessories, washstands, tubs
and radiators consist of very different materials to comply with the needs of the market
with regard to design and functionality.
To avoid damage and reclamations, it is necessary to consider certain criteria when
cleaning.
WITH REGARD TO CARING FOR THE HANSGROHE PROD-
UCTS, THE FOLLOWING MUST IN PRINCIPLE BE HEEDED:
⁄ Only use cleaning material which is explicitly provided for this type of application.
⁄ Never use cleaning materials, which contain hydrochloric acid, formic acid, chlorin
e
pale lye or acetic acid, as they cause considerable damage.
⁄ Phosphorus acidic cleaners are only conditionally applicable.
⁄ Mixing cleaning agents is not permitted, generally.
⁄ Never use cleaning materials or appliances with an abrasive effect, such as
unsuitable cleaning powders, sponge pads or micro fibre cloths.
⁄ The instructions of the cleaning agent manufacturers have to be followed absolutely.
⁄ Cleaning has to be carried out with a specified cleaner dosage, contact time,
object-related and adapted to the needs.
⁄ The building up of calcifications has to be removed by cleaning regulary.
⁄ When using spray cleaners, spray the cleaning solution onto a soft cloth or sponge,
never directly onto the Hansgrohe products, as the atomised spray could enter
openings and gaps in the Hansgrohe products and cause damage.
⁄ After cleaning rinse thoroughly with clean water to remove any cleaner residue.
⁄ The use of steam cleaners is not permitted. The high temperatures can damage the
products.
Important
Residues of toiletries such as liquid soaps, shampoos and shower gels, hair dyes,
perfumes, aftershave and nail varnish can also cause damage.
Here too: Carefully rinse with water after use to remove residues.
Likewise, do not store any cleaning agents or chemicals under the products, for
example in a vanity unit, as the vapours may damage the products.
The damage of already damaged surfaces will deteriorate under the effect of the
cleansers.
Components with damaged surfaces must be exchanged, otherwise there
could be an injury danger.
Damage caused by improper treatment will not be covered by our guarantee.
WARRANTY
Hansgrohe guarantees to the consumer that this product is free of production faults. If
evertheless any defect is detected within 5 years from date of purchase, Hansgrohe
will
remedy this defect free of charge. You will find the conditions and details of this
guarantee at www.hansgrohe-int.com/guarantee. Please contact your contracting
party to claim your rights under this guarantee. This guarantee does not affect the
customer‘s rights under the respective national legislation.
QUICKCLEAN
The QuickClean cleaning function only needs a small manual rub over to remove the
lime scale from the spray channels.
⁄
⁄
⁄
⁄
⁄
⁄
⁄
⁄
⁄
⁄
⁄
Hansgr
ohe
Hansgrohe
www
.hansgrohe-int.com/guarantee
QUICK
CLEAN
QuickClean
Reinigung

18

19

06⁄2022 9.01063.51
AXOR ⁄ Hansgrohe SE
Auestraße 5–9
77761 Schiltach
Deutschland
[e-mail]
axor-design.com
