Axxess AX-LR90082 User manual

CAUTION! All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
AX-LR90082
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 6/21/18 INSTAX-LR90082
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell
caps, etc.)
TABLE OF CONTENTS
Connections to be made .......................................2
Installing the AX-LR90082 interface.....................3
Programming the ASWC-1 interface .....................3
Land Rover Range Rover Vogue (with M.O.S.T. 25 amplifier) Data Interface with SWC 2006-2012*
• Provides accessory power
• Designed for amplified models
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Micro “B” USB updatable
• AX-LR90082 interface
• AX-LR90082 amplifier interface
• ASWC-1 interface
• AX-LR90082 harness
• ASWC-1 harness
• M.O.S.T. jumper harness
• Female 3.5mm connector with stripped leads
* Facelift models, with touchscreen

2
CONNECTIONS TO BE MADE
From the aftermarket radio to the AX-LR90082 harness:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Red wire to the accessory wire.
• If the aftermarket radio has an illumination wire, connect the Orange wire to it.
• Connect the Blue wire to the power antenna turn-on wire.
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire.
• Connect the Red and White RCA jacks to the front amplifier output jacks of the aftermarket radio .
From the aftermarket radio to the ASWC-1 harness:
This harness is only to be used if the vehicle is equipped with steering wheel controls.
• Connect the Red wire to the accessory wire.
• The 3.5mm jack is to be used to retain audio controls on the steering wheel control.
• For
the radios listed below, connect the female 3.5mm connector with stripped leads , to the male
3.5mm SWC jack from the ASWC-1 harness. Any remaining wires tape off and disregard :
• Eclipse: Connect the steering wheel control wire, normally Brown, to the Brown/White
wire of the connector. Then connect the remaining steering wheel control wire, normally
Brown/White, to the Brown wire of the connector.
• Metra OE: Connect the steering wheel control Key 1 wire (Gray) to the Brown wire.
• Kenwood or select JVC with a steering wheel control wire: Connect the Blue/Yellow
wire to the Brown wire.
• XITE: Connect the steering wheel control SWC-2 wire from the radio to the Brown wire.
• Parrot Asteroid Smart or Tablet: Connect the 3.5mm jack into the AX-SWC-PARROT (sold
separately), and then connect the 4-pin connector from the AX-SWC-PARROT into the radio .
Note:
The radio must be updated to rev. 2.1.4 or higher software.
• Universal “2 or 3 wire” radio: Connect the steering wheel control wire, referred to
as Key-A or SWC-1, to the Brown wire of the connector. Then connect the remaining
steering wheel control wire, referred to as Key-B or SWC-2, to the Brown/White wire of
the connector. If the radio comes with a third wire for ground, disregard this wire.
Note:
After the interface has been programmed to the vehicle, refer to the manual provided
with the radio for assigning the SWC buttons. Contact the radio manufacturer for more
information .
• For all other radios: Connect the 3.5mm jack from the ASWC-1 harness, into the jack on the
aftermarket radio designated for an external steering wheel control interface. Please refer to
the aftermarket radios manual if in doubt as to where the 3.5mm jack goes to.

3
REV. 6/21/2018 INSTAX-LR90082
With the key in the off position:
• Connect the AX-LR90082 harness to the AX-LR90082 interface.
• Connect the AX-LR90082 harness to the AX-LR90082 amplifier interface.
• Remove the dust cover from fiber optic port in the AX-LR90082 amplifier interface.
• Connect the factory fiber optic cable into the AX-LR90082 amplifier interface. *
• Connect the AX-LR90082 harness to the wiring harness in the vehicle. *
• Connect the ASWC-1 harness to the ASWC-1 interface, and then to the AX-LR90082 interface.
• Connect the M.O.S.T. jumper harness to the factory fiber optic cable from the display screen.
• Press and hold the Volume-Up button on the steering wheel.
• Turn the ignition on, the L.E.D. in the ASWC-1 interface will start flashing rapidly, which
means the ASWC-1 is looking for the vehicle and the radio.
Note:
If the L.E.D. did not start flashing rapidly, press the reset button for 3 seconds , while
still holding the Volume-Up button.
• After a few seconds the L.E.D. should stop flashing rapidly, and then go out for approximately 2 seconds .
• After approximately 2 seconds there will be a series of 7 Green flashes, some short, and
some long. The long flashes represent the wires that are connected to the ASWC-1. The 3rd,
4th, 5th, and 6th flashes should be longer.
Tip:
Knowing this will help to troubleshoot, if need be.
• The L.E.D. will pause for another 2 seconds, and then flash Red up to 18 times depending on
which radio is connected to the ASWC-1. Refer to the L.E.D. feedback section for information.
• This is the end of the auto detection stage.
Release from holding the Volume-Up button.
If the ASWC-1 detected the vehicle and the radio successfully, the L.E.D. will light up solid.
• Test the steering wheel controls for proper operation. Refer to the ASWC-1 instructions online
at axxessinterfaces.com for customizing the buttons, if so desired.
INSTALLING THE AX-LR90082 INTERFACE
PROGRAMMING THE ASWC-1
INTERFACE (CONT.)
L.E.D. feedback
The (18) Red L.E.D. flashes represent which brand radio the ASWC-1 is connected to. Each
flash represents a different radio manufacturer. For example, if you are installing a JVC radio,
the ASWC-1 will flash Red (5) times, and then stop. Following is a legend that dictates which
radio Manufacturer corresponds to which flash.
L.E.D. feedback legend
* Note: If the ASWC-1 flashes Red (7) times, and you do not have an Alpine radio connected to
it, that means the ASWC-1 does not detect a radio connected it. Verify that the 3.5mm jack is
connected to the correct steering wheel jack/wire in the radio.
** Note: The AX-SWC-PARROT is required (sold separately). Also, the Parrot radio must be updated
to rev. 2.1.4 or higher through www.parrot.com.
† Note: If you have a Clarion radio and the steering wheel controls do not work, change the radio type to
the other Clarion radio type; same for Eclipse. Refer to the “Programming Information” document online
.
‡ Note: If you have a Kenwood radio and the L.E.D. feedback comes back as showing as a JVC radio,
change the radio type to a Kenwood. Refer to the “Programming Information” document online.
1 flash - Eclipse (Type 1) †
2 flashes - Kenwood ‡
3 flashes - Clarion (Type 1) †
4 flashes - Sony / Dual
5 flashes - JVC
6 flashes - Pioneer / Jensen
7 flashes - Alpine *
8 flashes - Visteon
9 flashes - Valor
10 flashes - Clarion (Type 2) †
11 flashes - Metra OE
12 flashes - Eclipse (Type 2) †
13 flashes - LG
14 flashes - Parrot **
15 flashes - XITE
16 flashes - Philips
17 flashes - TBD
18 flashes - JBL
PROGRAMMING THE ASWC-1 INTERFACE
* These factory harnesses are located at the tuner brain, behind the glovebox
