Axxess AXDIS-HK1 User manual

AXDIS-HK1
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2021 METRA ELECTRONICS CORPORATION REV. 9/20/21 INSTAXDIS-HK1
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections are secure before
cycling the ignition to test this product.
NOTE: Refer to the instructions included with
the aftermarket radio.
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder,
and heat shrink • Tape • Wire cutter • Zip ties
TABLE OF CONTENTS
Connections ........................................................ 2-4
Installation .............................................................5
Programming .........................................................6
Steering Wheel Control Settings ...................... 7-9
L.E.D. feedback ....................................................5
Changing radio type ...........................................7
Remapping .......................................................7-8
Dual assignment .............................................8-9
Troubleshooting .....................................................9
Hyundai/Kia Data Interface with SWC 2010-2016
APPLICATIONS
INTERFACE FEATURES
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains BlueLink
• Designed for amplified* and non-amplified models**
• Retains balance and fade†
• Micro-B USB updatable
HYUNDAI
Elantra * 2011-2016
Genesis Coupe * 2013-2016
Santa Fe * 2013-2016
Santa Fe Sport * 2014-2016
Sonata * 2011-2016
Sonata Hybrid * 2011-2015
Tucson * 2010-2015
KIA
Optima * 2011-2015
Optima Hybrid * 2011-2016
Sorento (with UVO) * 2011-2013
Sorento * 2014-2016
Soul * 2012-2013
Sportage 2011-2016
INTERFACE COMPONENTS
• AX-HK1 interface
• AX-HK1 harness
• 16-pin harness with stripped leads
• Female 3.5mm connector with stripped leads
* Requires the AX-HYKIA-SPDIF (sold separately)
** Bristol Audio Systems not covered
† Non-amplified models only
* Without NAV
Visit AxxessInterfaces.com for more detailed information about the product and up-to-date
vehicle specific applications

2
NON-AMPLIFIED VEHICLES
Interface
22 Pin
16 Pin
Vehicle Connectors
8 Pin
SWC Jack
Red
White
AUX IN RETENTION
14 Pin
18 Pin
24 Pin
}
DO NOT USE
USB RETENTION
Back-up Camera
Camera Power 6 Volt
Camera Ground
Back-up Camera
USB Cable
16 Pin
Connect for
Non-Amplified Vehicles
Black - Ground
Yellow - Constant
Blue - Power antenna
Orange - Illumination
Blue/Pink - VSS
Green - Left Rear (+)
Green/Black - Left Rear (-)
Purple - Right Rear (+)
Purple/Black - Left Rear (-)
White - Left Front (+)
White/Black - Left Front (-)
Gray - Right Front (+)
Gray/Black - Right Front (-)
Red - Accessory
Blue/White - Amp turn-on
Brown - Mute
(A) DO NOT USE
(B) DO NOT USE
Vehicles with Bristol Audio
systems are not covered.
IMPORTANT!

3
REV. 9/20/21 INSTAXDIS-HK1
AMPLIFIED VEHICLES WITHOUT NAVIGATION
Interface
22 Pin
16 Pin
Vehicle Connectors
(A) DO NOT USE
SPDIF
14 Pin
18 Pin
24 Pin
(B) Connect
Sold Separately
Back-up Camera
Camera Power 6 Volt
Camera Ground
Back-up Camera
16 Pin
8 Pin
DO NOT Connect
SWC Jack
Red
White
AUX IN RETENTION
}
USB RETENTION
USB Cable
Black - Ground
Yellow - Constant
Blue - Power antenna
Orange - Illumination
Blue/Pink - VSS
Green - Left Rear (+)
Green/Black - Left Rear (-)
Purple - Right Rear (+)
Purple/Black - Left Rear (-)
White - Left Front (+)
White/Black - Left Front (-)
Gray - Right Front (+)
Gray/Black - Right Front (-)
Red - Accessory
Blue/White - Amp turn-on
Brown - Mute
Vehicles with Bristol Audio
systems are not covered.
IMPORTANT!

4
Interface
22 Pin
16 Pin
Vehicle Connectors
(B) DO NOT USE
SPDIF
14 Pin
18 Pin
24 Pin
(A) Connect
DO NOT USE
Back-up Camera
Camera Power 6 Volt
Camera Ground
8 Pin
Back-up Camera
Sold Separately
SWC Jack
Red
White
AUX IN RETENTION
}
USB RETENTION
USB Cable
Black - Ground
Yellow - Constant
Blue - Power antenna
Orange - Illumination
Blue/Pink - VSS
Green - Left Rear (+)
Green/Black - Left Rear (-)
Purple - Right Rear (+)
Purple/Black - Left Rear (-)
White - Left Front (+)
White/Black - Left Front (-)
Gray - Right Front (+)
Gray/Black - Right Front (-)
Red - Accessory
Blue/White - Amp turn-on
Brown - Mute
AMPLIFIED VEHICLES WITH NAVIGATION
Vehicles with Bristol Audio
systems are not covered.
IMPORTANT!

5
REV. 9/20/21 INSTAXDIS-HK1
With the key in the off position:
• Connect the 16-pin harness with
stripped leads, and the AX-HK1
harness, into the AX-HK1 Interface.
• For models equipped with a factory
amplifier, connect the AX-HK1-SPDIF
(sold separately) to the AX-HK1
interface.
Attention! Do not connect the AX-HK1 harness
to the vehicle’s wiring harness until Step 2 of
Programming.
Attention! If retaining steering wheel
controls, ensure that the jack/wire is
connected to the radio before proceeding.
If this step is skipped, the interface will need
to be reset for the steering wheel controls
to function.
I N S TAL L AT IO N
Flash Count Radio
1 Eclipse (type 1) †
2 Kenwood ‡
3 Clarion (type 1) †
4 Sony / Dual
5 JVC
6 Pioneer / Jensen
7 Alpine *
8 Visteon
9 Valor
10 Clarion (type 2) †
11 Metra OE
12 Eclipse (type 2) †
13 LG
14 Parrot **
15 XITE
16 Philips
17 TBA
18 JBL
19 Insane Audio
20 Magnadyne/Axxera
21 Boss
L.E.D. Feedback Legend
L.E.D. feedback
The (21) Red L.E.D. flashes represent which
brand radio the AX-HK1 detects.
Each flash represents a different radio
manufacturer. For example, if you are
installing a JVC radio, the AX-HK1 will flash
Red (5) times, and then stop.
Following is the L.E.D Feedback Legend
a legend that indicates which radio
Manufacturer corresponds to which flash.
*Note: If the AX-HK1 flashes Red (7)
times, and you do not have an Alpine radio
connected to it, that means the ASWC-1
does not detect a radio connected it. Verify
that the 3.5mm jack is connected to the
correct steering wheel jack/wire in the
radio.
** Note: The AX-SWC-PARROT is required
(sold separately). Also, the Parrot radio
must be updated to rev. 2.1.4 or higher
through www.parrot.com.
† Note: If you have a Clarion radio and
the steering wheel controls do not work,
change the radio type to the other
Clarion radio type; same for Eclipse.
Refer to the “Programming Information”
document online .
‡ Note: If you have a Kenwood radio
and the L.E.D. feedback comes back
as showing as a JVC radio, change the
radio type to a Kenwood. Refer to the
“Programming Information” document
online.
Continued on the next page

6
5. The radio will shut off at this point. This process should take 5 to 30
seconds. Once the vehicle has been auto detected by the interface, the
L.E.D. will turn solid Green, and the radio will come back on, indicating
programming was successful.
6. Turn the vehicle off then on again to make sure the programming worked.
7. Test all functions of the installation for proper operation, before
reassembling the dash.
For the steps below, the L.E.D. located inside the interface can only be seen while active. The
interface does not need to be opened to see the L.E.D.
1. Turn on the vehicle.
2. Connect the AX-HK1 harness to the wiring harness in the vehicle.
3. The L.E.D. will initially turn solid Green, then turn off for several seconds,
while it auto detects the radio installed.
4. The L.E.D. will then flash Red up to (21) times, indicating which radio is
connected to the interface, and then turn off for several seconds. The L.E.D.
will then turn solid Red, while the interface auto detects the vehicle.
O
F
F
A
C
C
O
N
S
T
A
R
T
Green & Red LED
Green or Red LED
Green & Red LED
Green LED
PROGRAMMING
Green & Red LED
Green LED
O
F
F
A
C
C
O
N
S
T
A
R
T
O
F
F
A
C
C
O
N
S
T
A
R
T

7
REV. 9/20/21 INSTAXDIS-HK1
STEERING WHEEL CONTROL SETTINGS
Changing radio type
If the LED flash count does not match the radio in the Radio Legend, then the AXDIS-HK1 must be
manually programmed:
1. Turn the key to the ignition and after (3) seconds press and hold the Volume-Down button
on the steering wheel until the L.E.D. in the AX-HK1 interface turns a solid green.
2. Release the Volume-Down button; the L.E.D. will go out indicating the interface is in
Changing Radio Type mode.
3. Press and hold the Volume-Up button until the L.E.D. turns a solid green and then release.
Repeat this step until the number of the radio manufacturer from the Radio Legend is
reached.
4. Once the desired radio number has been selected, press and hold the Volume-Down button
on the steering wheel until the L.E.D. turns a solid green. The L.E.D. will remain on for about
(3) seconds, while it stores the new radio information.
5. Once the L.E.D. goes off, the Changing Radio Type mode will then end. You can now test the
steering control wheel controls.
Note: If at any time the user fails to press any button for a period longer than (10) seconds, this
process will abort.
Attention: The Axxess Updater App can also be used to program the following (3) sub-sections as
well, after the interface has been initialized and programmed.
Remapping
Once the AX-HK1 has been programmed, the button assignment for the steering wheel controls
may be reassigned, if so desired. For example, the Seek-Up button can be reprogrammed to be
the Mute button. Follow the steps below to remap the steering wheel control buttons:
1. Ensure the AX-HK1 is visible so you can see the L.E.D. flashes to confirm button recognition.
Tip: Turning the radio off is recommended.
2. Within the first 20 seconds of turning the ignition on, press and hold the Volume-Up button
on the steering wheel until the L.E.D. turns a solid green.
3. Release the Volume-Up button, the L.E.D. will then go out; The Volume-Up button has now
been programmed.
4. Follow the list in the Button Assignment Legend to reference the order in which the steering
wheel control buttons need to be programmed.
Note: If the next function on the list is not on the steering wheel, press the Volume-Up button
for (1) second until the L.E.D. comes on, and then release the Volume-Up button. This will tell the
AX-HK1 that this function is not available and it will move on to the next function.
5. To complete the remapping process, press and hold the Volume-Up button on the steering
wheel until the L.E.D. in the AX-HK1 goes out.
Continued on the next page

8
1. Volume-Up
2. Volume-Down
3. Seek-Up/Next
4. Seek-Down/Prev
5. Source/Mode
6. Mute
7. Preset-Up
8. Preset-Down
9. Power
10. Band
11. Play/Enter
12. PTT (Push to Talk)
13. On-Hook
14. Off-Hook
15. Fan-Up *
16. Fan-Down *
17. Temp-Up *
18. Temp-Down *
Button assignment legend
Note: Some radios may not have these commands. Please refer to the manual provided with the
radio, or contact the radio manufacturer for specific commands recognized by that particular radio.
* Not applicable in this application
STEERING WHEEL CONTROL SETTINGS (CONT.)
Dual assignment (long button press)
The AX-HK1 has the capability to assign (2) functions to a single button, except Volume-Up and
Volume-Down. Follow the steps below to program the button(s) to the desired setting .
Note: Seek-Up and Seek-Down come pre-programmed as Preset-Up and Preset-Down for a
long button press.
1. Turn the key to the ignition but do not start the vehicle.
2. Press and hold the desired steering wheel control button for (10) seconds, or until the L.E.D.
flashes rapidly. At this point release the button; the L.E.D. will then turn a solid green.
3. Press and release the Volume-Up button the number of times corresponding to the new button
number selected. Refer to the Dual Assignment Legend. The L.E.D. will flash rapidly while the
Volume-Up button is being pressed, and then go back to a solid L.E.D. once released. Proceed
to the next step once the Volume-Up button has been pressed the desired number of times.
Caution: If more than (10) seconds elapses between pressing the Volume-Up button, this
procedure will abort, and the L.E.D. will go out.
4. Press the desired button to store it to memory. The L.E.D. will now go out indicating the new
information has been stored to memory.
Note: These steps must be repeated for each button desired to assign a dual assignment feature
to. To reset a button back to its default state, repeat Step 1, then press the Volume-Down button.
The L.E.D. will go out, and the dual assignment feature for that button will be erased.

9
REV. 9/20/21 INSTAXDIS-HK1
Dual assignment legend
1. Not allowed
2. Not allowed
3. Seek-Up/Next
4. Seek-Down/Prev
5. Mode/Source
6. ATT/Mute
7. Preset-Up
8. Preset-Down
9. Power
10. Band
11. Play/Enter
12. PTT
13. On-Hook
14. Off-Hook
15. Fan-Up *
16. Fan-Down *
17. Temp-Up *
18. Temp-Down *
TROUBLESHOOTING
Resetting
1. The Blue reset button is located between the two connectors on the outside of the interface.
2. Press and hold the reset button for 2 seconds, and then let go to reset the interface.
3. Refer to the Programming section from this point.
TROUBLESHOOTING
STEERING WHEEL CONTROL SETTINGS (CONT.)
* Not applicable in this application

10

11
REV. 9/20/21 INSTAXDIS-HK1

KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.edu or call
386-672-5771 for more information and take steps
toward a better tomorrow.
®
Metra recommends MECP
certified technicians
AxxessInterfaces.com © COPYRIGHT 2021 METRA ELECTRONICS CORPORATION REV. 9/20/21 INSTAXDIS-HK1
INSTALLATION INSTRUCTIONS
AXDIS-HK1
Having difficulties? We’re here to help.
Contact our Tech Support line at:
1-386-257-1187
Or via email at:
[e-mail]
Tech Support Hours (Eastern Standard Time)
Monday - Friday: 9:00 AM - 7:00 PM
Saturday: 10:00 AM - 7:00 PM
Sunday: 10:00 AM - 4:00 PM
