AXDIS-GMLN30
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2021 METRA ELECTRONICS CORPORATION REV. 3/17/21 INSTAXDIS-GMLN30
Product Info
INTERFACE FEATURES
INTERFACE COMPONENTS
TABLE OF CONTENTS
Connections to be made ....................................2-3
- 3.5mm jack steering wheel control retention .. 3
Installing the AXDIS-GMLN30 ................................3
Programming the AXDIS-GMLN30 ........................4
Steering wheel control settings ........................5-7
- L.E.D. feedback ....................................................5
- Changing radio type ...........................................5
- Remapping the steering wheel control buttons .. 6
- Dual assignment instructions ............................7
Troubleshooting .....................................................8
GM Data Interface with SWC 2019-Up
• Provides accessory power
(12-volt 10-amp)
• Retains R.A.P. (retained
accessory power)
• Provides NAV outputs (parking
brake, reverse, speed sense)
• Retains audio controls on the
steering wheel
• Non-amplified models only
• Retains balance and fade
• Micro-B USB updatable
• AXDIS-GMLN30 interface • AXDIS-GMLN30 harness
• 16-pin harness with stripped leads
• Female 3.5mm connector with stripped leads
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell
caps, etc.) • Small flat-blade screwdriver
APPLICATIONS
Chevrolet
Blazer (IOT, IOU) ** 2019-Up
Camaro (IOS, IOT) ** 2019-Up
Cheyenne (IOS, IOT) ** 2019-Up
Colorado (IOS, IOT) 2019-Up
Equinox (IOS, IOT) ** 2019-Up
Malibu (IOU, IOS) ** 2019-Up
Silverado (IOS, IOT) ** 2019-Up
Volt 2019-Up
GMC
Acadia (IOU) ** 2019-Up
Canyon (IOS, IOT) 2019-Up
Sierra 1500 (IOS, IOT) ** 2019-Up
Terrain (IOS, IOT, IOU) ** 2019-Up
** For extension, use AXEXH-GM30

2
CONNECTIONS TO BE MADE
From the 16-pin harness with stripped leads to the aftermarket radio:
• Connect the Red wire to the accessory wire.
• If the aftermarket radio has an illumination wire, connect the Orange/White wire to it.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire
• Tape off and disregard the following (5) wires, they will not be used in this application:
Blue/White, Green, Green/Black, Purple and Purple/Black.
From the AXDIS-GMLN30 harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative speaker output.
Note: The relay attached to the harness is only for audible turn signal clicks. No extra steps
are required to retain this feature, so leave the relay as-is.
Continue to 3.5mm jack steering wheel control retention

3
REV. 3/17/2021 INSTAXDIS-GMLN30
3.5mm jack steering wheel control retention:
• The 3.5mm jack is to be used to retain audio controls on the steering wheel.
•
For the radios listed below, connect the included female 3.5mm connector with stripped leads , to the
male 3.5mm SWC jack from the AXDIS-GMLN30 harness. Any remaining wires tape off and disregard .
•
Eclipse: Connect the steering wheel control wire, normally Brown, to the Brown/White
wire of the connector. Then connect the remaining steering wheel control wire, normally
Brown/White, to the Brown wire of the connector
.
•
Metra OE: Connect the steering wheel control Key 1 wire (Gray) to the Brown wire.
•
Kenwood or select JVC with a steering wheel control wire: Connect the Blue/Yellow wire
to the Brown wire.
Note: If your Kenwood radio auto detects as a JVC, manually set the radio type to
Kenwood. See the instructions under changing radio type.
• XITE: Connect the steering wheel control SWC-2 wire from the radio to the Brown wire.
•
Parrot Asteroid Smart or Tablet: Connect the 3.5mm jack into the AXSWCH-PAR (sold
separately), and then connect the 4-pin connector from the AXSWCH-PAR into the radio .
Note: The radio must be updated to rev. 2.1.4 or higher software.
• Universal “2 or 3 wire” radio: Connect the steering wheel control wire, referred to as Key-A
or SWC-1, to the
Brown wire of the connector. Then connect the remaining steering wheel
control wire, referred to as Key-B or SWC-2, to the
Brown/White wire of the connector. If the
radio comes with a third wire for ground, disregard this wire
.
Note: After the interface has been programmed to the vehicle, refer to the manual
provided with the radio for assigning the SWC buttons. Contact the radio manufacturer
for more information.
• For all other radios: Connect the 3.5mm jack from the AXDIS-GMLN30 harness into the jack on
the aftermarket radio designated for an external steering wheel control interface. Please refer
to the aftermarket radios manual if in doubt as to where the 3.5mm jack goes to.
CONNECTIONS TO BE MADE (CONT) INSTALLING THE AXDIS-GMLN30
With the key in the off position:
• Connect the 16-pin harness with stripped leads, and the AXDIS-GMLN30 harness, into the
interface.
Attention! Do not connect the AXDIS-GMLN30 harness to the wiring harness in the vehicle just yet .
Attention! If retaining steering wheel controls, ensure that the jack/wire is connected to the
radio before proceeding. If this step is skipped, the interface will need to be reset for the steering
wheel controls to function.

4
PROGRAMMING THE AXDIS-GMLN30
For the steps below, the L.E.D. located inside the interface can only be seen while active. The
interface does not need to be opened to see the L.E.D.
• Start the vehicle.
• Connect the AXDIS-GMLN30 harness to the wiring harness in the vehicle.
• The L.E.D. will initially turn on solid Green, then turn off for a few seconds while it auto
detects the radio installed.
• The L.E.D. will then flash Red up to (18) times indicating which radio is connected to the interface,
and then turn off for a couple of seconds. Pay close attention to how many Red flashes there
are. This will help in troubleshooting, if need be. Refer to the L.E.D. feedback section for more
information.
• After a couple seconds the L.E.D. will turn on solid Red while the interface auto detects
the vehicle. The radio will shut off at this point. This process should take 5 to 30 seconds.
• Once the vehicle has been auto detected by the interface, the L.E.D. will turn on solid
Green, and the radio will come back on, indicating programming was successful.
• Test all functions of the installation for proper operation, before reassembling the dash. If
the interface fails to function, refer to Resetting the AXDIS-GMLN30.
Note: The L.E.D. will turn on solid Green for a moment, and then turn off under normal
operation after the key has been cycled.

5
REV. 3/17/2021 INSTAXDIS-GMLN30
STEERING WHEEL CONTROL SETTINGS
L.E.D. feedback
The (18) Red L.E.D. flashes represent what brand radio the AXDIS-GMLN30 believes it is
connected to. Each flash represents a different radio manufacturer. For example, if you are
installing a JVC radio, the AXDIS-GMLN30 will flash (5) times. Following is a legend that
dictates which manufacturer corresponds to which flash.
L.E.D. feedback legend
* Note: If the AXDIS-GMLN30 flashes Red (7) times, and you do not have an Alpine radio connected
to it, that means the AXDIS-GMLN30 does not detect a radio connected it. Verify that the 3.5mm
jack is connected to the correct steering wheel jack/wire in the radio.
** Note: Part number AXSWCH-PAR is required (sold separately). Also, the Parrot radio must be
updated to rev. 2.1.4 or higher through www.parrot.com.
† Note: If you have a Clarion radio and the steering wheel controls do not work, change the radio
type to the other Clarion radio type; same for Eclipse. The following section explains how to do this.
‡ Note: If you have a Kenwood radio and the L.E.D. feedback comes back as showing as a JVC radio,
change the radio type to a Kenwood. The following section explains how to do this.
1 flash - Eclipse (Type 1) †
2 flashes - Kenwood ‡
3 flashes - Clarion (Type 1) †
4 flashes - Sony / Dual
5 flashes - JVC
6 flashes - Pioneer / Jensen
7 flashes - Alpine *
8 flashes - Visteon
9 flashes - Valor
10 flashes - Clarion (Type 2) †
11 flashes - Metra OE
12 flashes - Eclipse (Type 2) †
13 flashes - LG
14 flashes - Parrot **
15 flashes - XITE
16 flashes - Philips
17 flashes - TBD
18 flashes - JBL
Continued on the next page
Changing radio type
If the LED flashes do not match the radio you have connected, you must manually program
the AXDIS-GMLN30 to tell it what radio it is connected to.
1. After (3) seconds of turning the key on, press and hold the Volume-Down button on the
steering wheel until the L.E.D. in the AXDIS-GMLN30 goes solid.
2. Release the Volume-Down button; the L.E.D. will go out indicating we are now in Changing
Radio Type mode.
3. Refer to the Radio Legend to know which radio number you would like to have
programmed.
4. Press and hold the Volume-Up button until the L.E.D. goes solid, and then release. Repeat
this step for the desired radio number you have selected.
5. Once the desired radio number has been selected, press and hold the Volume-Down button
on the steering wheel until the L.E.D. goes solid. The L.E.D. will remain on for about (3)
seconds while it stores the new radio information.
6. Once the L.E.D. goes off, the Changing Radio Type mode will then end. You can now test the
steering control wheel controls.
Note: If at any time the user fails to press any button for a period longer than (10) seconds,
this process will abort.
Attention: The Axxess Updater App can also be used to program the following (3) sub-sections as
well, pending that the interface has been initialized and programmed.

6
STEERING WHEEL CONTROL SETTINGS (CONT)
Continued on the next page
Radio legend
1. Eclipse (Type 1)
2. Kenwood
3. Clarion (Type 1)
4. Sony/Dual
5. JVC
6. Pioneer/Jensen
7. Alpine
8. Visteon
9. Valor
10. Clarion (Type 2)
11. Metra OE
12. Eclipse (Type 2)
13. LG
14. Parrot
15. XITE
16. Philips
17. TBD
18. JBL
Remapping the steering wheel control buttons
Let’s say you have AXDIS-GMLN30 initialized and you want to change the button assignment
for the steering wheel control buttons. For example, you would like Seek-Up to become
Mute. Follow the steps below to remap the steering wheel control buttons:
1. Ensure the AXDIS-GMLN30 is visible so you can see the L.E.D. flashes to confirm button
recognition.
Tip:
Turning the radio off is recommended.
2. Within the first twenty seconds of turning the ignition on, press and hold the Volume-Up
button on the steering wheel until the L.E.D. goes solid.
3. Release the Volume-Up button, the L.E.D. will then go out; The Volume-Up button has now
been programmed.
4. Follow the list in the Button Assignment Legend to reference the order in which the steering
wheel control buttons need to be programmed.
Note:
If the next function on the list is not on the steering wheel, press the Volume-Up
button for (1) second until the L.E.D. comes on, and then release the Volume-Up button. This
will tell the AXDIS-GMLN30 that this function is not available and it will move on to the next
function.
5. To complete the remapping process, press and hold the Volume-Up button on the steering
wheel until the L.E.D. in the AXDIS-GMLN30 goes out.
1. Volume-Up
2. Volume-Down
3. Seek-Up/Next
4. Seek-Down/Prev
5. Source/Mode
6. Mute
7. Preset-Up
8. Preset-Down
9. Power
10. Band
11. Play/Enter
12. PTT (Push to Talk) *
13. On-Hook *
14. Off-Hook *
15. Fan-Up *
16. Fan-Down *
17. Temp-Up *
18. Temp-Down *
Button assignment legend
Note: Not all radios will have all of these commands. Please refer to the manual provided with the
radio, or contact the radio manufacturer for specific commands recognized by that particular radio.
* Not applicable in this application

7
REV. 3/17/2021 INSTAXDIS-GMLN30
STEERING WHEEL CONTROL SETTINGS (CONT)
Dual assignment instructions (long button press)
The AXDIS-GMLN30 has the capability to assign (2) functions to a single button, except Volume-
Up and Volume-Down. Follow the steps below to program the button(s) to your liking .
Note: Seek-Up and Seek-Down come pre-programmed as Preset-Up and Preset-Down
for a long button press.
1. Turn on the ignition but do not start the vehicle.
2. Press and hold down the steering wheel control button that you want to assign a long press
function to for about (10) seconds, or until the L.E.D. flashes rapidly. At this point release the
button; the L.E.D. will then go solid.
3. Press and release the Volume-Up button the number of times corresponding to the new button
number selected. Refer to the Dual Assignment Legend. The L.E.D. will flash rapidly while the
Volume-Up button is being pressed, and then go back to a solid L.E.D. once released. Go to the
next step once the Volume-Up button has been pressed the desired number of times.
Caution: If more than (10) seconds elapses between pressing the Volume-Up button, this
procedure will abort, and the L.E.D. will go out.
4. To store the long press button in memory, press the button that you assigned a long press
button to (the button held down in Step 2). The L.E.D. will now go off indicating the new
information has been stored.
Note: These steps must be repeated for each button you would like to assign a dual
purpose feature to. To reset a button back to its default state, repeat Step 1, and then
press the Volume-Down button. The L.E.D. will go out, and the long press mapping for
that button will be erased.
Dual assignment legend
1. Not allowed
2. Not allowed
3. Seek-Up/Next
4. Seek-Down/Prev
5. Mode/Source
6. ATT/Mute
7. Preset-Up
8. Preset-Down
9. Power
10. Band
11. Play/Enter
12. PTT
13. On-Hook
14. Off-Hook
15. Fan-Up *
16. Fan-Down *
17. Temp-Up *
18. Temp-Down *
* Not applicable in this application

AxxessInterfaces.com © COPYRIGHT 2021 METRA ELECTRONICS CORPORATION REV. 3/17/21 INSTAXDIS-GMLN30
INSTALLATION INSTRUCTIONS
AXDIS-GMLN30
KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
®
Metra recommends MECP
certified technicians
Having difficulties? We’re here to help.
Contact our Tech Support line at:
386-257-1187
Or via email at:
[e-mail]
Tech Support Hours (Eastern Standard Time)
Monday - Friday: 9:00 AM - 7:00 PM
Saturday: 10:00 AM - 7:00 PM
Sunday: 10:00 AM - 4:00 PM
TROUBLESHOOTING
Resetting the AXDIS-GMLN30
1. The Blue reset button is located inside the interface, between the two connectors. The
button is accessible outside the interface, no need to open the interface.
2. Press and hold the reset button for two seconds, and then let go to reset the interface.
3. Refer to “Programming the Interface” from this point.
