Axxess AXPIO-CAM2 User manual

AXPIO-CAM2
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2022 METRA ELECTRONICS CORPORATION REV. 2/14/22 INSTAXPIO-CAM2
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections are secure before
cycling the ignition to test this product.
NOTE: Refer to the instructions included with
the aftermarket radio.
TABLE OF CONTENTS
Interface Installation .............................................2
Dash Disassembly ...............................................2-3
Connections ........................................................4-5
Kit Assembly ..........................................................6
Radio Operations ................................................7-8
Chevrolet Camaro 2019-UP*
KIT FEATURES)
• Designed for Pioneer DMH-WC5700NEX receivers
• Allows for the retention and adjustment of the factory personalization
menu through the Pioneer radio
• Provides a visual view of HVAC and gauges on the Pioneer screen
(cannot be adjusted via the screen)
(cont. on page 2)
KIT COMPONENTS
• A) Display Screen Housing • B) Display Screen Trim Bezel • C) Display Screen Trim • D) Brackets •E) Panel Clips • F) Phillips Screws (4)
Not Shown: Radio Interface, LD-GM30-PIO, LD-GM31-PIO, AXEXH-GM30, AXEXH-GM31 LD-GMSWC, AD-EU5, 40-GPS-PIO, PR04AVIC-PIO / PRO4-PIORCA,
LD-AX-SPK, AXUSB-GM6
Visit AxxessInterfaces.com for more detailed information about the product and
up-to-date vehicle specific applications.
WIRING & ANTENNA CONNECTIONS (sold separately)
• RGB Extension Cable: Pioneer part # CD-RGB150E
(not sold by Metra)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• 9/32" socket wrench
A B DC E F

2
KIT FEATURES (cont. from cover)
• Complete Plug-n-Play installation
• Includes dash kit with Axxess interface and
vehicle-specific T-harness
• Includes a 3' USB/AUX/HDMI replacement
cable with panel
• Includes radio antenna adaptor for GPS
• Provides accessory power (12-volt 10-amp)
• Provides NAV outputs (parking brake,
reverse, speed sense)
• Retains audio controls on the steering wheel
• Works in both single and dual-zone vehicles
• Retains safety chimes through an included
off-board speaker
• USB Micro B updatable
• Dash kit is painted scratch-resistant matte
black to match the factory finish
• Designed for non-amplified vehicles only
KIT FEATURES (CONT.)
DASH DISASSEMBLY
Models equipped with a 7-inch touchscreen radio:
1. Using the panel removal tool, gently unclip,
unplug, and remove the radio control trim
panel. (Figure A)
2. Remove (4) 9/32" screws securing the radio,
disconnect the wiring, and then remove the
radio. (Figure B)
Continue to Connections
(Figure A)
(Figure B)

3
REV. 2/14/22 INSTAXPIO-CAM2
(Figure C)
(Figure D)
Models equipped with an 8-inch touchscreen radio:
1. Using the panel removal tool, carefully unclip
and remove the trim surrounding the radio
controls. (Figure C)
2. Remove (2) 9/32" screws securing the radio,
disconnect the wiring, and then remove the
radio. (Figure D)
Continue to Connections
DASH DISASSEMBLY (CONT.)

4
EXTERNAL SPEAKER
LD-AX-SPK
Pioneer Harness
LD-GM30-PIO
CARSIDE CONNECTORS (CONNECT TO EXTENSION)
MICRO-HDMI
ADAPTER NEEDED
(N/A)
EXT SPKR
CAN 2
CAN3
“TBA” WIRES
AXUSB-GM6
AD-EU5
AUX IN
High-Level
PRO4-AVIC-PIO
(CONNECT TO PIO HARNESS)
(CONNECT TO VEHICLE)
USB/AUX
(USE INSTEAD)
AXEXH-GM30
AXXESS INTERFACE
CONNECT TO
CLIMATE PANEL
CONNECT
TO PLUG REMOVED
FROM CLIMATE
PANEL
PRO4-PIORCA
Low-Level
AUX (INCL. W/RADIO)
GPS 4-PIN MIC HDMI
ANT
18P (M)
18P (F)
16P 22P
10P
10P
40-GPS-PIO
10
Extension Harness
TBA
LD-GM30-PIO
U
(
U
SB
/
AUX
(
USE INSTE
A
(
CONNECT TO VEHICLE
)
A
X
E
E
xt
e
N
S
A
D
)
O
EXTE
D EU5
AD
D-
EU5
AD
)
E
CT T
O
N
N
E
5
S
(
CO
N
D-EU5
CARSIDE C
O
NNECT
O
R
S
AD
)
0
r
n
n
n
R
NE
SS)
n
n
ess
AR
O
H
A
T
O PI
O
N
ECT
T
O
N
N
(
C
O
CONNECTIONS
Important: Verify the backup camera
installation, HVAC status & control, Steering
wheel audio controls, and External Speaker
output prior to completing dash assembly.
Important: Install the provided speaker
in the dash prior to assembling the
radio components.
Note: Make sure this is mounted in a
location suitable for the driver to hear.
(Audio level for the speaker can be
changed via the radio, once installed.)

5
REV. 2/14/22 INSTAXPIO-CAM2
CONNECTIONS (CONT.)
TBA
EXTERNAL SPEAKER
LD-AX-SPK
Pioneer Harness
LD-GM31-PIO
CARSIDE CONNECTORS (CONNECT TO EXTENSION)
MICRO-HDMI
ADAPTER NEEDED
(N/A)
EXT SPKR
CAN 2
CAN3
“TBA” WIRES
AXUSB-GM6
AD-EU5
CAMERA (IOR)
AUX (N/A)
High-Level
PRO4-AVIC-PIO
(CONNECT TO PIO HARNESS)
USB/AUX
(USE INSTEAD)
AXEXH-GM31
AXXESS INTERFACE
CONNECT TO
CLIMATE PANEL
CONNECT
TO PLUG REMOVED
FROM CLIMATE
PANEL
PRO4-PIORCA
Low-Level
AUX (INCL. W/RADIO)
GPS 4-PIN MIC HDMI
ANT
18P (M)
18P (F)
16P 22P
10P
10P
40-GPS-PIO
10
Extension Harness
AX
E
xt
(CONNECT TO VEHICLE)
LD-GM31-PIO
Important: Verify the backup camera
installation, HVAC status & control, Steering
wheel audio controls, and External Speaker
output prior to completing dash assembly.
Important: Install the provided speaker
in the dash prior to assembling the
radio components.
Note: Make sure this is mounted in a
location suitable for the driver to hear.
(Audio level for the speaker can be
changed via the radio, once installed.)

6
KIT ASSEMBLY
1. Secure the display screen housing to the
dash using the (4) 9/32" factory screws
removed in dash disassembly. (Figure A)
Note: For vehicles equipped with an
8-inch touchscreen radio, remove (2)
9/32" screws from the dash beforehand.
2. Remove the locator pins stamped “8”
from the display screen brackets. Using
the holes stamped “7”, secure the
display screen to the brackets using (6)
screws supplied with the radio.
(Figure B)
Note: Reference the installation manual
provided with the radio for which
hardware to use. The display screen and
radio chassis use two different types
of screws.
3. Find a suitable location for the radio
chassis. Route the RGB extension cable
from the radio chassis to the display
screen, then connect it to the
display screen.
(Figure A) (Figure C)
(Figure B) (Figure D)
4. Place the display screen trim over the
bracket/display assembly, then secure
the assembly to the display screen
housing using (4) Phillips screws
provided. (Figure C)
5. Locate the factory wiring harness and
antenna connector in the dash and
complete all necessary connections to
the radio assembly. Metra recommends
using the proper mating adapter from
Metra and/ or Axxess.
6. Reconnect the negative battery terminal
and test the Pioneer radio for proper
operation.
7. Attach (6) panel clips provided onto the
display screen trim bezel, then clip the
bezel over the radio to complete the
installation. (Figure D)

7
REV. 2/14/22 INSTAXPIO-CAM2
RADIO OPERATIONS
Vehicle Selection
• Allows the selection of the vehicle the
Pioneer radio is being installed in.
• Select Make, Model and Trim to activate
the extended functions of the radio.
• Press Confirm to lock in the selection.
• The vehicle type must be selected to
activate HVAC functions and steering
wheel controls.
Car Features
The source for accessing all vehicle
information and options.

8
RADIO OPERATIONS (CONT.)
HVAC Operation: HVAC Status and Control Screen About Screen : Feedback screen for interface software information.
• Helpful information for troubleshooting.
Customizations Menu : Allows full control of vehicle personalization options.
Access this menu by selecting the gear
icon on the previous screenshot:
• Provides SWC Configuration.
• Dual Assignment: Assign (2)
functions to a single SWC button.
• Remap: Reassign a button on the
steering wheel controls.
Vehicle Information Screen : The source for accessing all vehicle
information and options.

9
REV. 2/14/22 INSTAXPIO-CAM2

10

11
REV. 2/14/22 INSTAXPIO-CAM2
