Ayra Compar Kit Jr. User manual

Compar Kit Jr.
Compact LED Lighting Set
User Manual
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

Introduction
Thank you for purchasing the Ayra Compar Kit Jr. This highly versatile lighting system consists of powerful
RGBW ED chips installed in adjustable spot lights. This manual offers all the information needed to get the
very best out of your new lighting set.
We advise that you read this user manual in its entirety before unpacking the contents of the box, so that you
are familiar with all of the functionality that this product has to offer. Please be sure to check that all of the
components and accessories listed under 'Box Contents' below are included in the box. In the event that any
component or accessory does not function properly, or if you have any issues while operating it, please
remove the plug from the power socket and contact your retailer for assistance.
Box contents:
- Ayra Compar Kit Jr. ighting Set
- Infrared remote control
- Power cable from IEC C13 to Schuko, 1.5 mm²
lease thoroughly inspect the device and included accessories.
Should you discover that either the device or one or more of the included accessories has been damaged or
rendered defective while in transit, please contact your retailer directly.
Please note that the pictures used in this user manual serve illustrative purposes only and may differ from
the actual product.
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

Safety Instructions
Everyone involved with the installation, operation and maintenance of this device must:
- Be qualified.
- Be skilled.
- Have read the instructions included in this user manual.
- Be sure that neither the device nor the included accessories are damaged. Should the device or the
included accessories be damaged, please contact your retailer for more information.
- Ensure that the device is in good working condition and is safe to operate. Please follow the advice and
instructions as they are described in this user manual.
Damage caused by misuse and/or modifications made to the device are not covered by the warranty.
This device does not contain any parts that can be repaired or replaced by the user. Should maintenance or
repairs be necessary, they must be handled by a qualified technician.
The light source of this device is not replaceable. If the light source no longer functions, the entire device
needs to be replaced.
Important information regarding health and safety:
- Do not remove any labels or stickers from this device.
- Do not leave any cables lying around.
- The device should not be opened up and any hardware or software that may be present should not be
modified.
- To achieve optimal performance, any inputs on the device should not be fed with a signal higher than
necessary.
- The device should only be used indoors; contact with water, rain and moisture should always be avoided.
Do not place any objects containing liquid on top of the device.
- Remove the device from any nearby flames or heat sources; do not place it near flammable fluids, gasses
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -
WARNING!
Keep this device away from moisture, water and rain to avoid the chance of electric shocks!
WARNING!
Only connect this device to a suitable power socket. This device functions on a specific power
voltage. If it is plugged into a power socket with a different voltage, it could result in permanent
damage and even dangerous situations such as fire or electric shocks.
WARNING!
Be careful when operating this device. Touching the wires that are connected to the mains,
inside or outside the device, could result in electric shocks!

or objects.
- Disconnect this device from a power source if it is not being used for a long period of time; if maintenance is
necessary, or if it needs to be cleaned.
– Do not pull or tug on the cable to remove a connector as this may cause damage.
- Do not use any cables other than the ones described in this manual. Please note that a power cable from
IEC C13 to Schuko with a thickness of at least 1.5 mm² is always used because the current in this cable can
exceed 3 A. Do not use defective cables. Please contact your retailer if the included or necessary cables do
not function properly with this device.
- Only use this device with a stable AC power supply.
- Only use this device with power from a grounded power source.
- In the event that the device is exposed to extreme temperature changes (e.g. transported from a cold
outdoor environment into a warm indoor environment), it should not be turned on until it has reached room
temperature. This is necessary to prevent moisture (condensation) from forming inside the device, which
could lead to electric shocks.
Guidelines and operation of this device:
- This device is intended for use by professionals on stage, in theatres, in clubs and in similar entertainment
locations.
- This device is not suitable for use by children and should always be operated by an adult.
- This device is designed to create light effects for entertainment purposes. It is not suitable for household
illumination.
- This device may only be used in a suitable environment where no damage to the device can occur. Do not
use the device in moist or dusty environments such as:
- indoor swimming pools where chlorine is used
- beaches or any location where sand and/or salt is present
- outdoors
- indoors in spaces where intense heat sources are present, or where it can reach temperature levels
that would be considered uncomfortable for a person
- Avoid impact and collisions during use and transport. Do not move or transport the device while it is in use.
Avoid using excessive force when installing and operating the device.
- Any user must become familiar with the functions of this device before using it.
- Should the device not be used in the manner described in this user manual, damages or even injuries could
occur. Ayra cannot be held responsible for any injuries or damages that occur as a result of improper use of
this product.
Storage and transport:
- This product was designed for mobile use. Please only transport the device in the original packaging, or in
a flight case with a suitable foam inlay.
- This device was not designed for permanent (24/7) use. The expected lifespan of the device will not be
affected by occasionally turning the device off. Disconnect the device or turn off the power when it is not
actively in use.
- If the device is not in use for a long period of time, it should be disconnected and stored in a dust-free
environment.
- Do not expose the device to extreme temperature differences.
Housing:
- Inspect the device's housing frequently and always just before use. Avoid operating the device if there are
any large dents or cracks, or if screws are missing. Do not use the device if the housing is not in good
condition.
Contact your dealer or a qualified technician if you are unsure about the state of the device.
- Check the device and the screws for corrosion. Corrosion must not be present on this device. Contact your
dealer or a qualified technician if you find any corrosion on the screws.
Every power and signal connector should be securely attached. Do not use the device if the connectors are
not secure.
- Avoid dust and dirt build-up. Clean the device once a month by disconnecting it from the power supply and
wiping it down with a dry or slightly moist cloth. If the device is used frequently, the cleaning intervals should
increase.
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

Symbol explanation:
Ensure that this device is disposed of properly. This product falls under the WEEE (Waste
Electrical and Electronic Equipment) directive. The requirements of this directive apply to all
manufacturers and producers of electronic devices in the EU. Do not throw this product away
with regular rubbish. Please contact your local authority for more information about how to
recycle and dispose of these products in your region. By recycling this product in the proper
manner, we can work together to ensure that we can continue to enjoy these kinds of
products and still protect the environment as much as possible from pollution.
CE: The CE logo indicates that this product meets the European norms and requirements to
which it must legally conform.
Suitable for indoor use only: this product was designed for indoor use only. The maximum
environmental temperature must not exceed 40 degrees Celsius (104 degrees Fahrenheit).
Battery risk:
Warning!
Do not swallow the battery!
Risk of injury from chemical burns!
The included remote control is powered by a button-cell battery.
If a button-cell battery is swallowed, within just 2 hours, it could cause life-threatening internal
chemical burning and could eventually lead to death.
Keep both new and used batteries out of reach of children.
If the battery compartment does not close properly, stop using the product and keep it away from
children.
If you have swallowed or suspect that a battery has been swallowed or is otherwise inside the body,
seek medical help immediately.
LEASE NOTE!
If the battery is not correctly replaced, there is a danger of the battery exploding.
Always replace the battery for the same quality type.
Do not expose batteries to intense heat such as sunlight, fire etc.
Do not leave batteries in any environment that has a high temperature. This can lead to the battery exploding
as well the leakage of flammable gas or liquids.
Do not burn batteries or placed them in a hot oven. Do not damage the battery or make any cracks, holes or
incisions as this may cause the battery to explode.
Do not expose the battery to extremely low levels of air pressure (at higher altitudes) as this may cause the
battery to explode as well as the leakage of gas or flammable liquid.
If the device is not being used for a long period of time (for example, a few months), the battery must be
removed from the device.
Remove empty batteries from the device immediately.
Do not store batteries separately and do not carry them in a pocket, wallet or bag. Contact with metal objects
such as coins, keys etc. can cause leaks, cracks or short circuits.
Keep batteries out of reach of children.
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

Recycling:
Do not dispose of batteries along with the rest of your normal household waste. Batteries may
contain substances that are harmful to the environment. When batteries are correctly recycled, they
are valuable source of reusable materials. Contact your local council or government for information
about the safe disposal and recycling of batteries.
Contact:
Ayra Professional ighting Products
Verrijn Stuartweg 18
4462 GE Goes
The Netherlands
Please do not send any physical products to this correspondence address.
Should you wish to send a product for repairs or for a refund, please contact your retailer for an RMA re uest
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

(Return Merchandise Authorisation)
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

Operation Guidelines
1. ight output
2. DMX output via 3-pin X R
3. DMX input via 3-pin X R
4. Microphone
5. Power input via IEC C14
6. Power output via IEC C13
7. Safety eyelet
8. ED display with menu buttons
9. 35mm stand adapter
10. mounting points for suspension bracket (bracket not included / mounting points not visible in above
image)
11. Mounting point for one small extra fixture (not included)
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -
256
7
8
1
34
9
10 10
11 11 11

Operation and Installation
To activate the device, it must first be connected to an active mains power point. Once connected, the device
will switch on automatically.
During the start-up process, ‘AYRA’ will be displayed on the integrated menu screen and the device cannot
be operated yet. Once the start-up process has been completed, the device will jump to the last used mode
and from here, the various settings and modes can now be adjusted using the display and menu buttons.
If a DMX signal is detected, the device will automatically jump to DMX mode and the last DMX address used.
With a brand new device, the automatic DMX address is usually 001. The DMX address can be set manually
using the display and menu buttons.
Using the display and menu buttons, all the various functions and parameters of the device can be adjusted.
Use the ‘Enter’ button to select a function or to confirm an adjustment. Use the ‘Up’ and ‘Down’ buttons to
change values and use the ‘Menu’ button to return to the menu. After a setting has been saved, press and
hold the ‘Menu’ button down for 2 seconds so that the device returns to operation mode and the settings just
saved. This should be done after the operation mode or DMX address has been changed but is not always
necessary since the device will automatically return to operation mode and the settings just saved within a
few seconds.
In the Menu, the following modes and functions can be found:
Display Mode Function
ADDR / A001 DMX address configuration Address A001 … A512
CHAN Channel mode selection 4CH / 6CH / 7CH / 18CH
MASL Slave mode Master
Slave
SHOW Show selection + speed SH 0 – SH 15 (Show 0 = random)
speed S 00 – S 10
COLO Colour macros with dimmer,
macro selection + speed
DIM: 000-100
CO: 01 – 15 / JUMP / FADE
SPED: 000 - 010
MANU Manual mode STRO 0-100 (strobe effect, slow-fast)
DIMM 0-100 (master dimmer 0-100%)
RED 0-100 (dimmer red 0-100%)
GREE 0-100 (dimmer green 0-100%)
B UE 0-100 (dimmer blue 0-100%)
WHIT 0-100 (dimmer white 0-100%)
SOUN Sound controlled mode Mode: ON / OFF
SENS Sound sensitivity 0 - 99: sensitivity in %
LED ED Display On/Off when not
active
ON/OFF
DIS Display inversion Display inversion, disp - dslp
TEST Test mode Test program that activates and checks each
ED colours 1 by 1
INFO Fixture information (cannot be
adjusted by user)
HOUR: duration of use in hours
VER: firmware version
Below, you’ll find an explanation of each function:
ADDR: With this function, you can determine the DMX start address of the device. Set it channel 001, and
the device will respond to DMX channel 1. Set it to channel 003, then the device will respond to DMX
channel 3 and so on.
CHAN: This device can be operated using various DMX channel modes. If your DMX circuit is reasonably
full with devices and you do not need extensive control over the functions, a concise channel mode can be
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

selected. It is also possible to select a more extensive channel mode, making more channels available for
the control of several separate functions.
MASL: Using the Master / Slave Mode, it’s possible to connect several devices of the same type with one
another via DMX 3-pin X R cables so that they perform exactly the same movements and functions at the
same time. Therefore, single devices do not respond individually (or chaotically) and this results in a
completely coordinated show. In the Master / Slave function, the first device in the circuit is set as the Master
and does not receive DMX signal.
P EASE NOTE: When Slave mode is activated, the device shall wait for a signal from the designated Master
device. In this case, selecting an automatic or sound-controlled mode is not possible! To cancel the Slave
mode, enter the ‘S ND’ menu and select ‘NAST’. This then sets the device to Master mode and the stand-
alone functions can then be activated once more.
SHOW: Select one of the built-in shows and set the speed that the show will be performed in or set the
fixture to perform in SOUN mode (further in the menu) so that the show is performed in time to the beat of
any detected music. When show ‘0’ is selected, various shows are performed one by one.
COLO: Select one of the built-in colour macros or a fade or jump effect and manually set the dimmer and
speed of the program.
MANU: Manual colour mix function. Set a master-level, add an optional strobe effect and set the value of
each base colour (red, green, blue, white) to mix a custom colour.
SOUN: Here, you can determine whether the built-in microphone is switched on or off by simply selecting
‘On’ or ‘Off. When the microphone is switched on and the device is in Show mode, any selected show will be
performed in time to the beat of any detected music.
SENS: This mode allows you to set the sensitivity of the in-built microphone. The further away the device is
installed from the sound-source, the higher the sensitivity of the microphone needs to be so that the sound is
registered and the device responds accordingly and in time to the music. The microphone is able to
withstand high sound pressure. However, if the sound is loud and the sensitivity is high, the microphone will
find it more difficult to register the beat. Experiment with the sensitivity and distance from the positioning of
the device to make sure you’re getting the best possible signal and optimum performance.
LED: When the ED display is not in use, it can be switched off. By setting ‘ ED’ to ‘Off’, this will prevent red
symbols from illuminating when the device is being used in dark spaces. If you press one of the menu
buttons, the display shall immediately light up and show all necessary information. If the display is not used,
it shall automatically switch off again in 30 seconds.
DIS : This function is useful when the device is suspended and the display screen is upside down. Use this
function to flip the screen so that it can be easily read when the device is suspended.
TEST: When the device needs to be inspected, use the ‘TEST’ function to test one or more devices at the
same time. The device(s) shall continuously runs through a programme within which the EDs are tested so
that any deviations or defects can be easily detected. The device shall continue to repeat the programme
until it is manually interrupted (when you switch the device to sound control mode, for example).
INFO: When the device is used professionally, or is hired out regularly, it is important that general
maintenance and inspections of the device are frequently carried out. The HOUR function displays the total
amount of hours that the device has been in use. This total is updated automatically whenever the device is
used and cannot be adjusted by the user.
The VER function displays the firmware version installed. This cannot be adjusted or edited by the user.
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

Operation Modes
Please find a more detailed explanation of the differences between all available Operation Modes below and
how they are affected by the menu functions listed above.
Auto:
In Auto Mode, you can select one of the Operation Modes in which the device is not dependent on external
factors such as DMX signals, master signals or sound. Here, one of the basic programmes can be selected
and you can set the alternating speed or correct the intensity.
Sound:
Sound-controlled mode, or ‘sound mode’, uses a built-in microphone that registers the beat of music and
runs a program based on this. For example, the device can move in synchronisation with any music,
providing an automatic light-show.
When no music is detected or only the high-end (treble) is present in the music due to a break, the device
will continue its program at a slower pace. As such, the light show does not appear to come to a standstill. As
soon as sound is registered by the microphone again, the device will continue its program in synchronisation
with the beat.
Slave
In Slave Mode, it’s possible to connect several devices of the same type with one another so that they
perform exactly the same movements and functions at the same time. Therefore, single devices do not
respond individually (or chaotically) and this results in a completely coordinated show. In theory, by adding a
DMX booster, an unlimited number of Slave devices can be linked to one Master device. In general and
without the use of a DMX booster, it should be possible to connect four armatures without any problems.
Please note: If you link devices of a different type or brand (even if they appear to have the same function),
chaotic or strange behaviour can occur. This is often because certain functions are linked to incorrect
channels. This applies to DMX lighting of all types and brands.
DMX
The DMX Mode is the most comprehensive mode for optimum control over all functions of this device. Via
DMX, it is possible to control either a limited or large amount of functions via a DMX controller or DMX
software.
The device can be set in different channel modes so that the channel layout (included below) is in alignment
with the layout of your DMX circuit and with the functions you want to use.
DMX Modes
4CH mode:
CH Function Value
1 Dimmer red 000-255 (0-100%)
2 Dimmer green 000-255 (0-100%)
3 Dimmer blue 000-255 (0-100%)
4 Dimmer white 000-255 (0-100%)
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

6CH Mode:
CH Function Value
1 Master dimmer 000-255 (0-100%)
2 Strobe channel 000-005 ED on
006-255 strobe slow-fast
3 Playback colour selection 000-255 colour selection
4 Background colour selection 000-255 colour selection
5 Show selection 000-030 Open
031-080 Show 1
081-105 Show 2
106-130 Show 3
131-155 Show 4
156-180 Show 5
181-205 Show 6
206-230 Show 7
231-255 Random show
6 Playback speed 000-249 speed, slow-fast
250-255 sound controlled mode
7CH Mode:
CH Function Value
1 Master dimmer 000-255 (0-100%)
2 Strobe channel 000-005 ED on
006-255 strobe slow-fast
3 Dimmer red 000-255 (red 0-100%)
4 Dimmer green 000-255 (green 0-100%)
5 Dimmer blue 000-255 (blue 0-100%)
6 Dimmer white 000-255 (white 0-100%)
7 Colour macros 000-005 No function
006-013 Colour 1
014-021 Colour 2
022-029 Colour 3
030-037 Colour 4
038-045 Colour 5
046-053 Colour 6
054-061 Colour 7
062-069 Colour 8
070-077 Colour 9
078-085 Colour 10
086-093 Colour 11
094-101 Colour 12
102-109 Colour 13
110-117 Colour 14
118-125 Colour 15
126-190 Colour jump, slow-fast
191 No function
192-255 Colour fade, slow-fast
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

18CH Mode:
CH Function Value
1 Master dimmer 000-255 (0-100%)
2 Strobe channel 000-005 ED On
006-255 strobe slow-fast
3 Dimmer red 1 000-255 (red 0-100%)
4 Dimmer green 1 000-255 (green 0-100%)
5 Dimmer blue 1 000-255 (blue 0-100%)
6 Dimmer white 1 000-255 (white 0-100%)
7 Dimmer red 2 000-255 (red 0-100%)
8 Dimmer green 2 000-255 (green 0-100%)
9 Dimmer blue 2 000-255 (blue 0-100%)
10 Dimmer white 2 000-255 (white 0-100%)
11 Dimmer red 3 000-255 (red 0-100%)
12 Dimmer green 3 000-255 (green 0-100%)
13 Dimmer blue 3 000-255 (blue 0-100%)
14 Dimmer white 3 000-255 (white 0-100%)
15 Dimmer red 4 000-255 (red 0-100%)
16 Dimmer green 4 000-255 (green 0-100%)
17 Dimmer blue 4 000-255 (blue 0-100%)
18 Dimmer white 4 000-255 (white 0-100%)
Infrared Remote Control
If the Compar Kit Jr. is not operated via DMX, then all the basic functions can be triggered using the included
remote control.
Below is a list of the remote control buttons and their operation:
BL: Blackout on/off
S : Speed (for any automatic modes)
☼: Dimmer (scroll through diverse levels)
R: Red intensity
G: Green intensity
B: Blue intensity
W: White intensity
Ju: Colour jump programs
Fa: Colour fade programs
Au: Automatic programs
Su: Sound controlled mode
CM+: Program or preset +
CM-: Program of preset -
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

lease note: The included remote control also has an ‘A’ and ‘UV’ button that has no function when used to
operate the Compar Kit Jr.
The remote control battery can be replaced with any standard CR2025 type battery. The battery can be
swapped by first removing the battery cover on the underside of the remote control.
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

Installation and Connection Instructions
Now you know about everything that the Compar Kit Jr. can do and how it operates. So that you get the very
best out of your kit while using it in the safest way possible, please follow these installation and connection
instructions closely. This not only ensures that the device is used correctly, but safely.
Make sure that children do not have access to the device or any connecting cables. If there are children
present, make sure that they are supervised. Since the device can be placed upright or be suspended, it is
possible for children to pull on any connecting cables and cause the device to fall. To prevent any accidents
or injury, this must be taken into account whenever the device is being positioned and/or installed.
Standing Installation
When you want to place the Compar Kit Jr. in an upright position, make sure that the device is placed on a
stable surface such as a table, DJ booth or bar. The double suspension bracket is designed so that it can
function as a stand. This way, the spotlight can be directed towards your audience or positioned to provide
uplighting. Always make sure that the light is positioned on a stable surface and that any cabling is secured
so that no one can trip and knock or pull the device over.
The Compar Kit Jr. can also be stand mounted using the included 35mm stand adapter. Please note that a
stand is not included.
Suspended Installation
If the Compar Kit Jr. needs to be suspended, suspension brackets and mounting materials are required
(brackets and mounting materials not included).
If a G-hook or half coupler needs to be installed on the device, this can be done before the brackets are
mounted. Standard hooks and/or brackets for 35 to 50mm tubes (truss or lighting stand) should be available
from your local retailer.
The hardware needed to mount the Compar Kit Jr. to a wall is not included. If you are unsure what hardware
is needed to mount the device to a wall, then please contact a specialist since wooden strut and brick walls
will require different materials.
When the Compar Kit Jr. is suspended, you will need to attach a safety cable to the fixture. This is not
included but is available at your local retailer. The device is fitted with an attachment point for hooking a
safety cable. Once hooked on, the cable can be wrapped around the truss or light stand and attached once
more to the same hook. This ensures the device is secure and prevents it from falling, even if one or both of
the brackets should come loose and fail.
Ensure that the safety cable has a load capacity of 10x the weight of the device and that the device cannot
fall farther than 30cm. You can wrap the safety cable around the truss or light stand several times to ensure
the fall is as short as possible. The shorter the fall, the less chance of damage or injury.
Mounting Extra Lighting
When the Compar Kit Jr. is stand mounted, extra mounting points fitted to the top surface can be used to
mount extra lighting. These mounting points are intended for fixtures like small ED moving heads, lighting
effects or a strobe. The weight per extra fixture must not exceed 2kg.
Light Source
The Compar Kit Jr. uses powerful ED modules that are made even more powerful by a special lens that
combines and focuses these beams, much like a magnifying glass. Since the human eye cannot adjust
quickly enough to sudden and intense exposure to the level of brightness this device produces, never look
directly into the lens at close range. While it won't result in permanent damage, it can cause temporary blind
spots which may cause disorientation and discomfort.
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

arts and Repairs
This product does not include spare parts and can not be repaired by the user. Any inspections and overall
repairs or maintenance should be carried out by a specialist only.
Cleaning and Maintenance
Clean the exterior of this device on a monthly basis with a dry, or slightly damp microfibre cloth. Ensure that
the device is unplugged before cleaning.
Check that all screws are intact and secured and tighten or replace them where needed. Check all metal
parts of the device for any signs of corrosion. If corrosion is found, the device needs to be checked
thoroughly.
ower Output
The Compar Kit Jr. is fitted with a power sharing output via an IEC C13 socket so that more than one device
can be connected and fed power as part of a chain without the need for more than one mains power point.
The fuse fitted in this device is intended to protect that single device only. The input and output of the power
supply are directly wired to each other. If any problems occur with the Compar Kit Jr. itself, then this will have
no effect on any chained devices.
Since a standard 230V group can be loaded with a maximum of 16A and the maximum power that can be
processed by an IEC C13 or C14 is set to 10A, any devices connected to the power sharing output can
amount to a maximum or 2,000 Watts. This total includes a small safety margin.
This capacity is usually more than enough to daisy-chain a complete ED lighting set up. Avoid connected
equipment that requires a lot of power like smoke machines or halogen lighting.
Please note: An IEC C13 to IEC C14 power cable with a minimum 1.5 mm² thickness must always be used
since the current this cable can transfer can exceed 3A.
DMX Terminator
When using the device in DMX mode, it is common for a ‘terminator’ to be used at the end of the DMX
circuit. A DMX terminator is a terminal resistor, consisting of a 120 Ohm resistor placed between the second
and third pin to eliminate any data reflections. Data reflections can cause strange behaviour in DMX
controlled devices.
DMX-terminators are sold ready-made but it is possible to solder a 120 Ohm resistor between the second
and third pin of a standard male X R connector.
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

DMX Lighting Troubleshooting
If you have a problem with your DMX light effect, please consult the troubleshooting section for possible
solutions. If, after consulting this section, the problem remains unresolved, please contact your retailer for
more information and/or help.
This troubleshooting section contains information on how to solve the most common DMX light effect
problems, but it does not and cannot cover every eventuality. It is possible that you won't find your problem,
cause and solution in this section due to differences in device specifications.
roblem ossible Cause Solution
The device doesn’t turn on The fuse is blown Check the fuse to rule out if it is
blown or not. If it is blown, replace
it with a new fuse of the same type
and class.
Power cable not plugged in Check if the power cable is
properly connected to the device
and plugged into an active power
socket.
The device is not reacting to DMX
signals
Incorrect DMX start address Check if the device has been set
to the correct DMX start address
DMX controller is set to ‘Blackout’ Make sure the ‘Blackout’ function
on the DMX controller is not
activated
Make sure the polarity switch on
the DMX controller is set correctly
Try to reverse the DMX polarity
switch on the DMX controller.
The device is not reacting, there is
no DMX signal indication
Make sure the X R cables are
connected properly and are not
defective. Replace if necessary.
The device does not react to
sound/music
Incorrect operation mode Make sure the sound-activated
mode has been selected.
The internal microphone sensitivity
is too low
Check the microphone sensitivity
level and increase it if necessary.
The speaker is too far away, or is
not producing enough low tones
Place the light effect closer to a
speaker (or vice versa) and/or
increase the low-frequency level.
The built-in microphone is not
triggered by high tones.
The amount of projected light is
minimal
Dirty or dusty optics Clean the lens and/or other optics.
Dimmer is not completely open Check if the dimmers on the
spotlights themselves and/or if the
master dimmer is completely open.
Also, check the colour balance
settings.
The DMX signal appears to be
interrupted and some devices are
flashing or behaving strangely
Damaged/defective cables Check and replace the DMX
cables if necessary.
Power interference on the DMX
signal
Avoid connecting signal cables
parallel to power cables.
DMX terminator missing Close the DMX circuit with a DMX
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

terminator
Signal loss or interference in the
DMX circuit
Close the DMX circuit with a
terminator or connect a booster
after maximum 32 fixtures.
The device is not reacting properly
to DMX commands
Incorrect DMX channel mode Check that the correct DMX
channel mode is set
The operation mode can not be
changed
The device is in Slave mode If the device is in Slave mode, it
will wait for a master signal unless
there is a DMX signal present. Set
the device to Master to activate the
sound-controlled or automated
operation modes.
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -

Technical Specifications
Basic Features:
- Compact ED lighting set
- Electronic bar with four independently adjustable spots
- Can be installed standing or suspended
- Energy efficient ED technology
- Power sharing function for daisy-chaining
- Various operation modes
- Included IR remote control
- 4-digit menu display with various adjustable functions
Technical Specifications:
- 3x 3W RGBW ED light sources per spotlight
- Automatic, sound controlled, static, DMX and master-slave operation modes
- DMX control via 4, 6, 7 or 18 channels
- master/slave function for synchronised light shows using multiple and diverse fixtures without using DMX
- Built-in microphone for sound controlled mode with adjustable microphone sensitivity
- Built-in colour macros, colour jump and colour fade
- Adjustable status mode using colour macros and manual dimming per colour
- Fitted with 35mm stand adapter
- Power input: IEC C14 power socket
- Power output: IEC C13 power socket, max. 2000 W
- DMX input and output via 3-pin X R
- Supply voltage: 100 - 240V AC, 50/60 Hz
- Nominal power consumption: 33 W
- Nominal operating temperature: 0 to 40°C
- Fuse: F3A 250V
- Dimensions: 606 x 97 x 214 mm
- Weight: 3.1 kg
Remote Control
- Infrared remote control
- Battery type: CR2025 (included)
Light Output:
- Red: 790 lux @ 1m
- Green: 1350 lux @ 1m
- Blue: 1900 lux @ 1m
- White: 1790 lux @ 1m
- Full on: 5970 lux @ 1m
- Projection angle: 33°
Available Accessories (sold separately):
- Bracket set for standing or suspended installation
- Replacement remote control
- Carry bag
Contact your local retailer for more information about the availability of any parts or accessories.
The information included in this manual is subject to change at any time and without notice
Version: 1.0 Date and Author Initials: 17-02-2020 RV Revision Date and Author Initials: -
