ERO Motion Heads 1W
LED Moving Head
User Manual
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Introduction
Thank you for purchasing the ERO Motion Heads 1W LED moving head. This versati e and compact device
is guaranteed to be the ife of any great party. This manua provides a the information you need to know
about the product before you start using it.
We advise that you read this user manua in its entirety before unpacking the contents of the box, so that you
are fami iar with a of the functiona ity that this product has to offer. P ease be sure to check that a of the
parts and accessories isted be ow under 'Box contents' are inc uded in the package. In the event that the
ERO Motion Heads 1W does not function proper y, or if you have any issues whi e operating it, p ease
remove the p ug from the power socket and contact your retai er for assistance.
Box contents:
- ERO Motion Heads 1W LED moving head with fixed power cab e
- Suspension bracket with mounting materia s
Please inspect t e device and t e included accessories.
Shou d you discover that either the device or one or more of the inc uded parts have been damaged or
rendered defective whi e in transit, p ease contact your retai er direct y.
Please note that the pictures in this user manual serve illustrative purposes only and may differ from the
actual product.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Safety Instructions
Everyone invo ved with the insta ation, operation and maintenance of this device must:
- Be qua ified
- Be ski ed
- Have read the instructions in this user manua
- Be sure that neither the device nor the inc uded accessories are damaged. Shou d the device or the
inc uded accessories be damaged, p ease contact your dea er for more information.
- Ensure that the device is in good working condition and is safe to operate. P ease fo ow the advice and
instructions as they are described in this user manua .
Damage caused by misuse and/or modifications made to the device are not covered by the warranty.
This device does not contain any parts that can be repaired or rep aced by the user. Shou d maintenance or
repairs be necessary, they must be hand ed by a qua ified technician.
The ight source of this device is not rep aceab e. If the ight source no onger functions, the entire device
needs to be rep aced.
Important information regarding safety and ealt :
- Do not remove any abe s or stickers from this device.
- Do not eave any cab es ying around.
- The device shou d not be opened up, and any hardware or software that may be present shou d not be
modified.
- To achieve optima performance, inputs on the device shou d not be fed with a signa higher than
necessary.
- The device shou d on y be used indoors; contact with water, rain and moisture shou d a ways be avoided.
Do not p ace any objects containing iquid on top of the device.
- Remove the device from any nearby f ames or heat sources; do not p ace it near f ammab e f uids, gasses
or objects.
- Disconnect this device from a power source if it wi not be used for a onger period of time, if maintenance
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -
WARNING!
Keep t is device away from moisture, water and rain to avoid t e c ance of electric s ocks.
WARNING!
Only connect t is device to a suitable power socket. T is device functions on a specific power
voltage. If it is plugged into a power socket wit a different voltage, it could result in permanent
damage and even dangerous situations suc as fire or electric s ocks.
WARNING!
Be careful w en operating t is device. Touc ing t e wires t at are connected to t e mains,
inside or outside t e device, could result in electric s ocks.

is necessary, or if it needs to be c eaned.
- Do not pu on the cab e to remove a connector, as it can cause damage.
- Do not use any cab es other than the ones described in this manua . Do not use defective cab es. P ease
contact your dea er if the inc uded or necessary cab es do not function proper y with this device.
- On y use this device with a stab e AC power supp y.
- On y use this device with power from a grounded power source.
- In the event that the device is exposed to extreme temperature changes (e.g. transported through a co d
outside environment into a warm indoor environment), it shou d not be turned on unti it has reached room
temperature. This is necessary to prevent moisture from forming in the device, which cou d ead to e ectric
shocks.
Guidelines and operation of t is device:
- This device is intended for use by professiona s on stage, in theatres, in c ubs, and in simi ar entertainment
ocations.
- This device is not suitab e for use by chi dren, and shou d a ways be operated by an adu t.
- This device is designed to create ight effects for entertainment purposes. It is not suitab e for househo d
i umination.
- This device may on y be used in a suitab e environment where no damage to the device can occur. Do not
use the device in moist or dusty environments such as:
- indoor swimming poo s where ch orine is used
- beaches where there is sand and sa t
- outdoors
- indoors in spaces where intense heat sources are present, or where it reaches temperature eve s
that wou d be considered uncomfortab e for a person
- Avoid impact and co isions during use and transport. Do not transport the device whi e it is in use. Avoid
using excessive force when insta ing and operating the device.
- The user shou d become fami iar with the functions of this device before using it.
- Shou d the device not be used in the manner described in this user manua , damages or even injuries cou d
occur. Ayra cannot be he d responsib e for any injuries or damages that occur as a resu t of improper use of
this product.
Storage and transport:
- This product was designed for mobi e use. P ease on y transport the device in the origina packaging, or in
a f ight case with a suitab e foam in ay.
- This device was not designed for permanent (24/7) use. The expected ifespan of the device wi not be
affected by occasiona y turning the device off. Disconnect the device or turn off the power when it is not
active y in use.
- If the device wi not be used for a onger period of time, it shou d be disconnected and stored in a dust-free
environment.
- Do not expose the device to extreme temperature differences.
Housing
- Inspect the device's housing frequent y, and a ways just before use. Avoid operating the device if there are
arge dents or cracks, or if screws are missing. Do not use the device if the housing is not in good condition.
Contact your dea er or a qua ified technician if you are unsure about the state of the device.
- Check the device and the screws for corrosion. Corrosion must not be present on this device. Contact your
dea er or a qua ified technician if you find any corrosion on the screws.
Every power and signa connector shou d be secure y attached. Do not use the device if the connectors are
not secure.
- Avoid dust and dirt bui d-up. C ean the device once a month by disconnecting it from the power supp y and
wiping it down with a dry or s ight y moist c oth. If the device is used frequent y, the c eaning interva s shou d
increase.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Symbol explanation:
WEEE: Ensure that this device is disposed of proper y. This product fa s under the WEEE
(Waste E ectrica and E ectronic Equipment) directive. The requirements of this directive app y
to a manufacturers and producers of e ectronic devices in the EU. Do not throw this product
away with regu ar rubbish. P ease contact your oca authority for more information about how
to recyc e and dispose of these products in your region. By recyc ing this product in the proper
manner, we can work together to ensure that we can continue to enjoy these kinds of
products and sti protect the environment as much as possib e from po ution.
CE: The CE ogo indicates that this product meets the European norms and requirements to
which it must ega y conform.
On y suitab e for indoor use: this product was on y designed for indoor use. The maximum
environmenta temperature must not exceed 40 degrees Ce sius (104 degrees Fahrenheit).
Contact:
Ayra professiona ighting products
Verrijn Stuartweg 18
4462 GE Goes
The Nether ands
Please do not send any products to this correspondence address.
Should you wish to send in a product for repairs or for a refund, please contact your dealer for an RMA
re uest (Return Merchandise Authorisation).
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Overview and Operation Guidelines for t is Device
1. Moving head with ight putput via ens
2. DMX input and output via 3-pins XLR
3. LED disp ay with menu buttons
4. Rubber feet
5. Mounted suspension bracket
The power cable is not displayed in the picture.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -
45
1
3
2

Operation and Mounting
To activate the device, p ug it into a mains socket. Once it's connected to an active power source, it wi turn
on automatica y.
During start up, either ‘AYRA’ or a specific code wi be shown on the disp ay, which means the device is not
ready to be operated. Once the device has fu y started up, it wi jump to the ast-used mode. Operation
modes and other settings shown on the disp ay can now be adjusted or changed by means of the menu
buttons.
Shou d the device detect a DMX signa , it wi automatica y switch to DMX mode and wi disp ay the ast-
used address. For new devices, this wi norma y be DMX address 001. Of course, you can change the DMX
address via the disp ay using the menu buttons.
Using the disp ay and the menu buttons, you can adjust the functions and settings of the device. Press
'Enter' to confirm an adjustment or se ect a function, use ‘Up’ and ‘Down’ to change va ues press ‘Menu’ to
go back to the menu.
Changed settings or functions can be confirmed by pressing ‘Enter’. After severa seconds, the device wi
automatica y return to the main menu and perform its actions. This process can be sped up by ho ding down
the ‘Menu’ button for two seconds after confirming changes with ‘Enter’.
The menu contains the fo owing options and settings:
display Mode Function
ADDR DMX Address Configuration Address A001 … A512
SLND S ave Mode Master - NAST
S ave 1 – SL 1
S ave 2 – SL 2
SHND Show Mode (meant for sound-
contro ed operation)
SH 1 – Show program 1
SH 2 – Show program 2
SH 3 – Show program 3
SH 4 – Show program 4
SOUN Sound-contro ed mode (activates
interna microphone)
Mode: ON / OFF
SENS Sound Sensitivity 000 – 100: Sensitivity in %
LED LED Disp ay on/off if not in use ON/OFF
DISP Disp ay inversion Disp ay inversion, Idsp-dspI
PAN Pan Inversion (mirroring) NO – No inversion pan
YES – Inversion pan
TILT Ti t Inversion (mirroring) NO – No inversion ti t
YES – Inversion ti t
TEST Test Mode Test program to check if a functions are
working proper y
HOUR Operating Time Registration 0000 – 9999 Operating hours
VER Firmware Version Disp ays firmware version (cannot be updated by
end users)
RSET Reset Function Resets the device
The different functions exp ained:
ADDR:
With this function, you can determine the DMX start address of the device. Set it channe 001, and the
device wi read DMX channe 1. Set it to channe 003, then the device wi read DMX channe 3, etc.
SLND: The Master-S ave mode is designed to sync mu tip e devices. A copy of the interna program is sent
to the daisy-chained devices so that each one projects the same effect. The master-s ave function works by
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

means of standard 3-pin XLR cab es. The on y difference is that the first device in the chain does not receive
DMX input.
PLEASE NOTE: When S ave mode is activated, the device wi wait for a signa from the Master device. It is
not possib e to simp y se ect an automatic or sound-contro ed mode! To cance this, se ect 'NAST' mode in
the SLND menu, so the device goes to Master mode. Then, a standa one functions can be activated.
SHND: This mode consists of automatic programs, designed for sound-contro ed operation. In sound-
contro ed mode, the device uses the bui t-in microphone that can be activated by means of the SOUN
setting and adjusted in sensitivity. Any time the microphone detects sound, the device wi change movement
and/or co our in a way that syncs perfect y with your ight show. If no sound is detected, the device wi move
s ow y and change co our gradua y unti sound is detected again.
SOUN: This setting shows if the microphone function is activated or not, which you can see in the disp ay as
ON or OFF.
If SOUN mode is disab ed, the device wi execute its programs at a s ow, gradua pace.
SENS: This mode a ows you to determine the sensitivity of the interna microphone. The further the device is
from the speaker, the higher the sensitivity of the microphone needs to be so it can react proper y to the
music. The microphone is bui t to hand e high sound pressure eve s, but the ouder the signa , the higher the
microphone sensitivity eve , the more difficu ty the device wi have detecting the beat of the music.
Experiment with the eve of sensitivity and distance/positioning of the device to find the best resu ts.
LED: If the LED disp ay is not in use, it can be de-activated by turning the LED mode OFF. The red symbo s
wi no onger ight up when using the device in a dark environment. Press one of the menu buttons and the
disp ay wi ight up again and show any re evant information. If the device registers that the menu is not
active y being used, it wi automatica y turn off within 30 seconds.
DISP: This function determines whether the disp ay is shown norma y or inverted. If the device is
suspended, the disp ay may be harder to read. This function a ows you to rotate it vertica y for better
egibi ity.
PAN/TILT: Inverts the pan and /or ti t va ues independent y so that the motors work in reverse. This function
works in a modes.
TEST: Shou d the device need c eaning or maintenance, this function can be used to test one or more
devices simu taneous y. The device p ays a continuous program whi e the step motors and LEDs are used.
This way you can quick y detect any abnorma ities or defects. The device wi run the program unti stopped
manua y (for examp e when the sound-contro ed mode is activated.)
HOUR: If this device is used professiona y or rented, it shou d be regu ar y maintained and inspected in
between use. The HOUR function shows exact y how ong the device has been in use. This amount
accumu ates over time as ong as the device is being used and cannot be manipu ated by the user.
VERS: This function shows the device's firmware version. This cannot be changed by the user.
RSET: When this function is activated, the device wi be restarted. This has the same affect as turning the
power off and on again.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Operating Modes
The fo owing overview is designed to show the differences between the various operation modes that are
supported by the above-mentioned menu functions.
Sound:
When in Sound-contro ed mode, the device's interna microphone detects the music and reacts to the beat.
The device wi move in sync with the music and provide an automated ight show.
When there is no music for the device to detect or when on y high frequencies are audib e, the device wi
continue its program at a s ower pace, so the ight show wi not stop abrupt y. As soon as the microphone
detects music again, it wi resume the automated program and fo ow the beat.
Slave
In S ave mode, you can daisy-chain mu tip e devices of the same type so they a function a specific way.
This way you can coordinate your ight show by having mu tip e separate devices moving the same way
instead of a different directions, which can be chaotic. Basica y, you can connect an un imited number of
s ave devices to a master device, but a DMX booster is required in between. Genera y speaking, you can
connect up to four armatures together without the need for a DMX booster.
Be aware that when you attempt to connect devices of different types and brands, they may behave
strange y and you may not get the desired effect because certain functions are inked to the wrong channe s.
This is true of DMX ighting of a brands and types.
The ERO Micro Spot can, in fact, be inked with the ALO Micro Scan because these devices use the same
operating system. This enab es you to ink mu tip e moving heads and scanners of this type.
DMX
The DMX mode is the most comprehensive way to maintain u timate contro over a the functions this device
has to offer. It enab es you to determine exact y how many functions you want to contro via the DMX
contro er or DMX software.
This device can be set to various channe modes so the channe ayout, which is shown be ow, corresponds
perfect y with your DMX circ e ayout, as we as with the functions you wi be using.
14CH mode:
CH Function Value
1 Pan Positiion min-max 000-255
2 Pan Fine Position min-max 000-255
3 Ti t Position min-max 000-255
4 Ti t Fine Position min-max 000-255
5 Movement Speed Pan / Ti t 000-255 (Fast-s ow)
6 Dimmer 0-100% 000-255 (0-100%)
7 Stroboscope Function 000-255 (None - s ow - fast)
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Installation and connection requirements
Now that you know how the ERO Motion Heads 1W works, it's important to know how to use it correct y and
safe y, according to the insta ation and connection requirements.
Make sure the device and connection cab es are out of reach of chi dren, and that if chi dren are present,
they are under adu t supervision at a times. Because this device can be used upright or suspended,
chi dren cou d pu on the cab es, causing the device to fa on top of them. To avoid injury, it is important to
pay c ose attention to the position and/or insta ation of this device.
Uprig t use
If you want to use the ERO Motion Heads 1W in an upright position, ensure that it is p aced on a stab e
surface ike a tab e, DJ booth or T-bar. The ERO Motion Heads 1W is equipped with rubber feet that grip
suitab e surfaces.
Suspended use (brackets)
When you want to suspend the ERO Motion Heads 1W, attach the supp ied mounting bracket to the top of
this device and use the inc uded mounting materia s.
If you want to mount a ha f coup er or a G-hook to the brackets, it is advised to do this before mounting the
brackets to the armature. You can find standard hooks and/or brackets for 35 or 50mm tubes (truss or ight
stand) at your oca dea er.
Hardware for mounting the ERO Motion Heads 1W to the wa , cei ing, or beam is not inc uded. Contact a
specia ist if you're not sure which hardware is required for your situation. A wooden beam and stone wa
require different mounting methods.
Shou d you want to suspend the ERO Motion Heads 1W, you wi need to attach a safety cab e to the
armature. This is not inc uded, but is avai ab e at your oca dea er. The ERO Motion Heads 1W is equipped
with an eye et for hooking safety cab e. Once it's hooked on, you can wrap the cab e around the truss or ight
stand and attach it again by means of the same hook. This ensures the device is secured and prevents it
from fa ing, even if one or both of the brackets shou d come oose.
Ensure that the safety cab e has a oad capacity of 10x the weight of the armature and that the device can
not fa farther than 30 cm. You can wrap the safety cab e around the truss or ight stand severa times to
ensure the fa is as short as possib e. The shorter the fa , the ess chance of damage or injury.
Lig t source
The ERO Motion Heads 1W contains powerfu LED modu es that create an even more powerfu effect thanks
to a specia ens that bund es the beams together. Never ook direct y into the ens at c ose range, as the
human eye can't adjust to the sudden intensity of the beam of ight this device produces. It won't resu t in
permanent damage, but it can cause temporary b ind spots, which may cause disorientation and discomfort.
Cooling
The ERO Motion Heads 1W is coo ed by fans that are insta ed in the head and in the housing. These wi be
activated when the device is turned on. Make sure the fans and vents are not b ocked and regu ar y check
that they are functioning norma y. Be aware that shou d the fans suck in substances ike dust, smoke and
moisture, this may impair their operation and shorten the ife of the device.
Parts and repair
This product does not inc ude spare parts and can not be repaired by the user. A inspections and overa
maintenance shou d be done by a specia ist.
Cleaning and maintenance
C ean the exterior of this device month y with a dry, or s ight y damp microfibre c oth. Ensure that the device
is unp ugged before c eaning it.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Check if a the screws are intact and secured and tighten or rep ace them where needed. Check a meta
parts of the device for any signs of corrosion. If corrosion is found, the device needs to be checked
thorough y.
DMX terminator
In DMX mode, it’s standard practice to p ace a terminator at the end of a DMX circuit. A DMX terminator is an
e ectrica termination consisting of a 120 Ohm resistor, that’s p aced between the second and third pin to
e iminate possib e data ref ections. Data ref ections can cause strange behaviour in DMX-contro ed devices.
DMX-terminators are so d separate y but you may yourse f decide to so der a 120 Ohm resistor between the
second and third pin of a standard ma e XLR connector.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

DMX Lig ting Troubles ooting
If you have a prob em with your DMX ight effect, p ease consu t the troub eshooting section for possib e
so utions. If, after consu ting this section, the prob em remains unreso ved, p ease contact your dea er for
more information and/or he p.
This troub eshooting section contains information on how to so ve the most common DMX ight effect
prob ems, but it does not and cannot cover every eventua ity. It is possib e that you won't find your prob em,
cause and so ution in this section due to differences between various connecting devices.
Problem Possible cause Solution
The device can not be turned on. A fuse is b own Check the fuse to ru e out if it is
b own or not. If it is b own, rep ace
it with a new fuse of the same type
and c ass.
The device is not reacting to DMX
signa s
Power cab e not p ugged in Check if the power cab e is
proper y connected to the device
andp ugged into an active power
socket.
Incorrect DMX start address Check if the device has been set
to the correct DMX start address
DMX contro er is set to ‘B ackout’ Make sure the ‘B ackout’ function
on the DMX contro er is not
activated
Make sure the po arity switch on
the DMX contro er is set correct y
Try to reverse the DMX po arity
switch on the DMX contro er.
The device does not react to
sound/music
Incorrect operation mode Make sure the sound-activated
mode has been se ected.
The interna microphone sensitivity
is too ow
Check the microphone sensitivity
eve and increase it if necessary.
The speaker is too far away, or is
not producing enough ow tones
P ace the ight effect c oser to a
speaker (or vice versa) and/or
increase the ow-frequency eve .
The bui t-in microphone is not
triggered by high tones.
The amount of projected ight is
minima
Dirty or dusty optics C ean the ens and/or other optics.
Dimmer is not comp ete y open Check if the dimmers on the
spot ights themse ves and/or if the
master dimmer is comp ete y open.
The DMX signa appears to be
interrupted and some devices are
f ashing or behaving strange y
Damaged/defective cab es Check and rep ace the DMX
cab es if necessary.
Power interference on the DMX
signa
Avoid connecting signa cab es
para e to power cab es.
DMX terminator missing C ose the DMX circ e with a DMX
terminator
Signa oss or interference in the
DMX circ e
C ose the DMX circ e with a
terminator or connect a booster
after maximum 32 fixtures.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

The operating mode can not be
changed
The device is in S ave mode If the device is in S ave mode, it
wi wait for a master signa un ess
there is a DMX signa present. Set
the device to Master to activate the
sound-contro ed or automated
operation modes.
Movements are somewhat shaky. Movements have been
programmed to too s ow a pace
S ow-paced programmed
movements may cause the moving
head to move in incrementa motor
steps. This can be corrected to a
certain degree by adjusting, per
device, the Pan / Ti t speed in
DMX mode.
Pan and/or ti t are in reverse Pan or ti t inversion is set Check pan or ti t inversion settings
and switch them on or off as
required.
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -

Tec nical Specifications
Specifcations:
- Compact LED moving head
- Meta housing with p astic covers
- Light source: 10 Watt white LED
- Various operating modes
- Automatic mode with 4 customisab e programs and 9 speed settings
- Sound-contro ed mode with adjustab e sensitivity
- Master / S ave mode
- Pan / Ti t inversion mode
- DMX operation via 7 channe s
- Beam ang e: 8 degrees
- Light output: 76.000 Lux at 1 metre
- Fitted with suspension bracket
- Fixed power cab e with grounded Schuko
- 3-Pin XLR DMX input and output
- Fuse: on-board, cannot be rep aced by end user
- To be used in environmenta temperature: 0°C - 40°C
- Housing temperature during norma use: 41°C
- Maximum power consumption: 16.8W
- Power supp y: 100-240V AC, 50/60 Hz
- Power factor: 0.699 at 110V, 0.513 at 220V
- Dimensions: 230 x 160 x 140 mm
- Weight: 2 kg
Menu functions:
- Disp ay b ackout function when not in use
- Disp ay inversion option
- Pan / Ti t inversion option
- Test mode (to check a functions)
- Reset function (reboots the device)
- Hour registration
- Firmware version
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -
