Azbil Neosensor Series User manual

AB-7050
1
Specifications/Instructions
Neosensor
Room Temperature Sensor
Room Humidity Sensor
Room Temperature/Humidity Sensor
General
Neosensor is a series of electronic room sensors including
temperature sensor (Models TY7043, TY7053), humidity
sensor (Model HY7043), and temperature/humidity sensor
(Model HTY7043). Neosensor is coordinated in terms of
design and dimension with Neostat electronic room
temperature/humidity controller.
Platinum resistance temperature detector for temperature
sensing element and polymer capacitive detector (FP3™
developed by Azbil Corporation) for humidity sensing
element enhance accuracy and reliability of Neosensor
sensing. Neosensor is thus suitable for various applications
such as commercial building air conditioning or other indoor
uses.
Note:
* The specification data of the two-wire 4-20mA output model of
Neosensor is not included in this document. Refer to the
following document.
AB-7051 Specifications/Instructions:
Neosensor (Two-Wire 4-20 mA Output Sensor)
Room Temperature Sensor (Model TY7043D),
Room Humidity Sensor (Model HY7043D),
Room Humidity/Temperature Sensor (Model HTY7043D)
Features
•Wide temperature and/or humidity sensing range with
high accuracy.
•Excellent long-term stability.
•High environmental resistance.
•Quick response and high repeatability.
•Compact (thin) and lightweight.
•CE Marking certified product:
The following models conform to all the applicable
standards of CE Marking.
- Model TY7043Z0P0X
- Model TY7053Z0P00
- Model HY7043 series
- Model HTY7043 series

AB-7050
2
Safety Instructions
Please read instructions carefully and use the product as specified in this manual. Be sure to keep this manual near by for ready
reference.
Usage Restrictions
This product is targeted for general air conditioning. Do not use this product in a situation where human life may be affected. If
this product is used in a clean room or a place where reliability or control accuracy is particularly required, please contact our
sales representative. Azbil Corporation will not bear any responsibility for the results produced by the operators.
Warnings and Cautions
WARNING Alerts users that improper handling may cause death or serious injury.
CAUTION Alerts users that improper handling may cause minor injury or material loss.
Signs
Alerts users possible hazardous conditions caused by erroneous operation or erroneous use. The symbol inside 
indicates the specific type of danger.
(For example, the sign on the left warns of the risk of electric shock.)
Notifies users that specific actions are prohibited to prevent possible danger. The symbol inside graphically
indicates the prohibited action.
(For example, the sign on the left notifies that disassembly is prohibited.)
Instructs users to carry out a specific obligatory action to prevent possible danger. The symbol inside graphically
indicates the actual action to be carried out.
(For example, the sign on the left indicates general instructions.)
CAUTION
Use the product under the operating conditions (temperature, humidity, power, vibration, shock, mounting direction,
atmospheric condition, etc.) as listed in the specifications.
Failure to do so might cause fire or device failure.
Use the product within the rated operating ranges as listed in the specifications.
Failure to do so might cause device failure.
Installation and wiring must be performed by qualified personnel in accordance with all applicable safety standards.
All wiring must comply with applicable codes and ordinances.
Before wiring, be sure to turn off the power to the product.
Failure to do so might cause electric shock.
Do not disassemble the product.
Doing so might cause electric shock or device failure.
Dispose of the product as industrial waste in accordance with your local regulations.
Do not reuse all or part of this product.
IMPORTANT:
•Measuring accuracy of this product is preset before shipment. Output of the product, used even in normal air,
may be shifted depending on the operating conditions. Periodic inspection therefore is recommended.
•Corrosive gas or organic solvent may cause shift in output or damage the product. Before using the product
(Models HY7043, HTY7043) in abnormal atmosphere, consult with our salesperson.

AB-7050
3
Model Numbers
Base model
number Type — Power supply
Humidity
output
Temperature
output — Output wiring
Company
logo Description
HTY70 Room temperature/humidity sensor
TY70 Room temperature sensor
HY70 Room humidity sensor
4 Neosensor
5 Neosensor high sensitive type
3 Fixed
T 24 V DC / 24 V AC
Z No power required
0 No humidity sensing
1 1 V DC to 5 V DC
6 0 V DC to 10 V DC
0 No temperature sensing
P RTD (Pt100)
K RTD (Pt1000)
0 Fixed
0 Lead wire connection
1 Modular connection
(Modular jack is provided on the product.)
blank With company logo
-1 Without company logo
RTD: Resistance temperature detector
Regarding the available model numbers, refer to the table below.
Available model numbers
Model number Type Power Humidity output Temperature
output
Signal output wire
connection
Company
logo
HTY7043T1P00 Yes
HTY7043T1P00-1 Neosensor 24 V DC/AC 1-5 VDC RTD (Pt100) Lead wire connection No
HTY7043T6P00 Yes
HTY7043T6P00-1 Neosensor 24 V DC/AC 0-10 V DC RTD (Pt100) Lead wire connection No
TY7043Z0P00 Yes
TY7043Z0P00-1 Neosensor No power N/A RTD (Pt100) Lead wire connection No
TY7043Z0P01 Yes
TY7043Z0P01-1 Neosensor No power N/A RTD (Pt100) Modular connection No
TY7043Z0K00 Yes
TY7043Z0K00-1 Neosensor No power N/A RTD (Pt1000) Lead wire connection No
TY7053Z0P00 Yes
TY7053Z0P00-1
Neosensor
high sensitive type No power N/A RTD (Pt100) Lead wire connection No
HY7043T1000 Yes
HY7043T1000-1 Neosensor 24 V DC/AC 1-5 VDC N/A Lead wire connection No
HY7043T6000 Yes
HY7043T6000-1 Neosensor 24 V DC/AC 0-10 V DC N/A Lead wire connection No

AB-7050
4
Part Numbers of Optional Items
Mount Neosensor with the following optional items (sold separately). Order necessary items.
Item Part number/Model number
Wall-direct mounting kit Part No. 83165803-001
Thermoplate mounting kit Part No. 83165803-011
Dedicated mounting kit
Multi-Thermocase mounting kit Part No. 83165803-021
Thermoplate for individual room
control
Models QY1100C and QY1100D
(with rotary switch)
Part No. DY2000A1022 For mounting one Neosensor, lengthwise
Part No. DY2000A1023 For mounting one Neosensor, crosswise
Part No. DY2000A2023 For mounting two Neosensor in 94mm (H) x 192mm (W)
outlet box, crosswise
Part No. DY2000A2024 For mounting two Neosensor in 106mm (H) x 198mm
(W) outlet box, crosswise
Thermoplate
Part No. DY2000A3022 For mounting three Neosensor, crosswise
Part No. DY2000A1021 For mounting one Neosensor, square
Part No. DY2000A2021 For mounting two Neosensor, crosswise
Thermoplate for open wiring
* Thermoplate for open wiring
is used for open wiring
installation.
Part No. DY2000A3021 For mounting three Neosensor, crosswise
Auxiliary device
Multi-Thermocase Model TY1100Z
LAN cable Part No. DY7210 For modular connection type Neosensor
* Use Part No. DY7210 or the cable that meets the
following:
TIA/EIA-568 Category 3 or over (⌀0.5 x 4 pairs)
* For the wiring length, refer to the
Specifications/Instructions document of the controller
in connection with Neosensor.
TIA/EIA: Telecommunications Industry Association/Electronic Industries Association
Dedicated mounting kits for each mounting method
Mounting method Mounting kit Contents
Mounting directly on a
wall
Mounting onto
Thermoplate for open
wiring
Wall-direct mounting kit
(Part No. 83165803-001)
Mounting onto
Thermoplate
Thermoplate mounting kit
(Part No. 83165803-011)
Mounting in
Multi-Thermocase
Multi-Thermocase mounting kit
(Part No. 83165803-021)
One flat-head machine
screw (M3 ×16)
Main unit
Mounting plate
Two pan-head machine screw (M4
×
8)
Man unit
Two tapping screws (M2.6
×
8)
Main unit
66.7 mm
Mounting screws are supplied with
the Multi-Thermocase (optional).

AB-7050
5
Specifications
Item Specification
Temperature 0 °C to 60 °CMeasuring range
Humidity 0 %RH to 100 %RH (at 15 °C 35 °C)
RTD
(Pt100)
±0.3 °C (at 0 °C to 60 °C)
* 1mA applied current, 0.15 m/s downflow
for Models TY7043Z0P0X(-1), TY7053Z0P00(-1), and HTY7043 series
Temperature
RTD
(Pt1000)
±0.5 °C (at 0 °C to 60 °C)
* 0.1-0.3mA applied current, 0.15 m/s downflow
for Model TY7043Z0K00(-1)
Measuring accuracy
Humidity ±3 %RH (within 30 %RH to 70 %RH range, at 25 °C), ±5 %RH (within 20 %RH to 80 %RH
range, at 15 °C to 35 °C)
for Models HY7043 series and HTY7043 series
100 Ω/ 0 °C (RTD (Pt100) conforming to JIS C 1604 Class A)
for Models TY7043Z0P0X(-1), TY7053 series, HTY7043 series
Temperature
1000 Ω/ 0 °C (RTD (Pt1000)equivalent to JIS C 1604 Class A)
for Model TY7043Z0K00(-1)
1 V DC to 5 V DC (linear to 0 %RH to 100 %RH)
* Min. 50 kΩinput impedance of the controller in connection
for Models HY7043T1000(-1), HTY7043T1P00(-1)
Output signal
Humidity
0 V DC to 10 V DC (linear to 0 %RH to 100 %RH)
* Min. 50 kΩinput impedance of the controller in connection
for Models HY7043T6000(-1), HTY7043T6P00(-1)
Max. 4.5 min. (at 0.15 m/s air velocity)
for Models TY7043 series and HTY7043 series (Neosensor)
Temperature
Max. 2.5 min. (reference value) (at 0.15 m/s air velocity)
for Model TY7053 series (Neosensor high sensitive type)
Time constant
(at 0.15 m/s wind
velocity)
Humidity Max. 40 sec. (at 0.15 m/s air velocity)
for Models HY7043 series and HTY7043 series (Neosensor)
Power supply 24 V AC +10/-15 % (50 Hz/60 Hz), 24 V DC ±10 %
for Models HY7043 series, HTY7043 series
Power consumption 0.15 VA (24 V AC power), 100 mW (24 V DC power)
for Models HY7043TX000(-1), HTY7043TXP00(-1)
Insulation resistance Min. 500 V DC, 20 MΩ
Withstand voltage 500 V AC applied for 1 min. with max. of 1 mA leakage current
(between housing and terminals)
Environmental conditions Rated operating condition Limit operating condition Transport/storage condition
Ambient temperature 0 °C to 60 °C -10 °C to 60 °C -20 °C to 70 °CFor temperature
sensing Ambient humidity 0 %RH to 100 %RH
(non-condensing)
0 %RH to 100 %RH
(non-condensing)
5 %RH to 95 %RH
(non-condensing)
Ambient temperature 15 °C to 35 °C -10 °C to 60 °C -20 °C to 70 °CFor humidity
sensing Ambient humidity 20 %RH to 80 %RH
(non-condensing)
0 %RH to 100 %RH
(non-condensing)
5 %RH to 95 %RH
(non-condensing)
Vibration 1.96 m/s2(10 Hz to 150 Hz) 1.96 m/s2(10 Hz to 150 Hz) 9.8 m/s2(10 Hz to 150 Hz)
Color Pale gray
Cover PC resin Materials
Base Modified PPE resin
Weight Approx. 80 g
Installation With the mounting kit (sold separately).
Lead wire (0.75 mm2×300 mm long) connectionConnection
Modular connection only for Model TY7043Z0P01(-1)
* Modular jack is provided. LAN cable compliant with EIA/TIA-568 Category 3 or over
(⌀0.5 mm x 4 pairs) is required for modular connection.
Accessory Four main unit mounting screws (M3 x 16)
JIS: Japanese Industrial Standards
PPE: Polyphenylene ether
CE Marking Conformity
Models TY70X3Z0P0X, HY7043 series and HTY7043 series comply with the following Electromagnetic Compatibility (EMC).
EMC: EN61326-1 Class B, Table 1 (For use in a basic electromagnetic environment)
(CISPR11: 2003, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-11)
Note:
Models TY7043Z0K00 and TY7043Z0K00-1 (Pt1000 temperature sensor model of Neosensor) are "equipment which is inherently benign in
terms of electromagnetic compatibility" and "is excluded from the scope of the EMC Directive."
Guide for the EMC Directive 2004/108/EC (8th February 2010)

AB-7050
6
Dimensions: Neosensor with Wall-Direct Mounting Kit
Neosensor
Notes:
*1 For wiring, secure more than 15 mm clearance inside the mounting surface when installing Neosensor with Wall-direct mounting kit.
*2 The number of lead wires differs depending on the models. Note that the Pt100 temperature sensor model with modular connection has a
modular jack instead of lead wires. (Model TY7043Z0P01(-1))
Figure 1. Mounting dimensions (mm): Neosensor with Wall-direct mounting kit
Neosensor high sensitive type
Note:
* For wiring, secure more than 15 mm clearance inside the mounting surface when installing Neosensor high sensitive type with Wall-direct
mounting kit.
Figure 2. Mounting dimensions (mm): Neosensor high sensitive type with Wall-direct mounting kit
Wall-direct mounting kit
77
90
77
77 90
77
38.5 15*1
16.5
Mounting
surface
Lead wires*2
Wall-direct mounting kit
77
90
77
77
45.5 15*
16.5
Mounting
surface
77 90
Lead wires

AB-7050
7
Mounting plate
Note:
* Use JIS outlet box/box cover (JIS C8340:1999) with 66.7 mm mounting dimension.
Figure 3. Dimensions (mm): Mounting plate of Wall-direct mounting kit
Dimensions: Neosensor with Thermoplate Mounting Kit (on Thermoplate)
Neosensor
Notes:
*1 For wiring, secure more than 12.5 mm clearance from the Thermoplate surface to the inside of the mounting surface when installing
Neosensor with Thermoplate mounting kit.
*2 The number of lead wires differs depending on the models. Note that the Pt100 temperature sensor model with modular connection has a
modular jack instead of lead wires. (Model TY7043Z0P01(-1))
Figure 4. Mounting dimensions (mm): Neosensor with Thermoplate mounting kit on Thermoplate
80
8.2
4.2
66.7*
80
⌀4.2 mounting hole
Mounting screw (M3)
Mounting hole
77
77
77 77
41
19
Thermoplate mounting kit
Thermoplate
(optional)
Thermoplate mounting kit
12.5*1
Thermoplate
Lead wires*2
Mounting
surface

AB-7050
8
Neosensor high sensitive type
Note:
* For wiring, secure more than 12.5 mm clearance from the Thermoplate surface to the inside of the mounting surface when installing
Neosensor with Thermoplate mounting kit.
Figure 5. Mounting dimensions (mm): Neosensor high sensitive type with Thermoplate mounting kit on Thermoplate
Thermoplate mounting kit
Figure 6. Dimensions (mm): Mounting plate of Thermoplate mounting kit
8
⌀2.8 mounting hole
22
49
Thermoplate mounting kit
77
77
77
48
19
Thermoplate mounting kit
12.5*
77
Thermoplate
Thermoplate
(optional)
Lead wires
Mounting
surface

AB-7050
9
Dimensions: Neosensor (without the Cover) with Multi-Thermocase Mounting Kit (in Multi-Thermocase)
Neosensor
When installing Neosensor in the optional Multi-Thermocase, remove the cover of Neosensor.
Note:
* The number of lead wires differs depending on the models. Note that the Pt100 temperature sensor model with modular connection has a
modular jack instead of lead wires. (Model TY7043Z0P01(-1))
Figure 7. Mounting dimensions (mm): Neosensor (not covered) with Multi-Thermocase mounting kit
Multi-Thermocase mounting kit
Note:
* Assembling dimension with device mounting plate of Multi-Thermocase is 66.7 mm.
Figure 8. Mounting dimensions (mm): Multi-Thermocase mounting kit
55
68
66.7*
⌀3.4 mounting hole
Multi-Thermocase
mounting kit
72.8
85
52
72.8
85
23
85
72.8
72.8
Multi-Thermocase
mounting kit
Lead wires*

AB-7050
10
Installation
CAUTION
Use the product under the operating conditions (temperature, humidity, power, vibration, shock, mounting direction,
atmospheric condition, etc.) as listed in the specifications.
Failure to do so might cause fire or device failure.
Installation and wiring must be performed by qualified personnel in accordance with all applicable safety standards.
Requirements for installation location
IMPORTANT:
●Installation location of Neosensor largely affects temperature/humidity control. Carefully select the location.
●Chemical (organic solvent) atmosphere may shift the output values.
●Corrosive gas, organic solvent, and other chemicals contained in the atmosphere can cause measuring error
of Neosensor, shorten the service life of Neosensor, or damage Neosensor.
Ask our salesperson for use of Neosensor in a special application, as mentioned above.
Install Neosensor on an indoor wall where:
●Representative temperature and humidity (of the room/zone to control) are measured (approx. 1.5 m high above the floor).
●Ambient air velocity is 0.1 to 0.15 m/s.
●There is enough maintenance space left in front of Neosensor.
Do not install Neosensor on a wall where:
●Heat (generated by office device or equipment, for example) stays on.
●Air circulation is interfered (by furniture or door, for example).
●Temperature and/or humidity sensing is affected by draft, downdraft, and hot/cold air from water pipes/ducts.
●Temperature and/or humidity sensing is affected by weather conditions (including sunlight and outdoor air).
●There is vibration.
●Dew condensation occurs.
●Water drops.
●Corrosive gas, organic solvent, or other chemicals is contained in the atmosphere.
Do not install Neosensor outdoors or in a duct.
Do not horizontally install Neosensor directly on a ceiling surface.
Precautions for installation
●Install Neosensor with a dedicated mounting kit (sold separately) suitable for your application.
●Do not allow any refuse such as an electric wire scrap to get inside Neosensor.
●Do not get a cable caught between the Neosensor main unit and the mounting surface.
●Carefully handle Neosensor when the cover is removed so that the element does not get damaged.
●Check that the ambient air velocity is sufficient in a location (not on a ceiling surface) where Neosensor will be horizontally
installed.
●If air infiltrates to the rear side of the Neosensor from the inside of the installed wall through the outlet box, shut off the air by
sealing the outlet box.
●After installation, leave Neosensor well so that it adapts to ambient conditions (atmospheric environment).

AB-7050
11
Installation steps: Neosensor directly on a wall with Wall-direct mounting kit
1) Attach the mounting plate of the Wall-direct mounting kit to the outlet box cover (JIS C8340:1999 Boxes and box covers for
rigid metal conduits (mounting dimension: 66.7 mm)) on the mounting surface.
2) Attach the main unit of the Wall-direct mounting kit to the mounting plate. (See Fig. 11.)
3) Connect the lead wires of Neosensor and the wires from the load. (See Figs. 20 and 21.)
Note:
The number of the lead wires differs depending on the models. Note that the Pt100 temperature sensor model with modular connection
has a modular jack instead of lead wires. (Model TY7043Z0P01(-1))
4) Remove the cover of Neosensor as shown in Fig. 14.
5) Set the depth change levers on the bilateral sides of the Neosensor main unit to the upper position (indicated with "L" shown
in Fig. 17).
6) Mount the main unit of Neosensor on the main unit of the Wall-direct mounting kit with four mounting screws (M3 ×16)
supplied with Neosensor.
7) Attach the cover back to the Neosensor main unit and complete the installation. (See Fig. 14.)
Figure 9. Installation: Neosensor with Wall-direct mounting kit
66.7 mm
Wires
from the load
Mounting plate
of Wall-direct mounting kit
2 pan-head machine screws (M4
×
8)
of Wall-direct mounting kit
Main unit
of Wall-direct mounting kit
Lead wires of
Neosensor
1 flat-head machine screw (M3 ×16)
of Wall-direct mounting kit
Main unit of Neosenso
r
4 flat-head machine screws
(M3 ×16) of Neosensor
Cover of Neosensor
Neosensor Wall-direct mounting kit
(optional)
Mounting box cover (JIS C8340
with 66.7 mm mounting dimension,
commercially available)

AB-7050
12
Installation steps: Neosensor on the Thermoplate for open wiring with Wall-direct mounting kit
1) Attach the mounting plate of the Wall-direct mounting kit to the Thermoplate for open wiring on the mounting surface.
2) Attach the main unit of the Wall-direct mounting kit to the mounting plate. (See Fig. 11.)
3) Connect the lead wires of Neosensor to the wires from the load. (See Figs. 20 and 21.)
Note:
The number of the lead wires differs depending on the models. Note that the Pt100 temperature sensor model with modular connection
has a modular jack instead of lead wires. (Model TY7043Z0P01(-1))
4) Remove the cover of Neosensor as shown in Fig. 14.
5) Set the depth change levers on the bilateral sides of the Neosensor main unit to the upper position (indicated with "L" shown
in Fig. 17).
6) Mount the main unit of Neosensor on the main unit of the Wall-direct mounting kit with four mounting screws (M3 ×16)
supplied with Neosensor.
7) Attach the cover back to the Neosensor main unit and complete the installation. (See Fig. 14.)
Figure 10. Installation: Neosensor with Wall-direct mounting kit (on Thermoplate for open wiring)
Assembling the Wall-direct mounting kit (the main unit to the mounting plate)
Figure 11. Assembling the Wall-direct mounting kit
Neosensor Wall-direct mounting kit
(optional)
Thermoplate for open wiring
(optional)
66.7 mm
Wires
from the load
Mounting plate
of Wall-direct mounting kit
2 pan-head machine screws (M4
×
8)
of Wall-direct mounting kit
Main unit
of Wall-direct mounting kit
Lead wires of Neosensor
1 flat-head machine screw (M3 ×16)
of Wall-direct mounting kit
Main unit of Neosenso
r
4 flat-head machine screws
(M3 ×16) of Neosensor
Cover of Neosensor
Engage.
Mounting plate
Rear side of the main unit
A
ttach.

AB-7050
13
Installation steps: Neosensor on Thermoplate with Thermoplate mounting kit
1) Attach the mounting plate of Thermoplate to the outlet box cover (JIS C8340:1999 Boxes and box covers for rigid metal
conduits (mounting dimension: 83.5 mm)) on the mounting surface.
2) Attach the main unit of Thermoplate to the mounting plate.
3) Attach the Thermoplate mounting kit to the Thermoplate.
4) Connect the lead wires of Neosensor to the wires from the load. (See Figs. 20 and 21.)
Note:
The number of the lead wires differs depending on the models. Note that the Pt100 temperature sensor model with modular connection
has a modular jack instead of lead wires. (Model TY7043Z0P01(-1))
5) Remove the cover of Neosensor as shown in Fig. 14.
6) Set the depth change levers on the bilateral sides of the Neosensor main unit to the upper position (indicated with "L" shown
in Fig. 17).
7) Mount the main unit of Neosensor on the main unit of the Thermoplate mounting kit with four mounting screws (M3 ×16)
supplied with Neosensor.
8) Attach the cover back to the Neosensor main unit and complete the installation. (See Fig. 14.)
Figure 12. Installation: Neosensor with Thermoplate mounting kit (on Thermoplate)
Wires
from the load
83.5 mm
Mounting plate of Thermoplate
2 pan-head machine screws (M4
×
8)
of Thermoplate
Main unit of Thermoplate
2 pan-head machine screws (M4
×
5)
of Thermoplate
Main unit o
f
Thermoplate mounting kit
2 tapping screws (M2.6 ×8)
of Thermoplate mounting kit
Lead wires of
Neosensor
Main unit of Neosenso
r
4 flat-head machine screws
(M3 ×16) of Neosensor
Cover of Neosensor
Neosensor Thermoplate mounting kit
(optional)
Thermoplate
(optional)
Mounting box cove
r
(JIS C8340
with 83.5 mm mounting dimension,
commercially available)

AB-7050
14
Installation steps: Neosensor in Multi-Thermocase with Multi-Thermocase mounting kit
1) Attach the main unit of the Multi-Thermocase mounting kit to the device mounting plate of Multi-Thermocase.
2) Connect the lead wires of Neosensor to the wires from the load.
Note:
The number of the lead wires differs depending on the models. Note that the Pt100 temperature sensor model with modular connection
has a modular jack instead of lead wires. (Model TY7043Z0P01(-1))
3) Remove the cover from the Neosensor main unit as shown in Fig. 14.
4) Set the depth change levers on the bilateral sides of the Neosensor main unit to the lower position (indicated with "H").
5) Mount the Neosensor main unit to the Multi-Thermocase mounting kit with four screws (M3 ×16) supplied with the
Neosensor. In the Multi-Thermocase, Neosensor is installed with its cover removed.
IMPORTANT:
Before installing Neosensor in the Multi-Thermocase, be sure to set the depth change levers on the bilateral
sides of the Neosensor main unit at the lower position (indicated with “H”.)
Figure 13. Installation: Neosensor (in Multi-Thermocase) with Multi-Thermocase mounting kit
Device mounting plate
of Multi-Thermocase
Multi-Thermocase
Depth change levers at
the lower position (indicated with “H”).
Note:
Lower the depth change levers at "H" position first, then assemble the
Neosensor main unit (without the cover) with the Multi-Thermocase
mounting kit and fix with the four screws (Neosensor accessory).
Device mounting plate
of Multi-Thermocase
External wires
from the load
66.7 mm
Main unit of
Multi-Thermocase mounting kit
2 pan-head machine screws (M3
×
6)
of Multi-Thermocase
Main unit of Neosenso
r
4 flat-head machine screws
(M3 ×16) of Neosenso
r
Neosensor
(with the cover removed)
Multi-Thermocase mounting kit
(optional)
Set at the
lower position
Set at the
lower position
Lead wires of Neosenso
r

AB-7050
15
Cover removal
Do not bend the humidity sensing element attached to the PCB board assembly. Otherwise, measuring accuracy may drop.
To remove the cover:
Press the spring, located inside the top of the Neosensor
main unit, using a thin object.
To attach the cover:
Engage the tabs located on the lower part of the cover with
the slots on the lower part of the main unit. Then fix the
cover with the spring, located on the top of the Neosensor
main unit.
Protection form heat radiation and conduction
To protect the measuring accuracy from disturbances (including heat radiation and conduction) caused by the mounting surface
where Neosensor is mounted, the distance between the Neosensor sensing element and the mounting surface (depth of the
Neosensor main unit) can be changed. See the following steps to change the depth.
1) Remove four mounting screws of Neosensor.
Figure 15. Depth change: removing the mounting screws
2) Raise the Neosensor main unit from the Wall-direct
mounting kit. 9 mm max. can be raised.
Figure 16. Depth change: Raising the Neosensor main unit
3) Set the depth change levers, located on the bilateral
sides on the main unit front surface, at the lower position.
(The levers are factory-set at the upper position.)
Figure 17. Depth change: Lowering the depth change lever
4) Fix the raised Neosensor main unit to the Wall-direct
mounting kit with four mounting screws.
Figure 18. Depth change: Fixing the raised main unit
5) Check that the depth of the Neosensor is changed.
Follow the same steps to change the depth of Neosensor
installed on Thermoplate.
Figure 19. Depth change: Side view of the raised Neosensor
Note:
Effect of raised Neosensor differs depending on its installation
environment.
Wall-direct mounting kit
Neosensor main unit
Remove 4 mounting
screws.
Raise the Neosensor
main unit.
Depth change lever set at
the upper position (indicated
with “L”).
Depth change lever set at
the lower position (indicated
with “H”).
Fix with 4 mounting screws.
Mounting surface
38.5 mm 47.5 mm
9.0 mm
Raised
9.0 mm
Mounting surface
3. Disengage the tabs.
Wall-direct mounting kit
Cover
1. Press the spring.
Main unit
Tab of the cover
(at 2 locations)
Figure 14. Cover removal
2. Release the top o
f
the cover.
Wall-direct mounting kit
Neosensor main unit

AB-7050
16
Wiring
Lead wire connection type
Modular connection type (No power type)
Figure 21. Terminal wiring: Temperature sensor with RTD (Pt100) output, no power
J1
<
<
<
<
<
<
<
<
1 (A)
2 (B)
3 (A)
4 (B)
5 NC
6 (B)
7 NC
8 (B)
Pt100
(Modular jack)
Model TY7043Z0P01(-1)
Pt100
Red
White
White
A
B
B
Temp.
Models TY7043Z0P00(-1)
and TY7053Z0P00(-1)
Figure 20. Terminal wiring:
Temperature sensor with RTD (Pt100) output, no power
Note:
Black wires for power supply and for humidity output are
internally connected.
~(+) Brown
Black
Blue
Black
24 V AC/DC
1-5 V DC/
0-10 V DC
Power
supply ⊥(-)
+
-
Humidity
Models HY7043T1000(-1)
and HY7043T6000(-1)
Figure 22. Terminal wiring:
Humidity sensor with 1-5V/0-10V humidity output,
24 V AC/DC power
Pt1000
Red
White
A
B
Model TY7043Z0K00(-1)
Figure 21. Terminal wiring:
Temperature sensor with RTD (Pt1000) output, no power
Temp.
Note:
Black wires for power supply and for humidity output are
internally connected.
~(+)
Pt100
Brown
Black
Blue
Black
Red
White
White
A
B
B
24 V AC/DC
1-5 V DC/
0-10 V DC
Power
supply
⊥
(-)
+
-
Humidity
Models HTY7043T1P00(-1)
and HTY7043T6P00(-1),
Figure 23. Terminal wiring:
Temperature/humidity sensor with RTD (Pt100) output and
1-5V/0-10V humidity output, 24 V AC/DC powe
r
Temp.

AB-7050
17
Precautions for wiring
IMPORTANT:
•Do not connect the lead wires for temperature output to the power supply line to prevent smoking or burnout.
Make sure all the wires are correctly connected before supplying power.
•Single Neosensor must be powered by a single 24 V AC transformer. Do not connect the transformer to any
other device in addition to Neosensor.
●For power supply wiring and temperature/humidity output wiring, 1.25 mm2or greater shielded multi-core cables (JIS
CVV-S) are recommended. 1.25 mm2or greater JIS IV cable is also connectable. Be sure to ground the shielding on the
controller side.
The maximum cable length is 100 m.
●Because the temperature sensor model with RTD (Pt1000) output is two-wire, the wire resistance will cause measuring
error. For instance, 1.25 mm2size wire causes approx. 0.1 °C measuring error every 10 m. Correct the measuring error by
setting the controller in connection.
Transformer for Neosensor (humidity sensor, temperature/humidity sensor models)
IMPORTANT:
Use isolated transformer to supply 24 V AC power.
Single Neosensor must be powered by a single 24 V AC transformer. If the multiple Neosensor or a
Neosensor and a device in connection are powered by a single 24 V AC transformer, the common wiring will
form a loop, and Neosensor will get damaged.
24 V AC transformer: Two Neosensor powered by a single transformer
Figure 22. Bad wiring examples: Two Neosensor (temperature/humidity sensors) powered by a single 24 V AC transformer
24 V AC transformer: Two Neosensor separately powered by two transformers
Figure 23. Good wiring example: Two Neosensor (temperature/humidity sensors) powered by separate 24 V AC transformers
If the transformer is misconnected, it will short-circuit through the common wiring.
Bad wiring
Controller
Common
wiring
24 V AC
Temperature/
humidity sensor
+
-
+
∼
⊥-
∼+
-
+
-
⊥
Temperature/
humidity sensor
Bad wiring
Common wiring forms a loop.
24 V AC
Temperature/
humidity sensor
Temperature/
humidity sensor
Controller
+
-
+
∼
⊥
-
∼
+
-
+
-
⊥
Common
wiring
Common wiring does not form a loop.
Good wiring
24 V AC
Temperature/
humidity sensor Controller
+
-
+
∼
⊥
-
∼
+
-
+
-
⊥
24 V AC
Temperature/
humidity sensor

AB-7050
18
24 V DC transformer: Multiple Neosensor powered by a single transformer (correct example)
Multiple Neosensor or a Neosensor and another device in connection can be powered by a single 24 V DC power.
Figure 24. Good wiring example: Two Neosensor (temperature/humidity sensors) powered by a single 24 V DC transformer
Notes for signal wiring
Induction current flowing from Neosensor (humidity sensor, temperature/humidity sensor models) to the controller input circuit
and inadequate time constant of the controller might generate noise. To prevent noise, see the following.
•Use a controller with low pass filter (40 dB or higher removal ratio in normal mode) that receives signals from Neosensor.
•For insufficient removal ratio, provide an isolator on the controller input wiring.
Note:
No problem will occur for connecting Neosensor to our controller.
IMPORTANT:
•When Neosensor is faulty, reduced output may cause over-humidification. Provide safety measure against
over-humidification.
•Corrosive gas or organic solvent contained in the air may cause sensing error, shorten the service life, or
damage the Neosensor. Before using Neosensor in abnormal atmosphere, consult with our salesperson.
Though common wiring forms a loop, common mode noise affects a little.
24 V DC
Temperature/humidity sensor
Tem
p
erature/humidit
y
senso
r
Controller
+
-
Good wiring
+
-
+
∼
⊥
-
∼
+
-
+
-
⊥

AB-7050
19
Inspection and Maintenance
Since Neosensor is factory-inspected and -calibrated for high accuracy, no field calibration is necessary when Neosensor is
installed. For inspection and maintenance, follow the instructions below.
Periodic inspection
Periodically inspect Neosensor for its measuring accuracy, and clean the cover. Set the period between inspections based on
how much atmospheric dust and other contaminants are contained in the installation environment.
If Neosensor is installed in an animal holding room or a hospital operating room, cover Neosensor when the room is sterilized.
Troubleshoot
If any problem occurs during operation, refer to the table below for appropriate solutions.
Troubleshooting
Problems Check points Solutions
Loose wiring
Disconnected wiring
Re-perform wiring.
Power supply voltage
●No output
●Unstable output
Neosensor main unit damages Replace the Neosensor.
Slow response to output Moisture/condensation on Neosensor 1. Remove the cover.
2. Disconnect the power.
3. Air-dry the Neosensor in a clean air.
Installation location Refer to Installation section.
Clean the cover.
Calibrate.
Error in output
Dust and contamination on the Neosensor
main unit
Replace the Neosensor.
Calibration
Neosensor is factory-calibrated and does not require field calibration right after installation. However, field-calibrate Neosensor
if a shift in the output due to aged deterioration is found.
For a humidity output error, calibrate the Neosensor with adjustment knobs on the board inside the main unit. Follow the below
instructions for calibration.
●Two adjustment knobs (VR1 for fine adjustment and VR2 for rough adjustment) are provided.
Turn clockwise to increase the output value and counterclockwise to decrease the output value.
Note that the measuring accuracy specified hereinbefore will not be assured after field-calibration with the adjustment
knobs.
●Carefully field-calibrate Neosensor so that the heat on your hands do not affect the Neosensor.
Do not allow the heat generated from human body and/or appliances to affect Neosensor while calibrating.
●Use a reliable calibration instrument for field calibration.
●Carefully handle the product and check the appropriate environment for field-calibration.
●Calibrated digital multimeter is recommended to check output value.
Notes:
* Temperature output cannot be calibrated.
* Ask our salesperson if a shift in the output of new Neosensor is found.
Figure 25. Location of the adjustment knobs VR1 and VR2 on the board: Models HTY7043T series and HY7043T series
Fine adjustment knob (VR1)
Temperature sensing element
Rough adjustment knob (VR2)
Humidity sensing element

AB-7050
FP3 is a trademark of Azbil Corporation in Japan or in other countries.
Specifications are subject to change without notice.
Building Systems Company
http://www.azbil.com/
Rev. 2.0 Sep. 2015 AB-7050
(J: AI-7050 Rev. 3.2) Printed in Japan.
20
