Azpen DockAll D 108 User manual

D108
Fast Wireless Charging Sound Hub
Azpen Innovation
www.azpenpc.com

Volume Down
Volume Up
Previous
Track
Next
Track
Microphone
Qi
Charging
light
Play/Pause
Phone Speaker

Power
Button
USB 1 AMP
Micro SD Port
Speaker
USB 2 AMPS
Power
Port
Bass Port
Bass Port

GettingStarted
Power the Dockall:
First, plug in the included power adapter into the DC Power Port located on the back
of the docking station. Then, plug the power adapter into a wall socket. Next, turn the
DockAll on by pressing the Power Button located on the back. To power off, simply press
the Power Button or unplug the power adapter. It is recommended to power off the
Dockall when not in use.
Wireless Charging:
Wireless charging is available for smartphones or devices equipped with a built-in Qi
Wireless Charging Receiver or devices enabled through the addition of a third-party Qi
Wireless Charging Receiver. Ensure your device is compatible by reviewing the manufactures
user manual or website. Devices without a Qi Wireless Charging Receiver or receivers other
than Qi wireless are not compatible. To charge, place your device vertical on
the center of the stand. When positioned correctly, your device will begin to charge
within 1-2 seconds. Using your device as it charges is not a problem; however it could
reduce the time in which to complete the charge considering the process is at a reduced
rate compared to typical wire charging.
Wired Charging:
The Dockall has two USB ports which differ in charging power. USB1A(1 AMP) is
recommended for charging smaller devices like Smartphones or Mp3 players. USB2A(2 AMPS)
is best suited for charging larger items like tablets or laptops. However, either port is capable
of charging a device; regardless of its size; the difference would be the time in which to
complete the charge could vary depending on the device and/or USB port used. To wire
charge, simply connect your USB cable to your device then insert the other end to the
appropriate USB port located on the back of The DockAll. Then place your device on
The DockAll or to the side to complete the charging process. The DockAll is capable of
charging 3 devices simultaneously.
Micro SD Card Slot:
The DockAll’s equipped with an SD Card slot located on the back to allow you to listen
to music or audio files from a Micro SD card(up to 64GB). To use, simply insert the card into the
slot until you feel it “click” into place, the music or files will begin to play once inserted and
locked. You can control the Volume, Music, Media selections, Play, or Pause by pressing the
appropriate buttons on the front panel. To remove the Micro SD card, push the card in to unlock
and release. Micro SD cards are not included with the DockAll but can be purchased separately
at most retailers.

Bluetooth:
To use the Bluetoothe feature, the rst step is to pair your device to the DockAll. The Micro SD card
takes priority over bluetooth so make sure the card is disengaged or unlocked prior to pairing.
By default, the DockAll is in Bluetooth mode when rst powered on. Start by turning on the Bluetooth
function on your smartphone, tablet or laptop device. Your device should automatically start searching
for Bluetooth devices (if not, press “SEARCH” on your device). Once “Dock ALL”appears on
your device screen select “connect” and wait 3-5 seconds to complete the Bluetooth pairing process, no
password or code required. A rapid “ringing” sound means your device is out of range or the signal has
dropped. Once your device is paired and connected, you can control the volume, tracks, play, or pause
from the DockAll’s front panel or from your device. Additionally, if using a smartphone you’re now set to
make phone calls through the Speakers and Microphone.
The Qi charging light bar will illuminate during the wireless charging process. As your devices charges,
the light will turn on when a Qi wireless device Is placed on the dock and remain on even when your
device Is fully charged. The light will turn off when your device is removed from the dock.
Qi Charging Light:

12V DC power adapter (5'ft.) included
Product Details: D108
Processor:
CW6687E
Wireless Charging:
Supports Fast Charging Technology (15 watts: 9V/1.6A)
Wired Charging:
Supports Full Size USB Cables,2 USB Ports
2 USB Ports:
Memory:
Audio:
Buttons:
Power Supply:
Features:
USB1A: 1 AMP for Smartphones, Mp3 Players.
USB2A: 2 AMP’S for Tablets, Laptops or Battery packs.
Either port can be used to charge a device but are best utilized as
described above.
Micro SD Card Slot supports cards up to 64GB (card not included).
2 X 5 Watt Speakers
Capacitive Touch
Two Built-in Bluetooth Speakers
Qi Wirelesss Charging Light
Bluetooth 4.1
Speakerphone (Microphone)
Volume/Music Track Control
Slip Resistant Pads
Supports compatible smartphones and tablets up to 13 inches

LimitedWarranty-DockallDockingStation
What the warranty covers:
Azpen offers a limited manufacturer warranty from defects in material and workmanship through
normal use during the warranty period. If a product proves to be defective in material or workmanship
during the warranty period, Azpen will at its sole option, repair or replace the product with a new or
similar product. Replacement product may include re-manufactured, refurbished, rebuilt parts or
components. The replacement unit will be covered by the balance of the time remaining on the
customer’s original limited warranty. Warranty service can only be performed by Azpens’ authorized
service center. Shipping coss of the product to the service center and liability are the responsibility of
the purchaser. In the case of Fraud or Misrepresentation, Azpen reserves the right to deny all warranty
coverage or claims.
How long the warranty is effective:
Azpen products are warranted for one (1) year,(365 days) for parts and labor and begin on the original
date of purchase. Reconditioned, Refurbished or Re-manufactured products are warranted for ninety
(90) days for parts and labor. Out-of-warranty service fees may apply.
Who the warranty protects:
This warranty shall not extend to anyone other than the original purchaser of this product, and is
nontransferable. The original dated bill of sale or receipt must be provided as proof of purchase.
Warranty does not cover damage, deterioration or malfunction resulting from:
Damage which occurs in shipment; delivery and installation; applications and uses for which this
product was not intended; altered product; cosmetic damage or exterior finish; accidents, abuse,
normal wear and tear, neglect, fire, water, lightning or other acts of nature.
Incorrect electrical line voltage, fluctuations and surges; customer adjustments and failure to
follow operating instructions.
Use of products, equipment, services, parts, supplies, accessories, applications, modifications,
installations, repairs, external wiring or connectors not supplied or authorized bu Azpen.
Limitation of Liability:
In no event, under any cause of action or theory of liability, shall Azpen, its affiliates, distributors or
suppliers be liable for any indirect, incidental, consequential or punitive damages, of any nature
whatsoever, arising out of the use of or inability to use any Azpen product(s), including without
limitation, property damage, loss of value of product(s) that are used in or with Azpen product(s).You
agree and understand, Azpen has no liability for any damage, loss of data or destruction to consumer
electronics devices or other personal property including, without limitation, cellular phones, tablets,
laptops, or other handheld devices. Regardless of the legal theory on which a claim is based, shall limit
the recovery of any kind against Azpen not to be greater in amount than the purchased price of the
product if any. There are no express warranties other than those listed and described above.
