Aztec Beam Sharpy 200 Operator's manual
USER INSTRUCTION
MANUAL
Unpacking: Thank you for purchasing the
AZTEC BEAM SHARPY 200
Watt by AZTECELECTRONIC®. Every AZTEC BEAM SHARPY 200 Watt
has been thoroughly tested and has been shipped in perfect operating
condition. Carefully check the ship
ping carton for damage that may have
occurred during shipping. If the carton appears to be damaged, carefully
inspect your fixture for any damage and be sure all accessories necessary to
operate the unit has arrived intact. In the case damage has been foun
d or
parts are missing, please contact our toll free customer support number for
further instructions. Do not return this unit to your dealer without first
contacting customer support.
Introduction: The AZTEC BEAM SHARPY 200 Watt
is part of
AZTEC
-ELECTRONIC’’s conti
nuing pursuit for creating high quality
affordable intelligent fixtures. The Beam Sharpy 200
is a DMX intelligent
Moving Head Beam Effects Lights. This Beam Sharpy 200
is light weight and
compact which makes it a gre
at piece for mobile DJ’s, clubs, theater, stage
and many other applications. The Beam 200 Sharpy
has 4 operating modes;
sound-active, auto mode, Manual
mode, or controlled via DMX controller. It
can be used as a stand alone unit or in a master-slave configuration.
Customer Support: AZTEC-ELECTRONICS
provides a toll free customer
support line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may also visit
us on the web at www.aztec-
electronics.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to 5:00
p.m. Pacific Standard Time. E-mail:
support@aztec-electronic.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do not
expose this unit to rain or moisture.
Caution!
Ther
e are no user serviceable parts inside this unit. Do not attempt
any repairs yourself, doing so will void your manufactures warranty. In the
unlikely event your unit may require service please contact AZTEC
-
ELECTRONIC DEALER / DISTRIBUTOR.
PLEASE recycle the shipping carton when ever possible.
Bulb Replacement / Gobo Adjustment
Figure 16.
Periodical Cleaning
Periodical cleaning - Fig. 16
To ensure optimal operation and performance for a long time it is essential to periodically clean the parts
subject to dust and grease deposits. The frequency with which the following operations are to be carried
out depends on various factors, such as the amount of the effects and the quality of the working
environment (air humidity, presence of dust, salinity, etc.).
Use a soft cloth dampened with any detergent liquid for cleaning glass to remove the dirt from the
reflectors and filters.
t is recommended that the projector undergoes an annual service by a qualified technician for special
maintenance involving at least the following operations:
• General cleaning of internal parts.
• Restoring lubrication of all parts subject to friction, using lubricants specifically supplied by AZTEC.
• General visual check of the internal components, cabling, mechanical parts, etc.
• Electrical, photometric and functional checks; eventual repairs.
IMPORTANT: Grasp the modules using the support structure and not the details which could get
damaged.
Insertion of the effect modules: Repeat the operations indicated in Fig. 17
and 18 in reverse order.
Technical parameters:
Lamp Optional Model..
Channel mode: 16
，
or 20CH
Level scanning: 540 °(16bit precision scan) electronic error correction
Vertical scanning: 250 °(16bit precision scan) electronic error correction
Color Wheel: 14 colors with white, with rotating rainbow effect.
Gobo Wheel: 17 gobos with rotating gradually change effect and pattern swing effect.
Shut: up to 13 times per second with automatic pulse effect.
Dimmer: 0-100% linear dimmer
Focus: 5 meters to infinity
Prism: 3 or 8 can be choosed
Frost: 0% - 100% linear frost
Control table reset function.
Control table switch bubble function (Switch on or off bulb can choose when with power.
light half-power function
Power supply: AC110V-240V, 50 / 60HZ,
The light body size: 360X410X500
WT:20KG
Signal connection:
The connection of lights and the connection of light and controller must used two core shielding wire with its
diameter not less than 0.5 mm. We should pay special attention that the connection of three core of XLR plugs
and socket cannot contact with inner shell and between core and core also cannot contact.
When use XLR-XLR control line, connect the DMX outlet of controller with the DMX input of the first machine,
and connect the DMX outlet of the first machine with DMX input the second machine. Repeating the process until
all machines connected. At last connect the loop plug with the last lamp’s signal output the connection of
controller mode is completed.
This menu of control display board specifically designs for the various types of moving light equipped with
various function control mode, operate easy. For some operation that some type of light without it is invalid
corresponding menu options setting.
Menu Operation of Moving Head Light:
There are several features are offered in the base of control panel. Such as setting the DMX address, switch
on or off the bulb, run the program and the selection of work mode.
Menu operation:
It provides various functions on the base of the control panel. Such as setting DMX address, switch the bulb, test
program running, work mode selection and so on
DMX
ADDRESS 1--512
PARAMRTER
BACK
CONTROL
STANDARD
EXTENDED
SIMPLFY
MODELS
B200
OPTION
BACK
X REVERES No
Yes
Y REVERES No
Yes
XY OPTOCOUPLER No
Yes
LAMP CONTROL close
open
LAMP ON-OFF close
open
TURN SHORTEST No
Yes
COLOUR HALF No
Yes
BISPLAY
BACK
LANGUAGE English
中文
MAIN
CONTROL
BACK
CH1 0-255
CH2 0-255
----------
CH32
0-255
CH2 0-255
----------
TEST
OPERATION
BACK
SOUND
AUTO
RESUME
BEFAULT
BACK
ENTRE
RESET BACK
ENTER
DMX512 (16/20 Channel)
No DMX Value Feature
1
Color wheel Color wheel
0~6
：
White→7~13
：
Color 1→14~20
：
Color
2→21~27
：
Color 3→28~34
：
Color 4→35~41
：
Color
5→42~48
：
Color 6→49~55
：
Color 7→56~62
：
Color
8→63~69
：
Color 9→70~76
：
Color 10→77~83
：
Color
11→84~90
：
Color 12→91~97
：
Color 13→98~104
：
Color 14→105~110
：
halftone 1→111~116
：
halftone
2→117~122
：
halftone 3→123~128
：
halftone
4→129~134
：
halftone 5→135~140
：
halftone
6→141~146
：
halftone 7→147~152
：
halftone
8→153~158
：
halftone 9→159~164
：
halftone
10→165~170
：
halftone 11→171~176
：
halftone
12→177~182
：
halftone 13→183~188
：
halftone
14→189~191
：
White
；
192~223
：
Color wheel
anti-clockwise rotaion,from fast to slow ,rainbow
effect .224~255
：
Color wheel clockwise rotation,from
slow to fast,rainbow effect.
2
STOP/STROBE STOP
/STROBE
0~2 No function.3~7 Open.8~127 Strobe,from slow
to fast.128~251 Random strobe,from slow to
fast.252~255Open
3
Dimmer Dimmer
0~255 Prism Rotation
4
STATIC GOBO
CHANGE
STATIC
GOBO
CHANGE
0~4
：
White→5~9
：
Gobo 2→10~14
：
Gobo 3→15~19
：
Gobo 4→20~24
：
Gobo 5→25~29
：
Gobo 6→30~34
：
Gobo 7→35~39
：
Gobo 8→40~44
：
Gobo 9→45~49
：
Gobo 10→50~54
：
Gobo 11→55~59
：
Gobo
12→60~64
：
Gobo 13→65~69
：
Gobo 14→70~74
：
Gobo 15→75~79
：
Gobo 16→80~84
：
Gobo
17→85~89
：
from Gobo 17 to White shaking in turn
；
192~223
：
Gobo wheel anticlockwise rotation,from
fast to slow, flow effect
；
224~255
：
Gobo wheel
clockwise rotation,from fast to slow, flow effect
；
5
Prism INSERTION
Prism
INSERTION
0~255Prism
6
Prism Rotation Prism Rotation
0~95 anticlockwise rotation,from fast to slow
160~255 clockwise rotation,from slow to fast
7
EFFECTS
MOVEMENT
EFFECTS
MOVEMENT
EFFECTS MOVEMENT
8
FROST FROST
０－１２７
no frost
１２８－２５５
frost
9
FOCUS FOCUS
０－２５５
line focus
10
Pan Pan
0~255 pan movement
D X STRUCTURE
11
Fine pan
movement
Fine pan
movement
0~255 16-bit pan movement
12
Tilt Tilt
0~255tilt movement
13
Fine Tilt
movement
Fine Tilt
movement
0~255 16-bit tilt movement
14
FUNCTION FUNCTION
15
RESET RESET
16
LAMP CONTROL
(with Option
"Lamp Dmx" ON)
LAMP
CONTROL
(with Option
"Lamp Dmx"
ON)
60-62 Control table close bulb
255 Control table open bulb
17
PAN - TILT
TIME
Speed from fast to slow
18
COLOUR
TIME
Speed from fast to slow
19
BEAM TIME
Speed from fast to slow
20
GOBO TIME
Speed from fast to slow
D X STRUCTURE
(Cont.)
