B-I-C America DV32CLR User manual

© B.I.C America
Owne ’s Manual
Frequency
Response
75Hz - 20kHz
Characteristic
Sensitivity
90dB @
1 watt, 1 meter
Nominal
Impedance
8 ohms
Recommended
Amplifier Po er
5 - 125 watts
Dimensions
103/4˝ W
43/4˝ H
6˝ D
Shipping
eight
4 lbs.
Specifications
Model DV32CLR
TM
Certified BEST VALUE Performance
B.I.C America
925 N. Shepard Street
Anaheim, CA 92806
www. icamerica.com
For tech support call 1-877-558-4242 (4BIC)
B.I.C Speaker Systems are designed to the highest possible value and performance standards. Our confidence in
their quality is such that B.I.C America offers customers this transferable seven-year limited warranty:
B.I.C Speaker Systems Seven-Year Limited Warranty
If the B.I.C speaker system proves to be defective
in materials or workmanship within seven years
from the date of the original customer’s purchase,
we will, at our option, repair or replace the
defective product.
DISCLAIMER
THE WARRANTY STATED HEREIN IS IN LIEU
OF ALL OTHER WARRANTIES, EXPRESS OR
I PLIED, INCLUDING ERCHANTABILITY AND
FITNESS FOR PARTICULAR PURPOSE AND
ALL OTHER LIABILITIES AND OBLIGATIONS OF
B.I.C A ERICA, ALL OF WHICH ARE EXPRESSLY
DISCLAI ED. B.I.C A ERICA HAS NOT ADE
AND DOES NOT HEREBY AKE ANY OTHER
REPRESENTATION, WARRANTY OR COV-
ENANT WITH RESPECT TO THE CONDITION,
QUALITY, DURABILITY, DESIGN, OPERATION,
CAPACITY, FITNESS FOR USE OR SUITABILITY
OF THE B.I.C SPEAKER SYSTE S.
Exclusion of Certain Damages
B.I.C America’s liability for any defective product
is limited to repair or replacement of the product
at our option. B.I.C America shall not be liable for
incidental or consequential damages of any kind
or character because of product defects.
Some states do not allow limitations on implied
warranties and/or do not allow the exclusion or
limitation of incidental or consequential damages, so
the above limitations and exclusions may not apply.
This Warranty Does Not Cover:
Damage caused by abuse, accident, misuse,
negligence, or improper operation.
Products that have been altered or modified.
Any product whose serial number has been
altered, defaced, or removed.
Normal wear and maintenance.
Damages caused by shipping. (All claims for
shipping damage must be made with the carrier.)
Warranty Service
Warranty service must be performed by an
authorized service center, usually a B.I.C speaker
systems dealer or its authorized agent. You may
obtain a list of authorized service centers by writing
to the address below.
All warranty repairs must be accompanied by the
original bill of sales. No other document is
acceptable or is required.
This warranty gives you specific legal rights, and
you may also have other rights which vary from
state to state.
Due to our continual efforts to improve product
quality as new technology and techniques become
available, B.I.C America reserves the right to revise
Speaker Systems specifications without notice.
TM
Certified BEST VALUE Performance

Unpacking
Carefully remove your new DV32CLR speaker
from the box. Inspect the speakers for transit
damage. If you discover damage, contact your
dealer immediately.
Save your carton – it is the best possible
protection for your speakers should you ever
have a need to move them.
The Optimum Listening Position
Refer to figure 1 for 5.1 surround speaker
placement. The DV32CLR center channel
speaker should be placed as close to the TV as
possible, preferably directly above or below the
TV. The front channel speakers should be placed
at least 6 feet apart (TV/monitor center) to create
proper stereo imaging. The rear channel surround
speakers should be positioned behind and slightly
to the sides of the viewer/listener. It may take
some experimentation with different locations for
the surround speakers to suit your preference
and your room.
Hooking Up You DV32CLR Speake s
STOP! – ake sure that you consult your
amplifier’s owner’s manual regarding speaker
hook-up. Your amplifier should be turned off
throughout this procedure.
A word about speaker wire – There are a number
of quality speaker wire products available today.
ost of these products offer obvious sonic
benefits over lamp cord and light gauge wires.
The choice of speaker wire is dependent on the
type of amplifier, the distance you intend to run
the wire, and your budget, among other things. If
in doubt as to which brand or type of wire and
connector to use, consult your audio dealer.
ost speaker wire is polarity coded. This means
that each conductor is labeled either (+) positive
or (-) negative. The (+) positive side may be a
different color or texture than the (-) negative side.
On the back of your amplifier, each channel is
probably labeled (+) and (-) as well as color coded
red for (+) positive and black for (-) negative.
B.I.C speaker terminals are color coded red for
(+) positive and black for (-) negative. Be sure to
hook (+) to (+), (red to red), and (-) to (-), (black to
black). (See Figure 2.)
All connections should be tight and close fitting.
Inspect connections for frays and stray strands
of wire touching both (+) and (-) terminals.
(This will cause a short and, perhaps, damage
your equipment.)
Ca ing fo You Speake s
The DV32CLR speaker can be cleaned with a damp
soft cloth. The metal grille can be cleaned with the
same cloth, or if needed, a small hand vacuum.
T oubleshooting and Se vice
Your DV32CLR speaker does not use external
fuse protection or circuit breakers because
these devices tend to impede sound quality
and may only protect the speaker to a marginal
degree. Rather, we use components and designs
of the highest caliber as an effective method of
protecting the speaker. However, no amount of
protection will prevent damage caused by defec-
tive associated equipment or extreme abuse.
If you have a problem, first try to determine if it is
indeed a speaker problem. Determine whether
the problem exists in two speakers when hooked
to the same channel. If it does, the problem
likely originates in some other component in the
system. If the problem is in one speaker only,
reverse your speaker leads (left to right, right to
left) to make sure the speaker is not out of
phase. If the speaker was out of phase, switch-
ing the wires should solve the problem.
If you have determined that you have a speaker
problem, contact your dealer for authorized
factory service information. If you are unable to
contact your dealer, if your dealer is unable to
solve your problem, or if you have any questions
or comments regarding your B.I.C Speaker
System, please contact us at:
B.I.C America
925 N. Shepard Street
Anaheim, CA 92806
www. icamerica.com
For tech support call
1-877-558-4242 (4BIC)
Please describe the problem in detail. We will
decide on the most appropriate course of action.
Correct In-phase Hook-up
Amplifier
Speaker
Figure 2
Figure 1
