b-intense SW10032 User manual

b-intense Standalone
•Montageanleitung
•Assembly instructions
•Montagehandleiding
•Notice de montage
•Istruzioni di montaggio
230 Volt
INFRAROTKABINEN
Infrarotliege
Montageanleitung
Assembly instructions
Montagehandleiding
Notice de montage
Istruzioni di montaggio
www.b-intense.at
© b-intense®
Version 08/2022 Made in Austria

2
b-intense®Infrarotliege
b-intense Standalone
2
BI10___LUL
BI10___MKL
BI09___TA

3
b-intense®Infrarotliege
A1 3 x 16
4 x
A57 Ø16
4 x
A5 5 x 20
5 x
A36 Ø18
4 x
A19 M8
7 x
A37 Ø25
4 x
A20 M10
2 x
A67 400 x 100
1 x
A8 8 x 45
4 x
A68 Ø=60mm
2 x
A10 10 x 80
2 x
A44 Torx 10
1 x
A11 6 x 25
15 x
A45 Torx 20
1 x
A34
1 x
b-intense Standalone
3

4
b-intense®Infrarotliege
44
b-intense Standalone
4
BI10___MKL
b-intense Standalone
4
BI10___MKL
Schutzfolie
abziehen.
Remove
protecve foil.
Bedienteil
Steuerung/
control unit
BI10___MKR/L

5
b-intense®Infrarotliege
55
b-intense Standalone
5
A67 1 x
A68 2 x
A5 5 x
BI10___LUL
b-intense Standalone
5
A67 1 x
A68 2 x
A5 5 x
BI10___LUL

6
b-intense®Infrarotliege
66
b-intense Standalone
6
A37 4 x
A10 2 x
A20 2 x
A36 4 x
+
b-intense Standalone
6
A37 4 x
A10 2 x
A20 2 x
A36 4 x
+

7
b-intense®Infrarotliege
77
b-intense Standalone
7
A8 4 x
A19 4 x
A57 4 x
+
A19 1 x
A34 1 x
+
b-intense Standalone
7
A8 4 x
A19 4 x
A57 4 x
+
A19 1 x
A34 1 x
+

8
b-intense®Infrarotliege
88
b-intense Standalone
8
BI09___TA
BI09___TA
1 x
Lehne / back rest
b-intense Standalone
8
BI09___TA
BI09___TA
1 x
Sitz / seat

9
b-intense®Infrarotliege
99
b-intense Standalone
9
A11 5 x
+
A11 2 x
+
b-intense Standalone
9
A11 5 x
+
A11 2 x
+

10
b-intense®Infrarotliege
1010
b-intense Standalone
10
A11 4 x
+
b-intense Standalone
10
A11 4 x
+

11
b-intense®Infrarotliege
1111
b-intense Standalone
11
„Klick“
„Klick“
b-intense Standalone
11
„Klick“
„Klick“
1 x
Rückenstrahler
back heater

12
b-intense®Infrarotliege
1212
b-intense Standalone
12
A11 4 x
+
b-intense Standalone
12
A11 4 x
+

13
b-intense®Infrarotliege
1313
b-intense Standalone
13

14
b-intense®Infrarotliege
1414
b-intense Standalone
14
A19 2 x
+
A19 1 x
+
b-intense Standalone
14
A19 2 x
+
A19 1 x
+

15
b-intense®Infrarotliege
1515
b-intense Standalone
15
A1 4 x
+
Steuerung /
Control unit
b-intense Standalone
15
A1 4 x
+
b-intense Standalone
15
A1 4 x
+
b-intense Standalone
15
A1 4 x
+
b-intense Standalone
15
A1 4 x
+
b-intense Standalone
15
A1 4 x
+

16
b-intense®Infrarotliege
1616
b-intense Standalone
16

17
b-intense®Infrarotliege
T1
T2
LINKE Seite
LEFT Side
RECHTE Seite
RIGHT Side
BACK 1
BACK 2 IR-Strahler / Heater
IR-Strahler / Heater
Power Supply
115/230VAC 60/50Hz
nicht belegt not conected
nicht belegt not conected
nicht belegt not conected

18
b-intense®Infrarotliege
1818
b-intense Standalone
17
b-intense Standalone
17
