B-K lighting DEMI User manual

LED CATENARY CABLE MOUNT
DEMI WITH INTEGRAL DRIVER
CY-TR-DM
Demi Fixture
Canopy to Clamp
to Aircraft Cable
Splice
Compartment
RELEASE DATE
12/06/2022
REFERENCE NUMBER
INS-2813-00
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF B-K LIGHTING, INC. AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR
SELL ANYTHING IT MAY DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF B-K LIGHTING, INC. IS STRICTLY FORBIDDEN.
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION
INSTRUCTIONS
Hot Surface
High VoltageWarning
Standard Instructions
DEMI
CATENARY INTEGRAL - LED
· Suitable for wet locations
IMPORTANT LISTINGS AND CERTIFICATIONS
• Product must be installed by a qualified person in a manner
consistent with its intended use and in compliance with the
National Electrical Code, Canadian Electrical Code, and all
Local and Provincial Codes.
• Follow product label information and instructions.
• Qualified Personnel must perform all servicing or relamping
of this product.
• Before wiring to power supply and during servicing or
relamping, turn off power at fuse or circuit breaker before
service.
• The use of accessory equipment not recommended by the
manufacturer or installed contrary to instructions may cause
an unsafe condition. The use of damaged components may
cause an unsafe condition and void product warranty.
• Do not block light emanating from product in whole or part,
as this may cause an unsafe condition.
• Never operate the fixture with missing or damaged lens.
Lens must be cleaned on regular basis.
• Entire fixture may become extremely hot. Do not touch hot
lens or fixture body. Do not touch the lamp at any time. Use
a clean, dry, soft cloth to handle the lamp. Oil from skin
may damage the lamp and cause it to rupture.
• Replace lamp only with correct wattage and type of lamp
marked on fixture label.
• All gaskets, o-rings and sealing surfaces must be kept
clean during installation and service; failure to do this may
cause an unsafe condition and void product warranty.
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE ALL
SAFETY AND INSTALLATION INSTRUCTIONS
INSTRUCTIONS PERTAINING TO
A RISK OF FIRE, OR INJURY
TO PERSONS IMPORTANT SAFETY
INSTRUCTIONS
Lighted fixture is HOT!
WARNING - To reduce the risk of
FIRE OR INJURY TO PERSONS:
Turn off/unplug and allow to cool before
replacing lamp/LED. Fixture gets HOT quickly!
Contact only switch/plug when turning on.
Do not touch hot lens, guard, or enclosure.
Keep fixture away from materials that may burn.
Do not operate the luminaire fitting with a missing or
damaged shield. Do not touch the source at any time.
Use a soft cloth or gloves. Oil from skin may cause
damage.
SAVE THESE INSTRUCTIONS
TOOLS
NEEDED:
1/8”, 9/64” & 5/64” Allen Wrench
1/4” O.D. Aircraft Cable
Waterproof Wire Connectors (Supplied)

4. Bring branch circuit wiring with ROUND
jacketed line voltage cable to splice
compartment. (.236” min to .472” max. dia.,
cable not included)
Cut cable at 45 degree angle. Push through
Break-Thru Plug to insert cable.
NOTE: ROUND jacketed line voltage cable
must be used. (.236” min to .472” max. dia.,
cable not included)
1. Using a 1/8” allen wrench back out two (2)
10#-24 cap screws from clamp to separate.
3. Install clamp to splice compartment to 1/4”
O.D. aircraft cable (supplied not included) with
two (2) #10-24 cap screws using a 1/8” allen
wrench.
2. Use a 5/64” allen wrench to separate splice
compartment and fixture body.
5. Pull back cable gently to form a tight seal.
For Supplemental Wire Clamp Instructions,
please see next page.
7. Place connections inside splice compartment.
Attach fixture body to splice compartment.
Tighten #8-32 stainless steel set screws with
a 5/64” allen wrench.
NOTE: Do not over-tighten set screws.
RELEASE DATE
12/06/2022
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
REFERENCE NUMBER
INS-2873-00
Standard Instructions
DEMI
CATENARY INTEGRAL - LED
WIRING DIAGRAM
6. Pull branch circuit wiring. Make watertight
connections from branch circuit wiring to
fixture leads using waterproof wire connectors
(included) in splice location as per NEC.
UL Listed splice location required. Connect
incoming green ground wire to ground wire
from fixture. See wiring diagram.
All line voltage connections must be made
in compliance with the National Electrical
Code. Failure to do so will void warranty.
HOT (BLACK)
GROUND (GREEN) GROUND FIXTURE
NEUTRAL
HOT
NEUTRAL (WHITE)
WIRING DIAGRAM - Dimming 0/10
HOT (BLACK)
GROUND (GREEN) GROUND
FIXTURE
NEUTRAL
HOT
NEUTRAL (WHITE)
DIM + DIM +
DIM -
DIM -
