B-K lighting MINI-MICRO User manual

RELEASED
1-25-16
REFERENCE NUMBER
INS000927
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF B-K LIGHTING, INC. AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR SELL ANYTHING IT MAY
DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF B-K LIGHTING, INC. IS STRICTLY FORBIDDEN.
5/32” Allen Wrench
Waterproof Wire Connectors
NEEDED
FOR
INSTALLATION:
By Others
MINI-MICRO™ FLOODLIGHT
Solid State LED
Standard Installation
MM - Mini-Micro™ Floodlight
Locking ‘O’ Ring Compression
Knuckle (L.O.C.K.™)
1/2” NPS Threaded Nipple
Locknut (Retaining Ring)
For non-threaded mounting options
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION INSTRUCTIONS
• Product must be installed by a qualified person in a manner
consistent with its intended use and in compliance with the
National Electrical Code, Canadian Electrical Code, and all Local
and Provincial Codes.
• Followproductlabelinformationandinstructions.
• QualifiedPersonnel mustperform allservicing orrelamping of
this product.
• Beforewiringtopowersupplyandduringservicingorrelamping,
turnoffpoweratfuseorcircuitbreakerbeforeservice.
• The use of accessory equipment not recommended by the
manufacturer or installed contrary to instructions may cause an
unsafe condition. The use of damaged components may cause
an unsafe condition and void product warranty.
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE ALL SAFETY
AND INSTALLATION INSTRUCTIONS
• Donotblocklightemanatingfromproductinwholeorpart,
as this may cause an unsafe condition.
• Never operate the fixture with missing or damaged lens.
Lensmustbecleanedonregularbasis.
• Entire fixture may become extremely hot. Do not touch hot
lensorfixturebody.Donottouchthelampatanytime.Use
a clean, dry, soft cloth to handle the lamp. Oil from skin may
damage the lamp and cause it to rupture.
• Replace lamp only with correct wattage and type of lamp
markedonfixturelabel.
• All gaskets, o-rings and sealing surfaces must be kept clean
during installation and service; failure to do this may cause an
unsafe condition and void product warranty.
INSTRUCTIONS PERTAINING TO
A RISK OF FIRE, OR INJURY TO
PERSONS IMPORTANT SAFETY
INSTRUCTIONS
Lighted lamp is HOT!
WARNING - To reduce the risk of FIRE OR INJURY TO PERSONS:
Turnoff/unplugandallowtocoolbeforereplacinglamp.
LampgetsHOTquickly!Contactonlyswitch/plugwhen
turning on.
Do not touch hot lens, guard, or enclosure (see diagram/
picture).
Keeplampawayfrommaterialsthatmayburn.
Do no touch the lamp at any time. Use a soft cloth. Oil
from skin may damage lamp.
Do not operate the luminaire fitting with a missing or
damaged shield.
SAVE THESE INSTRUCTIONS
· Suitable for wet locations · Additionally suitable for mounting within 4 ft. of the ground
IMPORTANT LISTINGS AND CERTIFICATIONS
Warning Low Voltage Hot Surface
Please refer to the low voltage
designguideatwww.bklighting.
com/lvguidebeforeinstallationfor
proper wire selection.

MINI-MICRO™ FLOODLIGHT
Solid State LED
Standard Installation
RELEASED
1-25-16
REFERENCE NUMBER
INS000927
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF B-K LIGHTING, INC. AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR SELL ANYTHING
IT MAY DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF B-K LIGHTING, INC. IS STRICTLY FORBIDDEN.
PROJECT:
TYPE:
1. Mount knuckle onto suitable enclosure
according to designed lighting plan.
2. Secure ½” NPS stem to mounting option. Secure
withprovidedlocknutifapplicable.
3. Make watertight connections from remote
transformer to LED source leads using
waterproof wire connectors (By Others). See
wiring diagram.
Fixture Installation with Standard Knuckle
4. Use 5/32” Allen wrench to slightly loosen #10-
32 stainless steel black oxide socket head cap
screw at the knuckle for aiming purposes.
Tighten to secure desired location.
LINE 12V
Fixture
COM
Remote
Transformer
COM
WIRING DIAGRAM
LED - For use with 12VAC
remote transformer or magnetic
transformers only. B-K Lighting cannot
guarantee performance with third party
manufacturers’ transformers.

RELEASED
1-31-14
REFERENCE NUMBER
INS-2097-00
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF B-K LIGHTING, INC. AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR SELL ANYTHING IT MAY
DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF B-K LIGHTING, INC. IS STRICTLY FORBIDDEN.
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION INSTRUCTIONS
Warning Hot Surface
TOOLS
NEEDED:
By Others
5/32” & 5/64” Allen wrench
360SL™ Knuckle Mounting System
Standard Adjustment
• Product must be installed by a qualified person in a manner
consistent with its intended use and in compliance with the
National Electrical Code, Canadian Electrical Code, and all Local
and Provincial Codes.
• Follow product label information and instructions.
• Qualified Personnel must perform all servicing or relamping of
this product.
• Before wiring to power supply and during servicing or relamping,
turn off power at fuse or circuit breaker before service.
• The use of accessory equipment not recommended by the
manufacturer or installed contrary to instructions may cause an
unsafe condition. The use of damaged components may cause
an unsafe condition and void product warranty.
IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE ALL SAFETY
AND INSTALLATION INSTRUCTIONS
• Do not block light emanating from product in whole or part,
as this may cause an unsafe condition.
• Never operate the fixture with missing or damaged lens.
Lens must be cleaned on regular basis.
• Entire fixture may become extremely hot. Do not touch hot
lens or fixture body. Do not touch the lamp at any time. Use
a clean, dry, soft cloth to handle the lamp. Oil from skin may
damage the lamp and cause it to rupture.
• Replace lamp only with correct wattage and type of lamp
marked on fixture label.
• All gaskets, O-rings and sealing surfaces must be kept clean
during installation and service; failure to do this may cause an
unsafe condition and void product warranty.
INSTRUCTIONS PERTAINING TO
A RISK OF FIRE, OR INJURY TO
PERSONS IMPORTANT SAFETY
INSTRUCTIONS
Lighted lamp is HOT!
WARNING - To reduce the risk of FIRE OR INJURY TO PERSONS:
Turn off/unplug and allow to cool before replacing lamp.
Lamp gets HOT quickly! Contact only switch/plug when
turning on.
Do not touch hot lens, guard, or enclosure (see diagram/
picture).
Keep lamp away from materials that may burn.
Do no touch the lamp at any time. Use a soft cloth. Oil
from skin may damage lamp.
Do not operate the luminaire fitting with a missing or
damaged shield.
SAVE THESE INSTRUCTIONS
· Suitable for wet locations · Additionally suitable for mounting within 4 ft. of the ground
IMPORTANT LISTINGS AND CERTIFICATIONS
360SL™ Knuckle Mounting System
2. Rotate fixture at base and aim fixture to desired
horizontal location.
3. Use 5/32” Allen wrench to loosen #10-32 stainless
steel black oxide socket head cap screw at the
knuckle for vertical aiming purpose.
1. Use 5/64” Allen wrench to slightly loosen two (2)
#8-32 stainless steel set screws on the stem for 360°
aiming purpose.
4. Tighten two (2) #8-32 stainless steel set screws on
stem to secure horizontal aiming position.
Tighten #10-32 stainless steel black oxide socket
head cap screw to 15” minimum to 30” maximum
pounds to secure vertical aiming position.
Warning: Do not over tighten set screw. Doing
so will compromise O-ring seal and will void
warranty.

RELEASED
10-31-13
REFERENCE NUMBER
INS000003
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX [phone]
www.bklighting.com • [email protected]
B-K LIGHTING
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF B-K LIGHTING, INC. AND ITS RECEIPT OR POSSESSION DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR SELL ANYTHING
IT MAY DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF B-K LIGHTING, INC. IS STRICTLY FORBIDDEN.
PROJECT:
TYPE:
LED BOARD, DRIVER AND OPTICS - MINI-MICRO
Replacement / Installation Instructions
RE-PLACING LED BOARD, DRIVER AND OPTICS
1. Use 5/64” Allen wrench to loosen #8-32
stainless steel set screw and remove cap.
4. Reverse install LED board and driver by
carefully wrapping 18 gauge wires around
driver and inserting into fixture body. Secure
LED board in place with stainless steel set
screws.
5. Use small flat head screw driver to remove lens
from optic holder on the LED. Snap new optic
in place. Replace cap on fixture and tighten set
screw.
3. Disengage LED board and driver assembly.
Replace with new board and driver assembly.
2. Use .050” Allen wrench to loosen two (2) #4-40
stainless steel set screws below LED board on
the heat sink. Gently pull up on LED board and
Driver assembly to expose quick disconnect.
