BüRGE Ion Dome User manual

A Product
Ion Dome
An Ionizer for CleanAir
A Product

A Product
Ion Dome
A Product
We are BüRGE
Brief Intro of BüRGE

A Product
Ion Dome
Our Vision
Our Mission
Vision
Mission

A Product
Ion Dome
BüRGE ’s
Innovative Technology
About BüRGE Innovation

BüRGE Ionizer Generates Ions
Generates ions
found innature
usingElectronic
circuit &fine
electrodes.
The ionsform OH
radicals and
withdrawsH
(Hydrogen) from
surface proteinof
microorganisms,
breaking them
down
Effectively
neutralizes
viruses and
bacteria and
fungi
No Ozone
Generation&
Naturally
cleanstheair
Generateswater
as aby-product

A Product
Ion Dome
High
Voltage AC
generator
Needle Tip
Electrode
Needle Tip
Electrode
H+
O-
BLDC Fan
to blow out
ions
O-
virus
H+ O-
virus
-OH
H+
O-
H2O
virus
Ion Dome is an Enclosed High Voltage ION
generator. It generates Millions of ions (H+, 0-)
like nature by breaking water molecules in air.
These ions get attracted /attached to suspended
impurities/microorganisms in the room, like
Viruses, Bacteria, Fungi and Neutralizes them
while generating water molecules as a
byproduct.
H+

A Product
Ion Dome
Features of Ion Dome :
A Product
•Removes impurities / microorganisms in the room, like Viruses, Bacteria, Fungi and Neutralizes them while generating molecules as a by
product
•Decrease odor and smoke
•Bring Freshness in the Air
•99.9% Clean Air
•Suitable for : Bedroom, Office, Store, Clinic
•Auto Shut off with Timer function (3 hours)
•Simple start with single push button
•Power on indication
•No ozone generation
•Available in Two Different Colors

A Product
Ion Dome
Product Specification :
Model Number IONGNR008002 IONGNR008003
Filter Type
Ionizer (High Voltage Negative Ion generator)
Power Supply 100-264VAC, 50-60Hz (AC –DC Adaptor)
CLEAN AIR Fan Speed (CFM
)
51.5 75
Rated Power (W)10W 10W
Recommended Room Size
(Air circulation) 150 sq ft. (Bedroom) 200 sq. ft. (Living Room)
Operating Temperature 0˚C to 45˚C
Humidity 40% to 75%
Cord Length (mm) 1830
Negative Ion Count 10 Million
Dimensions [L*B*H] (mm) 95*135*130
Weight (gm) 800
Warranty 1Year
Removes Impurities/ microorganisms in the room ,like Viruses, Bacteria, Fungi and Neutralizes them
while generating molecules as a by product

A Product
Ion Dome
Storage
•When necessary wipe the surface of the appliance with a soft dry cloth (in OFF condition.)
•For storage :-
•Turn off the appliance and unplug from the power socket.
•Clean the appliance (Please refer above points.)Let it dry thoroughly before storing. Store the appliance in a cool, dry location.
•Ion Dome is an Enclosed High Voltage ION generator. It generates Millions of ions (H+, 0-) like nature by breaking water molecules
in air.
•These ions get attract / attached to suspended impurities / microorganism in the room , like viruses , Bacteria, Fungi and Neutralizes
them while generating watermolecules as a byproduct
Ion Dome

A Product
Ion Dome
OPERATION GUIDELINES :
•Plug in adapter (12V) to connector jack and the mains plug.
•Turn on mains switch.
•The LED light on unit will blink and fan will turn ON;it means the unit is ‘Powered ON’ and working.
•Once device is powered ON it will run for 3 Hrs.
•If LED is continuously glowing press the push button for 1 sec to turn ON device.
•In high humidity condition ionizer can generate the spark noise which has different from fan sound
INSTALLATION GUIDELINE :
•When using the unit place at least 2 meters away from equipment utilizing electric waves such as television or radios to avoid electrical
interference.
•Avoid use in locations where furniture fabrics or other item may come in contact with and restrict the air intake and/or air outlet.
•Avoid use in locations where the unit is exposed to condensation or drastic temperature changes appropriate conditions are when room
temperature is between 5°C - 35°C.
•Avoid the location where grease or oily smoke is generated.
•Place unit 2to 3feet above ground on stable surface for sufficient air circulation and 1 feet away from wall.

A Product
Ion Dome
Front View Side View
ON/OFF
Push Button
LED
Indication
Input Jack
Product Overview :

A Product
Ion Dome
Do’s :
•Read the user manual carefully before using appliance and save it for future reference.
•Use appliance for household under normal operating conditions.
•Always turn off appliance before moving or cleaning of appliance.
•Only use original Burge power adapter specially intended for this appliance.
•If power cord is damaged, you must replace it by Burge and stop the use of appliance until problem is solved.
Don'ts :
•Don’t sit or stand on appliance or place anything on top of the appliance.
•Don’t insert your fingers or foreign objects into the air outlet / inlet to prevent physical injury or malfunction of appliance.
•Don’t use this appliance when you have used indoor smoke-type insect repellents or in place with oily residues, burning incense or
chemical fumes.
•Don’t use the appliance near gas appliances, heating device or fireplaces.
•Don’t use appliance in wet surroundings or in surroundings, High humid and water dripping area.
•Don’t clean the appliance with water, any other detergent to avoid electric shock and/or fire hazard.
•Never use abrasive, aggressive or flammable cleaning agents such as bleach or alcohol to clean any part of the appliance.

A Product
Ion Dome
Φ x 174
Test
parameters Initial Log /pfu Exposure Duration in hour After exposure Log /pfu Percent Reduction (%)
Φ x 174 (Virus) 3.868 (7380
pfu)
1 3.255 (1800 pfu) 75.6
2 3.151 (1415 pfu) 80.8
3 3.117 (1309 pfu) 82.2
MS2 Phage
Test
parameters Initial Log /pfu Exposure Duration in hour After exposure Log /pfu Percent Reduction (%)
MS 2
(Virus)
3.851
(7100
pfu)
1 3.194 (1564 pfu) 77.9
2 3.089 (1230 pfu) 82.6
3 2.778 (601 pfu) 91.5
Formaldehyde
Test
parameters Initial Level mg/ m3 Exposure Duration in hour
After exposure
Formaldehyde
Level mg/ m3
Percent
Reduction (%)
Formaldehyde 0.32 1 0.189 40.9 2 0.183 42.8
3 0.175 45.3
Third Party Test Results :

A Product
Ion Dome
Product Test Parameters Initial level
ppm
Exposure
Duration in
hours After Exposure
DC
Ionizer Model:
IONGNR00 8 0003 Ozone Generation
<0.5pp m
(Below
detectabl e
limit)
01 <0.5ppm
02 <0.5ppm
03 <0.5ppm
Product Test
Parameter Initial Log/cfu
Exposure
Duration In
hour
After
Exposure
Log/cfu
Log
Reduction
after
exposure to
Test Material
Percent
Reduction
(%)
DC ionizer
Model :
IONGNR008
003
A. Niger 4.919
(83000 cfu)
01
4.342 (22000
cfu) 0.58 73.4
02 3.845
(7000 cfu) 1.07 91.5
03 3.255
(1800 cfu) 1.66 97.8

A Product
Ion Dome
Test conducted at Bio care Research India Pvt Ltd
Sr. No. Time (min) SARS-CoV-2
E Gene S Gene
Ct Value Delta Ct %Reduction
in Viral Load Ct Value Delta Ct %Reduction in Viral Load
1 0 23 - - 21 - -
210 24 1 - 22 1 -
315 27 310 25 310
430 32 560 30 560
560 ND - 99.99 ND - 99.99

A Product
Ion Dome
Contact Us
•Plot No.AL-18,AL-19 MIDC, Shendra SEZArea, Aurangabad, MH431001, India
•[phone]
•[e-mail]
