baby exo Smart Formula Maker User manual
www.babyexo.com
www.babyexo.com
1. Please read this manual carefully before you start to use it
2. This manual cation important information don’t lost it.
Control panel
Removable funnel
Removable powder box
Removable water tank
ON/OFF
Adjustable tray
02
Product
Powder capacity 300g Voltage 110V
Water capacity 1800ml Frequency 60Hz
Weight 2.75KG
Size 180×300×370mm
Working power 550W
Standby power 5W
Baby EXO Formula Maker
Specifications
Removable
water tank
Body
Powder cover
Powder turnable
Stator
Powder feeding carousel
Milk powder box
Water tank cover
Upper part of the funnel
Lower part of the funnel
Adjustment tray
Water tray
Boiler cover
03 04
Install the powder feeding carousel
2
1
3
Installation the powder mixing turntabl.
4
When installing, the milk powder
box must be aligned with the rails
on the main unit.
When installing the stator, align the
red arrow of the stator with the red
arrow in the box.
1.Pay attention to the buckle of the lid and the
powder box, screw it clockwise
2.Put on the water tank
1.Intall the boiler cover
Install the boiler cover. After installation,
firmly press down on the boiler cover.
Install the water tank. Secure the water
tank in the card slot of the machine to
stabilize the water tank.
0605
1.combine the upper and lower parts first 2.mixing chamber is docked with the
fuselage
0707
08
When the water level warning light is on, there is no water in
the boiler. Please confirm whether the water tank is short of
water; it will light up briefly after making milk each time.
When the bottle warning light is on, it means that the bottle
is not placed well. Please confirm that the bottle is placed
well and then make milk
When the powder box warning light is on during use, it
means that the powder box or the powder cover is not
installed. Please check and continue to use.
When the funnel warning light is on during use, please check
if the mixing chamber is in place.
When the temperature warning light is on during use, the
water temperature in the boiler is higher than the set milking
temperature. Please wait for the temperature to cool down.
When the motor warning light is on, please send it to the
repair.
Milking indicator
High temperature
Cleaning indicator
Warm water drinking
indicator
Milking water temperature Water volume
Water level warning light
Milk bottle warning light
Powder box warning light
Funnel warning light
Motor warning light
Temperature warning light
Warning light description
Milking indicator
The machine defaults brewing milk mode,and the milking indicator light flashs means
the water is heating. Click the button to adjust the amount of water, and the
number on the right is the current amount. When the milking indicator light is on, press
START to brew milk.
The machine is equipped with a bottle sensor
to prevent the milk from being accidentally
touched after the milk is flushed. If the
secondary brewing is required, the bottle must
be removed before re-positioning and the
machine can be started
NOTE
1009
Warm water drinking indicator
Temperature indicator
Press the MENU button to switch to the warm water drinking mode. The warm water
drinking indicator lights up to indicate successful switching of the warm water drinking
mode. In the warm water drinking mode, the warm water drinking indicator flashes to
indicate that the water is heating.Click the button to adjust the amount of water,
and the number on the right is the current amount. When the water indicator light is on,
press START come out warm water. click the menu button to return to the milking mode.
Press the menu button twice to the temperature adjustment function. When the
temperature indicator flashes, it indicates that the temperature adjustment mode has
been successfully entered. Click the button to adjust the temperature and display
the number as the set temperature. click the menu button to return to the milking mode.
Press the MENU button four time to the formula setting function(C2 Mode).Set the
formula concentration according to your formula powder.This numerical value means the
powder weight/1oz(or 30ml)water.Click the button to adjust the formula concen-
tration and display the number as the set formula concentration.
Please check<How to make the first bottle of your baby formula> for more detail.
Press and hold the MENU button for three seconds to enter the high temperature clean-
ing mode. The high temperature cleaning indicator lights up to enter the high tempera-
ture cleaning mode. The temperature indicator appears 176℉, the water level indicator is
7.0oz, and the high temperature cleaning indicator flashes to indicate that it is heating.
The temperature and water volume are fixed and cannot be adjusted. When the high
temperature cleaning indicator light is on, it means the heating is completed. Click start
to clean. Please do not stay in this mode for a long time.
11 12
2
1
3
Please clean and dry the following parts before use.
（Warning: powder box, lunch box cover, water tank, water tank
cover, adjustment tray, water tray prohibit steam sterilization of high
temperature water boiler to prevent deformation. Please use
122-158℉ warm water for cleaning and disinfection, dry and use.）
Pour milk powder into the powder box (300G
recommended, no more than 400G) and close
the powder cover
pour pure or cold water into the water tank, do
not exceed the maximum value, do not pour
the tap water directly for the baby's health
High temperature cleaning
1413
Adjust the tray to the right height White light is on
4
5
Press the menu button ,set the water
,concentration as you want and the
temperature to 113℉
Turn on the switch, wait until the milk
indicator light is on, indicating that the
heating is complete, you can use
Clean the funnel(clean every day) Clean the Powder box
Attention:
place the bottle on the tray. When the milking machine senses the
bottle, the body will light up in white. Then the bottle warning light
of the display goes out, indicating that it is correctly placed.
Please remove the funnel for cleaning
after it is no longer used within 2 hours.
Please remove and clean the powder box
every time after using all the powder in
the box
Note: When removing the powder box,
please press the fuselage with both hands
and pull it out.
1.Add the water to the tank,add the powder into the powder box and turn on the
machine.
3.Check the formula information on the package.
For example.
Note: As it’s the first use,it may take a few minutes for the water get to setting temperature.
2.Press the menu button and set the water as you want and the temperature to 113℉
This formula shows you need mix 8.7g powder with 2 fl oz water which means
8.7/2=4.35g powder in 1 fl oz water.
So you just need to set the C2 value to 4.4g or 4.3g.(don’t worry about
0.05g deviation,it will not effect your baby’s health ).
4.After you setting the formula concentration.Just press the Start button.
POWDER C2
=
WATER
1. Do not use the power supply or power cord if it is damaged or the plug is loose.
It may cause fire, electric shock or personal injury.If the power cord is damaged, in
order to avoid danger, it must be replaced by the manufacturer's maintenance
department or a similar department.
2. Use only under 110V AC power supply, otherwise it may cause electric shock, fire
and performance abnormality.
3. Please insert the power supply correctly, otherwise it may cause personal injury
such as fire and electric shock.
4. Prohibit excessive bending, bundling, dragging, or pressing the power cord with
heavy objects, and rushing the power cord close to the high temperature and fire
source.If the power cord is caught in the crack or the power cord is changed by
yourself, the power cord may be damaged, resulting in electric shock or fire.
5. It is forbidden to modify, disassemble or repair it by yourself. It is forbidden to
insert foreign objects such as fingers and iron sheets into the gap of the precursor.It
is easy to cause fire, electric shock, personal injury, malfunction and other accidents.
Please call the after-sales service hotline for A/S and inspection of the product.
1. Please read the instructions carefully before use.
2. This instruction manual contains important information and should not be
discarded.
3. Please read the following warnings and safety instructions carefully.
4. After the finished milk powder, confirm the proper temperature and give it to your
baby.
15 16
17
10. Do not insert spoons, chopsticks, etc. at the milking mouth. Do not move the
machine or disassemble or assemble parts during operation.Personal injury or
machine malfunction.
9. For safety reasons, be sure to use it after connecting it to a grounded outlet.
Otherwise, it may become an electric shock, fire, malfunction or explosion.
The cause of the accident.
11. Keep the product away from where children can touch.
12. Do not clean the machine's unremovable parts
13. Please comfirm the temperature before you give it to your baby.
2.Do not subject the unit to sharp temperature changes or high humidity.
3.Remove and dry the water tank if you do not plan to use the machine for a long
time (over 30 days)
1.The Preparing Machine for Baby Formula should be transported at an ambient
temperature of +41°F to +86°F and maximum relevant humidity of no more than
75%.
6. Do not plug or unplug the power supply directly with wet hands, which may cause
electric shock or personal injury.
7. Do not allow the body to get in or spray on the water to prevent foreign matter
and water from entering the ON/OFF button.
8. Do not touch the switch when the hand is wet, which may cause electric shock,
fire, etc.
18
When the display shows E05,it means the water tank is short of water.
Q1:The display shows «E05»
Q2.Excessive amount of milk powder
1.The lid of powder box have not closed
2.The powder box have not installed correctly
Q3.Short amount of milk powder
1.The powder box have not installed correctly
2.The powder box is short of formula powder
3.The rotor in the box stuck.
Q4.There is no formula came out when press the Start button
1.If the milking light is flashing,that means the water does not reach
the set temperature,please wait a few minutes.
2.The Warning lights turn on, please check the corresponding
warning light and operate.
3.The machine is equipped with a bottle sensor to prevent the milk
from being accidentally touched after the milk is flushed. If the
secondary brewing is required, the bottle must be removed before
re-positioning and the machine can be started.
Q5.The water output is not accurate enough
As there is a 5% error in the milk powder scale of the bottle, if you
think that the water output is too much or too little, please take the
electronic weighing result as the standard.
We will advice you clean the funnel everyday and clean the powder
box every time before you re-full it.
19 20
Q6.The cleaning of funnel and powder box
Q7:Why do you get more formula milk than you can see on the
display ?
The numerical value on the display is the amount of water.The excess
is the volume added after the milk powder is dissolved.
If you have any questions about our product,Please feel
check www.babyexo.com.Our customer service would
solve your problem in 24 hours.
