Tommee Tippee Holy Grail User manual

4m+ weaning 9m+ training 12m+ active
OUR NEW CUP RANGE IS INTERCHANGEABLE
No matter what handle, lid or cup you decide to use in our NEW range, everything will fit together.
Ensure the cut opens
by squeezing before use.
Lippee Cup
Straw Cup
Sippee Cup Sippee Cup
Active Sports Bottle
Straw Cup
SAFETY GUIDANCE
For your child’s safety and health.
WARNING!
• Always use this product with adult supervision. Accidents have occurred when babies have been left alone with drinking equipment due to the baby falling or if the
product has disassembled.
• Never use spouts or straws as a soother. Continuous and prolonged sucking of fluids will cause tooth decay. Tooth decay in young children can occur even when
non-sweetened fluids are used. This can occur if the baby is allowed to use the cup for long periods through the day and particularly through the night, when saliva
flow is reduced or if it is used as a soother.
• Always check food temperature before feeding.
• Always stir heated food to ensure even heat distribution and test temperature before serving.
• Keep all components not in use out of reach of children.
CLEANING AND STERILISATION
• Before first use, clean the product.
• Clean before each use.
• Always wash the product immediately after use.
• Wash in warm soapy water and rinse in clean water or use a dishwasher (top shelf only). Do not clean with solvents or harsh chemicals.
• Do not allow product to come into contact with oil based foods (e.g. oil/tomato based sauces) as staining will occur.
• Our insulated cups are suitable for sterilisation by cold water tablet/liquid solution only.
• All other cups are suitable for sterilisation by steam (electric and microwave), boiling or cold water tablet/liquid solution.
STORAGE AND USE
• Inspect before each use and pull the spout or straw in all directions.
• Throw away at the first signs of damage or weakness.
• Do not store or leave in direct sunlight or near a source of heat.
• Do not store with or allow to come into contact with solvents or harsh chemicals.
• Not suitable for use in a convectional oven or a combination microwave oven with the grill feature switched on.
• Not suitable for microwave use apart from sterilising. See cleaning and sterilisation instructions above.
• As with most sippy cups, ours are to be used with milk, water or juices that don’t contain pulp.
• DO NOT use with fizzy (carbonated) beverages, formula or hot liquids.
cups
valve, straw, lippee
INSTRUCTIONS FOR USE
roclosetnature®

24801020
INSTRUCTION FOR CLEANING LIPPEE CUPS
• Wash all parts thoroughly in
warm soapy water and rinse in
clear water
• All parts can be washed in the
dishwasher (top shelf only)
• Always shake parts after washing
to remove excess water and leave
to air dry before reassembling
2
1
3
CLEAN
You should thoroughly clean your valve after each use.
• Turn screw ring upside down
and place silicone disk inside
with grooves facing up
• Remove lid from cup base
• Grip lid and turn the locking
connector anti-clockwise
DISASSEMBLE REASSEMBLE
4
5
• Take the lid top and push down
through the hole in the silicone disk
• Align locking connector and turn
clockwise to lock
6
• Separate locking connector,
silicone disk, screw ring and lid top
• Place lid on base and align the 2
dots on the back - Remember:
Do not over tighten.
Alignment indicator
INSTRUCTIONS FOR CLEANING VALVE CUPS
You should thoroughly clean your valve after each use.
• Wash all parts thoroughly in
warm soapy water and rinse in
clear water
• All parts can be washed in the
dishwasher (top shelf only)
• Always shake parts after washing
to remove excess water and leave
to air dry before reassembling
• Un-screw the lid
• Pull out the valve
• Separate the 2 parts of
the valve (soft & hard)
WARNING
• Ensure parts Aand Bof the soft
side are pushed through the holes
of the hard side. Ensure the cut
B
opens by squeezing before use.
2 2
3
2
valve
1 4
5
6
DISASSEMBLE
CLEAN
REASSEMBLE
• Align the two parts
and press together
AS PER ILLUSTRATION
A
B
• Place the valve back in the lid, and
push until the sides lock into place
• Screw on lid
You should thoroughly clean your straw after each use.
INSTRUCTIONS FOR CLEANING STRAW CUPS
• Pull the straw downwards
and out from the lid
• Thread the straw back into
the trigger and clip the
trigger back into position.
CLEAN
REASSEMBLE
DISASSEMBLE
• Remove lid from cup base
• Pop up the straw by pressing
the trigger
• Remove the trigger from the lid
(wiggle left to right to release)
• Pull the trigger from the straw
• Pull straw up through lid
• Ensure silicone valve and straw
is clipped into place
1
2 5
63
4
Trigger
• Wash all parts thoroughly in
warm soapy water and rinse in
clear water
• All parts can be washed in the
dishwasher (top shelf only)
• Always shake parts after washing
to remove excess water and leave
to air dry before reassembling
tommeetippee.com.au
tommeetippee.co.nz
Mayborn ANZ Pty Ltd.
(ABN 66 154 703 134)
PO Box 475,
Mt Waverley VIC 3149
AUSTRALIA
Mayborn Group is a business name of Mayborn ANZ Pty Ltd.
Copyright © 2015 Jackel International Limited
Newborn Brands (NZ) Ltd.
PO Box 47-677
Ponsonby Auckland 1144
NEW ZEALAND
