Babymore Peanut User manual

Only suitable if the vehicle is fitted with -point static, 3-point
retractor safety belts, approved to UN/ECE Regulation No. 16 or other
equivalent standards.
Noce
1. This is a "Universal" child restraint; it is approved to ECE Regulation
44.04 for general use in vehicles and will fit most, but not all,vehicle
seats.
2. A correct fit is likely if the vehicle manufacturer has declared in the
vehicle handbook that the vehicle is capable of accepting a
"Universal" child restraint for this group.
3. This child restraint has been declared "Universal" under more
stringent conditions than those applied to earlier designs which do
not carry this notice.
4. If in doubt, consult either the child restraint manufacturer or the
retailer.
WARNING
DO NOT place rear-facing child seat on front seats with activatced
airbags.
Peanut Group 0+ Rear Facing Car Seat
USER MANUAL
Approved under ECER44/04
GROUP 0+ Suitable for newborn to 13kg
P44/V1/19 Babymore
Thank you for purchasing Babymore, If you need assistance.
Call: [phone] or email: [email protected]
www.babymore.co.uk

Contents
32
1.Applicability.............................................................................3
2.Safety instruction ...................................................................4
3.Parts and interior equipment..................................................5
4.General use..............................................................................6
4.1. Adjusting the carrying handle. .............................................6
5.Installation in ca ......................................................................7
6. Correct securing your baby.....................................................8
6.1.Setting the shoulder belt heig ............................................8
6.2.Adjust the shoulder straps.....................................................9
6.3.Securing the baby with the harness.....................................9
6.4.The use of buckle.................................................................10
7.Care and Maintenance..........................................................11
7.1.Remove the fabric cover.....................................................11
7.2. Cleaning of the fabric cover...............................................11
7.3.Care and Maintenance........................................................11
8.What to do after an accident ................................................11
NOTES
The following brief instructions are in ended to provide only an
overview. In order to achieve maximum security and comfort for your
child it is absolutely imperative that you read the whole instruction
manual carefully.
1. Applicability
The baby car seat is suitable for age Group 0+ (up to 13kg)
Group 0+: Newborn-13kg
DO NOT put the baby car seat on seats on which a front
airbag is activated
● Only suitable for vehicle seats with a three point automatic belt,
approved under ECE regulation no R.16 or equivalent standard
AIR BAG

54
2. Safety instruction
In order to achieve maximum security and comfort for your child,
please read the whole instruction manual carefully, to avoid any misuse
or carelessness use.
● Always keep this Instruction Manual with car seat
● Do not put this baby car seat on seats with activated airbags
● The baby car seat must be installed rearwards facing(the child’s feet
point towards to the backrest of the vehicle seat;
● This baby car seat can only be installed using a three-point vehicle
belt;
● Before every journey, always check the baby car seat is installed
correctly ;
● Do not or attempt to change any original components and accessory
parts;
● Always strap your baby into the car seat and never loose sign of
your baby;
● Do not leave your baby unattended in the vehicle
● Never use the baby car seat as a hopping bag or as a means for
transporting something
● Protect the child restraint system against direct sun light to prevent
high temperature from hurt;
● The child car seat must not be used without the cover;
● Ensure that all the parts are locked in place correctly;
● Luggage or other objects liable to cause injuries in the event of
collision shall be properly secured;
● The modifications or additions are not allowed to be made to thi
car seat without approval of brand owner. Repairs are only allowed to
be undertaken by persons who have been authorized to do so;
● Periodically inspect the restrict system, pay particular attention
the points of attachment, stitching and adjusting devic
● Do not continue to use the child car seat if parts have become
damaged or been loosened;
● The handle of the baby car seat must to be against the back of the
vehicle seat;
● The infant car seat must always be secured with the vehicle seat
even when not being used;
● Care has to be taken to only use an original this car seat cover
because the cover is also an essential functional component. Spar
covers can be obtained from your specialist retailer;
● The plastic parts of the infant car seat heat up in the sun. Your baby
can suffer burns from this. Protect your baby and the infant car seat
from intense sun exposure(e.g by placing a light cloth cover the seat)
Handle
Canopy
Shoulder belt slot
Harness
Chest pad
Buckle
Comfort pad
Harness release Butto
Harness belt strap
Shell
Button of handl
Lap belt guide
3.Parts and interior equipment.
Diagonal belt guide
Shoulder belt slot

76
Fig.1 Fig.2 Fig.3 Fig.4
4.General Use
4.1.Adjusting the carrying handl
● You can lock the carrying handle into 4
positions.
● To adjust the carrying handle, please
simultaneously press the red button on both
sides.
● Then rotate the carrying handle until it
automatically locks in the place in the desired
position
Fig. 1: Vehicle and carrying position, Place the infant car seat facing the
rear of the vehicle on the vehicle seat (the child’s feet point towards to
the backrest of the vehicle seat).
Fig .2:Straight up for carrying.
Fig.3:Handle clicked back to initiate the rocking feature
Fig.4:Handel clicked down for upright sitting position, for putting
inside.
● Always strap your child in with the integrated belt system and make
sure the handle is locked in right position
Fig.2
Fig.3
Click
Fig.1
5.Installation in ca
● Please read the instruction manuals in order to protect all passengers
● Do not put this infant car seat on a seat with activated front airbag
● The infant car seat can be suitable for vehicle seats with a three point
automatic belt
● The infant baby car seat must be installed rearward facing( the child’s
feet point towards to the backrest of the vehicle seat).
Step 1. Ensure the carrying handle in the
forward position(Fig.1)
Step 2.Put the infant car seat in vehicle’s
seat(Fig.2), put the infant car seat against
the backrest of the vehicle seat.
Step 3.Slide the lap belt of the vehicle’s
3-point seat belt through both lap belt
guides.Let the tongue plate snap in the
belt lock with a clearly audible“click”.Pull
the shoulder belt in narrow direction to
tighten the lap belt.Check to make sure
the tongue plate is locked by pulling on
the belt(Fig.3).
Step 4.Place the diagonal belt in the
diagonal belt guide at the back of the seat.
rotate the handle of the seat to the
appropriate place in the car.(Hearing
“click”) Be sure the handle has been
locked and it should be firmly against the
backrest of vechile’s seat.
Step 5.Tighten the vehicle’s own 3-point
seat belt by pulling hard on the positions
showed in fig.5.
Fig.4
Fig.5

98
Fig.6 Fig.7
● Attention:The handle of the seat must be firmly installed agains
the backrest of car seat.
● You can release the child if you act the above steps in reversal
ways.
● Make sure all the belts’ position is right and not been twisted.
Also check that the cover is not impeding the movement or fit of
the belt webbing in any way.
● The satisfactory position of the adult safety-belt buckle relative
to the child car seat is incorrect as the Fig 6. Fig.7 You can contact
the child car seat manufacturer if in doubt about this point.
-Too high
-Too low
6.Correct securing your baby
6.1.Setting the shoulder belt heig
Check whether the shoulder belts be at the right height for your
child. The should belts should be at shoulder height or just above.
6.2.Adjust the shoulder straps
If the height of your shoulder belts in infant car seat is not fit for
your child, adjust the height of the shoulder belts, please proceed
as follows:
Step 1:loosen the shoulder harness (see
point 6.2).
Step 2:Pull out the buckle tongues from the
chest pad and the slots on the cover and the
shell, then thread them into the
corresponding belt slots.
● Ensure that both of the shoulder belts go through slots at the
same height, and not twisted.
● The shoulder straps are slackened by
pressing the lever (under the seat cover) on
the front of the seat.
● Press down on the label marked“Press” as
you grip the two shoulder straps with your
other hand. Pull the shoulder straps towards
you to loosen it.
6.3.Securing the baby with the harness
1.Firstly, adjust the shoulder straps height (see point 6.1),proceed as
follows.
2.Loosen the harness(see point 6.2),open the buckle, and place them
down sideways. put your child in the child car seat. Place both
shoulder straps over your child’s shoulders.
3.Lock the buckle tightly
4.Ensure that the straps are close to the shoulder of the child by
pulling the straps tightly

1110
Fig.2Fig.1 Fig.3
● The harness should be adjusted as tightly as
possible without causing discomfort to your
child.
● It is dangerous not to tighten the straps. Check
the adjuster and be sure that the straps are
pulled tightly, not twisted after installati
everytime.
6.4.The use of buckle
1.Put the two metal sections of the buckle connectors together (fig.1)
2.Slot the two buckle connectors into the slot in the top of the buckle
until hearing “click”(fig.2)
3.Check the harness is correctly locked by pulling the shoulder straps
upwards (fig.3).
4.To release the harness, press the red button on the buckle
downwards. 30
P
7.Care and Maintenance
7.1.Remove the fabric cover
Step 1:First pull out the harness from the seat.
Step 2:Undo the press button on the handle, then remove the canopy
from backwards.
Step 3:Loosen the elastic, remove the fabric cover from upwards
● Follw the steps described above but in reverse order in order to
re-fasten the cover.
7.2 Cleaning of the fabric cover
Use only neutral detergent and warm water to wash the fabric
cover.Do not wash it by machine,spin-dry or tumble-dry are not
recommended.
THIS COVER SHOULD BE HAND WASH
7.3.Care and Maintenance
1.Please regularly check the function and spare parts of the baby car
seat are in good condition to provide the maxinum protectio
2.Before using, please check the locking fastness of the buckle by
pulling in effort the straps and see whether the buckle is loose or not.
3.Do not use the baby car seat in cold,wet or hot circumstance for a
long time
8.What to do after an acciden
Please change the seat without fail after an accident.
