Bacharach CO2 Analyzer 3150 Instruction Manual

CO2Analyzer Models 3100 & 3150
Operation & Maintenance
Instruction 0019-9339
Rev. 3 – May 2010

CO2 Analyzers 3100 & 3150
Instruction 19-9339 2
WARRANTY
Bacharach, Inc. warrants to Buyer that at the time of delivery this Product will be free from defects in
material and manufacture and will conform substantially to Bacharach Inc.’s applicable specifications.
Bacharach’s liability and Buyer’s remedy under this warranty are limited to the repair or replacement, at
Bacharach’s option, of this Product or parts thereof returned to Seller at the factory of manufacture and
shown to Bacharach Inc.’s reasonable satisfaction to have been defective; provided that written notice of
the defect shall have been given by Buyer to Bacharach Inc. within one (1) year after the date of delivery
of this Product by Bacharach, Inc.
Bacharach, Inc. warrants to Buyer that it will convey good title to this Product. Bacharach’s liability and
Buyer’s remedy under this warranty of title are limited to the removal of any title defects or, at the elec-
tion of Bacharach, to the replacement of this Product or parts thereof that are defective in title.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND ARE GIVEN AND ACCEPTED IN LIEU OF
(I) ANY AND ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITA-
TION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE: AND (II) ANY OBLIGATION, LIABILITY, RIGHT, CLAIM OR REMEDY IN CONTRACT OR
TORT, WHETHER OR NOT ARISING FROM BACHARACH’S NEGLIGENCE, ACTUAL OR IMPLIED.
The remedies of the Buyer shall be limited to those provided herein to the exclusion of any and all other
remedies including, without limitation incidental or consequential damages. No agreement varying or
extending the foregoing warranties, remedies or this limitation will be binding upon Bacharach, Inc. un-
less in writing, signed by a duly authorized officer of Bacharach.
Register Your Warranty by Visiting
www.mybacharach.com
Notice:
Product improvements and enhancements are continuous, therefore the specifications and information
contained in this document may change without notice.
Bacharach, Inc. shall not be liable for errors contained herein or for incidental or consequential damages
in connection with the furnishing, performance, or use of this material.
No part of this document may be photocopied, reproduced, or translated to another language without the
prior written consent of Bacharach, Inc.
Copyright © 2009, Bacharach, Inc., all rights reserved.
BACHARACH is a registered trademark of Bacharach, Inc. All other trademarks,
trade names, service marks and logos referenced herein belong to their respective companies.

CO2 Analyzers 3100 & 3150
Instruction 19-9339 3
NOTES:

CO2 Analyzers 3100 & 3150
Instruction 19-9339 4
1.0 Manual Guidelines......................................................................... 6
1.1 Safety Related Information...................................................... 6
1.2 Notes....................................................................................... 6
2.0 Introduction.................................................................................... 7
2.1 Features of the CO2Analyzer 3100/3150................................ 7
2.2 Instrument Components - Standard Product........................... 8
3.0 Optional Products and Accessories............................................ 9
3.1 Optional Products.................................................................... 9
3.1.1 PC Software (Optional)................................................ 9
3.1.1.1 Event Log......................................................... 9
3.1.2 Temperature Probe Reading (Optional)..................... 10
3.1.3 Humidity Probe Reading (Optional)........................... 10
4.0 Instrument Features.................................................................... 11
4.1 Physical Characteristics of the Instrument Panel...................11
4.2 Panel Key Functions ............................................................. 12
4.3 Instrument Connection Points ............................................... 13
5.0 General Operational Instructions............................................... 14
5.1 Switching the Instrument ON ................................................ 14
5.2 Switching the Instrument OFF............................................... 14
5.3 Instrument Main Read Screen .............................................. 15
5.4 Instrument Status Icons ........................................................ 16
5.5 Entering Data ........................................................................ 16
5.6 Changing Between Parameters ............................................ 17
5.7 Memory ................................................................................. 17
5.8 Storage.................................................................................. 17
5.9 Main Menu ............................................................................ 18
5.9.1 Information................................................................. 18
5.9.2 Utilities ....................................................................... 19
5.9.2.1 Time & Date ................................................... 19
5.9.2.2 Contrast ......................................................... 20
5.9.2.3 Alarms ............................................................ 21
5.9.2.4 Settings .......................................................... 22
5.9.2.5 Flow Fail......................................................... 22
5.9.2.6 Logging .......................................................... 25
5.9.2.7 Reset.............................................................. 26
5.9.3 Calibration ................................................................. 26
5.9.4 View Data .................................................................. 26
5.9.4.1 Clear Reading Memory .................................. 27
5.9.5 Diagnostics ................................................................ 28
5.10 Warning and Error Codes.................................................... 28
5.11 Battery / Charging................................................................ 28
6.0 Taking Readings..........................................................................30
6.1 Preliminary Checks - Best Practice....................................... 30
6.2 Gas Measurement Process - Best Practice .......................... 30
6.3 Alternative Reading Methods ................................................ 32

CO2 Analyzers 3100 & 3150
Instruction 19-9339 5
6.3.1 Logged Reading ........................................................ 32
6.3.2 Peak Reading ............................................................ 32
6.3.3 Hold Reading............................................................. 32
7.0 Calibration ................................................................................... 33
7.1 User Calibration .................................................................... 33
7.2 Calibration Gases.................................................................. 34
7.3 Calibration Set-Up................................................................. 34
7.4 Calibration Equipment........................................................... 35
7.5 Calibration Method ................................................................ 36
7.5.1 Zero CO2Channel ..................................................... 36
7.5.2 Span CO2Channel .................................................... 37
7.5.3 Zero O2Channel........................................................ 38
7.5.4 Span O2Channel....................................................... 38
7.5.5 Reset Factory Settings .............................................. 39
7.6 Last Field Calibration ............................................................ 39
7.7 Calibration Record ................................................................ 39
8.0 Problem Solving.......................................................................... 41
8.1 Warnings and Errors ............................................................. 41
8.2 Self-test Warning Messages ................................................. 42
8.3 User Calibration Trouble Shooting ........................................ 44
8.4 Cross-Gas Effects ................................................................. 44
8.5 Switching Off the Instrument ................................................. 44
9.0 Service.......................................................................................... 45
10.0 Warranty Policy .........................................................................46
11.0 Technical Specification............................................................. 47
12.0 Event Log................................................................................... 49
13.0 Emportant Notice to All Customers......................................... 50
14.0 Glossary of Terms..................................................................... 51
15.0 Replacement Parts.................................................................... 53
15.0 Service Centers ......................................................................... 54

CO2 Analyzers 3100 & 3150
Instruction 19-9339 6
1.0 Manual Guidelines
1.1 Safety and Related Information
Information in this manual that may affect the safety of the users and
others is preceeded by the following symbol:
WARNING
Failure to follow this information may result in physical injury which in
some cases could be fatal.
1.2 Notes
Important / useful information and instructions are shown clearly
throughout the manual in a note format.
For example:
NOTE: For further information, please contact your equipment
supplier.
NOTE: Actual screenshots will vary dependent on model.

CO2 Analyzers 3100 & 3150
Instruction 19-9339 7
2.0 Introduction
This manual explains how to use the instruments below:
• CO2Analyzer 3100 (0 - 20%)
• CO2P/N 19-7076
• CO2(with O2) P/N 19-7077
• CO2(with O2and Relative Humidity) P/N 19-7078
• CO2Analyzer 3150 (0 - 10,000 PPM)
• CO2P/N 19-7136
• CO2(with O2) P/N 19-7137
• CO2(with O2and Relative Humidity) P/N 19-7138
NOTE: The instrument is a sensitive piece of scientific equipment,
and should be treated as such.
The CO2analyzer is specifically designed to monitor CO2for the
verification of incubators in research and pharmaceutical markets.
This unit has been developed to incorporate the latest technology and
specification requirements, which provide the user with a fast, simple-
to-use and accurate piece of laboratory instrumentation.
2.1 Features of the CO2Analyzer
The analyzer has the following features:
• CO20 to 20% (3100)
• CO20 to 10,000 PPM (3150)
• Options for:
• O20 to 100%
• Dual Temperature probes 32 to 122°F (0 to 50 °C)
• Humidity Sensor 0 to 100%
• Improved accuracy on CO2readings
• Time saving dual temperature probes
• Large data storage and user friendly software and download
• Easy-to-read, large well-lit display
• Built-in gas moisture removal
Applications
• IVF/Medical • Research
• Laboratories • IAQ (Indoor Air Quality)
• Brewing • Atmosphere Control
• Incubators • Gas mixing

CO2 Analyzers 3100 & 3150
Instruction 19-9339 8
2.2 Instrument Components
The following items are included in the Analyzer Kit. Please check to
make sure all items have been included.
Analyzer (One of the following - refer to your model number):
CO2Analyzer 3100 0019-7076
CO2/ O2Analyzer 3100 0019-7077
CO2/ O2Analyzer 3100 w/RH 0019-7078
CO2Analyzer 3150 0019-7136
CO2/ O2Analyzer 3150 0019-7137
CO2/ O2Analyzer 3150 w/RH 0019-7138
Instruction Manual (on CD) 0019-9339
Battery Charger with adapters 0019-0610
Sample Tube Kit (includes sample filter and sample tube) 0019-0613
Quick Start Guide 0019-9338

CO2 Analyzers 3100 & 3150
Instruction 19-9339 9
3.0 CO2Analyzer Accessories
3.1 Optional Products
The CO2Analyzer has a number of optional products for purchase
which enhance the usability and enable further analysis of data and
reading information.
NOTE: For more information on the features listed in this section
please contact your nearest Bacharach Service Center.
3.1.1 PC Software (Optional)
The software enables the user to maximize the operation of the
incubator analyzer. Instrument readings and event log data may
be uploaded to a PC for further analysis and exported to other
applications such as MS Excel. It enables direct communication with
the unit, features a simple download facility and is fully compatible with
the latest Microsoft operating systems (32-bit only). A USB cable is
provided with the software.
3.1.1.1 Event Log
The instrument incorporates the ability to log significant events via
the “Event Log.” This can be used as an aid to monitoring the use of
the instrument. It can also be used as a diagnostic tool if there is a
problem with the instrument.
The event log can only be viewed via the optional software. It cannot
be viewed on the analyzer screen. Applicable events are stored in the
event log automatiaclly, meaning no user intervention is required.
The event log can hold approximately 270 events. If the log becomes
full then it begins to overwrite the older events. This can be identified
by the index field which starts from event number 1. The log is cleared
when the instrument is reset.
NOTE: Please refer to Section 12.0 Event Log of this operating
manual for further information.

CO2 Analyzers 3100 & 3150
Instruction 19-9339 10
3.1.2 Temperature Probe Reading (Optional)
The instrument has the ability to read and display two temperature
readings via optional temperature probes (P/N 0019-0611). When
a temperature probe is fitted to one of the temperature ports on the
top of the instrument, the display will automatically show the current
reading and a temperature probe icon will be displayed.
The display can also be changed to show a T1- T2calculation by
pressing the appropriate soft-key. The current mode of operation can
be identified by normal or inverse status of the soft-key, where inverse
indicates that the option is active.
NOTE: The T1- T2result is not stored as part of the reading.
The operator can also choose to display the reading in either
Centrigrade or Fahrenheit using the temperature option accessed from
the Settings Menu.

CO2 Analyzers 3100 & 3150
Instruction 19-9339 11
4.0 Instrument Features
4.1 Physical Characteristics
Front View Back View
Reference:
A = Main Read Screen
B = Soft-Keys
C = ON/OFF Key
D = Pump Key
E = Key 4 - Scroll LEFT
F = Key 8 - Scroll DOWN
G = Menu Key
H = Enter Key
I = Key 2 - Scroll UP
J = Key 6 - Scroll RIGHT
K = Moisture Removal Tube
L = Serial Number
M = Instrument Stand

CO2 Analyzers 3100 & 3150
Instruction 19-9339 12
4.2 Panel Key Functions
KEYS FUNCTION
A Main Read Screen Start and end screen when using the instrument.
B Soft Keys The function of the three “soft-keys” on the front of
the instrument panel are determined by menu op-
tions taken. Functions vary from screen to screen.
C ON/OFF Key Press the “ON/OFF” key briefly to switch the
instrument on and off.
D Pump Key Press the “Pump” key to start or stop the pump.
E Scroll LEFT Key Also “Key 4”. Enables the operator to scroll left to
display more information.
F Scroll DOWN Key Also “Key 8.” Enables the operator to scroll down
to display more information.
G Menu Key Press the “Menu” key to go to the MAIN MENU.
Enables the operator to pre-set values and set-
tings. Select options from the MAIN MENU to also
view data and readings stored or held.
H Enter Key The “Enter” key accepts/confirms choices made by
the operator to various functions and operations.
Also, required to confirm numeric data entry.
I Scroll UP Key Also “Key 2.” Press scroll up to view further infor-
mation on the instrument read screen.
J Scroll RIGHT Key Also “Key 6.” Press scroll right to view further
information on the instrument read screen.
K Moisture Removal Tube Removes the moisture from the sample gas.
L Serial Number Unique identification for the instrument. Verifica-
tion of the serial number will be required if Techni-
cal Support assistance is needed.
M Instrument Stand Instrument stand.
NOTE: Do NOT attempt to remove the cover off the back of the
analyzer which houses the moisture removal tube.
NOTE: Do NOT cover the moisture removal tube with your hand
when holding the analyzer to take readings.

CO2 Analyzers 3100 & 3150
Instruction 19-9339 13
4.3 Instrument Connections
Top View Side View
Refer-
ence Type Description
A Temperature 1 Temperature 1 connector measures differ-
ential temperature - incubator and ambient
temperatures.
B Temperature 2 Temperature 2 connector measures differ-
ential temperature - incubator and ambient
temperatures.
C Humidity Probe (Optional) Humidity probe attachment point.
D Gas Outlet Gas outlet port used to exhaust the gas.
E Gas Inlet Gas inlet point used to attach the sample
tube and filter in order to take the gas read-
ing.
F USB Port Used to connect the analyzer to a PC via a
USB cable to download data.
G Battery Charger Port Used to attach the mains charger to the
analyzer for charging.
NOTE: Depending on the configuration purchased, certain connectors
may not be present. Reference you model number for this
information.

CO2 Analyzers 3100 & 3150
Instruction 19-9339 14
5.0 General Operational Instructions
5.1 Switching the Instrument ON
1) To switch on the instrument, press the “ON/OFF” key briefly. There
will be a short beep and a slight pause followed by the Bacharach
logo.
2) The power on self-test will then commence (approximately 60
seconds).
3) If there are no warnings to display the instrument will continue to
the MAIN READ SCREEN.
5.2 Switching the Instrument OFF
1) Purge the analyzer with fresh air. Run the pump for approximately
30 seconds or until the readings have returned to normal levels.
NOTE: Before the instrument is switched off, a clean air purge should
be performed. This ensures that the instrument is free from
gas and ready for the next measurement. This final purge is
especially important for the oxygen sensor as it may degrade
if stored when contaminated with gas.
2) To switch off the instrument, press the “ON/OFF” key briefly.
NOTE: If the “AUTO OFF” setting is set to “YES”, the analyzer will
switch off automatically after 10 minutes if not in use.

CO2 Analyzers 3100 & 3150
Instruction 19-9339 15
5.3 Instrument Main Read Screen
After the analyzer has been switched on and the warm-up self-tests
have completed, the analyzer will display the “MAIN READ SCREEN.”
Soft-Keys:
Peak - Enables the operator to display the peak reading.
Store - Enables the operator to store the reading for viewing/download
later.
Hold - Enables the operator to hold the current reading being taken.
CO2Analyzer 3100 w/ O2 shown

CO2 Analyzers 3100 & 3150
Instruction 19-9339 16
5.4 Instrument Status Icons
The following icons may be displayed on the instrument read screens:
Icon Description
Battery Charge State
(flashing) < 1 Hour Remaining
(flashing) Battery Charging
Charged
Pump Running
(flashing) Pump Stalled
Alarm Set
(flashing) Alarm Active
USB Connected to PC (flickers when transferring data)
Logging Mode Active (flashes when memory nearly full)
Temperature Probe(s) Connected
Humidity Probe Connected
(flashing) Service Due (every 12 months)
Service Overdue
Fault / Repair (i.e. O2cell, battery, or pump may need replacing)
Waiting
5.5 Entering Data
During normal operation the user may be prompted to enter data or
information via the keypad, i.e. entering an ID code or setting an alarm
level.
When entering data into the instrument, all fields are fixed format and
are populated from the right. For example, to enter the new time,
09:25:00, the user would type in 092500 using the numeric keypad in
the following sequence:
• : : 0
• : :09
• : 0:92
• :09:25
• 0:92:50
• 09:25:00
Press the “ENTER” key to confirm/accept the data.
(fl
a
s

CO2 Analyzers 3100 & 3150
Instruction 19-9339 17
The soft-key “DELETE” will delete the last character typed.
Alternatively, the sequence can be re-typed before the “ENTER” key
is pressed and the existing numbers will be replaced by the new
sequence.
NOTE: The instrument will not allow invalid data to be entered; this
should be deleted and re-entered.
5.6 Changing Between Parameters
By default, the instrument displays the MAIN READ SCREEN (for gas
measurement). This shows the CO2reading along with the optional
readings (O2, %RH, etc). The instrument will return to this screen after
power on or when returning from the menus. The “SCROLL” keys can
be used to switch to another measurement screen, i.e. temperature or
humidity. Continue to press the “SCROLL” key to return to the MAIN
READ SCREEN.
5.7 Memory
The memory SHOULD NOT be used as a permanent storage medium
and any important data should be transferred to a more permanent
storage medium as soon as possible. The instrument should not be
stored for prolonged periods with valuable data in its memory.
5.8 Storage
When not in use, the instrument should be kept in a clean, dry, and
warm environment such as an office. It should be stored flat in order
to help prolong the life of the O2cell.

CO2 Analyzers 3100 & 3150
Instruction 19-9339 18
5.9 Main Menu
The “MAIN MENU” enables the operator to select options to set up
specific parameters and perform operational tasks prior to sample
readings being taken or to view data/information stored in the
instrument.
1) Press the “MENU” key on the front of the instrument panel and the
following screen will be displayed:
2) Press the soft-key “EXIT” to exit the MAIN MENU.
5.9.1 Information
The “INFORMATION” option enables the operator to display
information such as instrument type, serial number, current software
version, service due date, and the dates of the last factory and user
calibrations. Note that the dates are in DD/MM/YY format.
1) From the “MAIN READ SCREEN” press the “MENU” key on the
instrument panel.
2) Press “KEY 1” to display general information about the instrument.

CO2 Analyzers 3100 & 3150
Instruction 19-9339 19
5.9.2 Utilities
The “UTILITIES” option enables the operator to configure the
instrument settings prior to taking readings.
1) From the “MAIN READ SCREEN” press the “MENU” key on the
instrument panel.
2) Press “KEY 2” to display the “UTILITIES” menu and the following
screen will be displayed:
5.9.2.1 Time & Date
The “TIME AND DATE” option enables the operator to check or set the
instrument’s internal clock. The current time/date will appear on every
stored reading.
1) From the “MAIN READ SCREEN” press the “MENU” key on the
instrument panel.
2) Press “KEY 2” to display the “UTILITIES” menu.
3) Press “KEY 1 - TIME & DATE” and the “SET TIME & DATE” menu
is displayed as follows:

CO2 Analyzers 3100 & 3150
Instruction 19-9339 20
4) Press “KEY 1” to change the time or press “KEY 2” to change the
date. Type the time or date using the numeric keypad followed by
the “ENTER” key. The instrument will not allow invalid times or
dates to be entered.
NOTE: The clock will need to be manually adjusted to cope with
daylight saving changes or changes when crossing time
zones.
5.9.2.2 Contrast
The “CONTRAST” option enables the operator to adjust the
instrument screen contrast to compensate for changes in ambient
temperature. The default setting is 0.
1) From the “MAIN READ SCREEN” press the “MENU” key on the
instrument panel.
2) Press “KEY 2” to display the “UTILITIES” menu.
3) Press “KEY 2” to select the instrument panel contrast settings and
the following screen will be displayed:
4) Press “KEY 4 - SCROLL LEFT” and “KEY 6 - SCROLL RIGHT” to
adjust the value displayed.
5) Press the soft-key “ACCEPT” or “REJECT” accordingly to accept or
reject the changes.
NOTE: The manually-set contrast setting is retained when the
instrument is switched OFF.
