Spa Quick Start Guide
Balboa VS/GS100 System for VL 200 Topside Control
For use with Four Winds Spas Storm Series: One pump, 115Volt pack. Non-Wifi Topside.
Start-up
Your spa will enter Priming Mode ( ) after the initial start-up
sequence. During Priming Mode, press “Jets” button
repeatedly and be sure the pump is free of air. Priming
Mode lasts less than 5 minutes. Press “Warm” or “Cool” to exit.
After Priming Mode, the spa will run in its preset mode (see
Mode section for details).
Temp Control (80°F - 104°F / 26°C - 40°C)
The last measured water temperature is constantly displayed.
The water temperature displayed is current only when the
pump has been running for at least 1 minute.
To display the set temperature, press “Warm” or “Cool” once. To
change the set temperature, press a temperature button again
before the display stops flashing. Each press of “Warm” or
“Cool” will adjust the set temperature.
After three seconds, the display will stop flashing and begin to
display the current spa temperature.
Jets
Press “Jets” to turn the pump on or off, and to shift between low
and high speeds (if equipped). If left running, the pump will turn
off after a preset length of time, which on some systems may be as
long as 2 hours for low speed. Low speed may run automatically at
times, during which it cannot be deactivated from the panel, but
high speed may be operated.
Pump 1 low-speed is responsible for heating and filtration. In
multi-button sequences, if the buttons are pressed too quickly in
sequence, they may not register.
Light
Press “Light” to operate the spa light. Turns off after 4 hours.
Mode
Depending on system configuration, mode changing may not be
available and will be locked in Standard Mode.
Mode is changed by pressing “Warm” then “Light”.
Standard Mode maintains set temperature. will be displayed
momentarily when you switch into Standard Mode.
Economy Mode heats the spa to the set temperature only during
filter cycles. will display when water temp is not current, and
will alternate with water temp when the pump is running.
Sleep Mode heats the spa to within 20°F/10°C of the set
temperature only during filter cycles. will display when water
temp is not current, and will alternate with water temp when the
pump is running.
Preset Filter Cycles
The first preset filter cycle begins 6 minutes after the spa is
energized. The second preset filter cycle begins 12 hours later.
Filter duration is programmable for 1, 2, 3, 4, 5, 6, 7, or 8 hours.
It is important to set filter cycles on a pattern. We recommend
programing cycles at 7 am & 7 pm and avoiding the hours
from 10am-5pm.
To program, press “Warm,” then “Jets.” Press temperature buttons
to adjust. Press “Jets” to exit programming.
Automatic polling (in Standard Mode only)
The pump will activate for 1 minute to check the temperature:
- every 30 minutes
- whenever any other pump or blower is turned on
- whenever the set temperature is raised
This document covers VS and GS systems 300F using software v41 only with Balboa Panels VL200 through VL406.
Download complete user guide at http://www.balboawatergroup.com/getdoc.cfm?id=1155

Diagnostic Messages
Message
Meaning
Action Required
No message on display.
The control panel will be disabled until power returns. Spa settings
Power has been cut off to the spa.
will be preserved until next power up.
Temperature unknown.
After the pump has been running for 1 minute, the current water
temperature will be displayed.
“Overheat” - The spa has shut down.* One of the
DO NOT ENTER THE WATER. Remove the spa cover and allow
sensors has detected 118°F/47.8°C at the heater.
water to cool. Once the heater has cooled, reset by pushing any
button. If spa does not reset, shut off the power to the spa and call
your dealer or service organization.
“Overheat” - The spa has shut down.* One of
DO NOT ENTER THE WATER. Remove the spa cover and allow
the sensors has detected that the spa water is
water to cool. At 107°F/41.7°C, the spa should automatically reset.
110°F/43.5°C.
If spa does not reset, shut off the power to the spa and call your
dealer or service organization.
Spa is shut down.* The sensor that is plugged into
If the problem persists, contact your dealer or service organization.
the Sensor “A” jack is not working.
(May appear temporarily in an overheat condition.)
Spa is shut down.* The sensor that is plugged into
If the problem persists, contact your dealer or service organization.
the Sensor “B” jack is not working.
(May appear temporarily in an overheat condition.)
Sensors are out of balance. If alternating with spa
If the problem persists, contact your dealer or service organization.
temperature, it may just be a temporary condition.
If flashing by itself, spa is shut down.*
A significant difference between temperature
If the water level is normal, make sure all pumps have been primed.
sensors has been detected. This could indicate a
If problem persists, contact your dealer or service organization.
flow problem.
Persistent low flow problems. (Displays on the
Follow action required for message. Heating capability of the
fifth occurrence of message within 24 hours.)
spa will not reset automatically; you may press any button to reset.
Heater is shut down, but other spa functions
continue to run normally.
Possible inadequate water, poor flow, or air
If water level is normal, make sure all pumps have been
bubbles in detected in the heater. Spa is shut down
primed. Press any button to reset. This message will reset
for 15 minutes.
within 15 minutes. If problem persists, contact your dealer or
service organization.
Inadequate water detected in heater. (Displays on
Follow action required for message. Spa will not automatically
third occurrence of message.) Spa is
shut down.*
“Ice” - Potential freeze condition detected.
* - E v e n w hen s p a is s h u t d o w n , so m e
e q u ip m e n t w i ll turn on if freeze protection is
needed .
reset. Press any button to reset manually.
No action required. All equipment will automatically activate
regardless of spa status. The equipment stays on 4 minutes after the
sensors detect that the spa temperature has risen to 45°F/7.2°C or
higher. An optional freeze sensor may be added to protect against
extraordinary freeze conditions. Auxiliary freeze sensor protection is
advisable is colder climates. See your dealer for details.
Warning! Shock Hazard! No User Serviceable Parts.
Do not attempt service of this control system. Contact your dealer or service organization for assistance. Follow all owner’s manual
power connection instructions. Installation must be performed by a licensed electrician and all grounding connections must be
properly installed.
