Gecko in.ye-V3 User manual

in.ye-V3
optimize your customers’ spa experience
with Gecko’s new generation of in.ye control systems
TechBook
Gecko Alliance
450 des Canetons, Québec (Qc), G2E 5W6 Canada, 1.800.78.GECKO
www.geckoalliance.com Printed in Canada
9919-101682-E
Rev. 04-2021
© Groupe Gecko Alliance inc., 2021
All trademarks or registered trademarks
are the property of their respective owners.
a lot more to offer
relaxation in full colors with in.mix integration
installation made simple

11
Warnings ������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 2
Introduction ��������������������������������������������������������������������������������������������������������������������������������������������������������������������� 3
Features �������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 4
Overview
- in�ye overview ����������������������������������������������������������������������������������������������������������������������������������������������������� 5
- in�ye dimensions ������������������������������������������������������������������������������������������������������������������������������������������������ 5
Installation
- Floor installation procedure �������������������������������������������������������������������������������������������������������������������������������� 6
- Wall installation procedure with optional wall mounting brackets (option 1) ������������������������������������������������������� 7
- Wall installation procedure with optional wall mounting brackets (option 2) ������������������������������������������������������� 8
- Keypad installation ��������������������������������������������������������������������������������������������������������������������������������������������� 8
Connections
- Connection of main keypad �������������������������������������������������������������������������������������������������������������������������������� 9
- heat�wav water heater connections ������������������������������������������������������������������������������������������������������������������ 10
- Connecting high voltage accessories: all models ���������������������������������������������������������������������������������������������� 11
- Connecting high voltage accessories: North American model in�ye ������������������������������������������������������������������ 11
- Connecting high voltage accessories: European model in�ye���������������������������������������������������������������������������� 12
- AMP output connectors and typical accessories ���������������������������������������������������������������������������������������������� 13
- Completing the installation ������������������������������������������������������������������������������������������������������������������������������� 14
Wiring
- AMP connector and housing ���������������������������������������������������������������������������������������������������������������������������� 15
Electrical wiring
- Electrical wiring: all models ������������������������������������������������������������������������������������������������������������������������������ 16
- Electrical wiring: North Amercian model in�ye �������������������������������������������������������������������������������������������������� 17
- Electrical wiring: European model in�ye ������������������������������������������������������������������������������������������������������������ 18
Controler power up �������������������������������������������������������������������������������������������������������������������������������������������������������� 19
Compatible keypads ������������������������������������������������������������������������������������������������������������������������������������������������������ 20
Troubleshooting ������������������������������������������������������������������������������������������������������������������������������������������������������������� 21
Specifications ���������������������������������������������������������������������������������������������������������������������������������������������������������������� 22
Table of contents

2
Warnings
WARNINGS:
Before installing or connecting the unit, please read the following�
*FOR UNITS FOR USE IN OTHER THAN SINGLE-FAMILY DWELLINGS, A CLEARLY LABELED EMERGENCY SWITCH SHALL
BE PROVIDED AS PART OF THE INSTALLATION� THE SWITCH SHALL BE READILY ACCESSIBLE TO THE OCCUPANTS
AND SHALL BE INSTALLED AT LEAST 5' (1�52 M) AWAY, ADJACENT TO, AND WITHIN SIGHT OF THE UNIT�
*ANY DAMAGED CABLE MUST BE IMMEDIATELY REPLACED BY QUALIFIED PERSONNEL�
*TURN POWER OFF BEFORE SERVICING OR MODIFYING ANY CABLE CONNECTIONS IN THIS UNIT�
*TO PREVENT ELECTRIC SHOCK HAZARD AND/OR WATER DAMAGE TO THIS CONTROL, ALL UNUSED BUSHING
CONDUITS MUST BE PLUGGED WITH THE ATTACHED NIPPLE�
*THIS CONTROLLER MUST NOT BE INSTALLED IN PROXIMITY OF HIGHLY FLAMMABLE MATERIALS�
*LOW SUPPLY VOLTAGE OR IMPROPER WIRING MAY CAUSE DAMAGE TO THIS CONTROL SYSTEM�
READ AND FOLLOW ALL WIRING INSTRUCTIONS WHEN CONNECTING TO POWER SUPPLY�
*THIS PACK CONTAINS NO USER SERVICEABLE PARTS� CONTACT AN AUTHORIZED SERVICE CENTER
FOR SERVICE�
*ALL CONNECTIONS MUST BE MADE BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH THE NATIONAL
ELECTRICAL CODE AND ANY STATE, PROVINCIAL OR LOCAL ELECTRICAL CODE IN EFFECT AT THE TIME OF THE
INSTALLATION�
*PRODUCT MUST BE DISPOSED OF SEPARATELY IN ACCORDANCE WITH LOCAL WASTE DISPOSAL LEGISLATION�
* THIS APPLIANCE IS NOT INTENDED FOR USE BY PERSONS (INCLUDING CHILDREN) WITH REDUCED PHYSICAL,
SENSORY OR MENTAL CAPABILITIES, OR LACK OF EXPERIENCE AND KNOWLEDGE, UNLESS THEY HAVE BEEN GIVEN
SUPERVISION OR INSTRUCTION CONCERNING USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR
SAFETY�
* CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY DO NOT PLAY WITH THE APPLIANCE�
* MEANS FOR DISCONNECTION MUST BE INCORPORATED IN THE FIXED WIRING IN ACCORDANCE WITH
THE WIRING RULES�
* CAUTION: IN ORDER TO AVOID A HAZARD DUE TO INADVERTENT RESETTING OF THE THERMAL CUT-OUT,
THIS APPLIANCE MUST NOT BE SUPPLIED THROUGH AN EXTERNAL SWITCHING DEVICE, SUCH AS A TIMER,
OR CONNECTED TO A CIRCUIT THAT IS REGULARLY SWITCHED ON AND OFF BY THE UTILITY�
* PARTS CONTAINING LIVE PARTS, EXCEPT PARTS SUPPLIED WITH SAFETY EXTRA-LOW VOLTAGE NOT EXCEEDING
12 V, MUST BE INACCESSIBLE TO A PERSON IN THE BATH OR SPA�
* PARTS INCORPORATING ELECTRICAL COMPONENTS, EXCEPT REMOTE CONTROL DEVICES, MUST BE LOCATED OR
FIXED SO THAT THEY CANNOT FALL INTO THE BATH OR SPA�
* PARTS ARE TO BE INSTALLED IN THE CORRECT ZONE AND EQUIPOTENTIAL BONDING CARRIED-OUT IN
ACCORDANCE WITH THE WIRING RULES�
*CLEARANCE AND MINIMUM DISTANCE BETWEEN THE VARIOUS PARTS OF THE APPLIANCE AND THE SURROUNDING
STRUCTURE ARE NOT SPECIFIED AS LONG AS THEY ARE SUFFICIENT SO THAT THE AMBIENT TEMPERATURE
AROUND THE CONTROLLER DOES NOT EXCEED 60°C�
Gecko®, and their respective logos are Registered Trademarks of Gecko Alliance Group�
in�ye™, in�touch™, in�claw™, in�port™, in�flo™, in�put™, in�seal™, in�link™, in�t�cip™, in�stik™, in�k300™, in�k330™, in�k450™,
in�k1000™, in�k1000+™, in�k1001™, in�k1001+™, in�k800™, in�k500™, heat�wav™, and their respective logos are Trademarks of
Gecko Alliance Group�
All other product or company names that may be mentioned in this publication are tradenames, trademarks or registered trademarks of
their respective owners�

3
in�ye-V3
optimize your customers’ spa
experience with Gecko’s new
generation of in�ye control systems
A lot more to offer
After upgrading its smaller brother, we could not resist
doing the same with Gecko’s in�ye� With its boosted CPU,
external memory and higher capacity relays, in�ye-V3
now has the power it needs for new features��� like LED
lights for troubleshooting clues� We‘ve also added
a pathway to connected accessories with faster
communication, not only to open up the in�ye-V3 to the
network of connected objects but to be updatable
wirelessly, a definite plus for our OEM customers�
Relaxation in full colors with in.mix integration
With a light output capacity increased to 1�3A and the
integration of the in�mix 300 color system on the main
board, new in�lu�me cables and LED lights can be
connected directly to the in�ye-V3 box with full color
control directly from the keypad�
Installation made simple
With its new terminal block, onboard AMP connectors
and an evolved cable strain relief system, it has never
been easier to connect your accessories to a control box!
Introduction

4
Features
in�seal provides an extra level of protection against
water infiltration� Connectors and power box are
designed to be watertight (IPX5)�
in.seal
watertight protection
The in�ye is compatible with the low-voltage family
of in�link connectors, such as those used by
keypads and similar low-voltage accessories�
in.link
ingenious plugs and connectors
in�t�cip is an intelligent water temperature refresh
algorithm that calculates optimal time to start
pumps and get water temperature readings�
in�t�cip continuously readjusts the heater start
time (according to exterior temperature)�
in.t.cip
water temperature algorithm
The in�ye systems boast a long list of technical features� Each of them contributes to bringing the most advanced
solutions available to in�ye equipped spa owners:
The in�stik is a pen drive with an in�link connector
very similar to a USB memory stick� It connects
to the spa pack and contains data to program or
configure its system� The system executes the
data upload automatically�
in.stik
automated software upload
All in�ye packs support the in�touch internet
interface, allowing you to use your favorite iOS or
Android device to communicate with your spa�
in.touch 2
you're always in touch with your relaxation
in�flo is an all-electronic dry-fire protection�
The in�flo eliminates the burden of adjustments,
calibrations and failures associated to usual water
flow sensors�
in.flo
dry-fire protection
in�put was designed to ease wire insertion
(up to # 4 AWG) and connections� Tighter input
connection reduces heat generated for increased
component lifetime�
in.put
input terminal block
The in�claw is an easy-to-use, modular cable
clamp system that doesn’t require any tool�
It provides the possibility to connect up to eight
high-voltage cables�
in.claw
advanced cable clamp system
The in�port is the future of communication inside
a spa! The in�ye-V3 is fully compatible with all
keypads and accessories�
in.port
communication port

5
10.47”
(266 mm)
17.86”
(454 mm)
19.60”
(498 mm)
12.81”
(325 mm)
18.72”
(475 mm)
4.06”
(103 mm)
4.52”
(115 mm)
10.75”
(273 mm)
2.83”
(72 mm)
Overview
in.ye dimensions
Note: Shown with optional wall mouting brackets (see Installation)�
in.ye overview
55 mm
(2�15 po)
115 mm
(4�56 po)
Front view Side view
266 mm
(10�47 po)
41 mm
(1�63 po)
Rear view Bottom view
Main power
entry connection
Optional accessories board
heat�wav heater
in�claw - watertight strain
relief system
Mounting feet
Industry-standard AMP
connectors for outputs
Enough outputs for all
your spa needs
Optional board COM
(RS485)
C1 - Main keypad
connector
a�port (accessories)
k�port (keypad)
C0 - Communication
connectors
Accessible
bonding lugs
Access to heater
connections

6
Note: The spa pack must be installed at least 4"
(100 mm) above potential flood level. If floor is on ground
level, pack should be raised at least 4" (100 mm).
Important! Read before starting:
Please note that countersunk screws should not be used as they can damage the power box support�
The heat�wav element must be installed on the circuit of the main circulation pump (either the pressure or
the suction side)�
Installation
Warning!
Beware of the application of some products
commonly used against corrosion (such as
WD-40 family products) as they could damage
the pack, due to a negative chemical reaction
between some industrial oils and its plastic
enclosure� Any other materials which may
come in contact with the enclosure must be
carefully evaluated under end use conditions
for compatibility�
4" (100 mm)
Floor installation procedure
The following material is recommended:
4- # 10 screws of appropriate length with round, truss or pan head�
4- washers �5 OD» x �0625» thickness (12 mm OD x 1�5 mm)
Now firmly attach the front feet of the pack to the wooden
floor using 2 more screws backed by 2 washers�
Select the most appropriate location on the floor for
the spa pack and firmly attach the 2 rear feet to the
wooden base using 2 screws backed by 2 washers�

7
Installation
The following material
is recommended:
4- # 10 screws of
appropriate length with
round, truss or pan head�
4- washers �5 OD» x
�0625» thickness
(12 mm OD x 1�5 mm)
Use 2 standard 2" x 4" or 2" x 6" wall studs, spaced
17-inch from center to center to fix the spa pack�
Firmly attach, one at a time, upper mounting holes on
each side of the spa pack with 2 screws backed by
2 washers�
Firmly attach lower mounting holes on each side of the
pack with the 2 remaining screws and 2 washers�
Lower mounting holes are 2" (51 mm) below upper holes�
Part number: Wall mount bracket kit 100 pcs - 9920-101474
(with 200 screws to attach to pack)
Install mounting brackets on both sides of the rear of the
unit, using screws provided with the brackets�
Torque screws to 13 in� lb max (1�49 N�m)�
Wall installation procedure with optional wall mounting brackets (option 1)

8
For detailed instructions and drilling template, refer to the compatible keypad section and select your keypad to be
redirected to the corresponding techbook�
Keypad installation
Installation
The following material
is recommended:
4- # 10 screws of
appropriate length with
round, truss or pan head�
4- washers �5 OD» x
�0625» thickness
(12 mm OD x 1�5 mm)
Use 2 standard 2" x 4" or 2" x 6" wall studs, spaced
17-inch from center to center to fix the spa pack�
Firmly attach, one at a time, external mounting holes on
each side of the spa pack with 2 screws backed by
2 washers�
Firmly attach internal mounting holes on each side of the
pack with the 2 remaining screws and 2 washers�
Internal and external holes are distant from 2'' (51 mm)
on the mounting braket�
Part number: Wall mount bracket kit 100 pcs - 9920-101474
(with 200 screws to attach to pack)
Install mounting brackets on both sides on the top at the
rear, using screws provided with the brackets�
Torque screws to 13 in� lb max (1�49 N�m)�
Wall installation procedure with optional wall mounting brackets (option 2)

9
Connections
Connection of main keypad
Note: always shut power down before connecting an accessory to the in�ye�
To connect the keypad, remove the cover, then insert the in�link connector into the appropriate keypad connector
(as illustrated)� Route the cable through the molded strain relief channel on the bottom right side of the spa
pack (as illustrated)� Don’t forget to replace the cover and all screws (torque to 8 in� lb max (0�9 N�m))�
Strain relief
channel
C1 - Main keypad
connector
Table of contents
Other Gecko Spa Accessories manuals

Gecko
Gecko in.touch 2 User manual

Gecko
Gecko in.k1000 User manual

Gecko
Gecko in.k300 User manual

Gecko
Gecko in.k330 User manual

Gecko
Gecko in.yj-3 Technical manual

Gecko
Gecko in.mix 300 Series User manual

Gecko
Gecko M-CLASS MC-MP-SBD User manual

Gecko
Gecko Y Series User manual

Gecko
Gecko Y Series User manual

Gecko
Gecko S-CLASS 0202-205162 Technical manual

Gecko
Gecko MSPA-1-AS User manual

Gecko
Gecko Aeware 3 in.ye User manual

Gecko
Gecko BAHAMA SPAS Reference guide

Gecko
Gecko in.k506 User manual

Gecko
Gecko DJS-1 User manual

Gecko
Gecko Aeware3 in.touch User manual

Gecko
Gecko Aeware3 in.ye User manual

Gecko
Gecko Aeware In.Xe User manual

Gecko
Gecko in.ye-5 Technical manual
