Ballu Plaza Ext Series User manual

Operation
Manual
Warranty Card
Household electrical convection
heater,
Plaza Ext series
ВЕР/ЕХТ-1000 | BEP/EXT-1500 | BEP/EXT-2000
Prior to operation
read carefully this
Manual and keep it in a safe accessible place.

2 Contents
Designations
ATTENTION!
Requirements to be observed to avoid severe injury or
equipment damage.
CAUTION!
Requirements to be observed to avoid severe injury or
death.
NOTE:
1. If the power cable is damaged, to avoid severe
injuries, it should be replaced by the manufacturer
or the authorized service or another skilled
specialist service.
2. The convector should be installed with observance
of the existing local norms and regulations and rules
of operation of electrical networks.
3.
After the convector is installed, the electric plug
should be located in an accessible place.
4. The convector should be installed on the
sufficiently durable brackets.
5. The power rating of the heater (specified on the
nameplate) is based on the tests under certain
load.
6. The manufacturer retains the right to modify the
structure, delivery set or manufacturing
technology of the product for the improvement
purposes without prior notice.
7. Misprints may occur in the text and numerical
designations.
8. If there are questions on the appliance operation
after you have read the operation manual, contact
the special service center for explanations.
9. There is a nameplate on the product where its
technical specifications and another useful
information are.
2
3
4
5
6
6
7
8
8
8
9
9
9
9
10
10
10
10
11
D
esignations
Safety rules
Purpose
Convector design
Technical specifications
Operation
Care and maintenance
Safety measures
Maintenance
Installation
Electrical diagram
Service life
Storage
Date of manufacture
Warranty
Scope of delivery
Rules of disposal
Product certification
Warranty card

Safety Rules 3
Safety rules
ATTENTION!
The general safety rules should be observed during
operation os any electrical appliance.
To eliminate risk of fire, electrical shock, accidents or
property damage:
Prior to using the heater read the Manual and
keep in an accessible place.
Use the heater only at the voltage specified on
the nameplate.
To avoid overheating and fire never obstruct air
flow through the inlet and outlet grills.
Avoid placing the heater in the vicinity of any
surface; this may lead to obstruction of the grills
and impaired air intake and outlet.
Avoid placing the heater in the vicinity of other
heaters.
Do not use the heater in the places where fuel,
paint or other flammable liquids are stored.
This appliance gets hot during operation. Never
touch hot surfaces to avoid burns. Turn the
appliance off and let it cool down before moving
to another place.
Never use the heater for drying clothes.
Never insert foreign metal objects into the inlet
and outlet orifices; this may lead to electric
shock, fire or damage of the device.
Never immerse the device in a liquid, keep the
device away from liquids; otherwise, electric
shock is possible.
•
If the device falls in water, do not try to take it out
of it. Immediately take the plug out of the socket.
•Never operate the heater with damaged cable, plug
in case of faults, falls or other damages. Contact a
skilled electrician to check electrical, mechanical
adjustment, for service maintenance or repair of
the heater.
•Never touch the working heater with wet hands.
•The most common cause of overheating is dust
inside the heater. Remove the accumulated heat
regularly. For this, disconnect the device from the
mains and clean the vent orifices and the grills with
the vacuum cleaner.
•Do not place the device on the window-sill: ingress
of raindrops may lead to electric shock.
•Never use abrasive detergents during cleaning.
Clean it with the cloth (not soaking) wetted with hot
soaped water. Before cleaning always disconnect
the device from the mains.
•Do not connect the device to the power source
prior to full assembly and adjustment.
•Do not use the device in the vicinity of bath,
shower, swimming pool or other containers with
liquids.
•The device should be used in vertical position.
•Before moving the device turn it OFF and let it cool
down.
•Do not use the device with twisted power cable:
this may lead to overheating and accidents.
•It is not recommended to use an extension cable.
•Do not take the plug out of the socket before
turning the device OFF.
•Never pull the cable when taking the plug out of the
socket: hold the plug.
•Disconnect the device from the mains if it is not
used.

4 Safety rules
•
This device is not intended for using on carpets
with long nap and on Flocatti carpets.
• During operation ensure the cable does not touch
a heated surface.
• Do not hide the cable under carpets, carpets rolls,
etc. Place the cable in a stumble-free way.
• Never twist, bend or coil the cable around the
heater; this may lead to abrasion and wear of the
insulation. Ensure the cable is fully out of the coil.
• Do not use the device in the open air and do not
leave it on wet floor.
• Do not place the device to the place of storage
unless it is cool.
• Do not leave the device unattended in a place
where children or handicapped persons are.
• Do not allow children to play with the device.
• The device should not be located directly under
the mains socket.
• All the surfaces of the device are intended to
protect direct access to the heating elements and
should be in place during operation.
• Do not cover the heater to avoid overheating.
• The protective screen does not provide full
protection of children and handicapped persons.
• To avoid accidents, damaged power cable should
be replaced by a qualified electrician.
• To avoid reset of thermal fuse, this device should
not be used together with other disconnecting
devices, e.g., timer. Also, the device should not be
connected to a circuit which frequently opens and
closes.
• Use the device only for its intended purpose
according to this Manual. Any other use is not
is not recommen
ded by the manufacturer and
may lead to fire, electric shock or accident.

This is the device for household use only, not
intended for industrial purposes.
 Minimal distances to other objects:
Dimensions in mm
Fig. 1
 Prior to operation of the device remov
e the
coloured stickers from the front panel.
ATTENTION!
At first turning the heater on the characteristic smoke
odour may occur due to oil burned in the heating
elements. Before installation it is recommended to
turn the heater on for 10-20 minutes in a
well
ventilated premises.
Purpose
The device is intended for air heating in household
premises.

Convector design 5
Convector design
Fig. 2
1. Control unit
2. Air bleeding grills
3. Convection chamber
4. Temperature sensor
5. Stands
6. Rollers
7. Air intake grill
8. Power cable with plug
Control panel:
Fig. 3
1. Power On/Off button
2. Full/half power
3. Control buttons
4. Control buttons
5. Switch off timer
6. Anti-freeze device
Remote control:
Fig. 4
1. Power On/Off button
2. Full/half power
3. Control buttons
4. Control buttons
5. Switch off timer
Display on the convector front panel
Fig. 5
1. Operation with preset temperature
2. Operation with switch off timer
3. Anti-freeze device
4. Air temperature
5. - full power
6. - 1/2 power
7. Parent control

6 Technical specifications
Technical specifications
Part No.
ВЕР/ЕХТ
-
1000
ВЕР/ЕХТ
-
1500
ВЕР/ЕХТ
-
2000
Heating power I, W
500
750
1000
Heating power II, W
1000
1500
2000
Rated watts input I, kW
0.5
0.75
1.0
Rated watts input II, kW
1.0
1.5
2.0
Rated voltage, V ~ Hz
220
-
240 ~ 50
220
-
240 ~ 50
220
-
240 ~ 50
Rated cur
rent, A
4.3
6.5
8.7
Protection class, IP
ІР 24
ІР 24
ІР 24
Electrical protection class
I class
I class
I class
Heated area, m
2
up to 15
up to 20
up to 25
Dimensions (WхHхD), mm
480x415x111
640x415x111
800x415x111
Dimensions of package (WxHxD), mm
575x
470x142
735x470x142
895x470x142
Net weight, kg
5.78
6.63
7.48
Gross weight, kg
7.08
8.1
9.12
* Approximate heated area is specified.
The value may vary depending on actual operating conditions.
Operation
Preparation for operation
Carefully remove the heater out of the cardboard box.
Keep the box for out-of-season storage. Prior to
switching the convector heater on ensure it is in OFF
state. Install the heater following the installation
instructions. To avoid overloading of the mains it is not
recommended to connect the heater to a socket with
other high-power electrical appliances connected.
Switching the device ON
Plug the Timer into this socket. First press the power
button to turn the device on; at the switched off
timer on the display located on the front panel of the
device the room temperature will be displayed. The
factory preset temperature is 24°С.
'Comfortable' mode setting
This is the operational mode with the temperature set
by the user. This mode activates automatically unless
another mode is set. The factory temperature setting is
24°С.
Press the buttons and to increase the
temperature by 1°С or decrease by 1°С. The maximal
possible temperature is 35°С, the minimal - 5°С. If you
hold pressed the button or the temperature
will be increased or decreased by 1°С per 0.5 s. The last
temperature setting is taken as active. In 5 s the system
will resume operation; the temperature indicator on the
display will stop flashing, and the room temperature will
be displayed.
'Anti-freeze' mode setting
To set the mode press the... button the indication
will appear on the front panel of the device. The
temperature +5°С will be set. To exit the mode press
again . The indicator will be off.
Timer setting
Press the button to set the timer; the set time is
indicated on the

Operation 7
display, the time indicator flashes (the timer is set by
the clock). Press the buttons or to increase
or decrease the time by one hour; the timer can be set
for the period 0-24 hours. When holding the buttons
or pressed the operation time will be
increased or decreased by 1 hour per 0.5 s. The factory
setting - 0 hours. When the indicator is on, the system
starts to count time according to the previous setting
unless a new value is set within 5 s. Every time when
the buttons or are pressed the system
starts new count of time or returns to the initial
parameters after the timer finishes operation, then
turns off and ends operation. To cancel the timer
operation press again the... button
Switching the device OFF
To switch the device off press the power... button
in any mode of operation.
Auto Restart RESUME function
It enables to automatically switch the device on at an
unscheduled power cutoff with all the settings active
by the moment of power cutoff stored when the power
is resumed. The additional Resume function stores the
set temperature. Press the power button to turn the
device on after it is off or timer switch off: the last set
temperature will be the temperature set point.
Parent control (buttons lock)
During operation press simultaneously the buttons
or and hold them pressed for more than 3
s to lock the system. The indicator... will be lit on the
front panel. To unlock: holding pressed the
buttons or for more than 3 s.
Power saving mode
This mode enables to select power
of heating. Full power mode is set by default. Press the
power selector button to set the heating power.
The heater will operate at maximal power. The
indicator... will be lit on the front panel of the convector
. Press the button again, and half power of
the heater will be activated. When setting half power
the indicator will be lit on the front panel of the
convector.
Overheat protection function
The device is equipped with the automatic switch which
is activated when the upper temperature limit is
reached. In case of overheating the heater is
automatically switched off.
Care and maintenance
Regular cleaning of the device at continuous operation
Prior to cleaning disconnect the heater from the mains.
Prior to cleaning ensure the heater has cooled down.
Use wet cloth (not soaking) to clean dust and dirt from
the external part of the heater.
Use vacuum cleaner to remove dust and lint from the
heat dissipation grills. Prior to connecting the heater to
the mains ensure it is dry.
Cleaning of the rear panel of the wall-mounted heater
Fig. 6

8 Safety measures
Prior to cleaning disconnect the heater from the mains.
Loosen the spacer screws on the latches. Lower two
latches «Р» (see Fig. 6) on the rear panel of the heater
and pull the device to yourself. Remove the device
from the brackets and clean the rear panel. After
cleaning the heater should be mounted in the reverse
order.
Safety measures
• Fix the heater reliably on the wall or place it in the
correct position.
• The heater should be installed in such a way so
that a person in the bath or shower could not
accidentally touch the control panel.
• It is forbidden to place the heater under the
mains socket.
• If the heater is placed on the floor, keep it away
from the bath, shower or swimming pool.
• If wall-mounted, never locate the heater in the
vicinity of the bath, shower or the swimming pool.
• If the power cable is damaged, contact a qualified
electrician or a service person.
• NEVER cover the working heater.
• Before storage arrangements ensure the heater is
cool.
• If the heater is not intended for use for a long
time it is recommended to clean it and put for
storage (preferably in the factory package) in a
cool dry place.
Maintenance
If maintenance is necessary, contact the authorized
service center.
Power cable replacement
To avoid accidents the damaged power cable should
be replaced by the service centre representative or
another qualified specialist.
Installation
1. Wall mount. Install the heater on the wall near the
floor using the brackets according to the figures below.
The distance from the device to the floor should be at
least 10 cm.
Fig. 7
The wall bracket can be released from the convector as
follows:
• press the latches and pull the bracket to yourself;
• mark and drill the holes;
• install the bracket on the wall and fix it.
Fig. 8

Installation 9
The device can be fixed on the bracket as follows:
screw two fixing screws at the top into the
latches on the bracket;
put the lower part of the convector on the
bracket using the special holes on the lower part of
the convector;
put the upper part of the convector on the
bracket by fixing it with the latches on the bracket.
Fig. 9
2. Floor mount (stand fixing). Read the mounting
diagram below use the stands and rollers from the
delivery set and install the device on the floor.
turn the convector upside down;
take one of the stands with the rollers;
apply the plate of the stand to the place of fixing
on the convector so that the convex part of the
plate tightly joined the convector case: the screw
hole should match;
fix the stand using the special plastic half-turn fix
included in the delivery set;
do the same with the second stand.
Fig. 10
Electrical diagram
Fig. 11
Service life
The service life of the heater is 10 years.
Storage
• Before storage arrangements ensure the heater is cool.
• If the heater is not intended for use for a long time it is
recommended to clean it and put for storage (preferably in
the factory package) in a cool dry place.
Date of manufacture
The date of manufacture is on the package.

10 Warranty
Warranty
The warranty service of the device is performed
according to the warranty liabilities specified in the
warranty card.
Scope of delivery
1. Heater
2. Set of stands with rollers
3. Wall-mounting brackets
4. Set of fixing elements
5. Operation Manual with the Warranty Card
Rules of disposal
On expiry of the service life the device should be
disposed of according to the norms, regulations and
methods current in the place of disposal.
Product certification
The product is certified on the territory of Russia by
the Certification Authority:
ROSS R,11.0001.11АГ49 OS PRODUCTS,
GILDIA KACHESTVA, LLC
Registered office:
building 12, 4, Sharikopodshipnikovskaya str.,
Moscow 115088,
Russian Federation
Actual address:
building 12, 4, Sharikopodshipnikovskaya str.,
Moscow 115088,
Russian Federation
Phone: [phone]
Complies with the requirements of regulatory
documents:
GOST R 52161.2.30-2007,
GOST R 51318.14.1-2006 (section 4),
GOST R 51318.14.2-2006 (sections 5, 7),
GOST R 51317.3.2-2006 (sections 6, 7),
GOST R 51317.3.3-2008
No. of certificate:
ROSS СЫ.АГ49.В01962
Term of validity:
from 12.02.2013 till 11.02.2015
(In absence of the new certificate copy in the
box ask the Seller for a copy)
Manufacturer:
BALLU INDUSTRIAL GROUP LIMITED
Suite 18В, 148 Connaught Road Central, Hong
Kong, China
BALLU INDUSTRIAL GROUP LIMITED
Suite 18В, 148 Connaught Road Central, Hong
Kong, China
Manufactured by:
Foshan Shunde Big Climatic Manufacture Co.,
LTD.,
No. 10-6, Fuan Industrial area (First phase), Leliu
Town, Shunde District, Foshan City, Guangdong,
China, 528300
Importer:
IRMC, LLC, office 14, building 7 - 6, Leninsky prospekt,
Moscow 119049, Russian Federation

WARRANTY CERTIFICATE
This document does not restrict the consumers' rights defined by law but supplements
and specifies the liabilities stipulated by law assuming an agreement or a contract
between the parties
You have purchased the high-quality equipment.
Congratulations!
Be sure to attentively read the Warranty card and
check it is correctly filled in and stamped by the Seller.
In absence of the Seller's stamp and date of sale (or the
cashier's receipt with the specified date of sale) the
warranty period of the product is calculated from the
date of manufacture of the product.
Check the appearance of the product carefully and
the scope of its delivery; all claims for the appearance
and the scope of delivery are to be brought to the
Seller during purchase. The warranty service of the
purchased device is performed via the Seller, special
service centers or the mounting company that installed
the device (if it needs special installation, connection or
assembly).
Contact the special service centers for all issues
related to technical maintenance of the product. The
detailed information about the service centres
authorized for repair and maintenance of the product is
on the web-site: www.ballu.ru
Additional details you can obtain from the Seller or
from our information line in Moscow:
Phone: [phone]
Free call in Russia
E-mail: [e-mail]
Mail address: 125493, Moscow, P/O 310
Web: www.ballu.ru
In case of misfunctioning of the device by the
manufacturer's fault, the liability to eliminate the fault
is on the company authorized by the
manufacturer. In such a case the Buyer is entitled to
apply to the Seller. The liability for the device
misfunctioning by the fault of the installation
(mounting) company is laid on the latter. In such a case
apply to the installation (mounting) company which
installed (mounted) the device.
To install (connect) the product (if the product needs
special installation, connection or assembly) we
recommend to contact special service centers. You can
use the services of qualified specialists, however the
Seller, the company authorized by the manufacturer,
the Importer or the Manufacturer bear no liability for
faults of the product due to its incorrect installation
(connection).
The design, scope of delivery or manufacturing
technology can be modified for the purpose of
improvement of the product's technical specifications.
Such modifications are introduced without prior notice
to the Buyers and do not involve liabilities for
modification/improvement of previous products. To
avoid misunderstanding, we strictly recommend to
read the Operation Manual carefully prior to
installation/operation of the product. It is forbidden to
modify the Warranty Card or erase or re-write
whatever specified data. This Warranty is valid if the
Warranty card is filled in correctly/legibly, and the
following is specified: product name and model, serial
numbers, date of sale; also, the signature of the
authorized person and the Seller's stamp are present.
TYPE
Service life
Air conditioners, air dryers, electrical heaters (convectors), oil-filled radiators, water
heaters (series BWH/S Nexus (Н), BWH/S Nexus titanium edition (Н), BWH/S Omnium 0
(U)), IR-heaters for installation into suspended ceilings (series BIH-S)
10 (ten) years
Water heaters (series BWH/S Space)
8 (eight) years
Electrical IR-heaters, electrical fan heaters, curtains
7 (seven) years
The rest products
5 (five) years

TYPE
Warranty period
IR-heaters for installation into suspended ceilings (series BIH-S)
5 (five) years
Air conditioners (BSE, BSEI, BSA, BSAI, B20I-FM, B30I-FM, B40I-FM, BSEI-FM, BDI-FM,
BCI-FM, BPHS)*, air dryers (BDM), electrical convectors, electrical household IR-heaters,
electrical fan heaters (series VKH)
3 (three) years
Air conditioners (BSWI), water heaters (series BWH/S Nexus (H), BWH/S Nexus titanium
edition (H), BWH/S Omnium 0 (U)**, BWH/S Space***, electrical IR-heaters (series BIH-
AP, BIH-CM, BIH-T, BIH-L), electrical fan heaters (except for series VKH), gas thermal
generators, curtains, water fan heaters
2 (two) years
IR gas heaters, diesel heat generators, the rest of products
1 (one) year
* The warranty period for the compressor of the air conditioners of BSEI series is 60 (sixty) months.
** For water containing tank the warranty period is 84 (eighty four) months; for the rest parts of the product - 24
(twenty four) months.
*** For water containing tank the warranty period is 60 (sixty) months; for the rest parts of the product - 24
(twenty four) months.
The Warranty applies to manufacturing or design
defects of the product.
The repair works are performed by the authorized
service center and replacement of the defective parts
of the product in the service center or at the Buyer's
(on discretion of the service center). The warranty
repair is carried out within max. 45 (forty five) days. In
case it becomes evident that a fault can not be
eliminated within the term agreed by the parties, the
parties may make an agreement about new term of
faults elimination. The warranty periods above apply
only to the products used in personal, family or
household purposes not related to entrepreneurship.
In case of the product use in entrepreneurship, its
warranty period is 3 (three) months.
The warranty period for the accessories or
components (parts removable without tools: crates,
shelves, grills, baskets, head pieces, brushes, pipes,
hoses etc.) is 3 (three) months. The Warranty period
for the new parts of the product or those installed on
the product during warranty or paid for repair, or
purchased separately from the product is three months
from the date the Buyer received the repaired product
or sale to the latter of such parts. This Warranty is
effective only on the territory of Russian Federation for
the products purchased on the territory of Russian
Federation.
This Warranty does not provide rights for
reimbursement and cover of damage due to
modification and adjustment of the product without
prior written consent of the manufacturer in order to
bringing it into line with national or local technical
standards and safety regulations current in any other
country (except for Russia) where this product was
initially sold.
Not included in warranty:
•periodical service maintenance of the product
(cleaning, filter replacement or the devices serving as
filters);
•all adaptations and modifications of the product
including with the purpose of improvement and
expansion of its common sphere of use specified in
the Operation Manual without written consent of the
manufacturer.
•accessories included in the scope of delivery.
This warranty is not granted in cases:
•if the serial number of the product is modified,
erased, removed or illegible in full or partially;
•the product is used out of its direct application, not
in compliance with the Operation Manual including
operation at overload or jointly with the auxiliary
equipment not recommended by the Seller, the
company authorized by the manufacturer, the
importer, manufacturer;
•presence of mechanical damages (chips, cracks,
etc.), impacts of excessive force, chemically
aggressive substances, high temperatures, high
humidity/dust content, vapour concentrations if
anything of the above became the cause of the
product fault;
•repair/adjustment/installation/adaptation/commis
sioning of the product by non-authorized
companies/persons; acts of God (fire, flood, etc.)
and other causes beyond the Seller's, the company
authorized by the manufacturer, the importer,
manufacturer and the Buyer's control that
prejudiced the product;
•incorrect connection of the product to electrical or
water supply mains, as well as faults (non-
compliance with the working parameters and
safety)

of electrical or water supply mains and other external
networks;
•defects due to ingress of foreign objects, liquids
(except for those provided in the Operation
Manual), insects and their waste products, etc.
into the product.;
•wrong storage of the product;
•necessity to replace lamps, filters, power
elements, batteries, fuses, as well as
glass/porcelain/tissue and manually movable
parts and other additional wearing parts
(components) of the product having their own
limited service life due to their natural wear, or if
such replacement is provided by the design and
not related to disassembly of the product;
•defects of a system where the product was used
as a part of such system.
•defects due to the Buyer's non-observance of the
Care Checklist below.
Special conditions for warranty service of air
conditioning units
This warranty does not cover the defects of the
product's operation in case is the Buyer on his own
discretion (with no respect of appropriate information
of the Seller) chose and purchased an air conditioner of
proper quality but not intended for the premises it was
later installed in by the Buyer.
Dear customer! We hereby remind that improper
mounting of air conditioning units may lead their
improper operation and, consequently, failure of the
product. Mounting of this equipment should be
compliant with the document of Sanitary Engineering
Department NOSTROY 25 'MOUNTING AND
ADJUSTMENT OF EVAPORATING COMPRESSOR-
CONDENSING UNITS OF HOUSEHOLD AIR
CONDITIONING SYSTEMS IN BUILDINGS AND
CONSTRUCTIONS'. The mounting company is liable for
the installation works and the subsequent defects in
the product's operation. The manufacturer (Seller) is
entitled to reject the warranty for a product assembled
and commissioned in violation of the standards and
instructions.
Special conditions for warranty service of water
heating units
This warranty is not granted if faults of water heating
devices were caused by: freezing or at least one-time
excess of the maximal allowable pressure specified on
the nameplate with the technical specifications of the
device; operation without protection devices or with
the devices not complying with the technical
specifications of water heating units; use of corrosion-
active water; corrosion from electrical-chemical
reaction, untimely
technical maintenance of the water heating units
according to the Operation Manual, including: non-
observance of the frequency and terms of technical
maintenance provided by the instruction in the amount
also specified in the instruction).
Special conditions of air conditioning units operation
This warranty is not granted if by the request/desire of
the Buyer, in violation of the current SNiP
requirements, standards or other technical documents:
a wrong air conditioning unit was selected and
purchased for a certain room; the unit(s) of the
purchased air conditioning device(s) was/were
incorrectly mounted (installed). Also, we pay the
Buyer's attention at the fact that, according to the
Housing Code of RF, the Buyer is obliged to agree
mounting of the purchased equipment with the
operating company and the competent bodies of the
executive branch of the RF subject. The Seller, the
company authorized by the manufacturer, the Importer
and the Manufacturer bear no liability for negative
consequences related to the use of the purchased air
conditioning unit(s) without an approved mounting
layout and permits of the appropriate authorities.
Operational features of air humidifiers, air cleaners
and dryers
1. The original water-softening filter-cartridge
(patented) should be mandatory for ultra-sound air
humidifiers. Main water without preliminary
treatment or purification is recommended for use
if filter-cartridge is available. The service life of the
filter-cartridge depends on the hardness of the
used water and can be unpredictably reduced; as a
result, white sediments may occur around the
humidifier and on its membrane (this sediment
may withstand even the cleaning brush applied to
the air humidifier). To reduce possibility of such
sediment the filter-cartridge requires periodical
timely replacement. Due to filters resource
workout, moisture output of the air humidifiers
may be reduced which requires regular periodical
replacement of the filters according to the
Operation Manual. The Seller, the company
authorized by the manufacturer, the Importer and
the Manufacturer bear no liability for the
malfunctions of air humidifiers specified in this
clause or whatever damage; this warranty does not
cover such malfunctions of the air humidifiers.
When operating air humidifiers it is recommended
to use

only the original (patented) accessories of the
manufacturer.
2. Prior to operation of the air cleaner remove the
filters from the package. Do not install the air
cleaner in an air flow (in draft, in front of the fan,
etc.) to provide normal distribution of the
cleaned air within the volume of the premises.
Filter damage may cause decrease of air cleaning
efficiency. Dust accumulated on the filter can be
carefully removed using the vacuum cleaner. It is
not allowed to wash the filter of the air cleaner
with water.
3. During operation of the air dryer, to avoid water
leaks and noise, place the device on a flat surface.
Close the doors and windows of the treated
premises to provide efficient drying. Be careful
when moving the device: do not shock, tilt the
device and avoid its falling. Before switching the
device on ensure the condenser tank is installed
correctly.
Special features of liquid fuel heaters operation.
Operation of liquid fuel heaters should be
performed by adult persons familiar with the
Operation Manual. It is forbidden to operate
unattended heaters and access of unauthorized
persons to them. During operation of the heaters
stable ventilation of the heated premises should
be provided; there should be no flammable or
explosive materials in any state. The volume of
the heated premises should not exceed capacity
of the heaters. The fuel and parameters of the
electrical mains should comply with the
manufacturer's requirements. Check the
condition of the power cable and tightness of the
fuel system prior to each switching the heaters
on.
Air conditioner care checklist:
1. Once in 2 weeks (more often at intensive
operation) check the air filters in the internal
block for clogging (see Operation Manual). The
protective properties of these filters are based on
electrostatic effect; therefore, even at an
insignificant contamination this filter stops to
perform its functions.
2. Routine maintenance is required once a year; it is
to include cleaning the heat exchangers of both
the internal, and external units from dust and
dirt, pressure check within the system, diagnosis
of all the electronic components of the air
conditioner, cleaning of the drain system. This
procedure will prevent faults and provide reliable
performance of your air conditioner.
3. Once a year (better in spring), if necessary, clean
the heat exchanger of the external
unit and check the operation of the air conditioner
in all modes. This will provide stable operation of
your air conditioner.
4. It should be noted that there is a number of
peculiarities of using the air conditioner in winter. At
the lowest temperatures: from -10°С and below - for
the air conditioners of not invertor type and from -
15°С and below for the air conditioners of invertor
type, it is recommended to use them only in the
ventilation mode. Starting of the conditioner in the
cooling or heating modes may lead to failures or
damage of the compressor. If the ambient
temperature is negative, and the condensate (water
from the internal unit) is drained outdoors, the
water can be frozen in the drainage system and,
consequently, the condensate will flow out of the
internal unit tray into the premises.
The Buyer-user was warned that, according to cl. 11 of
the 'List of nonfoods of proper quality not subject to
return or substitution for a similar goods of other size,
dimensions, shape, style, colour or scope of supply' issued
by the RF Government Decree as of 19.01.1998, No.55, he
has no right to demand substitution of a purchased
product according to art. 25 of the 'Consumer protection'
law and art. 502 of the RF Civil Code. From the moment of
the Buyer's signing the Warranty card it is supposed that:
All the necessary information about the purchased
product and its consumer attributes according to art.
10 of the 'Consumer protection' law was provided to
the Buyer in full;
The Buyer received the Operation Manual in Russian
for the purchased product and
The Buyer is aware and agrees with the terms of the
warranty service/features of operation of the
purchased product
The Buyer is familiar with the Air conditioner care and
maintenance checklist and obliged to observe the
specified rules;
The Buyer has no claims to the appearance/scope of
delivery
if the product was tested in the presence of
the Buyer, fill in 'operation'
of the purchased product.
Buyer's signature:
Date:

To be filled in by the Seller
WARRANTY CARD
To be kept by the Customer
Model
Serial number
Date of sale
Seller's title
Seller's address
Seller's phone
Seller's signature
Seller's stamp
Taken by the specialist during maintenance
TEAR-OFF CARD
for warranty service
Model
Serial number
Date of sale
Date of acceptance for repair
Order No.
Defect occurrence
Customer's full name
Customer's address
Customer's phone
Date of repair
Specialist's signature
To be filled by the Installer
WARRANTY CARD
To be kept by the Customer
Model __________________________________
Serial number ____________________________
Date of sale ______________________________
Installer's name ___________________________
________________________________________
Installer's address _________________________
________________________________________
Installer's phone __________________________
________________________________________
Installer's signature ________________________
Installer's stamp
Taken by the specialist during maintenance
TEAR-OFF CARD
for warranty service
Model _________________________________
Serial number ___________________________
Date of sale _____________________________
Date of acceptance for repair _______________
Order No. _______________________________
Defect occurrence ________________________
_______________________________________
Customer's full name _____________________
_______________________________________
Customer's address _______________________
_______________________________________
Customer's phone ________________________
Date of repair ___________________________
Specialist's signature ______________________

www.ballu.ru
