That’s the 2 Drawer Chest completed
Take care of your unit by using a damp cloth to clean it.
Fit the Hinge Covers F306
over the Hinges.
Recycling – the packaging materials for this
product may be recycled through your local
recycling centre. When you want to dispose of
the product itself, please consider donating it
to a local charitable organisation, otherwise
recycle it through your local recycling centre.
F676
Recycling – the packaging materials for this product may be recycled through your local recycling centre. When you want to dispose of
the product itself, please consider donating it to a local charitable organisation. Otherwise, recycle it through your local recycling centre.
10 Fitting of Plinth
The plinth should be cut to the required length, allowing for the
mitre joint, and then stuck onto the unit, using a suitable adhesive.
11 Fitting of Top Panel
Note: Plinths are supplied separately. If you are in any doubt
about fitting these items, you should seek advice from an expert.
7Fitting of Drawer Runners To Drawers
Position each runner onto drawer bottom, as shown,
flush to the back of the drawer front. Then use a
bradawl to mark the two holes as indicated.
Secure with screws , as shown.
C
C
C
C
C
9
11
7
AF
AH
Fitting of Drawers to Unit
9
Turn the drawer over and locate the wheels on
the drawer over the wheels fitted in the unit and
push into position.
In order to secure the top panel, the drawers
should first be removed from the unit.
Then, once the top is in the correct position,
carefully clamp it in place, and then screw
through from the underside of the top rail,
using screws .
Now replace the drawers.
AK
AK
Fitting of Soft Close Bracket to Drawer Sides
8
The soft close brackets should be
fitted to both of the drawer sides,
using screws as shown.
C
9
11
7
AS
CSS1359 01/10
